Bauhn ARTTSC-1117 User manual

INSTRUCTION MANUAL
1300 886 649
www.tempo.org
AUS
*Accessories not included.
Model Number: ARTTSC-1117
Retro Briefcase Turntable
Model: ARTTSC-1117 Product Code: 55688 11/2017

2
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Warranty Details 3
Welcome 4
General Safety Instructions 5
Parts List 7
Getting Started 9
Instructions 10
FAQs 14
Technical Specifications 15
Repair and Refurbished Goods or Parts Notice 16
Contents

3
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts
for a period of 12 months from the date of purchase. Defects that occur within
this warranty period, under normal use and care, will be repaired, replaced or
refunded at our discretion, solely at our option with no charge for parts and
labour. The benefits conferred by this warranty are in addition to all rights
and remedies in respect of the product that the consumer has under the
Competition and Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and to compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
Retro Briefcase Turntable

4
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Welcome
Congratulations on choosing to buy a BAUHN®product.
All products brought to you by BAUHN®are manufactured to the
highest standards of performance and safety and, as part of our
philosophy of customer service and satisfaction, are backed by our
comprehensive 1 Year Warranty.
We hope you will enjoy using your purchase for many years to come.

5
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
General Safety Instructions
Read this manual thoroughly before first use and keep it in a safe place
for future reference, along with the completed warranty card, purchase
receipt and carton. The safety precautions enclosed herein reduce the
risk of fire, electric shock and injury when correctly adhered to.
Follow all instructions and take notice of all warnings to reduce
the risk of re or electric shock.
DANGER! CAUTION!
This symbol alerts you that there is dangerous voltage inside.
To prevent electric shock, do not open the enclosure.
IMPORTANT!
This symbol alerts you to read and observe important warnings
and instructions on the unit or in this manual.
Electrical safety and cord handling
• To prevent contact with high voltage components
inside, do not attempt to open the equipment.
• Before installing this equipment, make sure your
outlet voltage corresponds to the voltage stated on
the appliance rating label.
• When connecting the equipment, align the plug
properly and insert it fully to prevent electric shock.
• Only use this equipment with the cord and plug supplied, and do not overload
the power outlet.
• If the power cord is damaged, do not use the equipment. The cord must be
replaced by the manufacturer or similarly qualified personnel in order to avoid a
hazard. Contact the after sales support line for advice.
CAUTION: To reduce the risk of fire or electric shock, do not expose this
equipment, the cord or plug to rain or moisture; do not use it anywhere near water
or where water splashes or drips; do not touch the plug with wet hands. In the
event that water or other liquids enter the device, unplug it immediately and clean
and dry it as best as possible. Then have it checked for damage by a qualified
technician, or contact the after sales support line.
• Do not repair the unit yourself. Only have it serviced by qualified personnel.
Contact the after sales support line for advice.
• Unplug the unit from the power outlet after use to avoid possible damage
during electrical storms, or when the equipment will be unattended or unused
for a long period of time.

6
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
• Do not let the cord hang over the edge of a table or counter, or touch any hot
surface. Do not allow anything to rest on or roll over the power cord, and run
any cords so that no one steps on or trips over them.
• Do not run the cord near heat-producing appliances such as radiators, stoves
or irons. Excessive heat could melt insulation and expose live wires.
• Always grasp the plug, not the cord, when disconnecting the unit. Pulling the
cord can damage the internal wires and may cause a fire.
• Do not install the unit in an inclined position. It is designed to be operated in a
horizontal position only.
Installation
• When installing the unit, make sure to place it:
• Away from heat sources, radiators or other products that produce heat.
• Away from areas with high temperatures, high humidity or direct sunlight.
• Away from excess dirt and dust.
• Away from open windows and any place where water may get into the unit.
• Make sure there is free circulation of air around the unit. Do not place it on a
thick carpet, bed or any place where ventilation holes are obstructed.
• Make sure the mains socket is readily accessible at all times.
Usage conditions and restrictions
• Openings on the case are provided for ventilation and to protect the unit from
overheating. To ensure proper operation, do not cover them with things such as
newspapers, tablecloths, curtains etc.
• Do not place heavy objects on top of the equipment or step on it.
• Do not place objects filled with water (such as vases) or any naked flame
sources (such as lit candles, incense sticks or cigarettes) on top of the unit.
• The equipment is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the equipment by a person responsible for their safety.
• Young children should be supervised to ensure they do not play with the
equipment. Close supervision is always necessary when an appliance is used
by or near children.
• Unplug the unit from the power outlet before cleaning. Clean the unit only with a
dry, clean cloth. Do not use liquid or aerosol cleaners.
• We assume no liability for any damage caused by noncompliance with these
instructions or any other improper use or mishandling of the equipment.
General Safety Instructions (Cont.)

