Barco MVSP10 User manual

Getting Started Guide
MVSP10

(This page intentionally left blank.)
2
(This page intentionally left blank.)

3
Copyright notice
Copyright
This document is copyrighted. All rights are reserved. Neither this
document, nor any part of it, may be reproduced or copied in any
form or by any means - graphical, electronic, or mechanical including
photocopying, taping or information storage and retrieval systems -
without written permission of Barco
© 2009 Barco N.V. All rights reserved.
Disclaimer Notice
Although every attempt has been made to achieve technical accuracy
in this document, we assume no responsibility for errors that may be
found. Our goal is to provide you with the most accurate and usable
documentation possible; if you discover errors, please let us know.
Barco software products are the property of Barco. They are
distributed under copyright by Barco N.V. or Barco, Inc., for use only
under the specific terms of a software license agreement between
Barco N.V. or Barco Inc. and the licensee. No other use, duplication, or
disclosure of a Barco software product, in any form, is authorized.
The specifications of Barco products are subject to change without
notice.
Trademarks
All trademarks and registered trademarks are property of their
respective owners.

(This page intentionally left blank.)
4

Table of Contents
5
Table of Contents
Preface..................................................................................... 6
CE mark notice ................................................................................. 6
Environmental information ............................................................. 7
Safety Instructions ........................................................................... 8
Explanation of symbols.................................................................. 10
Introduction ........................................................................... 12
Parts, controls and connectors ...................................................... 12
Front ........................................................................................ 12
Rear ......................................................................................... 14
Marking of the unit........................................................................ 16
Installation............................................................................. 18
Installation precautions ................................................................. 18
Fixing the unit ................................................................................ 18
Connecting the signal cables......................................................... 20
Front ........................................................................................ 20
Rear ......................................................................................... 21
Cleaning instructions ............................................................. 23
Precautions..................................................................................... 23
Cleaning the unit............................................................................ 23
Technical information............................................................ 25
Connector pin assignments ........................................................... 25
Technical specifications ................................................................. 30
Warranty Statement .............................................................. 32

Preface
6
Preface
CE mark notice
Declaration of Conformity in accordance with Article 10 (1) of the CE directive
This product has been designed and manufactured in accordance with
the essential requirements of the Directives 89/336/EEC and
MDD 93/42/EEC (class II b product), and for this product the
procedures of Annex II have been applied to mark the product with
the CE label.

Preface
7
Environmental information
Disposal Information
This product consists of devices that may contain mercury, which must
be recycled or disposed of in accordance with local, state, or country
laws.
This equipment has required the extraction and use of natural
resources for its production. It may contain hazardous substances for
health and environment.
In order to avoid the dissemination of those substances in the
environment and to diminish the pressure on natural resources, we
encourage you to use the appropriate take-back systems.
Those systems will reuse or recycle most of the materials of your end-
of-life equipment in a sound way.
The crossed-out wheeled bin symbol invites you to use those
systems.
If you need more information on the collection, reuse and
recycling systems, please contact your local or regional waste
administrator.
You can also contact us for more information on the environmental
performances of our products.

Preface
8
Safety Instructions
General Recommendations
Read the safety and operating instructions before operating the
equipment.
Retain safety and operating instructions for future reference.
Adhere to all warnings on the equipment and in the operating
instructions manual.
Follow all instructions for operation and use.
Electrical shock
Type of protection (electrical):
Equipment with internal power supply: Class II equipment.
Degree of safety (flammable anesthetic mixture):
Equipment not suitable for use in the presence of a flammable
anesthetic mixture with air or with oxygen or nitrous oxide.
Non-patient care equipment
Equipment primarily for use in a health care facility that is intended
for use where contact with a patient is unlikely.
Power connection - equipment with internal power supply
The equipment must be powered by the AC mains voltage.

Preface
9
Power cords:
• Utilize a UL-listed detachable power cord, 3-wire, type SJ or
equivalent, 18 AWG min., rated 300 V min., provided with a
hospital-grade type plug 5-15P configuration for 120V
application, or 6-15P for 240V application.
• Do not overload wall outlets and extension cords as this may
result in fire or electric shock.
• Mains lead protection (U.S.: Power cord): Power cords should
be routed so that they are not likely to be walked upon or
pinched by items placed upon or against them, paying
particular attention to cords at plugs and receptacles.
Water and moisture
Never expose the equipment to rain or moisture.
Never use the equipment near water - e.g. near a bathtub,
washbasin, swimming pool, kitchen sink, laundry tub or in a wet
basement.
Ventilation
Do not cover or block the ventilation openings in the cover of the set.
When installing the equipment in a cupboard or another closed
location, heed the necessary space between the set and the sides of
the cupboard.
This apparatus conforms to:
CE0120 (MDD 93/42/EEC class IIb product), IEC 60601-1, UL 60601-1,
CAN/CSA C22.2 No. 601.01-M90 (c-UL).
National Scandinavian Deviations for Cl. 1.7.2 :
Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun
pistorasiaan"
Norway: "Apparatet må tilkoples jordet stikkontakt"
Sweden: "Apparaten skall anslutas till jordat uttag"

