Banner Q5X User manual

IO-Link Data Map
This document refers to the following IODD file: Banner_Engineering-Q5X-20180313-IODD1.1.xml. The IODD file and support files
can be found on www.bannerengineering.com , under the download section of the product family page.
Communication Parameters
The following communication parameters are used.
Parameter Value
IO-Link revision V1.1
Process Data In length 32 bits
Process Data Out length 8 bits
Bit Rate 38400 bps
Minimum cycle time 3.6 ms
Parameter Value
Port class A
SIO mode Yes
Smart sensor profile Yes
Block parameterization Yes
Data Storage Yes
IO-Link Process Data In (Device to Master)
Process Data In is transmitted cyclically to the IO-Link master from the IO-Link device.
Process Data (If Binary Data Is Included)
Process Data Input
Subindex Name Number of Bits Data Values
1 Channel 1 Output State 1 0 = inactive
1 = active
2 Channel 2 Output State 1 0 = inactive
1=active
3 Stability State 1 0 = no target/marginal
1 = stable
4 Measurement 1 Value 13 Value depends on "Configuration.Measurement 1
Selection"
5 Measurement 2 Value 16 Value depends on "Configuration.Measurement 2
Selection"
Octet 0
Subindex 5 5 5 5 5 5 5 5
Bit offset 31 30 29 28 27 26 25 24
Value 0 0 0 0 0 0 1 0
Octet 1
Subindex 5 5 4 4 4 4 4 4
Bit offset 23 22 21 20 19 18 17 16
Value 1 0 1 1 0 1 1 0
Octet 2
Subindex 4 4 4 4 4 4 4 4
Bit offset 15 14 13 12 11 10 9 8
Value 1 1 1 1 1 1 1 1
IO-Link Data Reference Guide: Q5X Sensor
Original Document
206834 Rev. B
7 February 2019
206834

Octet 3
Subindex 4 4 4 4 4 3 2 1
Bit offset 7 6 5 4 3 2 1 0
Value 1 1 1 1 1 1 0 1
Example Based on the Value Above
Channel 1 Output = Active
Channel 2 Output = Inactive
Stability State = Stable
Measurement 1 Value = 8191
Measurement 2 Value = 694
Process Data (If Binary Data Is Not Included)
Process Data Input
Subindex Name Number of Bits Data Values
1 Measurement 1 Value 16 Value depends on "Configuration.Measurement 1
Selection"
2 Measurement 2 Value 16 Value depends on "Configuration.Measurement 2
Selection"
Octet 0
Subindex 2 2 2 2 2 2 2 2
Bit offset 31 30 29 28 27 26 25 24
Value 0 0 0 0 0 0 1 1
Octet 1
Subindex 2 2 2 2 2 1 1 1
Bit offset 23 22 21 20 19 18 17 16
Value 0 1 0 0 1 0 1 1
Octet 2
Subindex 1 1 1 1 1 1 1 1
Bit offset 15 14 13 12 11 10 9 8
Value 0 1 1 0 0 1 1 1
Octet 3
Subindex 1 1 1 1 1 1 1 1
Bit offset 7 6 5 4 3 2 1 0
Value 1 0 0 0 1 1 1 1
Example Based on the Value Above
Measurement 1 Value = 26511
Measurement 2 Value = 843
IO-Link Process Data Out (Master to Device)
Process Data Output
Subindex Name Number of Bits Data Values
1 Transducer Disable 1 0 = Active
1 = Inactive
IO-Link Data Reference Guide: Q5X Sensor
2 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 206834 Rev. B

