Banner iVu Plus BCR User manual

iVu Plus BCR Quick Start Guide
154722 9/7/2012
Rev. D

Contents
Introduction ............................................................................................................................................... 3
Installing and Connecting the Sensor ....................................................................................................4
iVu Plus BCR with Integrated Display .................................................................................................................................5
iVu Plus BCR with Remote Display .................................................................................................................................... 5
Sensor Modes ............................................................................................................................................7
Demo Mode ......................................................................................................................................................................... 7
Live Mode Overview ............................................................................................................................................................ 7
Read/No Read, Pass/Fail, Match/No Match ............................................................................................................... 8
Output 1, Output 2, and Output 3 ...............................................................................................................................8
Acquiring a Good Image ...........................................................................................................................9
Setting Up a Barcode Application ......................................................................................................... 12
Compare Data .........................................................................................................................................13
Compare Data ................................................................................................................................................................... 13
Setting up for Data Compare .............................................................................................................................................13
Trigger Modes ......................................................................................................................................... 15
External-Single Mode ........................................................................................................................................................ 15
Continuous Mode ...............................................................................................................................................................16
External-Gated Mode ........................................................................................................................................................16
Command .......................................................................................................................................................................... 17
Industrial Ethernet Only .................................................................................................................................................... 17
iVu Plus Communications Overview ....................................................................................................18
Serial and Ethernet Output ................................................................................................................................................ 18
Communication Channels .................................................................................................................................................19
Multiple Inspections ...............................................................................................................................20
Adding a New Inspection ..................................................................................................................................................20
Changing Running Inspections .........................................................................................................................................21
Changing Inspection Name or ID ......................................................................................................................................22
Contents
2 154722

Introduction
The iVu Plus BCR sensor is a barcode reader used to read a variety of barcodes and to optionally compare data to known values. The
sensor has an integrated color touch screen display or a remote display connection making installation, setup, and configuration easy
without requiring a PC.
Quick Start Overview
This guide is designed to provide the necessary information to get the iVu Plus
BCR up and running quickly. It provides an overview of the sensor and illus-
trates how to set up the sensor to read barcodes. The flow chart at left provides
an overview of the process.
Related Information
The following documentation is available on the Product CD:
•iVU Plus BCR Datasheet
•iVu Series Remote Display Datasheet
•iVu Sensor Reference
•iVu Plus BCR User's Manual
•iVu Plus BCR Communications Guide
•iVu Plus BCR with Remote Display Datasheet
•iVu Plus BCR Integrated Datasheet
In addition, there is integrated Help built into the sensor itself.
NOTE: Before setting up the sensor, remove all
packaging. If using an iVu with an integrated touch
screen, carefully remove the plastic cover from the
sensor's touch screen display and put aside. You
should replace the cover after configuring the sen-
sor to protect the display.
WARNING: Not To Be Used for Personnel Protection
Never use this product as a sensing device for personnel protection. Doing so could lead to seri-
ous injury or death. This product does NOT include the self-checking redundant circuitry necessary to
allow its use in personnel safety applications. A sensor failure or malfunction can cause either an ener-
gized or de-energized sensor output condition.
CAUTION: Electrostatic Discharge
Avoid the damage that electrostatic discharge (ESD) can cause to the Sensor.
Always use a proven method for preventing electrostatic discharge when installing a lens or attaching a
cable.
154722 www.bannerengineering.com - tel: [phone]

