baxter ZeoSys CONTRAfluran User manual

CONTRAfluran™
Anaesthetic Gas
Capture System:
User Guide
07-19-00-4044A1
Distributed byManufactured by

2
Customer
services
FAQs PIs
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
What is
CONTRAfluranTM
The CONTRAfluran™ canister captures all modern fluorinated gases.1However, from a manufacturing/reprocessing perspective, it is recommended that the CONTRAfluran™ canister is used only to capture
desflurane and/or sevoflurane. Should the CONTRAfluran™ canister be used to capture isoflurane, it is recommended that is is captured in a dedicated canister which is separate from that used to capture
desflurane and/or sevoflurane. For complete installation support, please contact your Baxter sales representative.
Item Part number
Starter kit includes:
1 x SENSOfluran™ Sensor Unit
5 x medical adapters
1 x hose
1 x power supply
2 x power adapters (UK & EU)
ZEO000040
Gas Capture Canister (pack/6) ZEO000050
What is included in
the starter kit?
The starter kit and the CONTRAfluran™
Gas Capture Canister pack provide
everything needed to install the system.1
The CONTRAfluran™ Anaesthetic Gas Capture System helps to reduce hospitals carbon footprint by collecting exhaled desflurane
and sevoflurane in the surgical suite.
What is the CONTRAfluran™
Anaesthetic Gas Capture System?
WARNING: When CONTRAfluranTM is used without an Anaesthetic Gas Scavenging System (AGSS), nitrous oxide cannot be used as this
cannot be adsorbed.1Nitrous oxide should also not be used when the anaesthetic ventilator is in passive mode.

3
Customer
services
FAQs PIs
What is
CONTRAfluranTM
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
The components
of CONTRAfluran™
The components of the CONTRAfluran™
Anaesthetic Gas Capture System
Power Cord
2SENSOfluran™
Sensor Unit
1CONTRAfluran™
Gas Capture Canister
3Hose

4
Customer
services
FAQs PIs
What is
CONTRAfluranTM
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
The components
of CONTRAfluran™
1CONTRAfluran™ Gas Capture Canister
The CONTRAfluran™ canister contains a highly porous material
that adsorbs and retains volatile anaesthetics.1One canister holds
approximately 240 mL (one bottle) of Suprane (desflurane, USP)
and/or sevoflurane.
CONTRAfluran™

5
Customer
services
FAQs PIs
What is
CONTRAfluranTM
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
The components
of CONTRAfluran™
If the red and green LEDs light up simultaneously and a warning signal sounds, this indicates the gas sensor is defective. Please contact customer
service for a replacement.
FULLEMPTY
If the red and green LEDs light up simultaneously and a warning signal sounds, this indicates the gas sensor is defective.1After ensuring that
a spare SENSOfluranTM Sensor Unit is not available, please contact customer service for a replacement. If all 4 LEDs light up one after the
other, this indicates that a canister has not been placed into the SENSOfluran™ unit.1Place a canister into the SENSOfluran™ unit and wait
for a permanent green light.1
1 yellow LED and
1 green LED
The capacity of the
canister is diminishing,
but the concentration of
the anaesthetic gas in
the filtered exhausted air
lies within the minimum
alveolar concentration
(MAC) accepted values.1
2 yellow LEDs
The filter is approaching
maximum capacity.1
The canister should
be replaced as soon
as possible.1
Red LED
The maximum capacity
of the filter has been
reached.1The red LED light
and audible alarm signify
that the canister needs
replacing immediately.1
Green LED
The filter captures the
expired gas and still has
sufficient free capacity.1
If the red and green LEDs light up simultaneously and a warning signal sounds, this indicates the gas sensor is defective. Please contact customer
service for a replacement.
FULLEMPTY
If the red and green LEDs light up simultaneously and a warning signal sounds, this indicates the gas sensor is defective. Please contact customer
service for a replacement.
FULLEMPTY
If the red and green LEDs light up simultaneously and a warning signal sounds, this indicates the gas sensor is defective. Please contact customer
service for a replacement.
FULLEMPTY
If the red and green LEDs light up simultaneously and a warning signal sounds, this indicates the gas sensor is defective. Please contact customer
service for a replacement.
FULLEMPTY
SENSOfluran™
The coloured LEDs of the device (green, yellow and red) indicate the quality of the remaining adsorption capacity of the
CONTRAfluranTM filter.1
2SENSOfluran™ Sensor Unit
The CONTRAfluran™ canister is placed into the SENSOfluranTM Sensor Unit.1The sensor unit is attached to the mounting rail on
the anesthesia machine. The anaesthetic gas scavenging (AGS) waste gas outlet from the anesthesia machine is hose-connected
to the inlet of the CONTRAfluran™ canister. The SENSOfluranTM Sensor Unit signals when the filter canister is full with both a visual
and audible signal.1

