Baumatic B721-A Operating instructions



baumatic copertina libretto 23-12-2003 8:26 Pagina 1

B721BL-A
B721W-A
B722SS-A
USER AND INSTALLATION
INSTRUCTIONS
Models covered by this manual:
B723SS-A

For future reference please record the following
information which can be found on the Rating Plate and
the date of purchase which can be found in the invoice:
Model Number …………………….
Serial Number …………………….
Date of Purchase …………………….
Supplier …………………….

CONTENTS
General Information Pages 3-4
Warning and Safety Instructions Pages 5-6
Installation Instructions Pages 7-10
Timer Instructions Pages 11-13
Before the first use Page 14
Operating Instructions Pages 15-19
Cooking Guide Page 20
Cleaning and Maintenance Pages 21
Fault Finding Page 22
Technical Data Pages 23-24
Conditions of Guarantee Pages 25-26

GENERAL INFORMATION
Please read this booklet thoroughly before you use this appliance.
It is important that you understand all the control functions before
commencing to cook with your Baumatic appliance.
Please remember the advice and warnings shown on page 5which
is headed ‘IMPORTANT – Warning and Safety Instructions’.
This appliance is designed for domestic household use and can be
built into a standard kitchen cabinet or housing unit.
NOTE: The adjacent furniture or the housing and all materials used
in the installation must be able to withstand a minimum
temperature rise of 85°C above ambient during periods of use.
Certain types of vinyl or laminate kitchen furniture are particularly
prone to heat damage or discolouration at temperatures below the
above guidelines.
Installing the appliance in contravention of this temperature limit
or the placing of adjacent cabinet materials closer than 4mm to the
appliance, will be at the liability of the owner.
For use in Leisure Accommodation Vehicles, notice must be taken
of the appropriate statement in the Installation Instructions.
The use for any other purpose or in any other environment without
the express agreement of Baumatic Ltd, would invalidate any
warranty or liability claim.
Your new appliance is guaranteed against electrical or mechanical
defects subject to certain exclusions noted in Baumatic Ltd
Conditions of Guarantee.
The foregoing does not affect your statutory rights.
3
Any repairs or servicing must be carried out exclusively by a qualified
technician.
Never expose the oven to atmospheric agents.

In the event that you require any After Sales Service or advice,
please contact the Baumatic Service Department on telephone
number – 0118 933 6911.
Before using this appliance ensure that any protective packaging or
coatings have been removed. To aid the protection of the
environment, please sort the packing materials into different types
and dispose of them in accordance with the local waste disposal
laws.
Any further information on waste disposal can be obtained from
your local Environmental Agency office.
When first used, an odour may be emitted by any residual
protective finish or moisture, which will cease after a short period
of time.
This Appliance has been Constructed and Distributed in
compliance with the essential requirements of the following EEC
DIRECTIVES and EUROPEAN NORMS:
CE Marking – 93/68 Low Voltage – 73/23 EMC – 89/336
Safety Standards – EN 60 335-1, EN 60 335 – 2 – 6.
As Baumatic have a policy of continued product improvement, the
right is reserved to adjust and make any modifications deemed
necessary without notification.
4
The Warranty applies to Great Britain and Northern Ireland only.
Keep children away from the packing materials and do not let
them play with it.

IMPORTANT NOTE –
WARNING AND SAFETY INSTRUCTIONS
This appliance complies with all current European safety
legislation, however Baumatic do wish to emphasise that
compliance does not remove the fact that the appliance surfaces
will become hot during use and retain heat after operation.
Baumatic therefore strongly advise that babies,young children and
unable people are prevented from being near or touching the appliance
at any time.
If it is necessary for younger family members to be in the kitchen,
please ensure that they are kept under close supervision at all
times.
We also advise that great care is taken during use and cleaning
operations.
Do not place heavy objects on or lean on the oven door when open
as this can cause damage to the hinges.
Do not leave heated oil or fat unattended as there is a risk of fire.
Do not place pans or baking trays on the bottom of oven cavities or
line any part of the oven cavity with aluminium foil.
Do not allow electrical fittings or cables to be in contact with hot
areas of the appliance.
Do not use the appliance for space heating or to dry clothes.
Do not install the appliance next to curtains or soft furnishings.
Do not attempt to lift or move cooking appliances by pulling on
any door or handle as this can cause damage.
5
Always use oven gloves when moving food in or out of the oven cavity.
Warning: this appliance must be earthed.
Do not pour water directly into the inside of a hot oven. The enamel
coating could be damaged.
Before any cleaning operation inside the oven, wait until it has cooled
down.

NOTE: This appliance must be correctly installed by a
suitably qualified person, strictly in accordance with the
manufacturer’s instructions.
For electrical installations, NICEIC registration is
recommended.
Baumatic Ltd declines any responsibility for injury or
damage to persons or property as a result of improper use
or installation of this appliance.
Heat, steam and moisture will be created during use, take
care to avoid injury and ensure that the room is adequately
ventilated. If prolonged use occurs, additional ventilation
may be required – please consult your Qualified Installer if
you are in any doubt about the amount required.
6
This appliance must be connected to an a.c. single phase 230V -
50Hz electricity supply.
