Bastl Instruments Noise Square User manual

noise and square source
S
W
I
T
C
HD
I
G
I
T
A
L
M
E
T
A
L
I
C
S
Q
U
A
R
E
CV CV SQUARE
SQUARE
METALIC
WHITE PINK
DIGITAL
COW
(NOISE)²

Simple square wave oscillator tuning by knob and CV

two square wave oscillators with a fixed frequency ratio
suitable for making cowbell sounds - tuning CV input
isshared with the square wave

CV input for square wave and cow generator
(0-10V range)

6 square wave oscillators summed through an analog
circuit with frequency ratios inspired by the 808 (can
be used as base for synthesizing hats and cymbals)
tuneable with a knob and CV
Noise suare is a simle noises and suarewave enerator.
There are two analo noise enerators, WHITE noise
and PINK noise. All other sound sources are enerated
diitall. There is also a METALIC noise source, which is
a 6 oscillator sound bank, with freuenc ratios insired
b the 808. It is enerated diitall but with analo
summin and has a TUNE and CV control otion. The
DIGITAL noise outut enerates diital noise which has
adustable TUNE and CV control. The SQUARE and COW
oututs have one suare wave sinal in common and the
COW outut has another suare sinal added at a secific
freuenc, to et the cowbell sound easil. There are 2
CV inuts for controllin the diital sound sources. For
the first CV inut there is a switch to select whether it
controls the METALIC noise or DIGITAL noise tunin. The
second CV inut is dedicated to both the SQUARE and
COW oututs. The CV inuts react to a rane of 0-10V.
instruction













digital noise generator with adjustable sample rate
viaa knob and CV

The CV input switch either sends the incoming CV
tothe digital or metalic noise generator (0-10V range)

analog white noise generator

analog pink noise generator

FTDi breakout
the Noise square firmware is open source and open for
hacking. It can be done with the Arduino programming
environment. All you need is a FTDi USB connector
breakout (or an equivalent Arduino compatible
substitute).
Noise Suare
MULTI NOISE
& SQUARE SIGNAL GENERATOR

 2 analog noise generators: WHITE and PINK
 4 digital signal sources
 SQUARE is a simple square wave signal
 COW is composed of the SQUARE signal plus an
additional square wave at a special frequency to
compose the base of a cowbell sound
 METALIC are 6 square wave oscillators, summed
through an analog circuit with frequency ratios
inspired by the 808 (it can be used as base for
synthesizing hats and cymbals)
 DIGITAL is a digital noise source with a tuning
option
 digital signals with multiple square components
are summed using analog circuits
 tune controls for METALIC, DIGITAL and SQUARE
(applies also to COW)
 common CV input for SQUARE and COW signals
 another CV input with a switch to select
whether it affects METALIC or DIGITAL
 CV input range: 0-10V
 handmade in Brno, Czech republic
 breakout for FTDi USB adaptor for hacking the
opensource firmware (see github)
technical details
features
 5HP width
 35mm deep (skiff friendly)
 current +12: <15mA, -12: <15mA, +5:<20mA
 PTC fuse and diode protected 16 pin power connector
 requires 5V in bus board
Before connectin the ribbon cable to this module
disconnect our sstem from ower !
Double check the olarit of the ribbon cable and
that it is not shifted in an direction. the red cable
should match the -12V rail both on the module and
on the bus board !
lease make sure of the followin
 you have a standard pinout eurorack bus board
 you have +5V, +12V and -12V rails on that bus board
 the power rails are not overloaded by current
Although we put protection circuits in the device,
we do not take any responsibility for damages
caused by wrong power supply connection.
After you connected everything, double-checked
it and closed your system, so no power lines can
be touched by hand, turn on your system and test
the module.
!
Connectin module to our sstem
Take it Carefull
P C B
+12
+5
red
GND
noise square v1.0 btm
-12