Octet 0
Subindex Reserved Reserved Reserved Reserved Reserved Reserved Reserved 1
Bit offset 7 6 5 4 3 2 1 0
Value 0 0 0 0 0 0 0 1
Example Based on the Value Above
Transducer Disable = 1 (Inactive)
Parameters Set Using IO-Link
These parameters can be read from and/or written to an IO-Link model of the Q5X Laser sensor. Also included is information about
whether the variable in question is saved during Data Storage and whether the variable came from the IO-Link Smart Sensor
Profile.
Unlike Process Data In, which is transmitted from the IO-Link device to the IO-Link master cyclically, these parameters are read or
written acyclically as needed.
Index Sub-
index
Name Length Value Range Default Access
Rights
Data
Storage?
Smart Sensor
Profile?
AOI
0 1–16 Direct Parameter Page 1
(incl. Vendor ID & Device ID)
ro
1 1–16 Direct Parameters Page 2 rw
2 Standard Command 65 = SP1 Single Value Teach
67 = SP1 Two Value Teach TP1
68 = SP1 Two Value Teach TP2
71 = SP1 Dynamic Teach Start
72 = SP1 Dynamic Teach Stop
79 = SP1 Teach Exit
160 = Laser Disable
161 = Laser Enable
130 = Restore Factory Settings
162 = Start discovery
163 = Stop discovery
wo y
3 Data Storage Index (device-
specific list of parameters to
be stored)
rw
4–11 reserved by IO-Link
Specification
12 Device Access Locks
12 1 Parameter Write Access
Lock
0 = off
1 = on
0 rw y
12 2 Data Storage Lock 0 = off
1 = on
0 rw y
12 3 Local Parameterization Lock 0 = off
1 = on
0 rw y
12 4 Local User Interface Lock 0 = off
1 = on
0 rw y
13 Profile Characteristic ro
14 PDInput Descriptor ro
15 PDOutput Descriptor ro
16 Vendor Name string Banner Engineering Corporation ro
17 Vendor Text string More Sensors. More Solutions. ro
18 Product Name string Q5X ro
19 Product ID string Q5XKLAF2000-Q8 ro
20 Product Text string Laser Measurement Sensor ro y
21 Serial Number ro
22 unused/reserved ro
IO-Link Data Reference Guide: Q5X Sensor
P/N 206834 Rev. B www.bannerengineering.com - Tel: + 1 888 373 6767 3

Index Sub-
index
Name Length Value Range Default Access
Rights
Data
Storage?
Smart Sensor
Profile?
AOI
23 Firmware Version ro y
24 App Specific Tag (user
defined)
rw y y
25–35 reserved
36 Device Status 8-bit integer 0 = Device is OK
1 = Maintenance required
2 = Out of specification
3 = Functional check
4 = Failure
5..255 Reserved
ro
37 Detailed Device Status Array[6] of 3-octet ro
38–39 reserved
40 Process Data Input ro
41 Process Data Output
42–57 unused/reserved
58 Teach-in Channel 0= Default
1 = BDC1
2 = BDC2
0 rw y
59 Teach-In Status
59 1 Teach State: 4-bit Integer 4-bit Integer 0 = Idle
1 = SP1 Success
4 = Wait for Command
5 = Busy
7 = Error
ro y
59 2 SP1 TP1 1-bit integer 0 = not taught or unsuccessful
1 = successfully taught
ro y
59 3 SP1 TP2 1-bit integer 0 = not taught or unsuccessful
1 = successfully taught
ro y
60 BDC1 Setpoints
60 1 BDC1 Setpoint SP1 32-bit integer 95 mm – 2000 mm 250 mm rw y y
60 2 BDC1 Setpoint SP2 32-bit integer 0 mm for all teach modes except
One-Point Window (FGS)
95 mm to 2000 mm for One-Point
Window (FGS)
0 mm rw y y
61 BDC1 Configuration
61 1 BDC1 Switchpoint Logic 8-bit integer 0 = LO
1 = DO
0 rw y y
61 2 BDC1 Mode 8-bit integer 1 = One-Point BGS
128 = Two-Point Static BGS
129 = Dynamic BGS
130 = One-Point Window (FGS)
131 = Dual Teach
128 rw y y
61 3 BDC1 Hysteresis 16-bit integer 0 mm – 2000 mm 0 rw y y
62 BDC2 Setpoints
62 1 BDC2 Setpoint SP1 32-bit integer 95 mm – 2000 mm 500 mm rw y y
62 2 BDC2 Setpoint SP2 32-bit integer 0 mm for all teach modes except
One-Point Window (FGS)
95 mm to 2000 mm for One-Point
Window (FGS)
0 mm rw y y
63 BDC2 Configuration
63 1 BDC2 Switchpoint Logic 8-bit integer 0 = LO
1 = DO
0 rw y y
IO-Link Data Reference Guide: Q5X Sensor
4 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 206834 Rev. B