7
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Parts List
Front and Side View
7
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Parts List
1 Latch
2 Dust cover
3 Cue Lever
4 Power light
5 Power / Volume switch
6
Control buttons
7 Micro SD card slot
Power input 5V 1.5A
LINE OUT port
Front and Side View
1
2
4
11
14
13
15 16
12
65
887
9
3
10
8
USB Port
AUX OUT port
9
10
Speaker
11
Tone arm
12
Cartridge
13
Handle
14
15
16
Turntable plate
1. Latch
2. Dust Cover
3. Cue Lever
4. Power Light
5. Power / Volume Switch
6. Tone Arm
7. Cartridge
8. Speaker
9. Handle
10.Turntable Plate
11.Control Buttons
12.USB Port
13.AUX OUT Port
14.Micro SD (TF) Card Slot
15.Power Input 5V 1.5A
16.LINE OUT Port

8
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Getting Started/Instructions
Initial Set-Up
AC Power
Ensure that the mains voltage of your home corresponds to the operating
voltage of the adapter.
• Connect the Power adapter to the wall outlet.
• Connect the DC connector to the “DC IN” jack on the rear of the unit.
Playing a Record
• Place a record on the turntable. If required, place the 45 RPM adaptor
on the record spindle.
• Choose the desired playing speed (33, 45 or 78 rpm) by using the
speed selection switch.
• Turn on the rotary power switch (note that this also controls volume).
• Release the tone arm lock.
• Raise the arm using the cue lever and move the arm away from its
holder. This will prompt the turntable to start spinning automatically.
• Use the cue lever to slowly place the stylus down onto the record’s
groove.
• If the AUTO STOP switch is set to ON, the record will stop
automatically. If it is set to OFF, the record will not stop automatically.
NOTE: If your record stops before the last track finishes, set the AUTO
STOP switch to OFF. Your record will now play to the end, but you will
have to stop the turntable rotation manually.
Auto Stop
• When a record finishes playing, the turntable plate can be set to stop
turning automatically. This function controlled by the auto-stop ON/
OFF switch.
• Set the auto-stop switch to ON so that the turntable plate
automatically stops turning.
• Raise the tone arm and put it on the rest when finished.
• Replace the protective cap on the stylus/needle and close the tone
arm lock.

9
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Instructions
USB/SD Player
You can play digital music from a USB stick or Micro SD Card through the
Retro Turntable Briefcase.
• When the power is on and you insert a USB stick or Micro SD card,
the music will automatically begin to play.
NOTE: The Retro Briefcase Turntable will not stop playing the vinyl when
a USB disk is inserted, so you will need to stop the turntable manually.
USB/SD Recording
1. Play the vinyl track that you wish to record.
2. Insert a USB stick or SD card.
NOTE: If both a USB stick and an SD card are inserted, the recording
will be saved to the USB stick by default.
3. Press and hold the MODE/REC button for 3 seconds until you hear
a short beep sound - this indicates that recording has begun. Each
recording operation is created as one mp3 file - individual songs are
not separated.
4. When you want to stop recording, press the PLAY/PAUSE button.
Recording will stop and playback of the recorded file will start.
5. Manually stop the vinyl by placing the tone arm back onto the tone
arm rest.
Amplier Connection (if required)
You can listen to your Retro Briefcase Turntable using the built-in
speakers, or you may wish to connect it to your existing Hi-Fi system.
Connect the “LINE OUT” RCA ports to the “LINE IN” port on your mixer or
amplifier using an RCA cable (not supplied).
• Red plug into the Right Channel Input.
• White plug into Left Channel Input.

