Vision sensor for high speed
inspection and error-proofing
P4 EDGE
Vision Sensor
• Self-contained vision sensor
– no external controller required
• Easily and accurately repro-
grammable for new product
inspection at the push of a
button
• Convenient, 12-pin digital I/O
terminal block for ensuring
smooth integration into the
customer’s machine control
system
• High-speed measuring
and position monitoring
at speeds of up to 10 000
parts per minute
• Separate video output
allows direct connection
to optional real-time video
display without the need for
a PC
• Two housing options and
multiple mounting brackets
for easy installation

®
✓
✗
✓
✗
✓
✗
E-A041 03/05
Banner Engineering offers the industry a highly
complete and integrated line of photoelectric
sensors, ultrasonic sensors, machine safety
products, measurement & inspection products
and vision sensors.
Banner Engineering is a US based company
with subsidiaries around the world for global
sales and support.
Banner Engineering Europe
Koning Albert 1 laan, 50
1780 Wemmel • Belgium
Phone: [phone]
Fax: [phone]
e-mail: [e-mail]
www.bannereurope.com
▲Vial Stopper Alignment and Fill-Level Detection
The P4 EDGE verifies that the stopper is correctly positioned on a non-closed glass vial to ensure proper
sealing, and that the product fill level is correct. If the stopper is incorrectly positioned or if the vial is under
filled, a FAIL output is sent from the vision sensor to the filling machine.
▲Bottle Label Alignment
The P4 EDGE measures the horizontal displacement
between the labels and verifies that each individual
label is applied straight and not skewed.
▲Syringe Assembly Verification
The P4 EDGE checks for the presence of a needle
and verifies that it is straight. It also measures the
epoxy glue for over- or under-fill.
