Bauhn AFST-815 User manual

INSTRUCTION MANUAL
Model Number: AFST-815
Turntable with Cassette Deck
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
*Vinyl not included

21300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Warranty Details 3
Welcome 4
General Safety Instructions 5
Parts List 8
Getting Started 11
Instructions 12
FAQs 25
Technical Specifications 27
Repair and Refurbished Goods or Parts Notice 28
Contents

3
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts
for a period of 12 months from the date of purchase. Defects that occur within
this warranty period, under normal use and care, will be repaired, replaced or
refunded at our discretion, solely at our option with no charge for parts and
labour. The benefits conferred by this warranty are in addition to all rights
and remedies in respect of the product that the consumer has under the
Competition and Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and to compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
Turntable with Cassette Deck

41300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Welcome
Congratulations on choosing to buy a BAUHN®product.
All products brought to you by BAUHN®are manufactured to the
highest standards of performance and safety and, as part of our
philosophy of customer service and satisfaction, are backed by our
comprehensive 1 Year Warranty. We hope you will enjoy using your
purchase for many years to come.

5
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
General Safety Instructions
Read this manual thoroughly before first use and keep it in a safe place
for future reference, along with the completed warranty card, purchase
receipt and carton. The safety precautions enclosed herein reduce the
risk of fire, electric shock and injury when correctly adhered to.
Follow all instructions and take notice of all warnings to reduce
the risk of re or electric shock.
DANGER! CAUTION!
This symbol alerts you that there is dangerous voltage inside.
To prevent electric shock, do not open the enclosure.
IMPORTANT!
This symbol alerts you to read and observe important warnings
and instructions on the unit or in this manual.
Electrical safety and cord handling
• To prevent contact with high voltage
components inside, do not attempt to open
the equipment.
• Before installing this equipment, make sure
your outlet voltage corresponds to the voltage
stated on the appliance rating label.
• When connecting the equipment, align the
plug properly and insert it fully to prevent electric shock.
• Only use this equipment with the cord and plug supplied, and do not
overload the power outlet.
• If the power cord is damaged, do not use the equipment. The
cord must be replaced by the manufacturer or similarly qualified
personnel in order to avoid a hazard. Contact the after sales support
line for advice.
CAUTION: To reduce the risk of fire or electric shock, do not expose
this equipment, the cord or plug to rain or moisture; do not use it
anywhere near water or where water splashes or drips; do not touch
the plug with wet hands. In the event that water or other liquids enter
the device, unplug it immediately and clean and dry it as best as
possible. Then have it checked for damage by a qualified technician,
or contact the after sales support line.

61300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
• Do not repair the unit yourself. Only have it serviced by qualified
personnel. Contact the after sales support line for advice.
• Unplug the unit from the power outlet after use to avoid possible
damage during electrical storms, or when the equipment will be
unattended or unused for a long period of time.
• Do not let the cord hang over the edge of a table or counter, or touch
any hot surface. Do not allow anything to rest on or roll over the
power cord, and run any cords so that no one steps on or trips over
them.
• Do not run the cord near heat-producing appliances such as
radiators, stoves or irons. Excessive heat could melt insulation and
expose live wires.
• Always grasp the plug, not the cord, when disconnecting the unit.
Pulling the cord can damage the internal wires and may cause a fire.
• Do not install the unit in an inclined position. It is designed to be
operated in a horizontal position only.
Installation
• When installing the unit, make sure to place it:
• Away from heat sources, radiators or other products that produce
heat.
• Away from areas with high temperatures, high humidity or direct
sunlight.
• Away from excess dirt and dust.
• Away from open windows and any place where water may get into
the unit and damage it.
• Make sure there is free circulation of air around the unit. Do not place
it on a thick carpet, bed or any place where ventilation holes are
obstructed. Leave at least 10cm clearance around the unit.
• Make sure the mains socket is readily accessible at all times.
Usage conditions and restrictions
• Openings on the cabinet are provided for ventilation and to protect
the unit from overheating. To ensure proper operation, do not cover
General Safety Instructions (Cont.)

