Barco F70 Series User manual

ENABLING BRIGHT OUTCOMES
User Manual
F70 Series

Barco Fredrikstad AS
Habornveien 53, N-1630 Gamle Fredrikstad, Norway
[email protected]
www.barco.com
Registered address: Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
www.barco.com/en/support
www.barco.com

Changes
Barco provides this manual 'as is' without warranty of any kind, either expressed or implied, including but not
limited to the implied warranties or merchantability and fitness for a particular purpose. Barco may make
improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time
without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made
to the information in this publication; these changes are incorporated in new editions of this publication.
The latest edition of Barco manuals can be downloaded from the Barco web site www.barco.com or from the
secured Barco web site https://www.barco.com/en/signin.
Federal Communications Commission (FCC Statement)
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area may cause harmful interference, in which case the user will be responsible for correcting any interference
at his own expense
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights
of their respective holders. All brand and product names mentioned in this manual serve as comments or
examples and are not to be understood as advertising for the products or their manufacturers.
Turkey RoHS compliance
Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur.
[Republic of Turkey: In conformity with the WEEE Regulation]
Disposal Information
Waste Electrical and Electronic Equipment
This symbol on the product indicates that, under the European Directive (EU) 2015/863 governing waste
from electrical and electronic equipment, this product must not be disposed of with other municipal waste.
Please dispose of your waste equipment by handing it over to a designated collection point for the recycling of
waste electrical and electronic equipment. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
For more information about recycling of this product, please contact your local city office or your municipal
waste disposal service.
For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee
Disposal of batteries in the product
This product contains batteries covered by the Directive 2006/66/EC which must be collected and
disposed of separately from municipal waste.

If the battery contains more than the specified values of lead (Pb), mercury (Hg) or cadmium (Cd), these
chemical symbols will appear below the crossed-out wheeled bin symbol.
By participating in separate collection of batteries, you will help to ensure proper disposal and to prevent
potential negative effects on the environment and human health.
Guarantee and Compensation
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of
guarantee. On receipt, the purchaser must immediately inspect all delivered goods for damage incurred during
transport, as well as for material and manufacturing faults Barco must be informed immediately in writing of
any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on
the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of
complaint, Barco can repair the fault or provide a replacement at its own discretion within an appropriate
period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the
purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for
direct or indirect damage, and also damage attributed to the operation of software as well as to other services
provided by Barco, being a component of the system or independent service, will be deemed invalid provided
the damage is not proven to be attributed to the absence of properties guaranteed in writing or due to the
intent or gross negligence or part of Barco.
If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the
goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of
risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the
purchaser will be rendered invalid. Not included in the guarantee coverage are system failures which are
attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear
as well as normal maintenance are not subject to the guarantee provided by Barco either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual
must be complied with by the customer.
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be
recorded, transmitted or stored in a retrieval system without the prior written consent of Barco.
Software License Agreement
You should carefully read the following terms and conditions before using this software. Your use of this
software indicates your acceptance of this license agreement and warranty.
Terms and Conditions:
1. No redistribution of the software is allowed.
2. Reverse-Engineering. You may not reverse engineer, decompile, disassemble or alter this software
product.
Disclaimer of Warranty:
This software and the accompanying files are sold “as is”and without warranties as to performance or
merchantability or any other warranties whether expressed or implied. In no event shall Barco be liable for
damage of any kind, loss of data, loss of profits, business interruption or other pecuniary loss arising directly or
indirectly. Any liability of the seller will be exclusively limited to replacement of the product or refund of
purchase price.

1Safety.........................................................................................................................................................................................................................9
1.1 General considerations .................................................................................................................................................................10
1.2 Important safety instructions ...................................................................................................................................................... 11
1.3 Projector Hazard Distances ........................................................................................................................................................14
1.4 High Brightness Precautions......................................................................................................................................................14
1.5 Hazard Distance for fully closed projection system.......................................................................................................16
1.6 HD in function of the lens Throw Ratio (TR) ......................................................................................................................17
1.7 Safety symbols...................................................................................................................................................................................19
1.8 RoHS compliance.............................................................................................................................................................................21
1.9 Taiwan RoHS compliance............................................................................................................................................................23
1.10 Contact information .........................................................................................................................................................................24
1.11 Product Info..........................................................................................................................................................................................25
1.12 Statement..............................................................................................................................................................................................25
2Getting to know the projector. ..............................................................................................................................................................27
2.1 Main Components ............................................................................................................................................................................28
2.2 Service and Maintenance.............................................................................................................................................................29
2.3 LED Status Light ...............................................................................................................................................................................29
2.4 Power on / Standby button backlight indications ............................................................................................................29
2.5 LCD panel .............................................................................................................................................................................................29
2.6 Local keypad .......................................................................................................................................................................................30
2.7 Remote Control..................................................................................................................................................................................31
2.7.1 Remote control, Battery installation.....................................................................................................................31
2.7.2 Remote control, protocol setup..............................................................................................................................32
2.7.3 Functionality overview.................................................................................................................................................33
2.7.4 Remote control, on/off button..................................................................................................................................34
2.7.5 Enable / Disable Remote Control .........................................................................................................................34
2.7.6 Wired RC connection...................................................................................................................................................34
2.8 Projector Address .............................................................................................................................................................................35
2.8.1 Controlling the projector.............................................................................................................................................35
2.9 Connector panel ................................................................................................................................................................................35
2.10 Color Wheels.......................................................................................................................................................................................36
2.11 Optional Accessories......................................................................................................................................................................36
3Lenses ...................................................................................................................................................................................................................39
3.1 Approved Lenses..............................................................................................................................................................................40
3.2 Lens range............................................................................................................................................................................................40
3.3 Replace a lens....................................................................................................................................................................................43
3.4 Lens shift ...............................................................................................................................................................................................44
3.5 Adjust zoom and focus...................................................................................................................................................................45
601–426-03 F70 Series 5
Table of contents