Preface
10
Explanation of symbols
Symbols on the equipment
On the equipment, you may find the following symbols
(nonrestrictive list):
Indicates compliance to the essential require-
ments of the Directive 93/42/EEC
or
Indicates the equipment is approved accord-
ing to the UL regulations
or
Indicates the equipment is approved accord-
ing to the c-UL regulations
Indicates the equipment is approved accord-
ing to the DEMKO regulations
Indicates the USB connectors on the equip-
ment
Indicates the manufacturing date
Indicates the temperature limitations for the
equipment to operate within specs
Indicates the equipment serial no.
Consult the operating instructions

Preface
11
Symbols used throughout the manual:
Indicates this apparatus must not be thrown
in the trash but must be recycled, according
to the European WEEE (Waste Electrical and
Electronic Equipment) directive
Warning: Risk of
injury to human
beings
Caution: Risk of
damage to the
product
Important notice or
remark
Note
Hint, tip Additional
information

Introduction
12
Introduction
The MVSP10 (Medical Video Switcher and Processor) video interface is
intended as an interface between different video sources from
different modalities and is generating a single video format to be
connected to standard displays equipped with a DVI-D interface. The
interface is facilitating the cabling and is providing all required image
processing to convert the applied video formats into the single video
output format. 2 Ethernet interfaces allow controlling the video
interface remotely and also provide a frame grabber function to a
workstation.
Parts, controls and connectors
Below is a description of the default parts, controls and connectors
configuration.
Front
Figure 1: Parts, controls and connectors (front)
1234578
6910 11 12-14 15

Introduction
13
N° Description Lay-out
RS-232 connector (for
service only)
SD/HD-SDI 1
connector
SD/HD-SDI 2
connector
S-Video input
Sync input
B / COMP3 / Pb / C
input
G / COMP2 / Y / Y / Y
input
R / COMP1 / Pr / COMP1
input
VGA input
DVI-I 1 input
1
2
3
4
5
6
7
8
9
10

Introduction
14
Rear
Figure 2: Parts, controls and connectors (rear)
DVI-I 2 input
LED 0
LED 1
LED 2
USB 1 connector
N° Description Lay-out
CAT6 2 input (REF
IN)
N° Description Lay-out
11
12
13
14
15
12345678910 11 12
1

Introduction
15
CAT6 1 input (LIVE
IN)
DVI-I 1B output
DVI-I 2B output
CAT6 1A output
CAT6 2A output
Ethernet 1 con-
nector
Ethernet 2 con-
nector
Functional GND
connector
Power input
Power switch
USB 0 connector
N° Description Lay-out
2
3
4
5
6
7
8
9
10
11
I
O
12

Introduction
16
Marking of the unit
The unit is affixed with a label containing symbols and manufacturer-,
regulatory-, safety-, power- and administrative information. An
example label is shown in the figure below.
Figure 3: Label 1

Introduction
17
The unit is also affixed with a second label containing the model and
serial number. An example is shown in the following figure.
Figure 4: Label 2

Installation
18
Installation
Installation precautions
Precautions
• Keep your original packaging. It is designed for this unit and is
the ideal protection during transport.
• Wear gloves during installation to keep the unit free from
stains and fingerprints.
Fixing the unit
You can fix the unit into place by using the 7 fixation holes provided in
the metal housing. 4 of these holes are located at the top of the unit,
the other 3 are at the bottom.
Figure 5: Fixation holes (top)

Installation
19
Figure 6: Fixation holes (bottom)

Installation
20
Connecting the signal cables
Below is an overview of how to connect the signal cables of the
MVSP10 with other devices. Connect the unit as shown in the
following drawings:
Front
Figure 7: Connecting the signal cables (front)
N° Device
Laptop (for service only)
SD/HD-SDI generator
SD/HD-SDI generator
S-Video generator
Video generator
123456789
1
2
3
4
5