6
Customer
services
FAQs PIs
What is
CONTRAfluranTM
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
The components
of CONTRAfluran™
3Hose
The flexible hose connects the CONTRAfluran™ anaesthetic gas canister to the expiration gas outlet of the respirator
(AGS outlet).1The anaesthesia machine should be in passive operating mode before connecting the CONTRAfluranTM
canister to the outlet valve.
Other components:
Adapters
The operational adapters are for use with different exhaust ports.1
Power cord and power supply
The device must be connected to the provided plug-in power supply unit.1
Hose and other components

7
Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
How to install
CONTRAfluranTM
How to install the CONTRAfluran™
Anaesthetic Gas Capture System
Before using the CONTRAfluranTM Anaesthetic Gas Capture System, please ensure that the following components are available:
CONTRAfluranTM Anaesthetic Gas Capture Canister
SENSOfluranTM Sensor Unit
Accessories: flexible hose, operational adapters for use with different exhaust ports, power supply and power cord
Step 1:
Ensure the anaesthesia machine has been converted to passive gas scavenging mode/configuration.
• Please consult your anaesthesia machine User Manual or contact your anaesthesia machine company for support to convert
below model(s) of anaesthesia machines (or if your machine is not listed) to passive scavenging mode:
WARNING: when CONTRAfluranTM is used without an Anaesthetic Gas Scavenging System (AGSS), nitrous oxide cannot be used as
this cannot be adsorbed.1For more information on CONTRAfluranTM and SENSOfluranTM, including the anaesthetic gases these
can be used with, please see the CONTRAfluranTM and SENSOfluranTM Instructions For Use.1
Anaesthesia machine company Passive mode
conversion possible ()
Passive mode conversion
possible with additional part*
Passive mode conversion
not possible (X)
Dräger Primus, Fabius, Zeus, Apollo Perseus Atlan
GE -Avance, Aisys, Aestiva,
Aespire, Carestation 600/650 -
Löwenstein Leon/Leon Plus - -
Mindray All models - -
Getinge - - Flow-i
Dameca Philips - - All models
*Please consult representative of anaesthesia machine company for installation of the additional part needed for converting the specific anaesthesia machine model into passive mode

8
Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
How to install
CONTRAfluranTM
How to install the CONTRAfluran™
Anaesthetic Gas Capture System (continued)
Step 2:
Securely fasten the SENSOfluranTM Sensor Unit to the rail of the
respirator or anaesthesia machine.1
• The bracket can rotate 90 degrees to accommodate either a
vertical or horizontal bar. This allows the SENSOfluranTM unit to
be operated either with a view to the front or to the back of the
anaesthesia machine
• Place the SENSOfluranTM unit on the bar or rail at the point
furthest away from the anaesthesia machine. Ensure the area
beneath is clear of any obstruction, such as electrical equipment
or a drawer
• The bar or rail should be 27x30 mm in height and 6x10 mm in
width. This ensures that the clamp does not slip off the rail as
soon as it is loosened and that the star screw can always fix the
rail firmly in place