601–426-03 F70 Series6
3.6 Adjust Iris...............................................................................................................................................................................................45
4Physical Installation.....................................................................................................................................................................................47
4.1 Installation Process .........................................................................................................................................................................48
4.2 Installation conditions.....................................................................................................................................................................48
4.3 Initial inspection .................................................................................................................................................................................49
4.4 Positioning the projector ...............................................................................................................................................................49
4.5 Mounting the projector, general considerations...............................................................................................................50
4.6 Projector safe attachment points .............................................................................................................................................52
4.7 Throw distance...................................................................................................................................................................................52
4.8 Scheimpflug (Boresight) adjustment......................................................................................................................................55
4.9 Scheimpflug adjustment procedure........................................................................................................................................56
5Getting started .................................................................................................................................................................................................59
5.1 Projector source and control connections...........................................................................................................................60
5.1.1 Making connections......................................................................................................................................................60
5.1.2 Connector specifications ...........................................................................................................................................60
5.1.2.1 DVI-I ............................................................................................................................................................60
5.1.2.2 Display Port 1.2 ....................................................................................................................................61
5.1.2.3 HDMI 2.0 ..................................................................................................................................................61
5.1.2.4 3G-SDI.......................................................................................................................................................61
5.1.2.5 HDBase T.................................................................................................................................................62
5.1.3 Control interfaces...........................................................................................................................................................62
5.1.3.1 RS-232.......................................................................................................................................................62
5.1.3.2 LAN/Ethernet .........................................................................................................................................63
5.1.3.3 USB-A port ..............................................................................................................................................63
5.2 Power up the projector...................................................................................................................................................................63
5.3 Power down the projector ............................................................................................................................................................63
5.4 Power mode transitions.................................................................................................................................................................64
5.4.1 General................................................................................................................................................................................64
5.4.2 Power on projector........................................................................................................................................................64
5.4.3 Going from READY to ON ........................................................................................................................................65
5.4.4 Going from ON to READY ........................................................................................................................................65
5.4.5 Going from READY to ECO standby ..................................................................................................................65
5.4.6 Going from ECO to ON...............................................................................................................................................65
5.4.7 Wake On LAN (WOL) .................................................................................................................................................. 65
5.5 Power modes ......................................................................................................................................................................................65
5.6 Customize projector settings......................................................................................................................................................66
5.7 User interface......................................................................................................................................................................................66
5.7.1 On Screen Display (OSD).........................................................................................................................................66
6Source menu .....................................................................................................................................................................................................69
6.1 Connector selection.........................................................................................................................................................................70
6.2 Connector Settings ..........................................................................................................................................................................70
6.3 Using Dual inputs..............................................................................................................................................................................72
7Image menu........................................................................................................................................................................................................75
7.1 Contrast..................................................................................................................................................................................................77
7.2 Brightness ............................................................................................................................................................................................. 77
7.3 Saturation..............................................................................................................................................................................................77
7.4 Sharpness.............................................................................................................................................................................................78
7.5 Gamma Adjustment.........................................................................................................................................................................78
7.6 Advanced image adjustments ...................................................................................................................................................79
7.6.1 P7 Realcolor .....................................................................................................................................................................79
7.6.2 Edit the RealColor presets. ......................................................................................................................................81