Installing and Connecting the Sensor
The iVu Plus BCR sensor requires a bracket for mounting. Three brackets are available
from Banner. The brackets allow the sensor to be mounted either perpendicular to the part
or at an adjustable angle.
Available iVu Brackets
SMBIVURAL SMBIVURAR SMBIVUU
Thread three M4 x 4mm screws through the bracket into the mounting holes in the bottom of the sensor. Tighten all three screws.
iVu Plus BCR Quick Start Guide
4 www.bannerengineering.com - tel: [phone] 154722

iVu Plus BCR with Integrated Display
The cable connections on the iVu Plus with integrated display are shown below, and power I/O connections (C) are defined in the Power
I/O Connections table below.
C
A B
AUSB Connector
BEthernet Connector
CPower I/O Connector
NOTE: Microlens model shown, C-Mount model connections are
identical.
iVu Plus BCR with Remote Display
The cable connections on the iVu Plus with remote display are shown below, and power I/O connections (B) are defined in the Power I/O
Connections table below.
AB
C D
ARemote Display Connector
BPower I/O Connector
CUSB Connector
DEthernet Connector
NOTE: Microlens model shown, C-Mount model connections are
identical.
iVu Plus BCR Quick Start Guide
154722 www.bannerengineering.com - tel: [phone]

Power I/O Connections
Pin # Wire Color Description Direction
2 Brown 10-30V dc Input
7 Blue Common (Signal Ground) Input
6 Pink External Trigger Input
5 Gray Remote Teach Input
1 White Output 1 Output
8 Red Ready Output
4 Yellow Strobe Out (5V dc only) Output
3 Green Output 2 Output
9 Orange Output 3 Output
10 Light Blue RS-232 TX Output
11 Black RS-232 Signal Ground Output
12 Violet RS-232 Rx Input
iVu Plus BCR Quick Start Guide
6 www.bannerengineering.com - tel: [phone] 154722

Sensor Modes
Demo Mode
The first time you power up the iVu Plus BCR sensor, it starts in Demo Mode. Demo Mode uses stored images and inspection parame-
ters that demonstrate how the sensor is set up without having to worry about focus, lighting, or triggers. In this mode, you can learn how
to make adjustments working with the sensor types while observing how the adjustments affect the sensor results. To exit Demo Mode,
go to Main Menu > System > Sensor Mode and select Exit Demo Mode. When you exit Demo Mode, the sensor reboots into its normal
operating mode with default settings.
NOTE: You may return to Demo Mode any time by going to Main Menu > System > Sensor Mode and se-
lecting Demo.
Live Mode Overview
The iVu Plus BCR can be configured to evaluate one or more of the supported barcode types and can look for a specific number of
barcodes from 1 to 10. The barcode types are selected on the integrated touch screen by accessing Main Menu > Inspection > Bar-
code > Barcode Type . The barcode count is selected on the touch screen by going to Main Menu > Inspection > Barcode > Barcode
Count .
This section describes some general iVu Plus BCR concepts.
154722 www.bannerengineering.com - tel: [phone]

Read/No Read, Pass/Fail, Match/No Match
The following describes what is meant by Read/No Read, Pass/Fail, and Match/No Match:
• A Read condition occurs when the configured number of barcodes are found in a scan. These barcodes must be error-free.
• A No Read condition occurs when the configured number of barcodes are not found in a scan.
• If the sensor is configured where Data Compare is disabled, Pass and Fail are the same as Read and No Read.
• If the sensor is using the Data Compare feature, Pass indicates that a good barcode was found and the data compared.
• If the sensor is using the Data Compare feature, Fail indicates that either no good barcode was found or the data did not compare.
• A Match condition occurs when the required number of barcodes are found and the compare is successful.
• A No Match condition occurs when the required number of barcodes are found, but the compare is not successful.
Output 1, Output 2, and Output 3
The sensor has three output signals that you can configure for Pass, Fail, Read, No Read, Match, No Match, System Error, and Missed
Trigger. The default settings are Pass for Output 1, Fail for Output 2, and Pass for Output 3.
NOTE: For all outputs, the default setting is Latched, which means that the signal is active until the results of
an inspection cause a change in the signal output. If Pulsed is selected, the default pulse width is 50 ms.
iVu Plus BCR Quick Start Guide
8 www.bannerengineering.com - tel: [phone] 154722