9
Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
How to install
CONTRAfluranTM
Step 3:
Place the CONTRAfluranTM canister into the SENSOfluranTM unit
and remove the seal cap from the canister.1
• Hold the white lid down with one hand when removing the
seal cap
• Retain the red cap for sealing the used canisters into zipper
bags later on
Step 4:
Attach the hose between the AGS outlet and CONTRAfluranTM
in a straight configuration (keep this as short as possible with
no U-loop).
• If required, reduce the length of hose by cutting it to
approximately 80 cm to make it as straight as possible
with no U-loop going from the anaesthesia machine to
the CONTRAfluranTM inlet
How to install the CONTRAfluran™
Anaesthetic Gas Capture System (continued)

10
Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
How to install
CONTRAfluranTM
Step 5:
Attach one end of the flexible hose to the AGS outlet on the
anaesthesia machine using one of the adapters provided in
the starter kit.
• Please note that the location and appearance of the AGS outlet
will vary from one anaesthesia machine to another
• The colour of the hose provided in the starter kit may vary
• Usually, a 30 mm (F; female) and 22 mm (M; male) hose
adaptor/connector (Intersurgical Scavenging Connector
No. 197100) can fit with most Dräger and Löwenstein
anaesthesia machines. Other adapters can also work
with an AnaConDa connection
Step 6:
Attach the inlet of the CONTRAfluranTM canister to the expiration
gas outlet valve (AGS outlet) of the anaesthesia machine by
means of a flexible hose.1
How to install the CONTRAfluran™
Anaesthetic Gas Capture System (continued)
AGS

11
Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
How to install
CONTRAfluranTM
Step 7:
Connect the mains adapter to the plug socket located on the bottom
of the SENSOfluranTM unit and plug it into a wall outlet.1
The SENSOfluranTM unit will enter a self-diagnostic mode consisting of:1
• An LED and acoustic test:
• All 4 LEDs will light up and an acoustic signal will sound for
1 second
• CONTRAfluranTM filter placement test:
• The red LED will light up for 10 seconds. If there is a canister
detected, the green LED will illuminate
• Following this, the green light will blink steadily and repetitively
for about 5 minutes until the sensor is ready for use
• After approximately 5 minutes, the green LED should be in a
steady state of illumination
• The system will now be ready for use
How to install the CONTRAfluran™
Anaesthetic Gas Capture System (continued)
WARNING: When CONTRAfluranTM is used without an Anaesthetic Gas Scavenging System (AGSS), nitrous oxide cannot be used as this
cannot be adsorbed.1Nitrous oxide should also not be used when the anaesthetic ventilator is in passive mode.

12
Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
Maintenance and
calibration of SENSOfluran™
To determine how often the SENSOfluran™ unit needs to be wiped down, please follow the hospital-established protocol for
wiping down the anaesthesia cart.1
To clean the surface of the SENSOfluran™ unit, wipe down with a cloth that is dampened with hydrogen peroxide (1%−1.5%)
or aqueous detergents.1DO NOT USE alcohol or aldehyde-based cleaners, as these will impact the performance of the
SENSOfluran™ unit.
1Please check daily for condensation in the hose.
The electrical unit within the SENSOfluran™ must be replaced every 12 months.1Please refer to the sticker on the SENSOfluran™
unit that shows the replacement date.1For a newly-calibrated unit, please contact Baxter customer service before the date
of expiration.1
Please keep spare SENSOfluranTM units in case of any malfunction.
Maintenance and calibration interval
of SENSOfluran™
CAUTION: Avoid wetting the electrical unit or the sensor during cleaning or sanitisation activities.1
Allow 10 minutes for exposure and drying time before placing the SENSOfluranTM Sensor Unit back into operation.1

Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
13
Returning the CONTRAfluran™
gas canisters
Once a CONTRAfluran™ gas canister is full, the red seal cap needs to be closed.1The canister then needs to be marked as used and
securely sealed in a protective zipper bag.1Six used filters (each in zipper bags) should be packed into the original shipping carton
and stored in a cool, dry, well-ventilated place.1
Baxter collects full canisters from the hospital and holds them in environmentally safe conditions. To arrange a canister collection,
please contact Baxter customer service.
Returning the CONTRAfluran™
gas canisters
To help optimise the gas
recycling process, the correct
box(es) should be ticked on the
sticker on top of each canister,
indicating which gas (or gases)
are contained within.1