601–426-03 F70 Series 7
7.6.3 Output Resolution 4K ..................................................................................................................................................82
7.6.4 Smear Reduction ...........................................................................................................................................................83
7.6.5 Brilliantcolor ......................................................................................................................................................................84
7.6.6 HDR –Perceptual Quantizer (PQ) .......................................................................................................................85
7.6.7 HDR Status.......................................................................................................................................................................86
8Installation menu............................................................................................................................................................................................87
8.1 IR / Night vision functionality ......................................................................................................................................................88
8.2 Lens..........................................................................................................................................................................................................90
8.3 Orientation ............................................................................................................................................................................................90
8.4 Warping ..................................................................................................................................................................................................92
8.4.1 About Warping.................................................................................................................................................................92
8.4.2 Warping –On/Off............................................................................................................................................................92
8.4.3 Warping –Screen Size ...............................................................................................................................................93
8.4.4 Warp –4 Corners adjustment .................................................................................................................................95
8.4.5 Warping –Bow.................................................................................................................................................................96
8.4.6 Warping –Warp files ................................................................................................................................................. 100
8.4.7 Warping –Latency control in a multi projector setup .............................................................................. 101
8.5 Blending .............................................................................................................................................................................................. 103
8.5.1 Basic Blend .................................................................................................................................................................... 103
8.5.2 Set up the system ....................................................................................................................................................... 104
8.5.3 Adjustment Procedure ............................................................................................................................................. 104
8.5.4 Black Level Adjustment ........................................................................................................................................... 105
8.5.5 Black Level Files ......................................................................................................................................................... 106
8.5.6 Blend Files ...................................................................................................................................................................... 107
8.5.7 Advanced Blend .......................................................................................................................................................... 108
8.6 Illumination ........................................................................................................................................................................................ 108
8.7 CLO –constant light output...................................................................................................................................................... 109
8.8 Display Setup....................................................................................................................................................................................110
9System settings menu..............................................................................................................................................................................111
9.1 Communication................................................................................................................................................................................112
9.2 Apply a menu theme .....................................................................................................................................................................112
9.3 Standby ECO ....................................................................................................................................................................................112
9.4 Service..................................................................................................................................................................................................113
9.5 Reset......................................................................................................................................................................................................113
9.6 Lens Features...................................................................................................................................................................................115
9.7 Controlling the backlight of the LCD Display ...................................................................................................................115
10 Status menu ....................................................................................................................................................................................................117
10.1 Status menu overview..................................................................................................................................................................118
11 3D ........................................................................................................................................................................................................................... 121
11.1 Setup 3D mode............................................................................................................................................................................... 122
12 User Maintenance ...................................................................................................................................................................................... 125
12.1 Update Projector Firmware ...................................................................................................................................................... 126
13 Cleaning the projector ............................................................................................................................................................................ 127
13.1 Projector lenses .............................................................................................................................................................................. 128
13.2 Projector cabinet ............................................................................................................................................................................ 128
13.3 Filters .................................................................................................................................................................................................... 128
14 Technical Specifications ....................................................................................................................................................................... 129
14.1 F70 —4K6C ..................................................................................................................................................................................... 130
14.2 F70 —W6 .......................................................................................................................................................................................... 131

601–426-03 F70 Series8
14.3 FS70 —4K6 ..................................................................................................................................................................................... 132
14.4 FS70 —W6....................................................................................................................................................................................... 134

9
About this chapter
Read this chapter thoroughly before attempting to install or operate the projector.
To prevent personal injury to users or physical damage to the projector while installing and using your
projector, ensure that you understand and follow all safety guidelines, instructions and warnings included in
this chapter and this manual.
Clarification of the term F70 / F90 series used in this document
Use in this document of the term, F70 / F90 series, means that the content is applicable for the following
products:
•F90–W13WUXGA
•F90–4K13 4KUHD/WQXGA
•F70 —4K6
•F70 —W6
Defining the GP6 platform
The F90 series products in general, are all products within the Barco GP6 Platform.
Defining the GP7 platform
The F70 series products in general, are all products within the Barco GP7 Platform
Overview
•General considerations
•Important safety instructions
•Projector Hazard Distances
•High Brightness Precautions
•Hazard Distance for fully closed projection system
•HD in function of the lens Throw Ratio (TR)
•Safety symbols
•RoHS compliance
•Taiwan RoHS compliance
•Contact information
•Product Info
•Statement
601–426-03 F70 Series
Safety 1

