Baumer VCXG.2 User manual

V1.2 | 7/13/2023 | 11720432
EN-US
Operating Manual
VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2
(Gigabit Ethernet / USB3.0)

List of contents Baumer
ii Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
List of contents
1 About this document .................................................................................................................................. 11
1.1 Purpose............................................................................................................................................... 11
1.2 Warnings in this manual...................................................................................................................... 11
1.3 Labels in this manual .......................................................................................................................... 12
1.4 Liability limitation ................................................................................................................................. 12
1.5 Copyright............................................................................................................................................. 12
2 General information .................................................................................................................................... 13
3 Description................................................................................................................................................... 14
3.1 VCXG.2 ............................................................................................................................................... 14
3.1.1 Conception............................................................................................................................ 14
3.1.2 LED status indicator.............................................................................................................. 14
3.1.3 Camera models..................................................................................................................... 15
3.1.4 Dimensional drawing............................................................................................................. 16
3.2 VCXG.2.XC ......................................................................................................................................... 17
3.2.1 Conception............................................................................................................................ 17
3.2.2 LED status indicator.............................................................................................................. 17
3.2.3 Camera models..................................................................................................................... 18
3.2.4 Dimensional drawing............................................................................................................. 18
3.3 VCXG.2.I ............................................................................................................................................. 19
3.3.1 Conception............................................................................................................................ 19
3.3.2 LED status indicator.............................................................................................................. 19
3.3.3 Camera models..................................................................................................................... 20
3.3.4 Dimensional drawing............................................................................................................. 21
3.4 VCXU.2 ............................................................................................................................................... 22
3.4.1 Conception............................................................................................................................ 22
3.4.2 LED status indicator.............................................................................................................. 22
3.4.3 Camera models..................................................................................................................... 23
3.4.4 Dimensional drawing............................................................................................................. 24
4 Transport and storage ................................................................................................................................ 25
4.1 Transport............................................................................................................................................. 25
4.2 Delivery inspection .............................................................................................................................. 25
5 Installation ................................................................................................................................................... 26
5.1 Environmental requirements ............................................................................................................... 26
5.2 Mechanical Tests ................................................................................................................................ 27
5.3 Emergency shutdown at Overtemperature ......................................................................................... 28
5.4 Heat dissipation................................................................................................................................... 31
5.4.1 Cooling channel (VCXG.2.XC only)...................................................................................... 32
5.5 Lens mount ......................................................................................................................................... 34
5.6 Filter exchange.................................................................................................................................... 34
5.7 Modular tube system (please order separately).................................................................................. 35

Baumer List of contents
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual iii
6 Optical specification ................................................................................................................................... 41
6.1 VCXG.2 ............................................................................................................................................... 41
6.1.1 Sensor position accuracy...................................................................................................... 41
6.1.2 Filter glass color cameras..................................................................................................... 42
6.1.3 Spectral sensitivity ................................................................................................................ 42
6.2 VCXG.2.XC ......................................................................................................................................... 47
6.2.1 Sensor position accuracy...................................................................................................... 47
6.2.2 Spectral sensitivity ................................................................................................................ 48
6.3 VCXG.2.I ............................................................................................................................................. 49
6.3.1 Sensor position accuracy...................................................................................................... 49
6.3.2 Filter glass color cameras..................................................................................................... 50
6.3.3 Cover glasses Tubes ............................................................................................................ 50
6.3.4 Spectral sensitivity ................................................................................................................ 50
6.4 VCXU.2 ............................................................................................................................................... 54
6.4.1 Sensor position accuracy...................................................................................................... 54
6.4.2 Filter glass color cameras..................................................................................................... 55
6.4.3 Spectral sensitivity ................................................................................................................ 55
7 Electrical installation .................................................................................................................................. 60
7.1 General instructions for electric installation......................................................................................... 60
7.2 VCXG.2 ............................................................................................................................................... 60
7.2.1 Pin assignment ..................................................................................................................... 60
7.2.2 Digital IO ............................................................................................................................... 62
7.2.3 GPIO (General Purpose Input / Output) ............................................................................... 63
7.3 VCXG.2.XC ......................................................................................................................................... 64
7.3.1 Pin assignment ..................................................................................................................... 64
7.3.2 Digital IO ............................................................................................................................... 66
7.3.3 GPIO (General Purpose Input / Output) ............................................................................... 67
7.4 VCXG.2.I ............................................................................................................................................. 68
7.4.1 Pin assignment ..................................................................................................................... 68
7.4.2 Digital-IO............................................................................................................................... 69
7.5 VCXU.2 ............................................................................................................................................... 70
7.5.1 Pin assignment ..................................................................................................................... 70
7.5.2 Digital IO ............................................................................................................................... 71
7.5.3 GPIO (General Purpose Input / Output) ............................................................................... 72
8 Preventive maintenance ............................................................................................................................. 73
8.1 Cleaning .............................................................................................................................................. 73
9 Troubleshooting .......................................................................................................................................... 75
9.1 Support................................................................................................................................................ 75
9.2 Accessories......................................................................................................................................... 75
10 Software ....................................................................................................................................................... 76
10.1 Baumer GAPI ...................................................................................................................................... 76
10.2 Baumer neoAPI................................................................................................................................... 76
10.3 Baumer Camera Explorer ................................................................................................................... 76
10.4 3rd Party Software................................................................................................................................ 76