7
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
them with things such as newspapers, tablecloths, curtains etc.
• Do not place heavy objects on top of the equipment or step on it.
• Do not place objects filled with water (such as vases) or any naked
flame sources (such as lit candles, incense sticks or cigarettes) on
top of the unit.
• The equipment is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the equipment by a
person responsible for their safety.
• Young children should be supervised to ensure they do not play
with the equipment. Close supervision is always necessary when an
appliance is used by or near children.
• Unplug the unit from the power outlet before cleaning. Clean the unit
only with a dry, clean cloth. Do not use liquid or aerosol cleaners.
• We assume no liability for any damage caused by noncompliance with
these instructions or any other improper use or mishandling of the
equipment.
Condensation
The unit may suffer from condensation in the following situations:
• When you take the unit directly from a cold to a warm place, and vice
versa.
• When you use the unit in a room where you just turned on a heater, or
where cold air from an air conditioner is directed on to the unit.
• When you use the unit in hot and humid surrounds just after having
moved it from an air conditioned room.
• When the room is steamy or damp.
• If condensation exists, the unit will not operate properly. Remove
the disc, plug the power cord into the wall socket, turn on the unit
and leave it for two to three hours. After that time, the unit will have
warmed up and any moisture will have evaporated. Keeping the
unit connected to the wall socket will keep moisture condensation
problems to a minimum.
General Safety Instructions (Cont.)

81300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Parts List
Front and Side View
Top View
4
5
7
6
910
11
12
1314 15
16
17
18 19
21
20
23 24 25
26
27
28
29
30
8
2
1
3
22

9
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Parts List (Cont.)
1. Display Panel
2. Stop: Stop playback in CD/USB/SD modes;stop recording.
USB/SD: Switch to USB or SD card modes.
3. Record/Delete
4. Repeat/Program
5. Speakers (Stereo)
6. Function Knob: Rotate the knob to select PHONO, CD, AUX, or
RADIO.
7. Power
8. Compact Disc Tray
9. Band: Select AM/FM in RADIO mode.
10. Tuning Knob: Tune to a radio station in RADIO mode.
11. Earphone Jack
12. 3.5mm AUX-IN Jack
13. Volume Knob
14. OPEN/CLOSE CD Tray
15. : Press to select previous track or press and hold to fast
reverse.
16. : Press to select next track or press and hold to fast forward in
CD/USB/SD modes.
17. Play/Pause: Play/Pause playback in CD mode. The Play Indicator
illuminates during playback of a CD.
18. USB Port
19. SD Card Slot
20. Tape Operation Button: Eject/Fast Forward cassette.
21. Cassette Tray
22. Dust Cover
23. Turntable
24. 45 RMP Adapter
25. Tone Arm
26. Cue-Lever: Use this lever to lift the tone arm.
27. Auto Switch
28. Speed Selector
29. Tone Arm Lock
30. Cartridge with Stylus

10 1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
31. FM Antenna
32. LINE-OUT Sockets
33. Power Cord
Parts List (Cont.)
Back View
31
32
33

11
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Getting Started
Before First Use
• The unit may become hot during operation. Always leave sufficient
space around the unit for ventilation.
• The voltage supplied to the unit should match the voltage that is
printed on the back panel. If you have any doubts concerning this
matter, consult an electrician.
• Avoid placing the unit in direct sunlight or close to any sources of
heat. Also avoid locations subject to vibrations and excessive dust,
heat, cold or moisture.
• Do not place the unit on an amplifier or receiver.
• Do not open the cabinet as this might result in damage to the
circuits or an electric shock. If a foreign object gets into the unit,
contact your dealer or service company.
• When removing the power plug from the wall outlet, always pull
directly on the plug. Do not pull on the cord.
• To keep the laser pickup clean, do not touch it and always close
the disc tray.
• Do not clean the unit with chemical solvents as this may damage
the finish. Use a clean, dry cloth.
• Keep this manual in a safe place for future reference.
Moving the Unit
• During playback, the disc rotates at high speeds. Do not move or
lift the unit during playback as this may damage the unit and the
disc.
• When moving the unit to a different location or packing the unit
away, be sure to remove the record or disc. Moving the unit with a
disc or record inside may cause damage to the unit.

12 1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Instructions
Compact Discs
• This Turntable is compatible with conventional audio CD’s and
properly finalised CD-R and CD-RW discs.
• Always place the disc in the disc tray with the label side facing up.
(Compact discs can be played or recorded on one side only.)
• To remove the disc from its storage case, press down on the centre
of the case and lift the disc out, holding it carefully by the edges.
Should the disc become dirty, wipe the surface in a circular motion
from the centre hole outwards with a soft, dry cloth.
• Never use chemicals such as record sprays, antistatic sprays or
fluid, benzine or thinner to clean the disc. Such chemicals will do
irreparable damage to the discs plastic surface.
• Place the disc back in its case after use to avoid dust and scratches.
• Do not expose discs to direct sunlight or high temperatures for
extended periods of time. Long exposure to high temperatures will
warp the disc.
• Playing warped discs may damage the unit.
• Printable discs are not recommended for use with this unit as the
label side may be sticky and damage the unit.
• Do not use protective coating spray on the discs.
• Do not write on discs with ball point or hard tipped pens. Only use
oil-based felt tipped pens.
• Do not use stabilisers. Using commercially available CD stabilisers
may cause damage to this unit.
• Do not use CD’s with an irregular
shape as they may damage the
unit.