601–426-03 F70 Series10
1.1 General considerations
Notice on optical radiation F90 Series
•The projector is Class 1 laser product that conforms with IEC EN 60825-1:2014. For Northern America, the
projector is class 3R laser product up to throw ratio 2.33. The projector conforms with IEC 60825–1:2007,
and with performance standards for laser products under 21 CFR 1040, except with respect to those
characteristics authorized by Variance Number 2016–V-0144 effective March 6, 2017
Do not stare into Beam.
•This projector is Risk Group 2 (RG2) according to IEC EN 62471-5.
This projector may become Risk Group 3 (RG3) when an interchangeable lens with throw ratio greater
than 3.15 is installed. For Northern America, installation requirements according to Risk group 3 (RG3)
must be followed when interchangeable lens with throw ratio greater than 2.33 is installed.
Refer to the manual for the lens list and throw ratio before operation.
Such combination of projector and lens are intended for professional use only, and are not intended for
consumer use.
•For RG3, no direct exposure to the beam shall be permitted.
For RG3, operators shall control access to the beam within the hazard distance or install the product at a
height that will prevent eye exposure within the hazard distance.
•This projector has two (2) built-in Class 4 laser clusters. Disassembly or modification is very dangerous
and should never be attempted.
•Any operation or adjustment not specifically instructed by the user’s guide creates the risk of hazardous
laser radiation exposure.
•Do not open or disassemble the projector as this may cause damage by the exposure of laser radiation.
Notice on optical radiation F70 Series
•The projector is Class 1 laser product that conforms with IEC EN 60825-1:2014. For Northern America, the
projector is class 3R laser product up to throw ratio 2.5. The projector conforms with IEC 60825–1:2007,
and with performance standards for laser products under 21 CFR 1040, except with respect to those
characteristics authorized by Variance Number 2016–V-0144 effective March 6, 2017
Do not stare into Beam.
•This projector is Risk Group 2 (RG2) according to IEC EN 62471-5.
This projector may become Risk Group 3 (RG3) when an interchangeable lens with throw ratio greater
than 4.7 is installed. For Northern America, installation requirements according to Risk group 3 (RG3) must
be followed when interchangeable lens with throw ratio greater than 2.5 is installed.
Refer to the manual for the lens list and throw ratio before operation.
Such combination of projector and lens are intended for professional use only, and are not intended for
consumer use.
•For RG3, no direct exposure to the beam shall be permitted.
For RG3, operators shall control access to the beam within the hazard distance or install the product at a
height that will prevent eye exposure within the hazard distance.
•This projector has one (1) built-in Class 4 laser clusters. Disassembly or modification is very dangerous
and should never be attempted.
•Any operation or adjustment not specifically instructed by the user’s guide creates the risk of hazardous
laser radiation exposure.
•Do not open or disassemble the projector as this may cause damage by the exposure of laser radiation.
General safety instructions
•This product contains no user serviceable parts except the Color Wheel in F90 projectors.
When projector becomes RG3, change of color wheel must only be performed by authorized
service personnel.
Attempts to modify/replace mechanics or electronics inside the housing or compartments will violate any
warranties and may be hazardous.
Do not remove/replace any other parts than the Color Wheel. Other parts, service personnel only –
Warranty void if Removed. Follow the instructions in the User Guide to replace the Color Wheel.
•Do not stare into beam when the projector is on. The bright light may result in permanent eye damage.
•Not following the prescribed control, adjustment or operation procedure may cause damage by the
exposure of laser radiation.
•Before operating this equipment please read this manual thoroughly and retain it for future reference.
•Installation and preliminary adjustments should be performed by properly trained and qualified personnel.
Safety

601–426-03 F70 Series 11
•All warnings on the projector and in the documentation manuals must be adhered to.
•All instructions for operating and use of this equipment must be followed precisely.
•All local installation codes should be adhered to.
Notice on safety
This equipment is built in accordance with the requirements of the international safety standards IEC60950-1,
as basis for National safety regulation world wide. The safety standard covers information technology
equipment including electrical business equipment intended to operate in “normal”environments (offices and
homes). This safety standard imposes important requirements on the use of safety critical components,
materials and insulation, in order to protect the user or operator against risk of electric shock and energy
hazard and having access to live parts. Safety standards also impose limits to the internal and external
temperature rises, radiation levels, mechanical stability and strength, enclosure construction and protection
against the risk of fire. Simulated single fault condition testing reduce the risk of hazards and contribute to
ensure the safety of the equipment to the user even when the equipment’s normal operation fails.
Users definition
Throughout this manual, the term SERVICE PERSONNEL refers to Barco authorized persons having
appropriate technical training and experience necessary to be knowledgeable of potential hazards to which
they are exposed (including, but not limited to HIGH VOLTAGE ELECTRIC and ELECTRONIC CIRCUITRY
and HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk
to themselves or other persons. Only Barco authorized SERVICE PERSONNEL, knowledgeable of such risks,
are allowed to perform service functions inside the product enclosure. The term USER and OPERATOR refers
to any person other than SERVICE PERSONNEL.
When installing an interchangeable lens with a throw ratio that makes the projector become an RG3 unit, (See
chapter “Approved lenses”in the User manual), refer to chapter “High Brightness Precautions”, page 14 for
information regarding precautions.
Refer to the user manual for the lens list and hazard distance before operation. Such combination of projector
and lens are intended for professional use only, and are not intended for consumer use.
FOR PROFESSIONAL USE ONLY means installation can only be carried out by Barco AUTHORIZED
PERSONNEL familiar with potential hazards associated with high intensity light beams.
1.2 Important safety instructions
To prevent the risk of electrical shock
•This product should be operated from a mono phase AC power source.
•This apparatus must be grounded (earthed) via the supplied 3 conductor AC power cable. If none of the
supplied power cables are the correct one, consult your dealer.
If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet.
Do not defeat the purpose of the grounding-type plug.
Never use 2-prong power cords, as this is dangerous and could lead to electrical shock.
•Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the
cord. To disconnect the cord, pull it out by the plug. Never pull the cord itself.
•Use only the power cord supplied with your device or original replacement cords. While appearing to be
similar, other power cords have not been safety tested at the factory and may not be used to power the
device. For a replacement power cord, contact your dealer.
•Do not operate the projector with a damaged cord. Replace the cord.
Do not operate the projector if the projector has been dropped or damaged - until it has been examined
and approved for operation by a qualified service technician.
•Position the cord so that it will not be tripped over, pulled, or contact hot surfaces.
•If an extension cord is necessary, a cord with a current rating at least equal to that of the projector should
be used. A cord rated for less amperage than the projector may overheat.
•Never push objects of any kind into this product through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a risk of fire or electrical shock.
•Make sure that no objects enter into the vents and openings of the set.
•Do not expose this projector to rain or moisture.
•The projector is designed for indoor use only. Never operate the unit outdoors.
•Do not immerse or expose this projector in water or other liquids.
Safety