Acquiring a Good Image
The iVu Series sensor needs to capture a good image to ensure that it can read the barcode(s) correctly.
1. Go to Main Menu > Imager > Auto Exposure to run the Auto Exposure routine.
2. Check the lighting.
• Make sure that the lighting is constant and consistent (unchanging over time, no shadows or hot spots).
• Capture the barcode with lighting that optimizes its contrast and separates it from the background. Depending on the target,
this may mean the integral ring light is not the best choice and other Banner lights should be considered.
• Adjust the mounting angle to provide the clearest image of the barcode. The mounting bracket lets you easily position and
adjust the sensor on your line. Typically, a slight angle will help with read robustness.
3. If needed, go to Main Menu > Imager > Auto Exposure to run the Auto Exposure routine a second time or adjust Gain and
Exposure manually:
•Main Menu > Imager > Gain
•Main Menu > Imager > Exposure
154722 www.bannerengineering.com - tel: [phone]

4. Go to Main Menu > Imager > Focus to adjust the focus while monitoring the Focus Number:
For Micro-lens Models Only:
1. Use the supplied 1/16" hex key to loosen the Focusing Window locking screw (D), then adjust focus on the iVu Series sensor using
the clear Focusing Window (B).
2. Adjust focus while monitoring the focus number. To ensure the best image, adjust the focus until
the Focus Number peaks.
NOTE: Turning the Focusing Window counter-clockwise focuses on
closer objects, while turning the Focusing Window clockwise focuses
on more distant objects.
3. Once the best image has been acquired, lock the focusing window.
Micro-Lens Models
A Lens
B Focusing Window
C Locking Clip
D Locking Screw
E Filter Cap (optional)
F Filter (optional)
NOTE: Filter Kits are available separately.
iVu Plus BCR Quick Start Guide
10 www.bannerengineering.com - tel: [phone] 154722

For C-Mount Models Only:
1. Remove the Lens Enclosure
2. Adjust focus while monitoring the focus number. To ensure the best image, adjust the focus until the Focus Number peaks.
3. Replace the Lens Enclosure on the camera.
C-Mount Models
DC
A
B
E
C
A C-Mount Lens
B Lens Enclosure
C Retainer Ring (optional)
D Filter (optional)
E Filter Retainer Ring Tool
NOTE: Filter Kits are available separately.
iVu Plus BCR Quick Start Guide
154722 www.bannerengineering.com - tel: [phone]

Setting Up a Barcode Application
This section describes how to set up the iVu Plus BCR sensor.
1. Go to Main Menu > Inspection > Barcode > Barcode Type to select one or more Barcode Types from the list.
NOTE: To ensure optimal performance, select only the barcode types for your application. For example,
if you use only one of the of the barcode types listed for All Linear, uncheck the box next to All Linear,
and select a radio button next to the desired linear barcode type. If you use only DataMatrix, uncheck all
the boxes except the one next to DataMatrix.
2. Go to Main Menu > Inspection > Barcode > Barcode Count to select the number of barcodes (1 to 10) to be read at one time.
Once the sensor has been set up as described:
• Each successfully read barcode is marked by a green bounding box. If annotations are on, the barcode data is also displayed.
• Any case where data does not compare is marked with a solid red bounding box. If the barcode is marked with a dotted red bounding
box, this indicates a checksum error or quiet zone violation.
• Any barcodes in the field of view that the sensor does not detect (for example, because they are not one of the barcode types selec-
ted), are unmarked.
iVu Plus BCR Quick Start Guide
12 www.bannerengineering.com - tel: [phone] 154722