List of contents Baumer
iv Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
11 GenICam Camera Features ........................................................................................................................ 77
11.1 Category: AcquisitionControl............................................................................................................... 77
11.1.1 AcquisitionAbort.................................................................................................................... 77
11.1.2 AcquisitionFrameCount......................................................................................................... 78
11.1.3 AcquisitionFrameRate........................................................................................................... 78
11.1.4 AcquisitionFrameRateEnable ............................................................................................... 78
11.1.5 AcquisitionMode.................................................................................................................... 79
11.1.6 AcquisitionStart..................................................................................................................... 79
11.1.7 AcquisitionStatus .................................................................................................................. 79
11.1.8 AcquisitionStatusSelector ..................................................................................................... 80
11.1.9 AcquisitionStop .................................................................................................................... 80
11.1.10 ExposureAuto ....................................................................................................................... 80
11.1.11 ExposureMode...................................................................................................................... 81
11.1.12 ExposureTime....................................................................................................................... 81
11.1.13 ExposureTimeGapMax ......................................................................................................... 85
11.1.14 ExposureTimeGapMin .......................................................................................................... 85
11.1.15 ReadoutMode ....................................................................................................................... 86
11.1.16 ShortExposureTimeEnable................................................................................................... 86
11.1.17 TriggerActivation................................................................................................................... 87
11.1.18 TriggerDelay ......................................................................................................................... 87
11.1.19 TriggerMode.......................................................................................................................... 87
11.1.20 TriggerOverlap...................................................................................................................... 88
11.1.21 TriggerSelector ..................................................................................................................... 88
11.1.22 TriggerSoftware .................................................................................................................... 88
11.1.23 TriggerSource ....................................................................................................................... 89
11.2 Category: ActionControl (GigE only) ................................................................................................... 89
11.2.1 ActionDeviceKey................................................................................................................... 90
11.2.2 ActionGroupKey.................................................................................................................... 90
11.2.3 ActionGroupMask ................................................................................................................. 91
11.2.4 ActionSelector....................................................................................................................... 91
11.3 Category: AnalogControl..................................................................................................................... 91
11.3.1 BalanceWhiteAuto (color cameras only)............................................................................... 91
11.3.2 BlackLevel............................................................................................................................. 92
11.3.3 BlackLevelSelector ............................................................................................................... 93
11.3.4 Gain ...................................................................................................................................... 94
11.3.5 GainAuto............................................................................................................................... 96
11.3.6 GainSelector ......................................................................................................................... 96
11.3.7 Gamma ................................................................................................................................. 97
11.4 Category: AutoFeatureControl ............................................................................................................ 98
11.4.1 AutoFeatureHeight................................................................................................................ 101
11.4.2 AutoFeatureOffsetX .............................................................................................................. 101
11.4.3 AutoFeatureOffsetY .............................................................................................................. 102
11.4.4 AutoFeatureRegionMode...................................................................................................... 102
11.4.5 AutoFeatureRegionReference .............................................................................................. 102
11.4.6 AutoFeatureRegionSelector ................................................................................................. 103
11.4.7 AutoFeatureWidth ................................................................................................................. 103
11.4.8 BalanceWhiteAutoStatus ...................................................................................................... 104
11.4.9 BrightnessAutoNominalValue ............................................................................................... 104
11.4.10 BrightnessAutoPriority .......................................................................................................... 104
11.4.11 ExposureAutoMaxValue ....................................................................................................... 106

