Baumer SXC10 User manual

Safety
Further Information
For further information on our products visit www.baumer com
For technical issues, please contact our technical support:
support.cameras@baumer com Phone [phone] Fax [phone]
© Baumer Optronic GmbH Badstrasse 30 DE-01454 Radeberg, Germany
Technical data has been fully checked, but accuracy of printed matter not guaranteed.
Subject to change without notice. Printed in Germany 08/13. v1.3 11083691
FCC – Class B device
No t e : This equipment has been tested and found to
comply with the limits for a Class B digital device, pursu-
ant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interfer-
ence in a residential environment. This equipment gener-
ates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructios,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occure in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off an
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.▪
Increase the separation between the equipment and the▪
receiver.
Connect the equipment into an outlet on a circuit different▪
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician▪
for help.
Conformity:
CE, FCC Part 15 Class B, RoHS
Safety Precautions
Notice
See User s Guide for the com-
plete safety instructions!
Protect the sensor from dirt and▪
moisture.
Never open the camera housing.▪
Avoid camera contamination by▪
foreign objects.
Environmental requirements:
Storage temp. -10°C ... +70°C
Operating temp. +5°C ... +60°C
Housing temp. max. +60°C
Humidity 10 % ... 90 %
Non-condensing
Quick Start Guide
SXC CameraLink®cameras with Truesense Imaging sensors
Product Specication
SXC cameras – Maximum Performance with Truesense Imaging sensors
Excellent image quality at high image rates▪
Resolutions of 1, 2, 4 or 8 megapixel▪
Frame rates up to 120 fps▪
CameraLink▪®Base for high transmission rates
Compact design (52 x 52 x 55 mm)▪
Camera Type Sensor
Size Resolution Full Frames
[max. fps]
Monochrome
SXC10 1/2" 1024 x 1024 120
SXC20 2/3" 1600 x 1200 68
SXC21 2/3” 1920 x 1080 64
SXC40 1” 2336 x 1752 32
SXC80 4/3” 3296 x 2472 16
Color
SXC10c 1/2” 1024 x 1024 120
SXC20c 2/3” 1600 x 1200 68
SXC21c 2/3” 1920 x 1080 64
SXC40c 1” 2336 x 1752 32
SXC80c 4/3” 3296 x 2472 16
Installation
Connect the camera using▪
an appropriate cable to the
framegrabber board on your
PC using the mdr-26 jack on
he camera side
If required, wire the digital▪
I/Os by using the 8 pin
connector
Connect the camera to▪
power supply
Installation sample
1 - Framegrabber board; 2 - Camera Link®
cable; 3 - Process interface cable; 4 - Power
cable
Dimensions
● SXC-F (F-Mount version)
26 36
26 36
16 x M3 depth 6
UNC 1/4 20
52
52
26 36
55
Dimensions
● SXC (C-Mount version)
26 36
16 x M3 depth 6
UNC 1/4-20
4 x M3 depth 6
52
52
36 26 36
36
54
36 26
Latest software version and technical
documentation are available at:
www.baumer.com/vision/login

Camera Link®, Process Interfaces and Power Supply
Base Camera Link®
Pin Signal Pin Signal Pin Signal
1 GND 10 CC2+ 19 X3+
2 X0- 11 CC3- 20 SERTC-
3 X1- 12 CC4+ 21 SERTFG+
4 X2- 13 GND 22 CC1+
5 XCLK- 14 GND 23 CC2-
6 X3- 15 X0+ 24 CC3+
7 SERTC+ 16 X1+ 25 CC4-
8 SERTFG- 17 X2+ 26 GND
9 CC1- 18 XCLK+
Caution
A power supply with electrical isolation is required for proper operation
of the camera. Otherwise the device may be damaged.
Power Supply Process Interface
1
4
3
8
5
7 3
1
4
2
6
1 (bn) Power VCC 1 (wh) Out 3 5 (gr) IO Power VCC
3 (bu) GND 2 (bn) In 2 6 (pk) Out 1
4 (bk) NC 3 (gn) In 1 7 (bu) Out 2
4 (ye) IO GND 8 (rd) In 3
LED Signaling
2
1
Signal Meaning
1
green Power on
green / yellow ashing Readout active
2
green Conguration command processing
red (yellow on both) Transmitting
Heat Transmission
Caution
Provide adequate dissipation of heat, to ensure that the temperatures
does not exceed +60°C (+140°F).
The surface of the camera may be hot during operation and immediately
after use. Be careful when handling the camera and avoid contact over a
longer period.
T
T: Housing temperature
measurement point
As there are numerous possibilities for installa-
tion, a specic method for proper heat dissipa ion
is not dened, but the following principles are
suggested:
Operate the cameras only in mounted condition▪
with a good heat conductor (e.g. aluminum)
Mounting in combination with forced convection ▪
may provide proper heat dissipation
General Description
12
3
4
5
No. Description No. Description
1(respective) lens mount 4CameraLink®Base socket
2Power Supply 5Signaling-LEDs
3Digital IO-supply