601–426-03 F70 Series12
•Do not spill liquid of any kind on this projector.
•Should any liquid or solid object fall into the cabinet, unplug the set and have it checked by qualified
service personnel before resuming operations.
•Do not disassemble this projector, always take it to an authorized trained service person when service or
repair work is required.
•Do not use an accessory attachment which is not recommended by the manufacturer.
•Lightning - For added protection for this video product during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the device
due to lightning and AC power-line surges.
To prevent personal injury
•To prevent injury and physical damage, always read this manual and all labels on the system before
connecting to the wall outlet or adjusting the projector.
•To prevent injury, take note of the weight of the projector.
•To prevent injury, ensure that the lens and all covers are correctly installed. See installation procedures.
•Warning: high intensity light beam. NEVER look into the lens! High luminance could result in damage to the
eye.
•Warning: extremely high brightness laser: This projector uses extremely high brightness laser. Never
attempt to look directly into the lens or at the laser.
•Always switch off the projector and disconnect from the mains power supply before attempting to remove
any of the projector covers or access parts inside the projector.
•This product contains no user serviceable parts except the Color Wheel. Attempts to modify/replace
mechanics or electronics inside the housing or compartments will violate any warranties and may be
hazardous.
•Do not remove/replace any other parts than the Color Wheel. Other parts, service personnel only Warranty
void if removed
•Do not place this equipment on an unstable cart, stand, or table. The product may fall, causing serious
damage to it and possible injury to the user.
•Only place the projector on a stable surface, or mount it securely using an approved ceiling-mount.
•It is hazardous to operate without lens or lens cap. Lenses or shields shall be changed if they have
become visibly damaged, for example with cracks or deep scratches, to such an extent that their
effectiveness is impaired.
To prevent fire hazard
•Barco projection products are designed and manufactured to meet the most stringent safety regulations.
This projector radiates heat on its external surfaces and from ventilation ducts during normal operation,
which is both normal and safe. Exposing flammable or combustible materials into close proximity of this
projector could result in the spontaneous ignition of that material, resulting in a fire. For this reason, it is
absolutely necessary to leave an “exclusion zone”around all external surfaces of the projector whereby no
flammable or combustible materials are present. The exclusion zone in the exhaust area must be not less
than 100 cm (40”). The exclusion zone on the intake area must not be less than 50 cm (20”).
•Do not place flammable or combustible materials near the projector!
•For the F90 projector, the exclusion zone on the lens side within the light beam must be at least 1,5m.
•For the F70 projector the exclusion zone on the lens side within the light beam must be at least 1,0m.
•Caution! Hot air is exhausted from the rear vent. Do not place objects that are sensitive to heat nearer than
100 cm (40”) to the exhaust vent.
•Slots and openings in this equipment are provided for ventilation. To ensure reliable operation of the
projector and to protect it from overheating, these openings must not be blocked or covered.
•The openings should never be blocked by placing the projector too close to walls, or other similar surface.
Allow for sufficient distance to walls and ceilings to avoid overheating. Minimum safety distance to the
exhaust area of the unit must not be less than 100 cm (40”) and to the intake area, not less than 50 cm
(20”).
•This projector should never be placed near or over a radiator or heat register.
•This projector should not be placed in a built-in installation or enclosure unless proper ventilation is
provided.
•Do not cover the projector or the lens with any material while the projector is in operation. Keep flammable
and combustible materials away from the projector at all times.
•Mount the projector in a well-ventilated area away from sources of ignition and out of direct sun light.
Always allow ample airflow through the projector.
Safety