Baumer List of contents
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual v
11.4.12 ExposureAutoMinValue ........................................................................................................ 106
11.4.13 GainAutoMaxValue ............................................................................................................... 106
11.4.14 GainAutoMinValue ................................................................................................................ 106
11.5 Category: ChunkDataControl .............................................................................................................. 107
11.5.1 ChunkEnable ........................................................................................................................ 108
11.5.2 ChunkModeActive................................................................................................................. 108
11.5.3 ChunkSelector ...................................................................................................................... 108
11.6 Category: ColorTransformationControl (color cameras only).............................................................. 110
11.6.1 ColorTransformationAuto...................................................................................................... 111
11.6.2 ColorTransformationEnable .................................................................................................. 111
11.6.3 ColorTransformationFactoryListSelector .............................................................................. 112
11.6.4 ColorTransformationOutputColorSpace ............................................................................... 112
11.6.5 ColorTransformationResetToFactoryList .............................................................................. 112
11.6.6 ColorTransformationValue .................................................................................................... 113
11.6.7 ColorTransformationValueSelector....................................................................................... 113
11.7 Category: CounterAndTimerControl.................................................................................................... 113
11.7.1 CounterDuration.................................................................................................................... 113
11.7.2 CounterEventActivation ........................................................................................................ 114
11.7.3 CounterEventSource ............................................................................................................ 114
11.7.4 CounterReset........................................................................................................................ 115
11.7.5 CounterResetActivation ........................................................................................................ 115
11.7.6 CounterResetSource ............................................................................................................ 115
11.7.7 CounterSelector .................................................................................................................... 116
11.7.8 CounterValue ........................................................................................................................ 117
11.7.9 CounterValueAtReset ........................................................................................................... 117
11.7.10 FrameCounter....................................................................................................................... 117
11.7.11 TimerDelay............................................................................................................................ 118
11.7.12 TimerDuration ....................................................................................................................... 118
11.7.13 TimerSelector........................................................................................................................ 118
11.7.14 TimerTriggerActivation.......................................................................................................... 119
11.7.15 TimerTriggerSource .............................................................................................................. 119
11.8 Category: CustomDataControl ............................................................................................................ 120
11.8.1 CustomData .......................................................................................................................... 120
11.8.2 CustomDataConfiguration .................................................................................................... 120
11.8.3 CustomDataSelector............................................................................................................. 121
11.9 Category: DeviceControl ..................................................................................................................... 121
11.9.1 DeviceCharacterSet.............................................................................................................. 121
11.9.2 DeviceEventChannelCount................................................................................................... 121
11.9.3 DeviceFamilyName............................................................................................................... 122
11.9.4 DeviceFirmwareVersion........................................................................................................ 122
11.9.5 DeviceGenCPVersionMajor .................................................................................................. 122
11.9.6 DeviceGenCPVersionMinor .................................................................................................. 122
11.9.7 DeviceLinkSelector ............................................................................................................... 123
11.9.8 DeviceLinkSpeed .................................................................................................................. 123
11.9.9 DeviceLinkThroughputLimit .................................................................................................. 123
11.9.10 DeviceManufacturerInfo........................................................................................................ 124
11.9.11 DeviceModelName................................................................................................................ 124
11.9.12 DeviceRegistersEndiannes................................................................................................... 124
11.9.13 DeviceReset.......................................................................................................................... 125
11.9.14 DeviceResetToDeliveryState ................................................................................................ 125