Index Sub-
index
Name Length Value Range Default Access
Rights
Data
Storage?
Smart Sensor
Profile?
AOI
63 2 BDC2 Mode 8-bit integer 1 = One-Point BGS
128 = Two-Point Static BGS
129 = Dynamic BGS
130 = One-Point Window (FGS)
131 = Dual Teach
128 rw y y
63 3 BDC2 Hysteresis 16-bit integer 0 mm – 2000 mm 0 rw y y
64 Configuration
64 1 Response Speed 8-bit integer 0 = 3 ms
1 = 5 ms
2 = 10 ms
3 = 25 ms
4 = 50 ms
3 rw y
64 2 Gain 8-bit integer 0 = High excess gain mode
1 = Standard excess gain mode
0 rw y
64 3 Secondary Output Function 8-bit integer 0 = Remote Teach Input
1 = Laser On
2 = Master
3 = Slave
4 = Complementary Ouput
5 = Laser Off
6 = Pulse Frequency Modulation
7 = Independent Output
7 rw y
64 4 Zero Reference Location 8-bit integer 0 = Near
1 = Far
0 rw y
64 5 Shift Zero Reference After
Teach
8-bit integer 0 = Off
1 = On
0 rw y
64 6 Display Read 8-bit integer 0 = On
1 = On + Inverted
2 = Off
3 = Off + Inverted
0 rw y
64 7 Pushbutton Lockout 8-bit integer 0 = No Lockout
1 = Pushbuttons Locked
2 = Operator Lockout
0 rw y
64 8 Output Polarity 8-bit integer 0 = Default,
1 = PNP
2 = NPN
0 rw y
64 9 IOL Filter Time 16-bit integer 0 ms – 65535 ms 0 rw y
64 10 Includes Binary Data in
Process Data
8-bit integer 0 = Include
1 = Don't Include
0 rw y
64 11 Process Data Measurement
1 Selection
8-bit integer 0 = Disabled
1 = Excess Gain
2 = Excess Gain / 10
3 = Channel 1 Dual Mode Percent
1 rw y
64 12 Process Data Measurement
2 Selection
8-bit integer 0 = Disabled
1 = Distance Measurement Value
2 = Displayed Distance
Measurement Value
3 = Channel 2 Dual Mode Percent
1 rw y
65 BDC1 Vendor Specific
Configuration
65 1 BDC1 Delay Mode 8-bit integer 0 = Disabled
1 = On/Off Delay
2 = Oneshot
3 = Totalizer
0 rw y
65 2 BDC1 Delay Time 1 32-bit integer 0–90000 ms 0 ms rw y
65 3 BDC1 Delay Time 2 32-bit integer 0–90000 ms 0 ms rw y
IO-Link Data Reference Guide: Q5X Sensor
P/N 206834 Rev. B www.bannerengineering.com - Tel: + 1 888 373 6767 5

