BCP Maserati Alfieri Ride-On User manual

SKY4734 + SKY4735
Ver. 1
INSTRUCTION
MANUAL
Maserati Alfieri Ride-On

Charge item 8 to 12 hours
before initial use.
After initial charge, follow
the normal recommended
charging time.
bestchoiceproducts.com

Pg. 3
Please retain these instructions for future reference.
SAFETY
BATTERY WARNINGS
This vehicle must be assembled by an adult who has read and understood the instructions in this manual.
Keep the packaging and bags away from children and dispose of all packaging before use. Always use
common sense and safe practices when operating this vehicle. This product contains or emits chemicals
known in the state of California to cause cancer or birth defects or other reproductive harm.
NOTE: For best performance, only use this vehicle on flat and hard surfaces.
Age Range: 3 to 8 years old
Weight Capacity: 66 lbs.
The following safety hazards may result in serious injury or death:
• This product contains small parts. Keep children away during assembly. Make sure to remove all
packaging material and parts from underneath the vehicle body.
•Never open the battery. Batteries contain lead and lead compounds (acids) that are toxic and corrosive,
and known to the state of California to cause cancer and reproductive harm.
•Limbs, hair, and clothing can get caught in moving parts. Always wear shoes, keep limbs away from
moving parts, and do not wear loose clothing while operating this vehicle.
•This vehicle does not have brakes or braking capability. Do not leave a child unattended during
operation. Do not use this in a location that may require braking capability, as this could result in loss of
control, which may cause serious injury or death.
•Use of this vehicle near streets, motor vehicles, steps, bodies of water, sloped surfaces, hills, wet areas,
flammable vapors, in alleys, at night, or in the dark could result in an unexpected accident.
•Use of this vehicle in unsafe conditions such as snow, rain, loose dirt, mud, sand, or gravel may result in
an unexpected accident such as tipping over, and could damage the electrical system or battery.
•Do not operate this vehicle in an unsafe manner. Examples include but are not limited to:
- Pulling the vehicle with another vehicle or similar device
- Allowing more than one rider
- Pushing the user
- Traveling at an unsafe speed
The following safety hazards may result in serious injury or death:
•Use of a battery or charger other than the supplied rechargeable battery and charger may cause a fire or
explosion. Only use the supplied battery and charger.
•Use of the rechargeable battery and charger for any other product may result in overheating, fire,
or explosion. Never use the supplied rechargeable battery and charger with another product.
•Explosive gases are created during charging. Charge the battery in a well-ventilated area. Do not charge
the battery near heat or flammable materials.
•Contact between the positive and negative terminals may result in fire or explosion. Avoid direct contact
between the terminals. Picking up the battery by the wires or charger can cause damage to the battery
and may result in a fire. Always pick up the battery by its case or handles.
•Liquids on the battery may cause fire or electric shock. Always keep all liquids away from the battery and
keep the battery dry. Contact or exposure to battery leakage (lead acid) may cause serious injury.
If contact or exposure occurs immediately call your physician. If the chemical is on the skin or in the eyes,
flush with cool water for 15 minutes. If the chemical was swallowed, immediately give the person water
or milk. Do not give water or milk if the patient is vomiting or has a decreased level of alertness.
Do not induce vomiting.
•Battery posts, terminals, and related accessories contain lead and lead compounds (acid) – chemicals
known to the State of California to cause cancer, reproductive harm, and are toxic and corrosive. Never
open the battery.
•Tampering or modifying the electric circuit system may cause a shock, fire or explosion and permanently
damage the system. Exposed wiring and circuitry in the charger may cause electric shock. Always keep
the charger housing closed.