13
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
• If you have any doubts about the care and handling of a disc, read
the precautions supplied with the disc, or contact the manufacturer
directly.
Cassette Tapes
• Metal and Chrome (cobalt) tapes have identification holes.
Tape Handling
• Use your finger or a pencil to turn the
cassette tape’s hub and take up any slack
tape.
• Avoid touching the tape. Finger prints
attract dust and dirt.
• Avoid dropping or subjecting cassettes to excessive shock or
force.
• Do not use C-120 tapes as they are physically weak and could
become tangled in the transport mechanism.
Storage
• Do not store tapes on top of heaters, in direct sunlight or in high
temperatures/humidity.
• Do not store tapes on TV sets or amplifiers or in areas with a
strong magnetic field.
• Keep tapes away from excessively dusty and dirty places.
Head Maintenance
The head and tape path should be cleaned and demagnetised on a
regular basis. Use cassette tape head cleaner and demagnitiser. For
special details on the proper use of these items, read each item’s
instruction manual.
Vinyl Records
• Do not touch the records grooves. Only
handle records by their edges or the label.
Ensure that your hands are clean, as skin
oil will gradually deteriorate the record.
• Keep your records away from dust and
store in a dry, cool place.
Instructions (Cont.)

14 1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Instructions (Cont.)
• Keep your records in sleeves when not in use to avoid dust and
scratches.
• Store records upright. Records stored horizontally will bend and
warp.
• Do not store records in the trunk of a car.
• Store records in an area with a stable
temperature and low humidity.
• To clean, gently wipe the surface in a
circular motion using a soft anti-static
cloth.
Replacing the Stylus
It is recommended that the stylus is replaced as soon as you notice a
change in the sound quality. Prolonged use of a worn-out stylus may
damage the record. Wear and tear on the stylus will be accelerated
when playing 78 RPM records.
Caution
• Do not bend the stylus.
• To avoid injury, do not touch the needle.
• Turn off the unit’s power before you replace the stylus.
• Keep out of reach of children.
• Handle with care as the stylus is delicate. Use of a bent or broken
stylus may damage the record and cause malfunction.
• Do not expose the stylus to extreme heat.
• Contact a qualified repair person if you are having difficulties
changing the stylus.
Removing an Old Stylus
• Set a flathead screwdriver at the
tip of the stylus and push down
to the direction “A”.
• Pull the stylus out towards
direction “B”.

15
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Installing a New Stylus
• Hold the tip of the stylus
and insert the other edge by
pressing towards direction “C”.
• Push the stylus up towards
direction “D” until it locks at the
tip.
Connections
FM Antenna
While in FM mode, tune in to an FM station and extend the antenna to
find a position that provides the best reception. The antenna may need
to be repositioned if you move the unit to a new location.
AC Power Cord
Plug the AC power cord into an AC wall socket.
How to Open/Close the
Turntable Cover
To Open:
• Lift the Turntable cover all the
way up until it stops.
• Lower the cover slowly until the
latch engages. If the latch does
not engage, pull the lower bar
by hand.
• The cover will now stay open.
To Close
• Lift the cover all the way up until it stops.
• The latch should disengage. Slowly lower the cover. If the latch
does not disengage, push out the lower bar by hand.
• Make sure you hold the cover carefully to avoid pinching your
fingers as it closes.
Instructions (Cont.)

