BCP SKY4767 User manual

SKY4767 + SKY4768
Ver. 2
INSTRUCTION
MANUAL
Bentley EXP 12 Ride-On
with Remote Control

bestchoiceproducts.com
Charge for 4 - 6 hrs
before initial use.
After initial charge,
follow the normal
recommended
charging time.

| 3
Please retain these instructions for future reference.
SAFETY
This vehicle must be assembled by an adult who has read and understood the instructions in this manual.
Keep the packaging and bags away from children and dispose of all packaging before use. Always use
common sense and safe practices when operating this vehicle. This product contains or emits chemicals
known in the state of California to cause cancer or birth defects or other reproductive harm.
NOTE: For best performance, only use this vehicle on flat and hard surfaces.
AGE RANGE: 3 to 8 years old
WEIGHT CAPACITY: 66 lbs.
The following safety hazards may result in serious injury or death:
• This product contains small parts. Keep children away during assembly. Make sure to remove all packaging
material and parts from underneath the vehicle body.
• Never open the battery. Batteries contain lead and lead compounds (acids) that are toxic and corrosive,
and known to the state of California to cause cancer and reproductive harm.
• Limbs, hair, and clothing can get caught in moving parts. Always wear shoes, keep limbs away from
moving parts, and do not wear loose clothing while operating this vehicle.
• This vehicle does not have brakes or braking capability. Do not leave a child unattended during operation.
Do not use this in a location that may require braking capability, as this could result in loss of control,
which may cause serious injury or death.
• Use of this vehicle near streets, motor vehicles, steps, bodies of water, sloped surfaces, hills, wet areas,
flammable vapors, in alleys, at night, or in the dark could result in an unexpected accident.
• Use of this vehicle in unsafe conditions such as snow, rain, loose dirt, mud, sand, or gravel may result in
an unexpected accident such as tipping over, and could damage the electrical system or battery.
• Do not operate this vehicle in an unsafe manner. Examples include but are not limited to:
- Pulling the vehicle with another vehicle or similar device
- Allowing more than one rider
- Pushing the user
- Traveling at an unsafe speed
BATTERY WARNINGS
The following safety hazards may result in serious injury or death:
• Use of a battery or charger other than the supplied rechargeable battery and charger may cause a fire
or explosion. Only use the supplied battery and charger.
• Use of the rechargeable battery and charger for any other product may result in overheating, fire,
or explosion. Never use the supplied rechargeable battery and charger with another product.
• Explosive gases are created during charging. Charge the battery in a well-ventilated area. Do not charge
the battery near heat or flammable materials.
• Contact between the positive and negative terminals may result in fire or explosion. Avoid direct contact
between the terminals. Picking up the battery by the wires or charger can cause damage to the battery
and may result in a fire. Always pick up the battery by its case or handles.
• Liquids on the battery may cause fire or electric shock. Always keep all liquids away from the battery and
keep the battery dry. Contact or exposure to battery leakage (lead acid) may cause serious injury.
If contact or exposure occurs immediately call your physician. If the chemical is on the skin or in the eyes,
flush with cool water for 15 minutes. If the chemical was swallowed, immediately give the person water
or milk. Do not give water or milk if the patient is vomiting or has a decreased level of alertness. Do not
induce vomiting.
• Battery posts, terminals, and related accessories contain lead and lead compounds (acid) – chemicals
known to the State of California to cause cancer, reproductive harm, and are toxic and corrosive.
Never open the battery.
• Tampering or modifying the electric circuit system may cause a shock, fire or explosion and permanently
damage the system. Exposed wiring and circuitry in the charger may cause electric shock. Always keep
the charger housing closed.