Pg. 4
USER WARNINGS
SPECIFICATIONS
The following safety hazards may result in serious injury or death:
•Never leave a child unattended.
•Always sit in the seat when using this vehicle.
•Keep your hands, hair, and clothes away from moving parts.
•Always wear shoes when operating this vehicle.
•Only one rider is allowed on the vehicle at a time.
•Children under 3 years of age cannot use the vehicle.
•Only drive on level ground.
•Do not go near swimming pools or other bodies of water, drop-os, or up and down steep inclines.
•Do not drive the vehicle into loose dirt, mud, sand, fine gravel, or on wet surfaces.
•Do not drive the vehicle on streets or near cars.
Overall Dimensions
Weight
Weight Capacity
Age Range
Max Speed
Charging Time
Run Time
Battery Type
Electric Motor
Charger
Materials
47.5"(L) x 28.5"(W) x 21"(H)
51 lbs.
66 lbs.
3 – 8 years old
3.1 mph.
8 – 12 hours
Initial Charge Time 8 - 12 hours
1 – 2 hours
12V 7AH
Double drive: 12V
Output: DC 12V
PP Plastic, Metal

Pg. 5
66 LBS
CAPACITY
LBS
APPROXIMATELY
45 MIN.
ASSEMBLY
2 PERSON
ASSEMBLY
TOOLS REQUIRED
PARTS
A
2 PCS
FRONT WHEEL
G
2 PCS
SIDE MIRROR (L/R)
F
1 PC
WINDSHIELD
E
2 PCS
WINDOW (L/R)
B
2 PCS
REAR WHEEL
I
1 PC
REMOTE CONTROL
C
1 PC
SEAT
D
1 PC
STEERING WHEEL
H
1 PC
12V CHARGER
2 AA BATTERIES
(FOR REMOTE)
+AA -
SCISSORS
(OPTIONAL)

Pg. 6
PRODUCT ASSEMBLY
Make sure the rear axle is positioned evenly on the car. Slide a part B rear wheel onto the rear axle.
Compress the button on the wheel, push it in place, then release the button to lock it.
Repeat on the other side.
Slide a part A front wheel onto the front axle. Compress the button on the wheel, push it in place,
then release the button to lock it. Repeat on the other side.
Remove all packaging and parts from the interior of the car.
Check the hood and truck for parts. Flip the car over and lay it on a level surface.
B
B
1
2
AA

Remove caps from the rods on the part E seat.
Slide the seat into the holes and press the front
of the seat down to snap it in place.
NOTE: Compress the handle under the seat to
adjust it forwards and backwards.
3
Pg. 7
TOOLS REQUIREDPRODUCT ASSEMBLY
C

Join the connector from the part F steering wheel
to the connector on the steering wheel mount.
Compress the buttons on the side of the mount,
slide the steering wheel in, then release the button
to lock it in place.
NOTE: Compress the buttons to adjust the
steering wheel height.
Pg. 8
TOOLS REQUIREDPRODUCT ASSEMBLY
4
D

Snap on the part D windshield.
Firmly insert two part C windows,
one on each side.
5
PRODUCT ASSEMBLY
Pg. 9
6
E
F
x2

OPEN HOOD
CHARGING
SOCKET
Within the hood, connect the red wire to the red terminal on the battery.
Insert two part G side mirrors, one on each side.
7
PRODUCT ASSEMBLY
Pg. 10
8
G
x2

CHARGING INSTRUCTIONS AND WARNINGS
CARING FOR YOUR RIDE-ON
• There are two charging ports on this vehicle. One charging socket is located on the dashboard
(see Dashboard Diagram). Insert one end of the part H charger into the charging socket and plug
the other end into a wall outlet.
• Another charging socket is on the battery. Compress the battery lock and remove the battery to
charge it directly.
• Charge the battery 8 to 12 hours before initial use.
• On average, you will need to charge the battery between 8 and 12 hours. Do not charge the battery
for more than 20 hours. Failure to charge the battery as directed could cause permanent damage
to the battery and void the warranty.
• Damage to the battery may occur if it is allowed to drain completely. Do not allow the battery to
drain completely.
• Check the battery and charger (supply cord, connector) for wear and damage before charging.
Do not charge the battery if damage has occurred.
• Only an adult who has read and understood the safety warnings should handle, charge and
recharge the battery.
• Park the vehicle indoors or cover it with a tarp to protect it from wet weather.
• Do not leave the vehicle in the sun for long periods of time or fading may occur. Store in shade or
cover with tarp.
• Do not wash the vehicle with a hose.
• Do not wash the vehicle with soap.
• Charge battery at least once a month to prolong the life of the battery.
Pg. 11

