Bartscher Slim-Line 80L 700.180G User manual

Slim-Line 80L
700.180G
V
2
/
10
11

- 17 -
1. General Information 18
1.1 Information about the instruction manual 18
1.2 Key to symbols 18
1.3 Liability and Warrantees 19
1.4 Copyright protection 19
1.5 Declaration of conformity 19
2. Safety 20
2.1 General information 20
2.2 Safety instructions for use of the device 20-21
2.3 Intended use 21
3. Delivery, packaging and storage 22
3.1 Delivery check 22
3.2 Packaging 22
3.3 Storage 22
4. Technical data 23
4.1 Overview of parts 23
4.2 Technical specification 24
5. Installation and operation 24
5.1 Safety instructions 24-25
5.2 Installation and connection 25
5.3 Operating 26-28
6. Cleaning and maintenance 28
6.1 Safety advice 28
6.2 Cleaning 29
6.3 Safety instructions for maintenance 29
7. Possible Malfunctions 30-31
8. Waste disposal 31
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
GB/UK

- 18 -
1. General information
1.1 Information about the instruction manual
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device and
easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards, which could lead to injury.
Please follow the instructions very carefully and proceed with particular attention
in these cases.
WARNING! Electrical hazard!
This symbol draws attention to potential electrical hazards. If you do not follow
the safety instructions, you may risk injury or death.
CAUTION!
This symbol highlights instructions, which should be followed to avoid any risk of
damage, malfunctioning and/or breakdown of the device.
NOTE!
This symbol highlights tips and information, which have to be followed for
an efficient and trouble-free operation of the device.

- 19 -
1.3 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology. If you have any
questions, you should contact the manufacturer.
NOTE!
Read the instruction manual carefully before using the device. The manufacturer
does not accept liability for any damage or malfunction resulting from not
following the instructions for use.
The instruction manual should be kept near the device, easily accessible for anyone
wishing to work with or using it. We reserve the right to make technical changes for
purposes of developing and improving the useful properties.
1.4 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any form
or by any means without permission in writing from the manufacturer. Any person who
commits any unauthorized act in relation to this publication shall be liable to claims for
damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are copyright
and subject to other protection rights. Any person unlawfully using this
publication is liable to criminal prosecution.
1.5 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity.
If required we will be glad to send you the according declaration of conformity.

- 20 -
2. Safety
This section provides an overview of all important safety aspects.
In addition every chapter provides precise safety advice for the prevention of dangers
which are highlighted by the use of the above mentioned symbols.
Furthermore, attention should be paid to all pictograms, markers and labels on the
device, which must be kept in a permanent state of legibility.
By following all the important safety advice you gain an optimal protection against all
hazards as well as the assurance of a safe and trouble-free operation.
2.1 General Information
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
Knowing the contents of the instruction manual as well as avoiding mistakes and thus
operating this device safely and in a fault-free manner is very essential to protect
yourselves from the hazards.
To prevent hazards and to ensure optimum efficiency, no modifications or alterations to
the device that are not explicitly approved by the manufacturer may be undertaken.
This device may only be operated in technically proper and safe condition.
2.2 Safety instructions for use of the device
The specifications regarding the industrial safety are based on the Regulations of the
European Union applicable at the time of manufacturing the device.
If the device is used commercially, the user is obliged to ensure that the said industrial
safety measures concur with the state of the rules and regulations applicable at the time
in question for the entire period of use of the device and to comply with the new
specifications.
Outside the European Union, the industrial safety laws applicable at the place of
installation of the device and the regional territorial provisions must be complied with.
Besides the industrial safety instructions in the instruction manual, the general safety and
accident prevention regulations as well as environment protection regulations applicable
for area of application of the device must be followed and complied with.

- 21 -
CAUTION!
oThe device is not intended for use by individuals (including children) with physical or
mental disabilities, insufficient experience, and/or insufficient knowledge unless such
persons are under the care of a person responsible for their safety or have received
instructions regarding appropriate use of the device.
oChildren should be observed to ensure that they are not playing with the device.
oPreserve this manual safely. When passing on/selling the device to a third party, the
manuals must be handed over along with the device.
oEvery person using the device must act in accordance to the manuals and under
consideration of the safety advice.
oThe device is to be used indoors only.
2.3 Intended use
Safe operation is only guaranteed when using the device for its intended purpose.
Any technical interventions, as well as assembly and maintenance are to be made by a
qualified customer service only.
The Mini display fridge is designed for cooling beverages in bottles and cans.
Do not use the Mini display fridge for:
-storing flammable or explosive materials such as ether, oil and glue;
-storing pharmaceutical products or blood.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the device
is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use are
impossible.
The operator is liable for all damages resulting from inappropriate use.