4|
USER WARNINGS
SPECIFICATIONS
• Never leave a child unattended.
• Always sit in the seat when using this vehicle.
• Keep your hands, hair, and clothes away from moving parts.
• Always wear shoes when operating this vehicle.
• Only one rider is allowed on the vehicle at a time
• Children under 3 years of age cannot use the vehicle.
• Only drive on level ground.
• Do not go near swimming pools or other bodies of water, drop-os, or up and down steep inclines.
• Do not drive the vehicle into loose dirt, mud, sand, fine gravel, or on wet surfaces.
• Do not drive the vehicle on streets or near cars.
Overall Dimensions
Weight
Weight Capacity
Age Range
Max Speed
Charging Time
Run Time
Battery Type
Electric Motor
Charger
Material
42"(L) x 22.75"(W) x 17.5"(H)
32 lbs.
66 lbs.
3 – 8 years old
3.1 mph.
8 – 12 hours
Initial Charge Time 4 - 6 hours
1-2 hour
1 - Rechargeable SLA - 6V/7AH
Double Drive: 6V
Output: DC 6V
PP Plastic, Metal

PLASTIC SPANNER
(PROVIDED)
PHILLIPS
SCREWDRIVER
TOOLS
HARDWARE
APPROXIMATELY
45 MIN.
ASSEMBLY
2 PEOPLE
ASSEMBLY
Spare parts may be included
1 AAA BATTERY
+-
AAA
A
4 PCS
NUT
2 PCS
SPACER
4 5
A
8 PCS
M4x13mm SCREW
2 PCS 6 PCS
M5x18mm SCREW
12WASHER
3
PARTS
A
2 PCS
GEAR BOX (L/R)
2 PCS 2 PCS
REAR WHEEL
ABFRONT WHEEL
C
2 AA BATTERIES
+AA -
| 5

PS
A
4 PCS
CAP
2 PCS 1 PC
MOTOR HOOD
D
A
1 PC
SEAT
G
ESTEERING WHEEL
F
2 PCS
SIDE MIRROR (L/R)
I
1 PC
WINDSHIELD
H
PARTS
A
1 PC
REMOTE CONTROL
J
1 PC
6V CHARGER
K
6|

Slide a part 3 washer, part 5 spacer, and part C front wheel onto the front axle,
then secure it with another washer and part 4 nut.
Repeat on the other side. Snap a part D cap onto each wheel.
Slide a part A gear box onto the rear axle. Route the wires from the gear box through the body
of the vehicle and into the seat. Slide on a part B rear wheel and part 3 washer, then secure it
with a part 4 nut. Repeat on the other side.
x2 C
x6 3
REAR
FRONT
x2
B
x4
D
PRODUCT ASSEMBLY
1
x4
4
x2
A
x2 5
| 7

PRODUCT ASSEMBLY
2
8|
Within the seat, join the connectors from the gear boxes to the corresponding connectors.
Insert the red wire into the red terminal on one of the batteries.
Attach two part E motor hoods with eight part 1 screws, four screws per motor hood.
Position motor hoods so the
tracks face the inside & wires
route through the tracks.
x2
E
x8
1
CHARGING PORT

Snap on the part H windshield.
Remove the battery cover from the part F
steering wheel, install two AA batteries,
then replace the battery cover.
Remove the nut and bolt from the
steering wheel, slide it onto the steering
mount, and then replace the nut and bolt
to secure the steering wheel.
PRODUCT ASSEMBLY
3
4
F
H
| 9

Insert two part I side mirrors, one on each side.
Install the part G seat and secure it
with two part 2 screws
PRODUCT ASSEMBLY
5
6
I
G
I
x2
2
10 |

DASHBOARD DIAGRAM
•Push down on the pedal to drive forward/reverse. Release the pedal to slow down and stop.
MP3
USB
TF
MEDIA PLAYER
SEE STEP 2 DIAGRAM
SOUND EFFECTS
FOWARD/
REVERSE
POWER
SWITCH
HIGH/LOW
SPEED
CHARGING INSTRUCTIONS AND DIAGRAM
•Charging socket is located below the seat. Insert one end of the part K charger into the charging socket
and plug the other end into a wall outlet.
•Charge the battery 4 to 6 hours before initial use.
•On average, you will need to charge the battery between 8 and 12 hours. Do not charge the battery for
more than 20 hours. Failure to charge the battery as directed could cause permanent damage to the
battery and void the warranty.
•Damage to the battery may occur if it is allowed to drain completely. Do not allow the battery to drain completely.
•Check the battery and charger (supply cord, connector) for wear and damage before charging. Do not
charge the battery if damage has occurred.
•Only an adult who has read and understood the safety warnings should handle, charge and recharge the battery.
K
| 11