16 1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Instructions (Cont.)
Playing a Record
Important: To avoid stylus damage, make sure the included stylus guard
is in place whenever the turntable is being installed, moved and cleaned.
• Turn On the unit and adjust the volume to an appropriate level.
• Turn the Function knob to the PHONO position.
• Place a record on the turntable platter and select the
correct player speed: 33 1/3, 45, 78 RPM according
to the vinyl being played. When playing a 45 RPM
record, use the included 45 adaptor.
• Set the auto/manual stop control: Set the Auto
Stop switch to ON if you are playing a 33
RPM record and you want the turntable to
stop turning when the record is finished. If
the switch is set to OFF, the turntable will
continue turning.
• Remove the stylus guard and unlock the
Tone Arm lock.
• Push the Lift Lever up to raise the Tone
Arm and then gently move the Tone Arm
to the desired position over the record.
The platter will begin to spin
when the Tone Arm is moved
toward the record. Push the
Lift Lever forward to lower
the Tone Arm slowly onto
the desired position on the
record. The record will begin

17
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Instructions (Cont.)
playing.
• If the auto switch is turned to ON, the record will stop playing
automatically. If it is set to OFF, the record will not stop
automatically.
• When the record is finished, push the Lift Lever backwards to raise
the Tone Arm and gently move it back to its rest position.
• When you have finished playing records, engage the Tone Arm
lock to protect it from accidental movement. Turn the Power knob
to switch the unit OFF. Unplug it from the power supply if it is not
going to be used for a while.
NOTE: Should your record stop before the last track finishes, set the
Auto Stop switch to OFF. Your record will now play to the end, but you
will have to stop the turntable rotation manually.

18 1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Instructions (Cont.)
Playing a Cassette
• Turn ON the unit and adjust the volume to an appropriate level.
• Turn the Function knob to AUX and the display will show “tP”
• Insert a pre-recorded tape into the cassette
slot with the tape side to the right. By pushing
slightly, the tape will slide into place and begin
playing automatically.
NOTE: One end of the tape will remain visible.
• To fast forward the cassette tape, press the
Tape Operations button halfway down while
the cassette is playing.
• To resume normal playback, release the Tape
Operations button.
• To stop playback, press the Tape Operations
button completely. Playback will be stopped
and the cassette will be ejected.

19
1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
Playing a CD
• Turn the unit ON by pressing the Power button.
• Set the Function knob (PHONO/CD/AUX/
RADIO) to CD.
• “- -” will blink for a few seconds. When no
disc is loaded “no” will appear on the display
screen.
• Place a disc on the tray with the printed label
facing up.
• Do not place more than one disc in the tray
at a time.
• The disc must be placed in the centre of the
disc tray. If the disc is not properly inserted,
it may not be possible to get the disc out once it has closed.
• Do not force the tray by hand when it is opening and closing.
• Press the OPEN/CLOSE button ( ) to close the tray. The total
number of tracks will appear on the display screen.
• The system will start playback automatically after several seconds,
or press the PLAY/PAUSE button ( ) to start playback.
• Disc playback starts from the first track, and the PLAY indicator
will illuminate.
• During playback, the number of the track playing will display
on the screen.
• Turn the Volume knob to adjust the volume.
To Suspend Playback Temporarily
• Press the PLAY/PAUSE button ( ) during playback. Playback will
stop at the current position and the track number will blink on the
display screen.
• To resume playback, press the PLAY/PAUSE button ( ) again.
• Press the STOP button ( ) to stop playback.
Instructions (Cont.)

20 1300 886 649 Model: AFST-815 Product Code: 51109 08/2015
www.tempo.org
AUS
To Skip to the Next or Previous Track
• During playback, repeatedly press the NEXT/PREVIOUS buttons
( / ) until the desired track is found. The selected track will
play from the beginning.
• In STOP mode, press the NEXT/PREVIOUS buttons ( / )
repeatedly until the desired track is found. Press the PLAY/PAUSE
button ( ) within 5 seconds to start playback from the selected
track.
• When the PREVIOUS ( ) button is pressed during playback, the
track being played will restart from the beginning. To return to the
beginning of the previous track, press the PREVIOUS button ( )
twice.
Search for Part of a Track
• During playback, hold down the NEXT or PREVIOUS buttons
( / ), then release when the desired section is found.
Repeat Function
• During playback, press the REPEAT button once to repeat a single
track. The ‘REP’ LED indicator light will blink.
• During playback, press the REPEAT button one more time to
repeat all tracks. The ‘REP’ LED indicator light will stay lit.
Program Function
• In STOP mode, press the PROGRAM button. The display will show
“01”.
• Press ( / ) to select a track and press the PROGRAM button
again to save the track.
• Press ( / ) to select another track and press the PROGRAM
button again. Repeat this step to continue saving tracks.
• To play back the programed tracks, press the PLAY/PAUSE ( )
button.
• To erase the programed track, press the STOP ( ) button twice.
Instructions (Cont.)
