Lamp module with connection cable
Explosion protection Technical data
Description
These lamp modules are used everywhere
in Group IIC, Zone 1 hazardous areas where
machine functions are to be activated by
pressin a button and the functional status
of the respective machine is to be indicated
visually.
Each actuatin element is fitted into a
mountin hole on a control console or panel.
The respective lamp module is then fas-
tened without tools to the actuatin element
and secured with a fixin nut (see followin
pa es for assembly).
The easy installation of the actuators in the
control console or panel allows conformance
to a hi h IP de ree of protection.
Dimensions in mm
01-3353-7D0004-08/12-STVT-345343
Ex protection t pe
II 2G Ex d IIC T6
0044
Certification
PTB 97 ATEX 1065 X
Ambient temperature
-40 °C to +50 °C
Stora e, transport: -55 °C to +70 °C
approved for Zone
1
Protection class
determined by actuatin element and
additional enclosure.
Lamp module up to IP 67 in combination
with actuatin element
PTB 00 ATEX 3114 U.
Weight
approx. 180 (without connection
cable)
Rated insulation voltage
300 V
Power consumption
< 1 W
Rated operating voltage (Ue)
AC 12 V to 250 V (Ta < +50 °C)
DC 12 V to 60 V (Ta < +50 °C)
AC/DC 12 V to 24 V (Ta < +60 °C)
Enclosure material / manufacturing process
Thermoplastic / injection mouldin
Connection
inte rated connection cable, 3 m
ø 6.4 mm, 2 x 0.75 mm2
Lamp
LED (red, reen, yellow, white, blue)
Illumination
very bri ht, visible an le up to 180°
Service life
electrical > 105 runnin hours
Mounting
locked, by bayonet lock

Operating Instructions Lamp module Type 07-3353-31.3
BARTEC
GmbH Max-Eyth-Straße 16
D-97980 Bad Mer entheim
Tel.: [phone]
Fax: [phone]
[email protected]
www.bartec.de
Reservation Technical data subject to chan e without notice. Chan es, errors and
misprints may not be used as a basis for any claim for dama es.
2/3
01-3353-7D0004-08/12-STVT-345343
Safet Instructions
The lamp module and its actuatin element
may be used only within the specified ambient
and operatin temperature ran e.
Utilisation in areas other than those specified or
the modification of the product by anyone other
than the manufacturer will exempt BARTEC
from liability for defects or any further liability.
Incorrect installation can cause malfunctionin
and the loss of explosion protection.
The lamp module may be connected and
mounted only by qualified personnel who are
authorised and trained to assemble electric
components in hazardous (potentially explo-
sive) areas.
Always disconnect the lamp module from
volta e before assembly or disassembly.
The enerally applicable statutory rules and
other bindin directives relatin to workplace
safety, accident prevention and environmental
protection must be adhered to.
The lamp module may be used only if it is clean
and not dama ed in any way.
Marking
Particularly important points in these instruc-
tions are marked with a symbol:
DANGER
Non-observance leads to death or serious
physical injury. The necessary safety measures
must be taken.
CAUTION
Warning of damage to property and financial
and penal disadvantages (e.g. loss of guaran-
tee rights, liability etc.).
ATTENTION
mportant instructions and information on
preventing disadvantageous behaviour.
NOTE
mportant instructions and information on
effective, economical and environmentally
compatible handling.
Standards conformed to
EN 60079-0:2006
EN 60079-1:2004
DIN EN 60068-2-27:1995, 30 , 18 ms
Assembl and Commissioning
NOTE
The assembly of the lamp module and lamp
module actuator is described in the operating
instructions for the module actuators.
Assembl /disassembl
ATTENTION
Only authorised and qualified personnel may
do any of the assembly, disassembly, installa-
tion and commissioning work.
The minimum centre-to-centre spacing be-
tween two mounting holes must be observed.
Make sure the lamp module to be fitted is intact
(no cracks).
Position the lamp module’s bayonet lock at the
mounted actuatin element and turn the closin
latch to connect it securely to the actuatin
element.
Installation
The lamp module is to be installed as a station-
ary unit and with protection a ainst the risk of
mechanical dama e.
The free end of the connection cable must be
connected either in the safe area or in Groups I
and II hazardous areas with an appropriate
enclosure ensurin “Ex e” increased safety or
an enclosure that conforms to another ap-
proved type of protection under EN 60079-0
Section 1.
When installin in an enclosure with the "Ex e"
type of protection, the clearance and creepa e
distances as in EN 60079-7 Section 4.3, Sec-
tion 4.4 and Table 1 must be complied with at
the conductor ends.
Only suitable tools may be used for installation
work. It is not permissible to modify the module
in any way.
The cable is to be fixed in a way that prevents
mechanical strain (between the lamp module
and connection cable and between the junction
box and the cable). The minimum bendin
radius of the cable must be at least 26 mm.
ATTENTION
Avoid any capacitive influence from parallel
conductors as well as any additional adverse
heat effects on the cable.
Commissioning
Before commissionin check that:
• the device has been installed correctly
• the device is not dama ed
• the connection has been established
properly
Operation, Maintenance and
Fault Clearance
The operator of the lamp module must keep it
in ood condition, operate it properly, monitor it
and clean it re ularly. The lamp module,
module actuator, sealin s and cables must be
checked re ularly for cracks and dama e.
NOTE
Dirty modules/actuators can be cleaned with
compressed air.
The lamp module is defective if the LED cannot
li ht up any more. Defective lamp modules
cannot be repaired; they must be replaced.
Defective actuators can be removed and re-
placed by functionin actuators of the same
type.
Accessories, Spare Parts
See BARTEC catalo ue also.
Disposal
The components in the lamp module and the
actuator contain metal and plastic parts.
Therefore the statutory requirements for electri-
cal scrap must be observed (e. . disposal by
an approved disposal company).
Service address
BARTEC GmbH
Max-Eyth-Straße 16
D-97980 Bad Mer entheim
Tel.: [phone]
Fax: [phone]