12 |
• AUX INPUT: Plug in a music player to play music
• MICROSD (TF) PORT: Play music from a MicroSD card
• USB PORT: Play music from a USB drive
MEDIA PLAYER
AUX INPUT
USB PORT DECREASE VOLUME
INCREASE VOLUME
MICROSD (TF) PORT
REVERSE
SPEED SELECT
SPEED INDICATOR
TURN RIGHT
TURN LEFT
REMOTE CONTROL FUNCTIONS
•Insert 1 AAA battery into the remote control.
• After 10 seconds of non-operation, the remote will go into power-saving mode.
Linking the remote control:
1. Press and hold the frequency key for 2-4 seconds. The low speed light will flash.
2. Turn the vehicle on. The low speed light will turn solid to indicate a successful link.
3. If the low speed light continues to flash (indicating an unsuccessful link), remove the battery and repeat
steps 1 and 2.
PS
PARK
FREQUENCY KEY
FOWARD

TROUBLSHOOTING
Reason
Low battery
Electrical protection
Switch not in the correct position
Battery connectors disconnected
Low battery
Overloaded vehicle
Uneven or sloped road
Loose connection to motor
Attempting to shift while vehicle
in motion
Gear boxes are installed
incorrectly
Battery connectors disconnected
Charger not connected to socket
or outlet
Battery does not have a full charge
Normal
Problem
Battery is warm and
makes a slight noise while
charging
Slow speed
Vehicles shakes while
driving
Diculty shifting between
forward/reverse
Forward and reverse
switch is flipped (forward
goes in reverse, reverse
goes forward)
Battery does not last
Battery does not recharge
Vehicle does not move
Solution
Fully charge the battery
Stop use for several minutes and restart
Completely press in switches
Plug in battery connectors
Fully charge the battery
Reduce the weight on the vehicle
Drive on flat pavement
Ensure the motor is properly connected to
the battery
Only shift when the vehicle is at a stop
Make sure the L gear box is on the left and
R gear box is on the right
Plug in battery connectors
Completely plug in the charger
Fully charge the battery
Normal
| 13
•Park the vehicle indoors or cover it with a tarp to protect it from wet weather.
•Do not leave the vehicle in the sun for long periods of time or fading may occur. Store in shade or cover
with tarp.
•Do not wash the vehicle with a hose.
•Do not wash the vehicle with soap.
•Charge battery at least once a month to prolong the life of the battery.
CARING FOR YOUR RIDE-ON

14 |
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)
This product may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Responsible party (contact for FCC matters only):
Quality Control Dept.
5642 Ontario Mills Parkway
Ontario, CA 91764
FCC COMPLIANCE STATEMENT

Pg. 15
Pg. 3
Pg. 2
Thank you for choosing us! Since 2002, Best
Choice Products has been bringing customers
high-quality products at the absolute lowest
price. With everything ranging from instruments
and toys to furniture and outdoor, we’ve got
your everyday living essentials covered. We’re
centered around a customer-first philosophy –
with free shipping, exceptional customer
service, and a catalog sourced with you in mind.

All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long
as the item is returned in its original product packaging and all accessories from its original shipment are
included. All returned items will receive a full refund back to the original payment method. All returned
items will not be charged a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best
Choice Products Customer Service Representative when the return request is submitted. Items received
without an RA may not be accepted or may increase your return processing time. Once an item has been
received by Best Choice Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If
the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide
a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products,
and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items
returned are not considered undamaged until they are received by Best Choice Products and verified as
such. All damages to items are the customer’s responsibility until the item has been received by and
acknowledge by Best Choice Products as undamaged.
PRODUCT WARRANTY INFORMATION
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
HELP CENTER
Product Assembly
Product InquiryChat Support Returns & Refunds
Orders FAQ
WARNING
Question about your product? We're here to help. Visit us at:
help.bestchoiceproducts.com
CHAT
US!