List of contents Baumer
vi Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
11.9.15 DeviceSFNCVersionMajor .................................................................................................... 125
11.9.16 DeviceSFNCVersionMinor .................................................................................................... 126
11.9.17 DeviceSFNCVersionSubMinor.............................................................................................. 126
11.9.18 DeviceScanType................................................................................................................... 126
11.9.19 DeviceSensorType................................................................................................................ 126
11.9.20 DeviceSerialNumber ............................................................................................................. 127
11.9.21 DeviceStreamChannelCount ................................................................................................ 127
11.9.22 DeviceStreamChannelEndianness ....................................................................................... 127
11.9.23 DeviceStreamChannelSelector............................................................................................. 127
11.9.24 DeviceStreamChannelType .................................................................................................. 128
11.9.25 DeviceTLType....................................................................................................................... 128
11.9.26 DeviceTLVersionMajor.......................................................................................................... 128
11.9.27 DeviceTLVersionMinor.......................................................................................................... 128
11.9.28 DeviceTLVersionSubMinor ................................................................................................... 129
11.9.29 DeviceTemperature .............................................................................................................. 129
11.9.30 DeviceTemperatureExceeded .............................................................................................. 129
11.9.31 DeviceTemperatureSelector ................................................................................................. 129
11.9.32 DeviceTemperatureStatus .................................................................................................... 130
11.9.33 DeviceTemperatureStatusTransition .................................................................................... 130
11.9.34 DeviceTemperatureStatusTransitionSelector ....................................................................... 130
11.9.35 DeviceType ........................................................................................................................... 131
11.9.36 DeviceUserID........................................................................................................................ 131
11.9.37 DeviceVendorName.............................................................................................................. 131
11.9.38 DeviceVersion....................................................................................................................... 132
11.9.39 ReadOutTime........................................................................................................................ 132
11.9.40 TimestampLatch ................................................................................................................... 132
11.9.41 TimestampLatchValue .......................................................................................................... 133
11.9.42 USB2SupportEnable (USB cameras only) ........................................................................... 133
11.10 Category: DigitalIOControl .................................................................................................................. 134
11.10.1 LineDebouncerHighTimeAbs ................................................................................................ 136
11.10.2 LineDebouncerLowTimeAbs................................................................................................. 136
11.10.3 LineFormat............................................................................................................................ 137
11.10.4 LineInverter ........................................................................................................................... 138
11.10.5 LineMode .............................................................................................................................. 138
11.10.6 LinePWMConfigurationMode ................................................................................................ 138
11.10.7 LinePWMDuration................................................................................................................. 140
11.10.8 LinePWMDutyCycle .............................................................................................................. 140
11.10.9 LinePWMMaxDuration .......................................................................................................... 140
11.10.10LinePWMMaxDutyCycle ....................................................................................................... 140
11.10.11LinePWMMode ..................................................................................................................... 141
11.10.12LinePWMOffTime.................................................................................................................. 141
11.10.13LinePWMPeriodTime ............................................................................................................ 142
11.10.14LineSelector .......................................................................................................................... 142
11.10.15LineSource............................................................................................................................ 143
11.10.16LineStatus ............................................................................................................................. 145
11.10.17LineStatusAll ......................................................................................................................... 145
11.10.18UserOutputSelector .............................................................................................................. 145
11.10.19UserOutputValue .................................................................................................................. 146
11.10.20UserOutputValueAll .............................................................................................................. 146
11.11 Category: EventControl....................................................................................................................... 147

Baumer List of contents
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual vii
11.11.1 EventNotification ................................................................................................................... 150
11.11.2 EventSelector........................................................................................................................ 150
11.11.3 LostEventCounter ................................................................................................................. 151
11.12 Category: ImageFormatControl........................................................................................................... 151
11.12.1 BinningHorizontal.................................................................................................................. 155
11.12.2 BinningHorizontalMode......................................................................................................... 158
11.12.3 BinningSelector..................................................................................................................... 158
11.12.4 BinningVertical ...................................................................................................................... 158
11.12.5 BinningVerticalMode ............................................................................................................. 161
11.12.6 Category: ImageFormatControl → CalibrationControl (MP cameras only)........................... 161
11.12.6.1 CalibrationAngleOfPolarizationOffset............................................................... 163
11.12.6.2 CalibrationEnable ............................................................................................. 163
11.12.6.3 CalibrationMatrixValue ..................................................................................... 163
11.12.6.4 CalibrationMatrixValueSelector ........................................................................ 164
11.12.7 ComponentEnable (MP cameras only)................................................................................. 164
11.12.8 ComponentSelector (MP cameras only)............................................................................... 164
11.12.9 Height.................................................................................................................................... 165
11.12.10HeightMax............................................................................................................................. 167
11.12.11OffsetX .................................................................................................................................. 169
11.12.12OffsetY .................................................................................................................................. 169
11.12.13PixelFormat........................................................................................................................... 170
11.12.14ReverseX (monochrome cameras/pixel formats only) .......................................................... 173
11.12.15ReverseY (monochrome cameras / pixel formats only) ........................................................ 173
11.12.16SensorHeight ........................................................................................................................ 174
11.12.17SensorName ......................................................................................................................... 174
11.12.18SensorPixelHeight ................................................................................................................ 174
11.12.19SensorPixelWidth.................................................................................................................. 174
11.12.20SensorShutterMode .............................................................................................................. 175
11.12.21SensorWidth ......................................................................................................................... 177
11.12.22TestPattern ........................................................................................................................... 177
11.12.23TestPatternGeneratorSelector .............................................................................................. 178
11.12.24Width..................................................................................................................................... 178
11.12.25WidthMax .............................................................................................................................. 180
11.13 Category: LUTControl ......................................................................................................................... 183
11.13.1 DefectPixelCorrection ........................................................................................................... 185
11.13.2 DefectPixelListEntryActive .................................................................................................... 185
11.13.3 DefectPixelListEntryPosX ..................................................................................................... 185
11.13.4 DefectPixelListEntryPosY ..................................................................................................... 185
11.13.5 DefectPixelListIndex ............................................................................................................. 186
11.13.6 DefectPixelListSelector ......................................................................................................... 186
11.13.7 LUTContent........................................................................................................................... 186
11.13.8 LUTEnable ............................................................................................................................ 187
11.13.9 LUTIndex .............................................................................................................................. 187
11.13.10LUTSelector .......................................................................................................................... 188
11.13.11LUTValue .............................................................................................................................. 188
11.14 Category: MemoryManagement.......................................................................................................... 188
11.14.1 MemoryMaxBlocks................................................................................................................ 188
11.15 Category: SequencerControl............................................................................................................... 189
11.15.1 SequencerConfigurationMode .............................................................................................. 190
11.15.2 SequencerFeatureEnable ..................................................................................................... 190