601–426-03 F70 Series 13
•Never expose the projector to rain or moisture. In the event of fire, use sand, CO2 or dry powder fire
extinguishers.
•Never use water on an electrical fire.
•Always have service performed on this projector by authorized Barco service personnel. Always insist on
genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety
of this projector.
•Projection rooms must be well ventilated or cooled in order to avoid heat buildup.
•Let the projector cool down completely before storing. Remove cord from the projector when storing.
To prevent projector damage
•To ensure correct airflow is maintained the projector should only be operated when all of its covers in
place.
•Always remove lens cap before switching on the projector. If the lens cap is not removed, it may melt due
to the high energy light emitted through the lens. Melting the lens cap may permanently damage the
surface of the projection lens
•Only connect the projector to signal sources and voltages as described in the technical specification.
Connecting to unspecified signal sources or voltages may lead to malfunction and permanent damage of
the unit.
•To ensure correct airflow is maintained, it should only be operated when all of its covers are in place.
•The projector must always be installed in a manner which ensures free flow of air into its air inlets and
unimpeded evacuation of the hot air from its cooling system.
•Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product
and to protect it from overheating, these openings must not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should
never be placed near or over a radiator or heat register. The device should not be placed in a built-in
installation or enclosure unless proper ventilation is provided. Ensure that nothing can be spilled on, or
dropped inside the projector. If this does happen, switch off and unplug the mains supply immediately. Do
not operate the projector again until it has been checked by Barco authorized service personnel.
•Do not block the projector cooling fans or free air movement around the projector. Minimum safety distance
to the exhaust area of the unit must not be less than 100 cm (40”) and to the intake area, not less than 50
cm (20”).
•Do not use this equipment near water.
•Do not operate the projector outside its temperature and humidity specifications as this may result in
overheating and malfunction.
•Never place the projector in direct sun light. Sun light on the lens can severely damage the Digital Mirror
Devices™in which case there is a loss of warranty.
•Save the original shipping carton and packing material. They will come in handy if you ever have to ship
your equipment. For maximum protection, repack your set as it was originally packed at the factory.
•Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning. Never use strong solvents, such as thinner or benzine, or abrasive
cleaners, since these will damage the cabinet. Stubborn stains may be removed with a cloth lightly
dampened with mild detergent solution.
•To ensure the highest optical performance and resolution, the projection lenses are specially treated with
an anti-reflective coating, therefore, avoid touching the lens. To remove dust on the lens, use a soft dry
cloth. Do not use a damp cloth, detergent solution, or thinner.
On servicing
•Do not attempt to service this product yourself, as opening or removing covers may expose you to
dangerous voltage potentials and risk of electric shock.
•Refer all servicing to Barco authorized repair centers.
•Attempts to alter the factory-set internal controls or to change other control settings not specially discussed
in this manual can lead to permanent damage to the projector and cancellation of the warranty.
•Unplug this product from the wall outlet and refer servicing to Barco authorized service personnel or
technicians under the following conditions:
-If liquid has been spilled into the equipment.
-If the product has been exposed to rain or water.
-If the product does not operate normally when the operating instructions are followed. Adjust only those
controls that are covered by the operating instructions since improper adjustment of the other controls
Safety

601–426-03 F70 Series14
may result in damage and will often require extensive work by a qualified technician to restore the
product to normal operation.
-If the product has been dropped or the cabinet has been damaged.
-If the product exhibits a distinct change in performance, indicating a need for service.
-When the power cord or plug is damaged or frayed.
•Replacement parts: When replacement parts are required, be sure the service technician has used original
Barco replacement parts. Unauthorized substitutions may result in degraded performance and reliability,
fire, electric shock or other hazards. Unauthorized substitutions may void warranty.
•Safety check: Upon completion of any service or repairs to this projector, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
1.3 Projector Hazard Distances
For F90 series: WARNING. This may be a RG3 laser Product, dependent on which
lens used.
This projector may become Risk Group 3 (RG3) when an interchangeable lens with throw ratio greater than
3.15 is installed. For Northern America, installation requirements according to Risk group 3 (RG3) must be
followed when interchangeable lens with throw ratio greater than 2.33 is installed
Refer to the product manual for the lens list and throw ratio before operation.
Do not look directly in to the beam from the projector lens.
No direct eye exposure to the beam is permitted.
Operators shall control access to the beam within the hazard distance or install the product at a height that will
prevent eye exposure within the hazard distance.
See table below for a definition of hazardous distances versus the throw ratio of the lens.
For F70 Series: WARNING. This may be a RG3 laser Product, dependent on which
lens used.
This projector may become Risk Group 3 (RG3) when an interchangeable lens with throw ratio greater than
4.7 is installed. For Northern America, installation requirements according to Risk group 3 (RG3) must be
followed when interchangeable lens with throw ratio greater than 2.5 is installed
Refer to the product manual for the lens list and throw ratio before operation.
Do not look directly in to the beam from the projector lens.
No direct eye exposure to the beam is permitted.
Operators shall control access to the beam within the hazard distance or install the product at a height that will
prevent eye exposure within the hazard distance.
See table below for a definition of hazardous distances versus the throw ratio of the lens.
1.4 High Brightness Precautions
Restriction Zone (RZ) based on the HD (Hazard Distance).
The HD depends on the amount of lumens produced by the projector and the type of lens installed. See next
chapter"HD in function of the lens Throw Ratio (TR)", page 8 .
To protect untrained end users (as cinema visitors) the installation shall comply with the following installation
requirements: Operators shall control access to the beam within the hazard distance or install the product at
the height that will prevent spectators’eyes from being in the hazard distance. Radiation levels in excess of
the limits will not be permitted at any point less than 2.0 meter (SH) above any surface upon which persons
other than operators, performers, or employees are permitted to stand or less than 1.0 meter (SH) lateral
separation from any place where such persons are permitted to be. In non-cinema environments where
unrestrained behavior is reasonably foreseeable, the minimum separation height should be greater than or
equal to 3.0 meter to prevent potential exposure, for example by an individual sitting on another individual’s
shoulders, within the HD.
Safety