Compare Data
Compare Data
The iVu Plus BCR has a data compare feature for comparing read barcode data against reference data. Data can be manually entered
by accessing the Main Menu > Inspection > Barcode > Data Compare > Set Data screen. Data of up to 3200 characters can be
entered. Additionally, the data compare feature provides for masking characters within the data.
There are two other ways to enter compare data:
• Importing the last read data while viewing the Set Data screen. The new data is effective on the first trigger that occurs after this
action.
• Using Remote Teach. When a Remote Teach occurs, the data of the first read barcode is saved as Data Compare input. Inspections
executed on the next trigger will use the new data for comparison with subsequently read barcodes. If the previous input data con-
tained any masked characters, Remote Teach will retain the masked characters only if the new data is of the same length as the
previous input data. If the length does not match, masking is removed.
The sensor tries to compare full length of this string with the data read from the barcode. If not equal, inspection will be marked as Fail.
NOTE: If the sensor reads more than one barcode in the field of view, only the first barcode data that the
sensor reads can be compared.
Setting up for Data Compare
This section describes how to set up the data compare feature. For this example, the reference data will be from a previously decoded
barcode.
1. Go to the Main Menu > Inspection > Barcode > Data Compare > Compare to Enable data compare.
2. Go to the Main Menu > Inspection > Barcode > Data Compare > Set Data , and click the Show last read data button.
154722 www.bannerengineering.com - tel: [phone]

3. Press the Yes button.
4. Press the Home icon to return to the main screen.
For all subsequent triggers, when the sensor reads the barcode data, it will compare it against this reference data.
iVu Plus BCR Quick Start Guide
14 www.bannerengineering.com - tel: [phone] 154722

Trigger Modes
The iVu Plus BCR has five trigger modes that determine how the sensor captures and processes images:
• External - Single
• Continuous
• External - Gated
• Command
• Industrial Ethernet Only
You can select one of the trigger modes by accessing Main Menu > Imager > Trigger on the iVu touch screen display.
External-Single Mode
In External-Single mode, the sensor depends on an external trigger. For each trigger, the sensor captures an image and executes one
scan through the configured barcode types looking for the specified number of barcodes. This trigger mode uses the Scan Time Limit
parameter ( Main Menu > Inspection > Properties > Scan Time Limit ) to limit the amount of time the sensor will attempt to scan for
barcodes on an image.
154722 www.bannerengineering.com - tel: [phone]

Continuous Mode
In Continuous mode, the sensor uses internal timing to continuously capture images. For each captured image, the sensor scans through
the configured barcode types looking for the specified number of barcodes. If the specified number of barcodes is found, a Read event
occurs. If the specified number of barcodes is not found, the sensor captures another image and repeats the scan. There are two param-
eters that are used to fine-tune how Continuous Scan mode operates:
• Same Code Reject Time (set at the bottom of Main Menu > Imager > Trigger )—time in seconds that must elapse before the scan-
ner will report a previously scanned symbol again. A different symbol will be read immediately.
• Scan Time Limit ( Main Menu > Inspection > Properties > Scan Time Limit )—limits the amount of time the sensor will attempt to
scan for barcodes on an image.
NOTE: A No Read condition will not occur in Continuous mode as another image capture and scan automati-
cally follows.
External-Gated Mode
External-Gated mode is similar to Continuous mode. While an external trigger input signal is active, the sensor continues to capture
images and run barcode scans until a successful Read occurs or the External Trigger input signal becomes inactive. The External -
Gated mode uses the Scan Time Limit parameter ( Main Menu > Inspection > Properties > Scan Time Limit ) to limit the amount of
time the sensor will attempt to decode barcodes on an image.
iVu Plus BCR Quick Start Guide
16 www.bannerengineering.com - tel: [phone] 154722

