1. Product description
The RLAnet monitoring device is a component of the BARTEC
water detection system and is used to detect electrically
conductive and non-electrically conductive liquids.
Together with the SCR sensor line and the PS point sensor, the
RLAnet monitoring device can detect electrically conductive
liquids, together with the PSO/PSO+ point sensor, electrically
non-conductive liquids can be detected.
The system quickly and reliably detects smaller leaks and
generates an optical and acoustic warning signal. The floating
contact is switched at the same time to forward the signal to the
PLC or a building management system.
With the integrated software of the RLAnet monitoring device, it is
possible to establish an exact localisation of the leak that has
occurred. The leakage is determined with an accuracy of one
meter and shown on the four-digit display.
The speed at which a leak is detected depends on the volume
and conductivity of the leaked liquid. The SCR sensor line
achieves the shortest response time when it is completely
surrounded by water (approx. 5 mm water level) or when it is
surrounded by a sensor line length of at least 20 cm. Due to its
geometry, a minimum amount of leaking liquid is required for
detection by the point sensor PS or PSO/PSO+. See the point
sensor data sheet for more information.
Product variants
Type
Variant
17-85G5-
21230000
for the assembly of top-hat rails
17-85G5-
21230100
within the IP housing: 1 universal power pack,
1 monitoring device RLAnet, 1 power relay
17-85G5-
21230200
within the IP housing: 1 universal power pack,
2 monitoring devices RLAnet, 2 power relays
17-85G5-
21230400
within the IP housing: 2 universal power
packs, 4 monitoring devices RLAnet, 4 power
relays
More upon request.
2. Safety regulations
The RLAnet monitoring device is state-of-the-art and reliable. In
order to ensure safe operation, careful system planning, proper
transport, professional assembly, commissioning and
maintenance of all components used is required.
RLAnet may only be operated and used in accordance with its
intended use in compliance with these assembly and operating
instructions, the applicable national standards, regulations and
approvals (e.g. directives 2014/30/EU, DIN VDE series 0100).
Improper use or handling of the product can result in serious
personal injury or death. This can also damage the product, the
system and the environment.
BARTEC GmbH assumes no liability for damages resulting from
the installation and use of the software, and in particular not for
personal injuries and property damages as well as financial
losses that are directly or indirectly associated with the use of the
software.
Please read carefully through these assembly and operating
instructions in full before you carry out any work on the RLAnet or
the system. The instructions and warnings included in these
assembly and operating instructions must be read, understood
and observed.
Keep the manual near the RLAnet monitoring device for future
reference and pass it on to new owners where relevant.
Product specifications are subject to change without prior notice.
Claims for damages resulting from changes, errors or misprints
are excluded.
2.1. Intended use
The RLAnet monitoring device is used to detect and localise
electrically conductive and non-electrically conductive liquids. It is
intended for the use outside of potentially explosive atmospheres.
The RLAnet monitoring device is intended for operation with a
suitable control line or the SCR sensor line and the PS point
sensor or the PSO/PSO+ point sensor.
Before start-up, the parameters set on the monitoring device must
be compared with the actually required parameters of the system
and corrected if necessary. Set parameters must match the
installed components of the system.
All system components may only be operated as intended and
within their specifications (technical data). The applicable national
installation regulations must be observed.
The information in these assembly and operating instructions for
the respective life phases must be observed and complied with.

6Assembly and operating instructions / EN
2.2. Foreseeable misuse
The use of the RLAnet monitoring device is not permitted:
–outside of its intended use
–with non-approved or unintended components
–in potentially explosive areas
–outside of its specifications (technical data)
–the technical modification or opening of the component
–without observing the information in the assembly and
operating instructions and applicable national installation
regulations
2.3. Personnel qualifications
Only trained personnel may use the RLAnet monitoring device.
The personnel must have basic electrical knowledge.
The wiring for electrical installations and, if necessary, for
maintenance or changes to the installed system may only be
carried out by a qualified electrician.
Decommissioning and dismantling may only be carried out by
trained persons. Disposal is only permitted through an approved
specialist company.
2.4. Symbols and signs
The warnings shall be intended to protect against dangerous
situations, personal injury and damage to property.
In the operating instructions, the severity of the possible dangers
is indicated by the following signal words.
DANGER!
DANGER indicates an imminent danger. If not
avoided, death or serious injury will result.
WARNING!
WARNING indicates a potentially imminent danger.
If not avoided, it can result in death or serious injury.
CAUTION!
CAUTION indicates a potentially imminent danger. If
not avoided, minor injuries may result.
ATTENTION!
ATTENTION indicates a potentially harmful
situation. If not avoided, the plant or something in its
vicinity may be damaged.
PLEASE NOTE!
PLEASE NOTE indicates notes and information on
an effective, economical and environmentally
friendly handling.