List of contents Baumer
viii Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
11.15.3 SequencerFeatureSelector ................................................................................................... 190
11.15.4 SequencerMode ................................................................................................................... 191
11.15.5 SequencerPathSelector ........................................................................................................ 191
11.15.6 SequencerSetActive ............................................................................................................. 192
11.15.7 SequencerSetLoad ............................................................................................................... 192
11.15.8 SequencerSetNext................................................................................................................ 192
11.15.9 SequencerSetSave ............................................................................................................... 192
11.15.10SequencerSetSelector .......................................................................................................... 193
11.15.11SequencerSetStart ............................................................................................................... 193
11.15.12SequencerTriggerActivation ................................................................................................. 193
11.15.13SequencerTriggerSource...................................................................................................... 194
11.16 Category: TestControl ......................................................................................................................... 194
11.16.1 TestPendingAck.................................................................................................................... 194
11.17 Category: TransportLayerControl........................................................................................................ 195
11.17.1 EnergyEfficientEthernetEnable (GigE only).......................................................................... 195
11.17.2 Category: GigEVision............................................................................................................ 196
11.17.2.1 GVSPConfigurationBlockID64Bit ..................................................................... 196
11.17.2.2 GevCCP ........................................................................................................... 196
11.17.2.3 GevCurrentDefaultGateway ............................................................................. 196
11.17.2.4 GevCurrentIPAddress ...................................................................................... 197
11.17.2.5 GevCurrentIPConfigurationDHCP.................................................................... 197
11.17.2.6 GevCurrentIPConfigurationLLA........................................................................ 197
11.17.2.7 GevCurrentIPConfigurationPersistentIP........................................................... 197
11.17.2.8 GevCurrentSubnetMask ................................................................................... 198
11.17.2.9 GevFirstURL..................................................................................................... 198
11.17.2.10 GevGVCPExtendedStatusCodes..................................................................... 198
11.17.2.11 GevGVCPExtendedStatusCodesSelector........................................................ 198
11.17.2.12 GevGVCPPendingAck ..................................................................................... 199
11.17.2.13 GevIPConfigurationStatus................................................................................ 199
11.17.2.14 GevInterfaceSelector........................................................................................ 199
11.17.2.15 GevMACAddress.............................................................................................. 200
11.17.2.16 GevMCDA ........................................................................................................ 200
11.17.2.17 GevMCPHostPort ............................................................................................. 200
11.17.2.18 GevMCRC ........................................................................................................ 200
11.17.2.19 GevMCSP......................................................................................................... 201
11.17.2.20 GevMCTT ......................................................................................................... 201
11.17.2.21 GevNumberOfInterfaces .................................................................................. 201
11.17.2.22 GevPAUSEFrameReception ............................................................................ 201
11.17.2.23 GevPersistentDefaultGateway ......................................................................... 202
11.17.2.24 GevPersistentIPAddress .................................................................................. 202
11.17.2.25 GevPersistentSubnetMask............................................................................... 202
11.17.2.26 GevPrimaryApplicationIPAddress .................................................................... 202
11.17.2.27 GevPrimaryApplicationSocket.......................................................................... 203
11.17.2.28 GevPrimaryApplicationSwitchoverKey ............................................................. 203
11.17.2.29 GevSCDA ......................................................................................................... 203
11.17.2.30 GevSCFTD ....................................................................................................... 203
11.17.2.31 GevSCPD ......................................................................................................... 204
11.17.2.32 GevSCPHostPort.............................................................................................. 204
11.17.2.33 GevSCPInterfaceIndex..................................................................................... 204
11.17.2.34 GevSCPSDoNotFragment ............................................................................... 205