Index Sub-
index
Name Length Value Range Default Access
Rights
Data
Storage?
Smart Sensor
Profile?
AOI
65 4 BDC1 BGS Teach Offset
Mode
8-bit integer 0 = Auto
1 = User Selected
0 rw y
65 5 BDC1 FGS Window Size
Mode
8-bit integer 0 = Auto
1 = User Selected
0 rw y
65 6 BDC1 User Teach Offset 16-bit integer -1905 mm – 1905 mm 0 mm rw y
65 7 BDC1 FGS User Window
Size
16-bit integer 0 mm – 1905 mm 0 mm rw y
65 8 BDC1 Auto Thresholding 8-bit integer 0 = On
1 = Off
2 = High Speed
1 rw y
66 BDC2 Vendor Specific
Configuration
rw
66 1 BDC2 Delay Mode 8-bit integer 0 = Disabled
1 = On/Off Delay
2 = Oneshot
3 = Totalizer
0 rw y
66 2 BDC2 Delay Time 1 32-bit integer 0–90000 ms 0 ms rw y
66 3 BDC2 Delay Time 2 32-bit integer 0–90000 ms 0 ms rw y
66 4 BDC2 BGS Teach Offset
Mode
8-bit integer 0 = Auto
1 = User Selected
0 rw y
66 5 BDC2 FGS Window Size
Mode
8-bit integer 0 = Auto
1 = User Selected
0 rw y
66 6 BDC2 User Teach Offset 16-bit integer -1905 mm – 1905 mm 0 mm rw y
66 7 BDC2 FGS User Window
Size
16-bit integer 0 mm – 1905 mm 0 mm rw y
66 8 BDC2 Auto Thresholding 8-bit integer 0 = On
1 = Off
2 = High Speed
1 rw y
67 Status
67 1 Measurement Value (distance
in mm)
32-bit integer ro
67 2 Excess Gain Percent 32-bit integer ro
67 3 Stability 8-bit integer 0 = No target
1 = Marginal/Multiple Peaks
2 = Stable
ro
67 4 Multiple Peak State 8-bit integer 0 = Multiple Peaks Not Present
1 = Multiple Peaks Present
ro
67 5 Emitter Status 8-bit integer 0 = Active
1 = Inactive
ro
67 6 Laser Fault Status 8-bit integer 0 = Not Present
1 = Laser Fault Present
ro
67 7 BDC1 Totalizer Counts 16-bit integer ro
67 8 BDC2 Totalizer Counts 16-bit integer ro
68 unused/reserved
69 All-Time Run Time
69 1 Run Counter 32-bit integer ro
70 Resettable Run Time
70 1 Run Counter 0 rw
71 Pulse Frequency
Configuration
71 1 Near Frequency 32-bit integer The frequency corresponding to a
target at the near limit of the
sensing range
100 Hz – 45000 Hz
100 Hz rw y
IO-Link Data Reference Guide: Q5X Sensor
6 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 206834 Rev. B

Index Sub-
index
Name Length Value Range Default Access
Rights
Data
Storage?
Smart Sensor
Profile?
AOI
71 2 Far Frequency 32-bit integer The frequency corresponding to a
target at the far limit of the sensing
range
100 Hz – 45000 Hz
600 Hz rw y
72 Display String
72 1 Line 1 5-octet String
US_ASCII
ro
73-75 unused/reserved
76 All-Time Run Time Event
Time
76 1 Event Time 32-bit integer 0–2147483647 0 rw y
77 Resettable Run Time Event
Time
77 1 Event Time 32-bit integer 0-2147483647 0 rw y
IO-Link Events
Events are acyclic transmissions from the IO-Link device to the IO-Link master. Events can be error messages and/or warning or
maintenance data.
Code Type Description
25376 (0×6320) Error Parameter error (check datasheet and values)
36000 (0×8CA0) Warning All-time Run Time Event (Event indicating the corresponding configured running time has elapsed.)
36001 (0×8CA1) Warning Resettable Run Time Event (Event indicating the corresponding configured running time has
elapsed.)
36003 (0×8CA3) Notification Teach Completed Event (Event indicating a teach has been completed.)
36004 (0×8CA4) Notification Factory Settings Restored Event (Event indicating that the factory settings have been restored.)
36005 (0×8CA5) Notification Teach Coerced Event (Event indicating a taught condition resulting in a setpoint being coerced.
Taught was updated.)
36007 (0×8CA7) Notification Teach Failed Event (Event indicating an invalid target condition was attempted to be taught. Taught
setpoint was not updated.)
36096 (0×8d00) Error Laser fault event (laser shut down for safety)
36097 (0×8D01) Error System Fault Event (Contact Banner Engineering to resolve.)
IO-Link Data Reference Guide: Q5X Sensor
©Banner Engineering Corp. All rights reserved