11-85G5-7D0002/B-EHT-10/2021 7
3. Technical data
General
Type of control
Monitoring device for the detection and
localisation of electrically conductive and non-
electrically conductive liquids
Display
1 line, four digits with 7 segments respectively,
height 10 mm, colour red; an additional 3
LED’s:
Power red LED (relay dropped out)
Service green LED (relay energized)
Leak green LED (relay energised)
Alarm signal
Optical with LED’s, acoustically with
piezoelectric buzzer
Measurement
and display
accuracy
1.0 m
Ambient
temperature
range
-20 °C to +50 °C, with 5% to 95% humidity,
not condensing
Storage
temperature
-40 °C to +60 °C
Housing
thermoplastic material,
fastening onto DIN top-hat rail TS35
Connection
Screw terminal, 0.25 mm² - 1.5 mm²
Measurements
86 mm x 70 mm x 53 mm (WxHxD)
Type of
protection
IP20
Electrical data
Power supply
12 V to 24 V DC, ±10%
Power
consumption
3 W
Alarm relay
Umax AC 125 V; Imax 0,5 A; AC-12
Umax DC 24 V; Imax 1,0 A; DC-13
Measurement
method
Electrical conducted
with sensor cable SCR and sensor PS >30
µS,
Sensor PSO/PSO+ can be integrated in
the measuring circuit
Connection
Terminals
Alarm relay power connection,
leak sensor, RS485 (4 terminals)
Leak sensor limits
Max. length of SCR sensor line: 500 m
Max. number of point sensors PS,
PSO/PSO+: 50 pcs.
50 PS or PSO+ (60 Ohm) or 500 m SCR
sensor cable (6 Ohm/m) can be connected
to each RLAnet. The sensors can also be
mixed. It is important to ensure that the
resistance does not exceed the maximum
limit of 3000 ohms.
Conformity in accordance with
–EN 62321:2009
–EN 61326-1:2013
–EN 61000-3-2:2014
and compliance with directives 2014/30/EU (EMC directive) and
2011/65/EU (RoHS directive) is confirmed by the manufacturer.

8Assembly and operating instructions / EN
3.1. Wiring diagram
Connection as a stand-alone system
Connection of sensors, cables and plugs
Key
N1
Monitoring device RLAnet
B1
SCR sensor line, PS sensor
B2
SCR sensor line, PS sensor
XS1
Plug/plug-in coupling M12
(BARTEC item 05-0091-0054, item 05-0091-0055)
Xend
Terminating plug (BARTEC Art. 05-0080-0161)

11-85G5-7D0002/B-EHT-10/2021 9
Connection in the MODBUS network
Connection of the RS485 line
Key
N1
Monitoring device RLAnet
H1
HMI, such as PC
RS485-
Leitung
Twisted pair cable, 2x 0.5 mm²
120R
Termination resistance (optional)
In the event of transmission errors, the optional use of a bus termination with R=120 Ohm or a data line Z0=120 Ohm is possible.
Connection and switching situations
LED
Voltage
Relay contact
Display
Output status
Power
Leak
Service
OUT
NO-COM
no leak
open
OUT
OUT
OUT
ON
NO-COM
no leak
open
ON
OUT
OUT
leak
closed
ON
ON
OUT
power failure
open
OUT
OUT
OUT
broken sensor
line
open
ON
OUT
ON
ON
NC-COM
no leak
closed
ON
OUT
OUT
leak
open
ON
ON
OUT
power failure
closed
OUT
OUT
OUT
broken sensor
line
closed
ON
OUT
ON

10 Assembly and operating instructions / EN
4. Device description
4.1. Module description
Key
Item
Description
Function
1
Display, 4 digits
Description of the location of the
leak (no leaks, distance to the
leak in running meters)
2
Power supply connection
3
Connection alarm relay
4
LED, Modbus RTU communication
(RX = incoming, TX = outgoing)
Display of the interface
communication
5
RS485 communication interface
connection
6
LED, devices and system status
Display of the device and
system status (power, service,
leak)
7
"Confirm" button
Acknowledging error messages
8
Connection sensor cable, 4-wire
Description of the display
---- no leak
12.3 leakage at 12 running meters
err line break
no display no power present
Scope of delivery
1 piece
Monitoring device RLAnet
1 piece
Data sheet/quick guide
Type label
Exemplary depiction of type plate:
8
7
5
4
3
2
6
1