Baumer List of contents
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual ix
11.17.2.35 GevSCPSFireTestPacket ................................................................................. 205
11.17.2.36 GevSCPSPacketSize ....................................................................................... 205
11.17.2.37 GevSCSP ......................................................................................................... 206
11.17.2.38 GevSecondURL ............................................................................................... 206
11.17.2.39 GevStreamChannelSelector............................................................................. 206
11.17.2.40 GevSupportedOption........................................................................................ 206
11.17.2.41 GevSupportedOptionSelector .......................................................................... 207
11.17.2.42 InterfaceSpeedMode ........................................................................................ 207
11.17.3 PayloadSize .......................................................................................................................... 207
11.17.4 Category: PtpControl ............................................................................................................ 208
11.17.4.1 PtpClockAccuracy ............................................................................................ 210
11.17.4.2 PtpClockID........................................................................................................ 210
11.17.4.3 PtpDataSetLatch .............................................................................................. 210
11.17.4.4 PtpEnable ......................................................................................................... 211
11.17.4.5 PtpGrandmasterClockID................................................................................... 211
11.17.4.6 PtpMode ........................................................................................................... 211
11.17.4.7 PtpOffsetFromMaster ....................................................................................... 212
11.17.4.8 PtpParentClockID ............................................................................................. 212
11.17.4.9 PtpServoStatus ................................................................................................ 212
11.17.4.10 PtpStatus .......................................................................................................... 213
11.17.5 Category: TransportLayerControl → USB3Vision ................................................................ 214
11.17.5.1 InterfaceSpeedMode ........................................................................................ 214
11.17.5.2 SIControl........................................................................................................... 214
11.17.5.3 SIPayloadFinalTransfer1Size........................................................................... 214
11.17.5.4 SIPayloadFinalTransfer2Size........................................................................... 215
11.17.5.5 SIPayloadTransferCount .................................................................................. 215
11.17.5.6 SIPayloadTransferSize..................................................................................... 215
11.18 Category: UserSetControl ................................................................................................................... 216
11.18.1 UserSetDefault...................................................................................................................... 216
11.18.2 UserSetFeatureEnable ......................................................................................................... 216
11.18.3 UserSetFeatureSelector ....................................................................................................... 216
11.18.4 UserSetLoad ......................................................................................................................... 218
11.18.5 UserSetSave......................................................................................................................... 219
11.18.6 UserSetSelector.................................................................................................................... 219
11.19 Category: boCalibrationData............................................................................................................... 220
11.19.1 boCalibrationAngularAperture .............................................................................................. 220
11.19.2 boCalibrationDataConfigurationMode................................................................................... 220
11.19.3 boCalibrationDataSave ......................................................................................................... 220
11.19.4 boCalibrationDataVersion ..................................................................................................... 221
11.19.5 boCalibrationFocalLength ..................................................................................................... 221
11.19.6 boCalibrationMatrixSelector.................................................................................................. 221
11.19.7 boCalibrationMatrixValue...................................................................................................... 221
11.19.8 boCalibrationMatrixValueSelector ........................................................................................ 222
11.19.9 boCalibrationVectorSelector ................................................................................................. 222
11.19.10boCalibrationVectorValue ..................................................................................................... 222
11.19.11boCalibrationVectorValueSelector ........................................................................................ 223
11.19.12boGeometryDistortionValue.................................................................................................. 223
11.19.13boGeometryDistortionValueSelector .................................................................................... 223
12 USB interface functionality ........................................................................................................................ 224
12.1 Device information .............................................................................................................................. 224

List of contents Baumer
x Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
13 GigE interface functionality........................................................................................................................ 225
13.1 packet size and Maximum Transmission Unit (MTU).......................................................................... 225
13.2 Inter Packet Gap (IPG)........................................................................................................................ 225
13.3 Frame Transmission Delay ................................................................................................................. 227
13.4 Multicast .............................................................................................................................................. 230
13.5 IP-Konfiguration .................................................................................................................................. 231
13.5.1 Persistent IP.......................................................................................................................... 231
13.5.2 DHCP (Dynamic Host Configuration Protocol) ..................................................................... 231
13.5.3 LLA (Link-Local-Address) ..................................................................................................... 231
13.5.4 Force IP (Static IP)................................................................................................................ 232
13.6 Packet Resend.................................................................................................................................... 232