- 22 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately after
receipt.
In case of visible damage do not accept or accept the delivery with reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in your
country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-Do not store outdoors.
-Keep it dry and dust-free.
-Do not expose it to aggressive media.
-Do not expose it to direct sunlight.
-Avoid mechanical shocks and vibration.
-In case of longer storage (> 3 months) make sure you
check the state of the packaging and the parts regularly.
If required refresh or renew.

- 23 -
4. Technical data
4.1 Overview of parts
①
Glass door
②
Digital temperature regulator
③
Casing
④
Removable shelf
⑤
LED lighting
⑥
Removable drip tray
⑥
①
② ③
④
⑤

- 24 -
4.2 Technical specification
Name Slim-Line 80L Mini display fridge
Article no.
700.180G
Capacity: 80 litres
Coolant: R600a
Temperature range: approx. 2°C – 10°C
Power: 230 V ~ 50 Hz 160 W
Energy safety class: I
Device dimensions : W 375 x D 385 x H 1050 mm
Adjustable shelf dimensions: W 315 x D 325 mm
Weight: 36.2 kg
Equipment: 3 adjustable shelves
We reserve the right to make technical changes!
5. Installation and operation
5.1 Safety instructions
WARNING! Electrical hazard!
The device must only be connected to a properly installed single socket with
protective contact.
Never yank cord to disconnect from outlet.
Cable must not touch any hot parts.
•See that the cable does not touch any heat sources or sharp edges. Do not let the
cable dangle over the counter edge.
•Do not use the device in case it does not function properly, has been damaged or
dropped.
•Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the device
or personal injury, and further, the warranty expires.
•Do not lay the cable over carpets or heat insulations. Do not cover the cable. Keep
away the cable from operating range and do not dunk it into water.
•Do not move or tilt the device when in operation.

- 25 -
WARNING! Hazard via electrical current!
The device can cause injuries due to improper installation!
Before installation the local power grid specification should be compared with
that of the device (see type label).
Connect the device only in case of compliance!
Take note of the security advice!
5.2 Installation and connection
•Discard the complete packing material after unpacking the device.
•Place the device on top of an even and safe surface which supports the weight of the
device.
•Not at any time should you place the device on an inflammable surface.
•Do not place the device in the vicinity of open sources of fire, electric cookers,
furnaces or other sources of heat such as e.g., in places exposed to direct sunlight.
The heat can damage the surface of the device, as well as have a negative effect on
the cooling power and increase the consumption of energy.
•To avoid damage to the compressor, do not tilt the device to an angle greater than 45°
during setup or transport. Be careful when touching the condenser and doors, as
damage to them will negatively impact the working of the device.
•Place the device in such a manner that there is a minimum of 10 cm between it and
other objects, including walls, in order to ensure proper air circulation.
•Do not place the device where humidity or temperature are high as the device may
be damaged.
•Before the first use the device should stand for at least 2 hours before it is connected
to the power source.
•Do not drill holes in the device nor mount other objects to it.
•The electrical circuit in the socket must be secured to at least 16A. Only connect the
device directly to the wall socket; do not use any extension cords or power strips.
•Place the device so that the plug is easily accessible and can be quickly removed
from its socket in case of necessity.

- 26 -
5.3 Operating
Preparation
•Clean the device and equipment prior to first use (see 6.2 Cleaning).
•After cleaning, insert the shelves at heights appropriate for the bottles or cans with
beverages that will be cooled in the device. To do so, mount the guides at the
desired height and place the removable shelves on them.
•Connect the device to a single, grounded outlet.
•Beverages in bottles or cans can only be placed inside when the device has reached
the appropriate cooling strength.
Digital temperature regulator
•The digital temperature regulator is located at the front of the device, on the left side.
① Lower temperature button
② Raise temperature button
③ LCD compressor control light (cooling)
④ LCD defrost control light
⑤ Lighting button
⑥ Settings button
⑦ Display
⑦
⑥
①
②
③ ④
⑤

- 27 -
•The primary temperature is pre-set at the factory, and is set to ensure a working
temperature range of approx. 2°-10°C.
•To change temperature settings, proceed as follows:
Press to display the current temperature.
Press or to adjust the temperature.
Press to complete setup and display the internal temperature.
If no button is pressed within the next 10 seconds, the internal temperature will
appear on the digital regulator display.
NOTE!
To make further adjustments or changes to parameters, contact a sales agent or
assign the work to a qualified service technician.
Lighting
•The device is equipped with 2 LED lights. They are located at the front of the door
frame, in the centre of the device.
•Press „ “ for one second to turn the device’s lighting on. By pressing „ “ a
second time, the lighting will be turned off.
LED control lights
LED compressor control light (cooling):
The control light comes on during cooling, goes off when the temperature inside
the chamber is stable, and flashes when there is a delay in activating the cooling.
LED defrost control light:
The control light comes on during defrost, goes off when defrost is completed, and
flashes when there is a delay in the defrost process.
Automatic defrost
The device automatically defrosts 4 times every 24 hours.

