WORLD-BEAM®Q12
E-A039 02/05
Powerful sensing performance
in a universal miniature housing!
Q12 Miniature
Sensor
• Powerful sensors suitable for
extremely confined areas
• Opposed, retro-reflective
(polarised & non-polarised) and
fixed-field sensing modes
• Precise cutoff background-
suppression available in three
fixed-field models
• Rated IP67 for use in the
widest range of locations
and applications
• Overmoulded
design provides
enhanced
durability and
shielding
• Robust metal-
lined mounts with
standardised loca-
tion on all models
• Mounting flexibility
directly on and inside
manufacturing equipment
• Solid-state bipolar outputs
(PNP and NPN)

E-A039 02/05
Banner Engineering offers the industry a highly
complete and integrated line of photoelectric
sensors, ultrasonic sensors, machine safety
products, measurement & inspection products
and vision sensors.
Banner Engineering is a US based company
with subsidiaries around the world for global
sales and support.
Banner Engineering Europe
Koning Albert 1 laan, 50
1780 Wemmel • Belgium
Phone: [phone]
Fax: [phone]
e-mail: [e-mail]
www.bannereurope.com
Rugged sealed
housing and protected
circuitry
Supplied with 2 m
cable or 150 mm
pigtail cable with M8
or M12 QD connector
Robust metal-lined
mounts
Powerful LED
operating status
indicators visible
from 360º
Mode Model and Range
Opposed
Type E/R: 2 m
Polarised Retro
Type LP: 1 m
Retro-Reflective
Type LV: 1,5 m
Fixed-Field Type FF15: 15 mm cutoff, 10 mm focus
Type FF30: 30 mm cutoff, 16 mm focus
Type FF50: 50 mm cutoff, 16 mm focus
Typical application in fixed-field
sensing mode: Cap inspection
Typical application in opposed
sensing mode: Detection of passing
objects
®