14
Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
07-19-00-4044A1
SENSOfluran™ Sensor
Unit: Dos and Don’ts
SENSOfluran™ Sensor Unit:
Dos and Don’ts
Dos
Don’ts
Run a self-testing sequence in a separate area
Check if passive mode is available and configured on the
anaesthesia machine being used
Connect the SENSOfluranTM unit on a medical-rail system
(or similar system)1
Change the anaesthesia machine to passive mode
Use a connector to attach the transparent hose to the
AGS outlet
Insert a canister and connect the hose to the port of
the canister1
Run the system until the red light shows.1Remove the
used canister and replace with a new, unused canister1
Note that the canister may be changed at any time
Disconnect the power plug and reconnect it again if the
alarm and red light are inadvertently triggered
Use the original cardboard box (inserted into zipper bags)
to send back used canisters1
Clean the exterior of SENSOfluranTM unit with a hydrogen
peroxide swab1
Do not use any disinfectant near the base of the
SENSOfluranTM unit as the sensor is highly sensitive (it may
even be triggered by small amounts on your hands), but not
very selective, so this could pick up vapours from alcohols
and halogenated gases1
Do not make any modifications to the anaesthesia machine
without first consulting and gaining approval from the
manufacturer
Do not disconnect the hose without connecting
a new canister
Do not use this gas capture system if nitrous oxide
is going to be used.1This relates to cases when
CONTRAfluranTM is used without an AGSS. The
activated carbon filter will not adsorb nitrous oxide,
and SENSOfluranTM does NOT detect nitrous oxide1

Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
FAQs 15
During surgery After the canister is filled Installation
Section 1) Installation
1. Which gases does the CONTRAfluranTM canister capture?
The CONTRAfluranTM canister captures all fluorinated gases.1However, for practical purposes, it is recommended that this is used with desflurane
and sevoflurane, since the capturing of isoflurane will delay the desorption process of desflurane and sevoflurane from the canister.
2. What are the components of starter kit?
The starter kit includes the following components:
3. Who is responsible for the system installation and return of used canisters?
The Baxter sales team will support customers with installing the CONTRAfluranTM Gas Capture System. For returning used canisters,
the hospital will need to inform/call Baxter customer service to discuss their return request.
4. What voltage does the unit/power cord use?
It is designed for an operating voltage of 100V–240 V AC/47–63 Hz.1
5. If CONTRAfluranTM is not classified as a medical device, what is it categorised as?
The CONTRAfluranTM Gas Capture System falls under Class 1 of medical devices.1The devices in this category are mostly exempt from registration
in the EU due to low-to-moderate patient impact.
FAQs about CONTRAfluran™ and SENSOfluran™
Item Part number
Starter kit includes:
1 x SENSOfluran™ Sensor Unit
5 x medical adapters
1 x hose
1 x power supply
2 x power adapters (UK & EU)
ZEO000040
Gas Capture Canister (pack/6) ZEO000050

Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
FAQs 16
During surgery After the canister is filled Installation
6. What will make the alarm on the SENSOfluran™ unit go off inadvertently?
Do not use volatile alcohol-based disinfectant near the base of the SENSOfluran™ unit as the sensor is highly sensitive and this will trigger the alarm
(even small amounts of disinfectant on your hands may trigger the alarm). The sensor is not very selective and could pick up vapours from alcohol and
halogenated gases.
If the alarm and red light are inadvertently triggered, disconnect the power plug and reconnect it again.
Please consider writing the date of installation on a new canister to help evaluate whether this needs to be changed in the event of false alarms.
7. Have the canisters been validated to be placed on anaesthesia machines by the manufacturers?
Will it affect the machines warranty OEMs?
Baxter has informed Dräger/GE/Maquet of this product. To make any mechanical changes in order to use CONTRAfluranTM with a
Dräger/GE/Maquet anaesthesia machine, the hospital should contact their local anaesthesia machine sales representative.
8. What are the dimensions of the Sensor Unit and the canister?
Technical data1
Section 1) Installation
FAQs about CONTRAfluran™ and SENSOfluran™
SENSOfluranTM
fill level control unit
External material Powder-coated aluminium
Temperature +5°C to +35°C
Voltage
Power supply (Euro)
100V–240V AC/47–63 Hz
Output 6.0V DC
Power consumption approx: 6W
Weight Approx. 700 g
Measurements of
the circuit board (50x55x20) mm
Grout circuit board Bectron MR 3404
External wall wart ATM006T-W060E; GSM06E06-P1J;
GEM06106-P1J
CONTRAfluranTM
anaesthetic gas canister
Product-class according to MPG Class 1
Temperature Operation: +5°C to +35 °C
Storage: –5°C to +35 °C
Relative humidity Operation: to 70%
Storage: to 70%
Storage capacity Approx. 400 g
Flow-Resistance ≤ 0.15 mbar
Height 19 cm
Diameter 12 cm
Weight Approx. 1,000 g
Volume 2 L

Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
FAQs 17
During surgery After the canister is filled Installation
Section 1) Installation
9. Is the device MRI compatible?
The SENSOfluranTM Sensor Unit should not be used in the vicinity of an MRI scanner. The strong, static magnetic field of the MRI scanner may cause unwanted
movement, including dangerous projectile motion of the device. The radiofrequency energy and magnetic fields that change with time may also cause heating
of the metallic housing, which could lead to burns.
However, the CONTRAfluranTM canister is non-metallic and could be used alone in the vicinity of an MRI scanner if connected to a hose that does not contain
any metallic components (e.g. reinforcing ribs).
To ensure the safe use of CONTRAfluranTM inside an MRI room, hospital staff should conduct a thorough check of the hose and other accessories connected
to the CONTRAfluranTM canister to confirm that there are no metallic materials inside the safety zone defined by the MRI scanner manufacturer.
10. Is it device latex free?
Yes, the SENSOfluran™ unit is latex free.
11. Can we purchase circuit boards separately?
Yes, there is a separate part number for ordering circuit boards.1This is: ZEO000042.1
12. I believe the AGSS needs to be turned off when using CONTRAfluranTM with an anaesthesia machine.
Do we have detailed instructions on how this is done? Or preferably, will the hospital or manufacturer
representatives do this?
Anaesthesia machines need to be configured for PASSIVE gas scavenging. The Hospital Biomedical engineers/qualified technicians will be able to make changes
to the anaesthesia machine AGSS. To make the mechanical changes required to use the CONTRAfluranTM unit with a Dräger/GE/Maquet anaesthesia machine, the
hospital should contact their local anaesthesia machine sales representative.
For hospitals that do not want to switch off their AGSS, we have developed SENSOfluranTM PLUS. This can be connected to the AGSS, but the anaesthesia machine
still needs to be changed to passive mode. SENSOFluranTM PLUS also provides a solution for hospitals using nitrous oxide.
Please note, nitrous oxide must ONLY be used when the hospital’s AGSS is connected to SENSOFluranTM PLUS.
FAQs about CONTRAfluran™ and SENSOfluran™

Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
FAQs 18
During surgery After the canister is filled Installation
Section 1) Installation
13. How do we know that we can switch off the AGSS and it will still be safe for staff?
The CONTRAfluranTM unit captures 99% of a patient’s exhaled anaesthetic gas in the operating theatre.2ZeoSys conducted testing that showed how gas escape
was minimal. Hospitals should exercise caution when setting up their inhaled anaesthetic circuits to ensure that there are no leaks elsewhere in the system.
Only gas that passes through the CONTRAfluranTM filter will be adsorbed. There is a test protocol available for hospitals to test this themselves if they choose to.
In the event that hospital personnel smell any anesthetic gas when using the CONTRAfluranTM system, please check all connections to determine the source.
14. What are the mounting options available?
The bracket on the SENSOfluranTM unit seems to work for all anaesthesia machines seen to date. It can rotate 90 degrees to accommodate either a vertical
or horizontal bracket on the back of all anaesthesia machines. This allows SENSOfluranTM to be operated either with a view to the front or to the back of the
anaesthesia machine.
The images below demonstrate how the SENSOfluranTM unit can be installed on different anaesthesia machines
15. When we try to pull off the red cap, the lid also comes off quite easily. How do we stop this?
Hold the white lid down with one hand while removing the red cap. Ensure the lid is firmly attached after removing the red cap and hose connection.
FAQs about CONTRAfluran™ and SENSOfluran™

Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
FAQs 19
During surgery After the canister is filled Installation
Section 1) Installation
16. Will there be any risks (such as activated carbon spilling on the floor or captured gas leakage)
if the container falls on the floor and lid comes off?
No, there is no risk. In the event of a spillage, collect and place the contents in a Ziploc®bag and place it in the normal waste receptacle.
17. Does this system fit all anaesthesia machines?
Currently the Zeosys gas capturing technology can function with any anaesthesia machine that can be configured for passive scavenging mode. Dräger, GE and
machines from other manufacturers are designed to provide this scavenging configuration. There are a few machines, such as Dräger Atlan and Getinge Flow,
that do not have the ability to be configured to passive mode. In case of doubt, please consult the manufacturer of the anaesthesia machine.
FAQs about CONTRAfluran™ and SENSOfluran™

Customer
services
FAQs PIs
What is
CONTRAfluranTM
The components
of CONTRAfluran™
How to install
CONTRAfluranTM
Returning the CONTRAfluran™
gas canisters
Maintenance and
calibration of SENSOfluran™
SENSOfluran™ Sensor
Unit: Dos and Don’ts
07-19-00-4044A1
FAQs 20
During surgery After the canister is filled Installation
FAQs about CONTRAfluran™ and SENSOfluran™
Section 2) During surgery
1. Can one canister capture a combination of sevoflurane and desflurane?
Yes, one canister can capture a mixture of the two gases.
2. Do the inhalational anesthetic gases need to be manufactured by Baxter, or can the canisters capture gases regardless of
the manufacturer?
The canisters are designed to capture sevoflurane or desflurane1regardless of the manufacturer.
3. How long does it take to fill one canister?
The time taken to fill one canister will vary depending on the FGF (fresh gas flow) rate and concentration (similar to how the length of time a container of
sevoflurane or desflurane lasts seems to vary). However, on average, the canister lasts ~3 days, but this will vary significantly depending on the circumstances.
Regardless, a CONTRAfluranTM filter is likely to accommodate a full canister of inhalational anaesthetic gas.
4. Can the canister be changed mid-surgery?
Yes, the amount of gas released from the hose while changing the canister is not significant. The new canister should be readily accessible
so that the anaesthesia gas hose can be disconnected quickly from the used canister and attached to the new one.
5. Does the SENSOfluranTM Sensor Unit work by weighing the canister or does it physically analyse the gas flow?
The sensor unit does not work by weighing the canister. Instead, there is a gas sensor built into the bottom of the sensor unit. The gas detector analyses the air
that flows out of the canister through a small hole in the bottom of the canister. The gas sensor can detect different types of anaesthetic gases.
• Please note, SENSOfluranTM does not detect nitrous oxide and CONTRAfluranTM does not capture nitrous oxide1
6. Will the CONTRAfluranTM canister capture all gases (including nitrous oxide and isoflurane) or just sevoflurane and desflurane?
The technology is currently designed to capture only fluorinated halocarbon inhaled anaesthetic gases (more specifically, sevoflurane and desflurane)
from the expired air of a patient.1The system can capture isoflurane, but Baxter will not collect the canisters filled with isoflurane. It does not capture nitrous oxide.