10
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Instructions (Cont.)
Maintanence
Replacing the stylus
Push the arm lock to release the tone
arm.
Take off the cap of the cartridge to
expose the needle.
Separate the cartridge from the cartridge
holder by loosening the locker.
Gently pull the audio-lines from the
cartridge, taking care to pull from the
terminal connector and not the wire
itself.
1
2
3
4

11
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Instructions (Cont.)
Carefully insert the audio line connector
to the new cartridge.
Carefully slide the cartridge into the
cartridge holder.
Make sure the audio-lines are not
touching each other.
Gently clip the cartridge into the
cartridge holder.
NOTE: Please exercise care whilst performing this operation so as to
avoid the tone arm and audio wires from any damage.
Installing a new stylus cartridge
Refer to the figures 5-8
5
6
8
7

12
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Transporting
When transporting your record player do not forget to:
• Replace the protective cap on the stylus.
• Secure the tone arm lock around the tone arm.
Cleaning
We advise you to clean your records with an anti-static cloth to gain
maximum enjoyment from them and to make them last.
We would also point out that for the same reason your stylus should
be replaced periodically (approximately every 250 hours.)
Dust the stylus from time to time using a very soft brush dipped in
alcohol (brushing from back to front of the cartridge.)
Instructions (Cont.)

13
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
FAQs
Turntable plate
will not turn.
Ensure the AC adapter is plugged in at the wall.
Check the plug connected to the unit.
The tone arm will
not move.
Release the tone arm lock.
No Sound can be
heard.
Ensure the stylus / needle cover has been removed.
Check the volume is turned up.
Excessive
crackling can be
heard.
Clean the record with a high quality anti-static cloth
and cleaning solution.
NOTE: Only use cleaning products designed
specifically for vinyl records. Using incompatible
cleaning products may permanently damage records
and the Retro Briefcase Turntable.

14
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Technical Specication
AC Adaptor Input: 100-240V ~ 50/60Hz 0.3A
Output: 5V 1.5A
Power Consumption 5W
Speeds 33.33, 45, 78 RPM
Speakers 2 x 3W
File System Format FAT32 only (Does not support NTFS)
Vinyl Records
Supports playback speed 33.33 / 45 / 78
Supports record sizes: 7” = 17.7cm, 10” = 25.5cm SP,
12” = 30cm LP

15
Retro Briefcase Turntable
Repair and Refurbished
Goods or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to
be returned to the supplier for repair.
Please be aware that if your product is capable of retaining user-generated data
(such as files stored on a computer hard drive, telephone numbers stored on
a mobile telephone, songs stored on a portable media player, games saved on
a games console or files stored on a USB memory stick) during the process of
repair, some or all of your stored data may be lost. We recommend you save this
data elsewhere prior to sending the product for repair.
You should also be aware that rather than repairing goods, we may replace them
with refurbished goods of the same type or use refurbished parts in the repair
process.
Please be assured though, refurbished parts or replacements are only used
where they meet ALDI’s stringent quality specications.
If at any time you feel your repair is being handled unsatisfactorily, you may
escalate your complaint. Please telephone us on 1300 886 649 or write to us at:
Tempo (Aust) Pty Ltd ABN 70 106 100 252
PO BOX 6056 Frenchs Forest, Sydney, Australia NSW 2086
Telephone: [phone] (Aust) - Fax: [phone]
Tempo Help Desk: 1300 886 649 (Aust)
(Operating Hours: Mon-Fri 08:30am to 06:00pm EST)
Email: [email protected]g
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS

16
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Notes

17
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
Notes

Warranty returns
Should you for any reason need to return this product
for a warranty claim, make sure to include all accessories
with the product.
Product does not work?
If you encounter problems with this product, or if it fails
to perform to your expectations, make sure to contact
our After Sales Support Centre on 1300 886 649 before
returning it to the store for a refund.
1300 886 649 Model: ARTTSC-1117 Product Code: 55688 11/2017
www.tempo.org
AUS
