Barnett Engineering ProTalk Cv3 User manual

ProTalk
Battery Installation Instructions
Remove the 4 screws on both sides of the Cv3:
Attach the provided power cable to the battery:

ProTalk
Battery Installation Instructions
The red wire must match the red terminal (+) and the black wire the black terminal (-). Failure to connect the
battery properly could damage the Cv3.
Position the battery against the side of the base:
Place the bracket on top of the battery:
Press the bracket towards the corner of the base and then fasten it using the lock nuts:

ProTalk
Battery Installation Instructions
Connect the other end of the cable to the Cv3:

ProTalk
Battery Installation Instructions
Reassemble the unit.
The firmware now needs to be updated before the battery can be used.

ProTalk
Battery Installation Instructions
Open the Cv3 Database Editor and select File -Update Module Firmware. Follow the instructions until the
following window appears:
Check the Battery Charger - enabled box and press the Update Module Options button:

ProTalk
Battery Installation Instructions
Verify that the option settings are confirmed (under the Status heading) and press the Close button.
The Cv3 battery backup option is now available.