601–426-03 F70 Series 15
These values are minimum values and are based on the guidance provided in IEC 62471-5:2015 section
6.6.5.
The end user must understand the risk and apply protective measures based upon the hazard distance as
indicated on the label and in the user information. Installation method, barriers, detection system or other
applicable control measure shall prevent hazardous eye access to the radiation within the hazard distance.
For example, projectors that have a HD greater than 1 m and emit light into an uncontrolled area where
persons may be present should be positioned in accordance with “the fixed projector installation”parameters,
resulting in a HD that does not extend into the audience area unless the beam is at least 2.0 meter above the
floor level. In non-cinema environments where unrestrained behavior is reasonably foreseeable, the minimum
separation height should be greater than or equal to 3.0 meter to prevent potential exposure, for example by
an individual sitting on another individual’s shoulders, within the HD. For example, a sufficiently large
separation height may be achieved by mounting the image projector on the ceiling or through the use of
physical barriers.
For applications installed in the USA market the above limits for cinema like environments do not apply. The
relevant minimum separation height is 2.5m (8,2 ft) by the FDA CDRH. Non cinema like environments require
2.5 meter (8.2 ft) separation height and 1.0 meter (3.3 ft) separation width for areas where restrained behavior
is to be expected. All other areas require 3.0 (9.9 ft) separation height.
RA
TH
PR
RZ
HD
SW
1m
SW
SW
SW
HD
EXIT
SH
RA
PR
TH
RZ
SH
(B) TOP VIEW(A) SIDE VIEW
Image 1-1
ASide View
BTop View
RA Restricted Area
PR Projector
TH Theater
RZ Restriction Zone in the theater
SH Separation Height
SWSeparation Width
Regarding the SH Distance: For Cinema applications, the distance must be >2m. For Concert
applications, the distance must be >3m.
Based on national requirements, no person is allowed to enter the projected beam within the zone between
the projection lens and the related hazard distance (HD). This shall be physically impossible by creating
sufficient separation height or by placing barriers. The minimum separation height takes into account the
surface upon which persons other than operator, performers or employees are permitted to stand.
On image 1-2 a typical setup is displayed. It must be verified if these minimum requirements are met. If
required a restricted zone (RZ) in the theater must be established. This can be done by using physical barrier,
like a red rope as illustrated in image 1-2.
The restricted area sticker can be replaced by a sticker with only the symbol.
Safety

601–426-03 F70 Series16
PR
RESTRICTED
AREA
RESTRICTED
AREA
Image 1-2
1.5 Hazard Distance for fully closed projection
system
HD
Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the
energy per surface unit becomes lower than the applicable exposure limit on the cornea or on the
skin. The light beam is considered (to be) unsafe for exposure if the distance from a person to the
light source is less than the HD.
Restriction Zone RZ Based on the HD
The projector is also suitable for rear projection applications; projecting a beam onto a defuse coated
projection screen. As displayed in image 1-3 two areas should be considered: the restricted enclosed
projection area (RA) and the observation area (TH).
Safety

601–426-03 F70 Series 17
RA TH
sw
PD
HDDIFFUSE
sw
RZ
sw sw
PR
HD
REFLECTION
RESTRICTED
AREA
RESTRICTED
AREA
Image 1-3
RA Restricted Access location (Enclosed projection
area)
PR Projector.
TH Theater (observation area).
RZ Restriction Zone
PD Projection Distan
SWSeparation Width. Must be minimum 1 meter.
Restriction zone (RZ) based on the HD continued.
For this type of setup 3 different HD shall be considered:
•HD as discussed in "High Brightness precautions: Hazard Distance (HD)", page 6 , relevant for intrabeam
exposure.
•HDreflection : the distance that has to be kept restrictive related to the reflected light from the rear
projection screen.
•HDdiffuse : the relevant distance to be considered while observing the defuse surface of the rear projection
screen.
As described in "High Brightness precautions: Hazard Distance (HD)", page 6 , it is mandatory to create a
restricted zone within the beam areas closer than any NOHD. In the enclosed projection area the combination
of two restricted zones are relevant: The restricted zone of the projected beam toward the screen; taking into
account 1 meter Separation Width (SW) from the beam onward. Combined with the restricted zone related to
the rear reflection from the screen (HDreflection); also taking into account a 1 meter lateral separation.
The HDreflection distance equals 25% of the difference between the determined HD distance and the
projection distance to the rear projection screen. To determine the HD distance for the used lens and projector
model see graphs in chapter "HD in function of the lens Throw Ratio (TR)", page 8 .
HDreflection = 25% (HD –PD)
The light emitted from the screen within the observation shall never exceed the RG2 exposure limit,
determined at 10 cm. The HDdiffuse can be neglected if the measured light at the screen surface is below
5000 cd/m² or 15000 LUX.
1.6 HD in function of the lens Throw Ratio (TR)
TR (Throw Ratio)
The ratio of the distance to the screen (throw) to the screen width.
Safety

601–426-03 F70 Series18
HD versus Throw Ratio
Image 1-4: Hazard Distance in meters versus Throw ratio of
the lens for the F90 projectors
0
0,2
0,4
0,6
0,8
1
1,2
1,4
1,6
1,8
0,5 0,9 1,3 1,7 2,0 2,3 2,7 3,1 3,5 3,9 4,3 4,7 5,1 5,5 5,9 6,3 6,7 7,1 7,5
Hazard Distance [m]
Throw Ra!o
Hazard Distance Thermal Acidental Exposure
Image 1-5: Hazard Distance in meters versus Throw ratio of
the lens for the F70 projectors
Graphs shows Hazard Distance in meters versus Throw ratio of the lens
Safety