Baumer About this document | 1
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual 11
1 About this document
1.1 Purpose
This operating manual (subsequently referred to as manual) allows the safe and efficient han-
dling of the product .
The manual does not provide instructions on operating the machine in which the product is inte-
grated. Information on this is found in the operating manual of the machine.
The manual is a constituent part of the product. It must be kept in the immediate vicinity of the
product and must be accessible to personnel at all times.
Personnel must have carefully read and understood this manual before beginning any work.
The basic prerequisite for safe working is compliance with all safety instructions and handling
instructions given in this manual.
In addition, the local occupational health and safety regulations and general safety regulations
apply.
The illustrations in this manual are examples only. Deviations are at the discretion of Baumer at
all times.
1.2 Warnings in this manual
Warnings draw attention to potential personal injury or material damage. The warnings in this
manual indicate different hazard levels:
Symbol Warning term Explanation
DANGER Indicates an imminent potential danger with high risk of death or
serious personal injury if not being avoided.
WARNING Indicates potential danger with medium risk of death or (serious)
personal injury if not being avoided.
CAUTION Indicates a danger with low risk, which could lead to light or
medium injury if not avoided.
NOTE Indicates a warning of material damage.
INFO Indicates practical information and tips that enable optimal use of
the devices.

1 | About this document Baumer
12 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
1.3 Labels in this manual
Identifier Usage Example
Dialog element Indicates dialog elements. Click the OK button.
Unique name Indicates the names of products,
files, etc.
Internet Explorer is not supported
in any version.
Code Indicates entries. Enter the following IP address:
192.168.0.250
1.4 Liability limitation
All information and notes in this manual have been compiled in accordance with the applicable
standards and regulations, the state of the art, and our many years of knowledge and experi-
ence.
The manufacturer accepts no liability for damage due to the following reasons:
nNon-observance of the manual
nImproper use
nUse of unqualified personnel
nUnauthorized conversions
The obligations agreed in the delivery contract, the general terms and conditions and the deliv-
ery conditions of the manufacturer and its suppliers, as well as the legal regulations valid at the
time of conclusion of the contract apply.
1.5 Copyright
Any duplication or reprinting of this documentation, in whole or in part, and the reproduction of
the illustrations even in modified form is permitted only with the written approval of Baumer. The
information in this document is subject to change without notice.

Baumer General information | 2
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual 13
2 General information
Intended use
This product is a precision device and serves the detection of items, objects, or physical mea-
surement variables and the preparation or provision of measured values as electric variables for
the higher-level system.
Unless specifically labeled, this product may not be used in explosive environments.
Commissioning
Assembly, installation, and calibration of this product may only be performed by a specialist.
Installation
Only use the fasteners and fastener accessories intended for this product for installation. Out-
puts not in use must not be wired. Unused wires of cable outputs must be insulated. Do not go
below the permissible cable bending radii. Disconnect the system from power before the prod-
uct is electrically connected. Use shielded cables to prevent electro-magnetic interference. If the
customer assembles plug connections on shielded cables, then EMC-version plug connections
should be used and the cable shield must be connected to the plug housing across a large sur-
face area.
Disposal (environmental protection)
Used electrical and electronic devices may not be disposed of in household
waste. The product contains valuable raw materials that can be recycled. There-
fore dispose of this product at the appropriate collection point. For additional in-
formation visit www.baumer.com.

3 | Description Baumer
14 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
3 Description
3.1 VCXG.2
3.1.1 Conception
12
3
1 Lens mount (C-mount) 2 Power supply / Digital IO
3 Network connection with LEDs
3.1.2 LED status indicator
1
2
Signal Meaning
1 green Connection active
green flashing receiving data
2 yellow Error
yellow flashing Transmitting data

Baumer Description | 3
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual 15
3.1.3 Camera models
Camera type Sensor size Resolution
(Width × Height)
Max. FPS1)
Monochrom
VCXG.2-13M 1/2" 1280 × 1024 145 | 94
VCXG.2-15M 1/1.8" 1440 × 1080 120 | 79
VCXG.2-25M 2/3" 1920 × 1200 59 | 53
VCXG.2-32M 1/1.8" 2048 × 1536 55.5 | 39.5
VCXG.2-51M 2/3" 2448 × 2048 35.5 | 23.5
VCXG.2-51MP 1/1.8" 3072 × 2048 29 | 16
VCXG.2-57M 1/1.8" 2464 × 2048 25 | 25
VCXG.2-65M.R 1/1.8" 3072 × 2048 29 | 16
VCXG.2-82M 2/3" 2848 × 2832 15 | 15
VCXG.2-124M 1.1" 4096 × 3000 15 | 10
VCXG.2-127M 1/1.1" 4096 × 2992 10 | 10
VCXG.2-201M.R 1" 5472 × 3648 9 | 6
VCXG.2-204M 1/1.1" 4480 × 4496 6 | 6
VCXG.2-241M 1.2" 5312 × 4592 5 | 5
Color
VCXG.2-13C 1/2" 1280 × 1024 145 | 94
VCXG.2-15C 1/1.8" 1440 × 1080 120 | 79
VCXG.2-25C 2/3" 1920 × 1200 59 | 53
VCXG.2-32C 1/1.8" 2048 × 1536 55.5 | 39.5
VCXG.2-51C 2/3" 2448 × 2048 35.5 | 23.5
VCXG.2-57C 1/1.8" 2464 × 2048 25 | 25
VCXG.2-65C.R 1/1.8" 3072 × 2048 29 | 16
VCXG.2-82C 2/3" 2848 × 2832 15 | 15
VCXG.2-124C 1.1" 4096 × 3000 15 | 10
VCXG.2-127C 1/1.1" 4096 × 2992 10 | 10
VCXG.2-201C.R 1" 5472 × 3648 9 | 6
VCXG.2-204C 1/1.1" 4480 × 4496 6 | 6
VCXG.2-241C 1.2" 5312 × 4592 5 | 5
1) image acquisition to the camera's internal memory | Interface

