BCP SKY6126 User manual

SKY6126 + SKY6127
INSTRUCTION
MANUAL
Computer Desk
Ver. 2

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.

| 3
HARDWARE
TOOLS REQUIRED
1
4 PCS
M6 X 12MM
BOLT
M6 X 28MM
BOLT
2
11 PCS
•Please do not exceed the weight limitations of this item.
•Do not stand on or use any part of this item as a step ladder.
•Firmly secure all bolts, screws, and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is
completely assembled.
•Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
•Be aware that some parts are heavy and have sharp edges.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void
the product warranty.
NOTICE
3
22 PCS
M6 X 30MM
BOLT
4
5 PCS
M6 X 40MM
BOLT
8
12 PCS
FASTENING
SCREW
7
15 PCS
M6 END NUT
5
2 PCS
M6 X 46MM
BOLT
M6 X 48MM
BOLT
6
1 PC
Please retain these instructions for future reference.
9
2 PCS
JOINER PLATE
UP TO 30 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
200 LBS
CAPACITY
LBS
WRENCH
(PROVIDED)
ALLEN WRENCH
(PROVIDED)
PHILLIPS
SCREWDRIVER

4|
D
2 PCS
END FRAME PANEL
PARTS
1 PC
LEFT DESKTOP
A
1 PC
RIGHT DESKTOP
B
1 PC
BACK SUPPORT PANEL
F
E
1 PC
MIDDLE FRAME PANEL
1 PC
CENTER DESKTOP
C
J
1 PC
MALE CONNECTOR
PANEL
2 PCS
BACK CONNECTOR
PANEL
G
1 PC
FRONT CONNECTOR
PANEL
H
8 PCS
FOOT
L
K
4 PCS
SUPPORT ROD
1 PC
FEMALE CONNECTOR
PANEL
I

PRODUCT ASSEMBLY (CORNER DESK)
1Attach the part I female connector rod to the part J male connector rod with two part 1 bolts,
then set aside.
Locate the part E middle frame panel and attach to the part F back support panel with two
part 5 bolts and two part 7 end nuts, then set aside.
Attach one part G back connector rod to one part D end frame panel with one part 4 bolt.
| 5
PARTS
3 PC
WIRE FUNNEL
M
This product features two construction methods,
depending on your preference.
G
D
E
F
4
I
J
1x2
7x2
5
x2

PRODUCT ASSEMBLY (CORNER DESK)
6|
2Connect the part G connector rod to the back support panel assembly with one part 2 bolt and
one part 7 end nut.
Connect the part D and E panels with the male/female connector rod and secure with two part
4 bolts.
3Attach one part G connector rod to the part E middle panel with one part 2 bolt and one part 7
end nut.
Attach the part H front connector rod to the part J connector rod with one part 2 bolt and one
part 7 end nut.
Attach the part D end panel with two part 4 bolts.
2x2
G
H
G
D
D
E
E
J
2
7
4x2
4x2
7x2

4Secure two support rods between the part D and E panels with four part 2 bolts and four part 7
end nuts. Connect the rods with one part 1 bolt and one part 7 end nut.
Secure two support rods between the part D and F panels with four part 2 bolts and four part 7
end nuts. Connect the rods with one part 1 bolt and one part 7 end nut.
| 7
5Locate the part B and C tabletops and attach two part 9 joiner plates with twelve part 8 screws.
Flip the frame assembly and attach the tabletop with fourteen part 3 bolts. Locate the part A
tabletop and attach with eight part 3 bolts.
Insert eight part L feet.
PRODUCT ASSEMBLY (CORNER DESK)
2x8 1x2
7x10
C
BA
K
x4
L
x8
9
8
x12
x2
3x22

PRODUCT ASSEMBLY (LONG DESK)
1Attach the part I female connector rod to the part J male connector rod with two part 1 bolts,
then set aside.
Locate the part E middle frame panel and attach to the part F back support panel with one part
5 bolts and one part 7 end nut, then set aside.
Attach one part G back connector rod to one part D end frame panel with one part 4 bolt.
8|
6Flip the assembly and insert three part M wire funnels into the tabletop.
PRODUCT ASSEMBLY (CORNER DESK)
G
D
E
F
4
57
I
J
1x2

PRODUCT ASSEMBLY (LONG DESK)
| 9
2Connect the part G connector rod to the back support panel assembly with one part 2 bolt and
one part 7 end nut.
Connect the part D and E panels with the male/female connector rod and secure with two part
4 bolts.
3Attach one part G back connector rod to the part E panel with one part 6 bolt and one part 7
end nut.
Attach the part H front connector rod to the part E panel rod with one part 2 bolt and one part
7 end nut.
Attach the part D end panel with two part 4 bolts.
2
E
D
G
2
7
D
E
4
x2
4
x2
67x2
G
H

10 |
PRODUCT ASSEMBLY (LONG DESK)
4Secure two support rods between the part D and E panels with four part 2 bolts and four part 7
end nuts. Connect the rods with one part 1 bolt and one part 7 end nut.
Secure two support rods between the part D and F panels with four part 2 bolts and four part 7
end nuts. Connect the rods with one part 1 bolt and one part 7 end nut.
5Locate the part B and C tabletops and attach two part 9 joiner plates with twelve part 8 screws.
Flip the frame assembly and attach the tabletop with fourteen part 3 bolts. Locate the part A
tabletop and attach with eight part 3 bolts.
Insert eight part L feet.
2x8
1x2
7x10
C
B
A
K
x4
L
x8
9x2
8x12
3x22
