Quick Start Guide
VLXT.FO cameras (10 Gigabit Ethernet)
Download latest camera software:
www.baumer.com/vision/software
Download latest technical documentation:
www.baumer.com/cameras/docs
Product Specication
VLXT.FO cameras – Extremely functionality and high frame rates
▪Up to 12 megapixel and 216 fps
▪Power supply: 12 – 24 V ± 20 %
▪GigE VisionTM standard compliant
▪SFP+ (Enhanced small form-factor pluggable)
▪Optional: Protection classes IP65 / IP67 (with installed tube and Harting adapter)
▪Optional: Modular tube system
▪M12 industry connector
▪PWM on outputs for direct controlled illuminations
▪4 outputs with maximum 1.5 A (2.5 A with 40% periode time)
Notice
Further technical details are available in the respective data sheets.
Dimensions
79,6 ±0,3
12,9
5,5
8,33
26
26
8,33
7,83
68,5
26
15,7
15,7
19,6
18,2
M3 x 5/78 x
M3 x 5/72 x
temperature
measurement point
35
35
M3 x 6/8
4 x
Pixel 0,0
1/4"-20 UNC x 6/9
28,7Ø
6,4
C-Mount
Installation
Modular tube system and Harting Adapter (ordered separately)
Do not forget the seals!
Recommended grease
for easier installation:
ELKALUB GLS 867
Tube
Tube Adapter
Camera
Distance Ring
The peak torque while
tightening the
screws is 0.9 Nm.
Use a torque wrench!
Harting Adapter
The peak torque while
tightening the
screws is 0.9 Nm.
Use a torque wrench!
Conformity
We declare, under our sole responsibility, that
the previously described Baumer VLXT.FO
cameras conform with the directives of the CE.
All VLXT.FO cameras complies with the recom-
mendation of the European Union concerning
RoHS Rules.
ULUS
LISTED
C
The camera has been tested by UL (Under-
writers Laboratories) and complies with the
requirements of the standards.
Please see the User’s Guide for further
information.
Safety Precautions
Notice
See the User's Guide for the complete
safety instructions!
Caution
Observe precautions for handling
electrostatically sensitive devices!
Environmental Requirements
Storage temp. -10 °C ... +70 °C
Operating temp. see Heat Transmission
Humidity 10 % ... 90 %
Non-condensing
System Requirements
Recommended for
GigE
Recommended for
10 GigE
CPU Intel®Core™i5-2520M
CPU @ 2.50 GHz, Cores: 4
Intel®Core™i7-3770
CPU @ 3.40 GHz, Cores: 8
RAM 4 GB 8 GB
Oper-
ating
system
(OS)
Microsoft®Windows® 7 (32 / 64 bit systems)
Microsoft®Windows®8 (32 / 64 bit systems)
Microsoft®Windows®10 (32 / 64 bit systems)
Installation
Lens mount
Notice
Ensure the sensor and lens are not contaminated with dust and airborne particles
when mounting the support or the lens to the device!
The following points are very important:
▪Install the camera in an environment that is as dust free as possible!
▪Keep the dust cover (bag) on the camera for as long as possible!
▪Hold the camera with the sensor downwards if the sensor is uncovered.
▪Avoid contact with any of the camera‘s optical surfaces!

LED Signaling
2
1
LED Signal Meaning
1GigE LED
green static link active
green ash receiving
2Camera LED
yellow static error
yellow ash transmitting
orange static overheated
General Description
146
7
2 53
No. Description No. Description
1Lens mount (C-mount) 5GigE LED
2Lens control (not connected) 6Camera LED
34 x Tube Adapter /front mount-
ing threads 7SFP+ Socket
4Power- and process interface
Heat Transmission
Caution
Provide adequate dissipation of heat, to ensure that the temperature
does not exceed the values in the table below.
The surface of the camera may be hot during operation and immediately
after use. Be careful when handling the camera and avoid contact over a
longer period.
As there are numerous possibilities for installation, Baumer do not speci-
y a specic method for proper heat dissipation, but suggest the following
principles:
▪operate the cameras only in mounted condition
▪mounting in combination with forced convection may provide proper
heat dissipation
T
Measure Point Maximal Temperature
T +65 °C (149 °F)
Data Interface
SFP+ Socket
8
9
10
11
12
5
7
3
1
4
2
6
13
14
15
16
17
18
19
20
1VEET 11 VEER
2TX_FAULT 12 RD-
3TX_DISABLE 13 RD+
4SDA 14 VEER
5SCL 15 VCCR
6MOD_ABS 16 VCCT
7RS0 17 VEET
8RX_LOS 18 TD+
9RS1 19 TD-
10 VEER 20 VEET
Power Supply
Power Supply
Power VCC
12 V ... 24 V ±20 %
For UL conform installation:
Class 2 per NEC / Protection Class III
The device is intended to be supplied from an isolated Limited Ener-
gy Source per UL61010-1, 3rd ed cl. 9.4 or Limited Power Source
per UL60950-1 or Class 2 per NEC.
Digital IOs
Power supply / Digital IOs (on camera side)
(SACC-CI-M12MS-12CON-L180)
M12 / 12 pins / wire colors of the connecting cable (ordered separately)
8
9
10
11 12
5
7
3
1
4
2
6
1Power VCC brown 7OUT3 (Line6) black
2GND (Power) blue 8RS232 Txd (Line2) grey
3IN1 (Line0) white 9OUT4 (Line7) red
4OUT1 (Line4) green 10 RS232 RxD (Line3) violet
5IN2 (Line1) pink 11 GND (IO) grey-pink
6OUT2 (Line5) yellow 12 Power (IO) red-blue
Caution
IP
Protection
In order to achieve the mentioned IP protection level, the M12 connector
need to be tightened with a torque value of 0.4 Nm.
For that Baumer suggests the use of a torque driver (such as Wiha Tor-
queVario®-S ESD) in combination with a wrench for assembling sensor/
actuator cables with M12 connector (such as Phoenix Contact SAC BIT
M12-D15).
On the SFP+ socket, a Harting Adapter must be used.
Installation
Installation of the camera:
▪Connect the camera using appropriate fibre optic cables to the transceivers.
▪If required, connect a trigger and / or flash to process interface.
▪Connect the camera to power supply.
open wire 4
Installation sample
1 - Cable for trigger and ash
2- Optical Fibre cables
3- SFP+ Transceiver
4- PCI board