MEDIA PLAYER
POWER SWITCH
JOKE MODE
AUX INPUT
PRE-PROGRAMMED MUSIC
PLAY/PAUSE FORWARD/VOLUME+
BACK/VOLUME-
USB PORT
ENGLISH PRACTICE MODE
MICROSD
(TF) PORT
STORYTELLING MODE
FORWARD
PARK
REVERSE
CHARGING PORT
•Push down on the pedal to drive forward/reverse. Release the pedal to slow down and stop.
• USB Port: Play music from a USB drive
• MicroSD (TF) Port: Play music from a MicroSD card
• Forward/Volume+: Short press to play to the next song, long press to increase volume
• Back/Volume-: Short press to play the previous song, long press to decrease volume
• AUX Input: Plug in a music player to play music
POETRY MODE
TOGGLE MUSIC MODE
DASHBOARD DIAGRAM
MEDIA PLAYER
Pg. 12

TROUBLESHOOTING
Reason
Low battery
Electrical protection
Switch not in the correct position
Battery connectors disconnected
Low battery
Overloaded vehicle
Uneven or sloped road
Loose connection to motor
Battery connectors disconnected
Charger not connected to socket
or outlet
Battery does not have a full charge
Normal
Problem
Battery is warm and
makes a slight noise
while charging
Slow speed
Vehicles shakes
while driving
Battery does not last
Battery does not recharge
Vehicle does not move
Solution
Fully charge the battery
Stop use for several minutes and restart
Completely press in switches
Plug in battery connectors
Fully charge the battery
Reduce the weight on the vehicle
Drive on flat pavement
Ensure the motor is properly connected
to the battery
Plug in battery connectors
Completely plug in the charger
Fully charge the battery
Normal
Diculty shifting between
forward/reverse Only shift when the vehicle is at a stop
Vehicle is silent Properly connect the steering
wheel connector
Attempting to shift while
vehicle in motion
Steering wheel is not
properly connected
REVERSE
FORWARD
SPEED INDICATOR
(MIDDLE LIGHTS)
PARK
SPEED SELECT
TURN RIGHT
TURN LEFT
FREQUENCY KEY
Linking the remote control:
1. Turn the vehicle on.
2. Press and hold the frequency key. Release the key when the speed indicator light flashes.
3. The speed indicator light will turn solid to indicate a successful link.
4. If link fails, remove the batteries and repeat steps 1 to 3.
•Insert 2 AA batteries into the part I remote control
I
REMOTE CONTROL DIAGRAM
Pg. 13

Pg. 14
CAR FEATURES

Thank you for choosing us! Since 2002, Best
Choice Products has been bringing customers
high-quality products at the absolute lowest
price. With everything ranging from instruments
and toys to furniture and outdoor, we’ve got
your everyday living essentials covered. We’re
centered around a customer-first philosophy –
with free shipping, exceptional customer
service, and a catalog sourced with you in mind.

ASSEMBLY IS COMPLETE!
All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the
item is returned in its original product packaging and all accessories from its original shipment are included. All
returned items will receive a full refund back to the original payment method. All returned items will not be charged
a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best Choice
Products Customer Service Representative when the return request is submitted. Items received without an RA
may not be accepted or may increase your return processing time. Once an item has been received by Best Choice
Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If the
reason for return is a result of an error by Best Choice Products then Best Choice Products will provide a pre-paid
shipping label via email. Boxes for return shipping will not be provided by Best Choice Products, and is the
customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items returned are
not considered undamaged until they are received by Best Choice Products and verified as such. All damages to
items are the customer’s responsibility until the item has been received by and acknowledge by Best Choice
Products as undamaged.
CONTACT US; WE’RE HERE 7 DAYS A WEEK TO HELP YOU!
WARNING
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
PRODUCT WARRANTY INFORMATION
bestchoiceproducts.com customerservice@
bestchoiceproducts.com 844.948.8400 LEARN MORE!
Use the blinker to turn on
and o the lights.