601–426-03 F70 Series 19
1.7 Safety symbols
Description of safety symbols used in product documentation or on product.
Image Description
Refer to user manual for further
information!
Caution! Do not stare into beam,
RG2 product.
No telephone! Do not connect to
telephone lines.
For F90 series: Warning Label
For North America, this projector may become RG3 when an interchangeable lens with throw ratio greater than
2.33 is installed.Refer to the manual for the lens list and hazard distance before operation. Such combinations of
projector and lens are intended for professional use only, and are not intended for consumer use.
This projector may become RG3 when an interchangeable lens with throw ratio greater than 3.15 is
installed.Refer to the manual for the lens list and hazard distance before operation. Such combinations
of projector and lens are intended for professional use only, and are not intended for consumer use.
Ce projecteur peut devenir un projecteur RG3 en cas d'installation d'un objectif interchangeable
dont le rapport de projection est supérieur à 3,15.Veuillez vous reporter au manuel pour en savoir
plus sur la liste des objectifs et la distance de sécurité avant toute utilisation.De telles combinaisons
entre projecteur et objectif sont conçues pour des applications professionnelles uniquement et pas
pour des applications grand public.
3.15 RG3
Caution! For North America: With
interchangeable lens with throw ratio
greater than 2.33, consider hazard
distance and installation
requirements for RG3 product. Refer
User Manual.
Caution! With Interchangeable lens
with throw ratio greater then 3.15,
consider hazard distance and
installation requirements for RG3
product. Refer User manual.
For F90 series: FDA Label
THIS PRODUCT IS IN CONFORMITY
WITH PERFORMANCE STANDARDS
FOR LASER PRODUCTS UNDER 21
CFR 1040, EXCEPT WITH RESPECT TO
THOSE CHARACTERISTICS
AUTHORIZED BY VARIANCE NUMBER
2016-V-0144 EFFECTIVE
MARCH 6, 2017.
For F70 Series: Warning label
For North America, this projector may become RG3 when an interchangeable lens with throw ratio
greater than 2.5 is installed.Refer to the manual for the lens list and hazard distance before operation.
Such combinations of projector and lens are intended for professional use only,and are not intended
for consumer use.
This projector may become RG3 when an interchangeable lens with throw ratio greater than 4.7 is
installed. Refer to the manual for the lens list and hazard distance before operation. Such
combinations of projector and lens are intended for professional use only,and are not intended
for consumer use.
Ce projecteur peut devenir un projecteur RG3 en cas d'installation d'un objectif interchangeable
dont le rapport de projection est supérieur à 4.7.Veuillez vous reporter au manuel pour en savoir
plus sur la liste des objectifs et la distance de sécurité avant toute utilisation. De telles combinaisons
entre projecteur et objectif sont conçues pour des applications professionnelles uniquement et pas
pour des applications grand public.
4.7 RG3
Caution! For North America: With
interchangeable lens with throw ratio
greater than 2.5, consider hazard
distance and installation
requirements for RG3 product. Refer
User Manual
Caution! With Interchangeable lens
with throw ratio greater then 4.7,
consider hazard distance and
installation requirements for RG3
product. Refer User manual.
For F70 Series: FDA Label
THIS PRODUCT IS IN CONFORMITY WITH
PERFORMANCE STANDARDS FOR LASER
PRODUCTS UNDER 21 CFR 1040, EXCEPT
WITH RESPECT TO THOSE CHARACTERISTICS
AUTHORIZED BY VARIANCE NUMBER
2016-V-0144 EFFECTIVE MARCH 6, 2017.
Safety

601–426-03 F70 Series20
Image Description
F70 EMC Label
This is a class A product. In a domestic environment this product
may cause radio Interference in which case the user may be
required to take adequate measures.
This device complies with part 15 of the FCC Rules,Operation is subject to the following
conditions: (1)This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This Class A digital apparatus complies with Canadian ICES-003,/ Cet appareil numerique
de Ia classe est conforme à Ia norme NMB-003 du Canada.
EMC:
FCC:
CANADA:
IEC EN 60825-1
CLASS 1 LASER PRODUCT
RG2 IEC EN 62471-5
F90 EMC Label
This Class A digital apparatus complies with Canadian ICES-003, / Cet
appareil numerique de Ia classe est conforme à Ia norme NMB-003 du
Canada.
CANADA:
This device complies with part 15 of the FCC Rules, Operation is subject to the following
conditions: (1)This device may not cause harmful interference, and (2) this device must
accept any interference received,including interference that may cause undesired operation.
FCC:
This is a class A product. In a domestic environment this product may
cause radio Interference in which case the user may be required
to take adequate measures.
EMC:
RG2 IEC EN 62471-5
IEC EN 60825-1
CLASS 1 LASER PRODUCT
Location of Safety Label
8
9
EMC Label Warning Label
Image 1-6: F90 Projector
Warning and EMC labels
Image 1-7: F70 Projector
Disposal Information
Waste Electrical and Electronic Equipment
Safety