- 28 -
Manual defrost
If cooling power decreases, manual defrost must be performed. To begin manual defrost,
press „ “ and hold for 6 seconds. The LED control light „ “ will come on.
NOTE!
To change other settings or parameters, information on doing so is contained in
the attached documentation of temperature control. Such changes can also be
performed by a qualified technician.
Tips for the user
•To reduce loss of cold, keep the door open for as short of a time as possible. The
door should also not be opened more often than is necessary.
•Do not block the display fridge’s air ducts. Air circulation is necessary for the device
to function properly.
•Beverages stored in the display fridge must be kept an appropriate distance apart from
other beverages. If stored too closely together, they will not cool as effectively.
•Regularly empty the drip tray. It is located at the front of the device, under the glass
door.
•Do not open the door during a sudden power outage, to avoid loss of cold.
•After an interruption in the power supply or after removing the plug from its socket,
do not connect the Mini display fridge to a power source for at least 5 minutes.
6. Cleaning and maintenance
6.1 Safety advice
oBefore beginning with repair or cleaning works make sure the device has been
disconnected from power socket (pull the power plug!!!) and has cooled down.
oDo not use any acid agents and make sure no water ingresses the device.
oTo protect yourself from electric shock, never immerse the device, its cables and the
plug in water or other liquids.
CAUTION!
The device is not suited for direct washing via water jets. Therefore, you must not
use any kind of pressure water jet for cleaning the device!

- 29 -
6.2 Cleaning
oClean the display fridge regularly.
oRemove the shelves and wash them with a gentle cleaning agent and soft cloth.
oWash the inside and outside of the display fridge with warm water, a moist cloth and
gentle cleaning agent. Wipe down with clean water.
oNever use aggressive cleaning substances, such as those containing alcohol or
solvents that may damage plastic parts and/or paint.
o Use only soft cloths, never use sharp cleaning tools that may damage the device’s
surface.
oAfter cleaning, use a soft, dry cloth to dry and polish the device.
If the Mini display fridge is to remain unused for a longer period of time:
oremove the plug from its socket;
oremove all beverages from inside the Mini display fridge;
owash the inside and outside of display fridge. Remove water and traces of mold;
oleave the door open until the Mini display fridge is completely dry.
6.3 Safety instructions for maintenance
oCheck the mains connection cable for damage from time to time. Never operate the
device when the cable is damaged. A damaged cable must immediately be replaced
by customer service or a qualified electrician to avoid dangers.
oIn case of damage or malfunction, please contact your stockist or our customer
service centre. Pay attention to the troubleshooting tips in pt. 7.
oOnly a qualified technician and using original spare parts and accessories should
carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.

- 30 -
7. Possible Malfunctions
Problem Cause Solution
Device not
cooling
•Plug not in socket.
•Damaged fuse.
•Power outage.
•Insert the plug into the
socket.
•Check the power supply.
•Check the power supply.
Device is not
providing
enough cooling
power
•Direct sunlight or heat
source nearby.
•Poor air circulation around
device.
•Door not closed fully or left
open for too long.
•Seals around door damaged
or deformed.
•Space between bottles and
cans is too small, or there
are too many bottles and
cans in the device.
•Move the device away from
heat sources.
•Ensure proper distance from
walls and/or other objects.
•Close door fully, keep door
open for as short a time as
possible.
•Contact a sales agent.
•Ensure sufficient space
between bottles and cans in
the device, remove
unneeded objects.
The device is too
loud
•The device is not on a level
surface.
•The device is touching a wall
or other objects.
•Place the device on a level
surface.
•Ensure sufficient distance
between the device and
walls or other objects.
The compressor
does not turn on
automatically
•The device is overfilled.
•The door has been left open
too long.
•Remove unneeded objects.
•Keep door open for as short
a time as possible.
The above described problem cases are given for orientation and as examples.
Should these or similar problems occur, please turn off the machine immediately
and don´t use it anymore. In order to check and repair your machine, please contact
a qualified expert or the manufacturer immediately.

- 31 -
The following events are not indicators of malfunction:
1. The sound of running water. This is normal when the device is functioning properly.
It is coolant flowing through the cooling system.
2. Condensation forming on the glass side walls during periods of high humidity is
normal. Wipe with a dry cloth.
8. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make the waste device unfit for
use before disposal. For that purpose disconnect device from mains supply and
remove mains connection cable from the device.
NOTE!
For the disposal of the device please consider and act
according to the national and local rules and
regulations.
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