3 | Description Baumer
16 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
3.1.4 Dimensional drawing
29
29
20
20
4,45
7,2
8,7
20
3
28,7
20
22
40
C-mount
6,6 ±0,3548,98,9
3
8 x M3 x 4
2 x M3 x 4
ø
Ill.1: Dimensional drawing - VCXG

Baumer Description | 3
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual 17
3.2 VCXG.2.XC
3.2.1 Conception
12 3
45
1 Lens mount (C-mount) 2 Cooling channel (inlet)
3 Cooling channel (outlet) 4 Network connection
5 Power supply / Digital IO
3.2.2 LED status indicator
1
2
Signal Meaning
1 green Connection active
green flashing receiving data
2 yellow Error
yellow flashing Transmitting data

3 | Description Baumer
18 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
3.2.3 Camera models
Camera type Sensor size Resolution
(Width × Height)
Max. FPS1)
Monochrom
VCXG.2-51M.XC 2/3" 2448 × 2048 35.5 | 23.5
VCXG.2-241M.XC 1.2" 5312 × 4592 5 | 5
1) Image is acquired to the camera's internal memory | Interface
3.2.4 Dimensional drawing
4 x M3 x 4,5
26
8,9 46,1 8,75
C-Mount
26
3,5
8 x M3 x 4,5
36,7
temperature
measurement
point
31
20
12,2
16
2xM3x4,5
2xM2x4,5
36
30
26
ø
Ill.2: Dimensional drawing - VCXG.XC

Baumer Description | 3
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual 19
3.3 VCXG.2.I
3.3.1 Conception
1
2 3 4
5
1 Lens mount (C-mount) 2 4 x tube adapter with front mounting
threads
3 Power supply / Digital IO 4 Network connection
5 GigE status indicator
3.3.2 LED status indicator
1 2
Signal Meaning
1 yellow Error
yellow flashing Transmitting data
2 green Connection active
green flashing receiving data

3 | Description Baumer
20 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
3.3.3 Camera models
Camera type Sensor size Resolution
(Width × Height)
Max. FPS1)
Monochrom
VCXG.2-15M.I 1/1.8" 1440 × 1080 120 | 79
VCXG.2-32M.I 1/1.8" 2048 × 1536 55.5 | 39.5
VCXG.2-51M.I 2/3" 2448 × 2048 35.5 | 23.5
VCXG.2-57M.I 1/1.8" 2464 × 2048 25 | 25
VCXG.2-82M.I 2/3" 2848 × 2832 15 | 15
VCXG.2-127M.I 1/1.1" 4096 × 2992 10 | 10
VCXG.2-201M.R.I 1" 5472 × 3648 9 | 6
VCXG.2-241M.I 1.2" 5312 × 4592 5 | 5
Color
VCXG.2-15C.I 1/1.8" 1440 × 1080 120 | 79
VCXG.2-32C.I 1/1.8" 2048 × 1536 55.5 | 39.5
VCXG.2-51C.I 2/3" 2448 × 2048 35.5 | 23.5
VCXG.2-57C.I 1/1.8" 2464 × 2048 25 | 25
VCXG.2-82C.I 2/3" 2848 × 2832 15 | 15
VCXG.2-127C.I 1/1.1" 4096 × 2992 10 | 10
VCXG.2-201C.R.I 1" 5472 × 3648 9 | 6
VCXG.2-241C.I 1.2" 5312 × 4592 5 | 5
1) image acquisition to the camera's internal memory | Interface