NOTE: A No Read condition will not occur in External - Gated mode while the external trigger is active.
Command
In Command mode, the sensor will capture images when Trigger commands are received. The various trigger command modes descri-
bed above can also be set through a command channel. Refer to Communications Chapter 6 for specific commands. The commands can
come from either Serial I/O or Ethernet I/O.
Industrial Ethernet Only
When Industrial Ethernet communication channel is enabled, triggers can be received from the modes mentioned above. Triggers
through Industrial Ethernet will not be executed if selected Trigger Mode is 'Continuous Scan'. If it is desired to receive triggers only
through Industrial Ethernet channel, select the 'Industrial Ethernet Only'.
iVu Plus BCR Quick Start Guide
154722 www.bannerengineering.com - tel: [phone]

iVu Plus Communications Overview
Serial and Ethernet Output
The iVu Plus provides for communicating with other devices via Ethernet or a UART serial communications port (RS-232). In order to
establish an Ethernet connection to the sensor, the external device must be configured with the correct IP address and correct TCP port
to communicate. If planning to use the serial communications connection, port settings for baud rate, data bits, parity, and stop bits must
be configured on the iVu Plus to match the settings of the external device.
The iVu Plus BCR RS232 port or ethernet port can be used to output barcode data to other applications. To access the Data Export
screen, go to Main Menu > System > Communications > Data Export . The user can enable or disable this feature. When enabled:
• if the sensor is configured for either External-Single or External-Gated trigger modes, every trigger results in the transmission of out-
put data (if the sensor does not successfully read a barcode, the output will be NO_READ).
• if the sensor is configured for Continuous trigger mode, the sensor will only transmit output barcode data upon a successful read.
To access the Serial Output screen, go to Main Menu > System > Communications > Serial I/O
When RS-232 serial output is enabled, the user can configure:
• Serial Port Settings (listed below)
• Type of Data to Export (listed below)
• Output Format (listed below)
To access the Ethernet Output screen, go to Main Menu > System > Communications > Ethernet I/O .
When ethernet output is enabled, the user can configure:
• IP Address, Port number, Subnet Mask, and Gateway
• Type of Data to Export (listed below)
• Output Format (listed below)
Type of Data to Export:
• Pass/Fail Output
• Inspection Name
• Barcode Count
• Data Length
• Symbol Type
• Barcode Data
• Frame Number
• Inspection Time (ms)
Serial Port Settings:
• Baud Rates
• Start Bits
• Stop Bits
• Data Bits
• Parity Control
Output Format:
• Start String
• Delimiter
• End String
iVu Plus BCR Quick Start Guide
18 www.bannerengineering.com - tel: [phone] 154722

Communication Channels
The iVu Plus BCR supports up to four communications channels. To access the channels, go to Main Menu > System > Communica-
tions .
• Command Channel — a bi-directional communication protocol that currently supports ASCII and enables other devices to remotely
control the iVu Plus sensor and access sensor results
• Industrial Ethernet — a bi-directional communication channel that allows the user to control the sensor and access sensor results
using Ethernet/IP, Modbus/TCP, or PCCC protocol
• Data Export — used to export selected inspection data to a remote device
• Image Export — used to export inspection images to a remote device
Data export and command channel can be configured for either Ethernet or Serial I/O (but not both); image export is only available over
Ethernet. The table below briefly summarizes valid communication channel configuration options.
Command Channels
Scenario #1 Scenario #2 Scenario #3
Ethernet Serial I/O Ethernet Serial I/O Ethernet Serial I/O
Command Channel Yes No No Yes Yes No
Industrial Ethernet Yes No Yes No Yes No
Data Export Yes No Yes No No Yes
Image Export Yes No Yes No Yes No
iVu Plus BCR Quick Start Guide
154722 www.bannerengineering.com - tel: [phone]

Multiple Inspections
The iVu Plus BCR supports multiple inspections that facilitate storing and controlling up to 30 inspections of different types of barcodes.
By default, Inspection 1 is crated with Data Matrix and Linear Barcodes enabled.
Adding a New Inspection
To add a new stored inspection:
1. Go Main Menu > Inspection > Stored Inspections and click Add New.
2. Select Rename to type a new name for the new inspection.
3. Click Done. The new inspection with automatically begin running.
iVu Plus BCR Quick Start Guide
20 www.bannerengineering.com - tel: [phone] 154722
