BCP SKY3486 User manual

SKY3486 + SKY3487
Ver. 2
INSTRUCTION
MANUAL
Kids Ride-On Dirt Bike
with Training Wheels

Pg. 2
Pg. 2
Thank you for choosing us! Since 2002, Best
Choice Products has been bringing customers
high-quality products at the absolute lowest
price. With everything ranging from instruments
and toys to furniture and outdoor, we’ve got
your everyday living essentials covered. We’re
centered around a customer-first philosophy –
with free shipping, exceptional customer
service, and a catalog sourced with you in mind.

Pg. 3
Please retain these instructions for future reference.
SAFETY
BATTERY WARNINGS
This vehicle must be assembled by an adult who has read and understood the instructions in this manual.
Keep the packaging and bags away from children and dispose of all packaging before use. Always use
common sense and safe practices when operating this vehicle. This product contains or emits chemicals
known in the state of California to cause cancer or birth defects or other reproductive harm.
NOTE: For best performance, only use this vehicle on flat and hard surfaces.
Age Range: 3 to 6 years old
Weight Capacity: 44 lbs.
The following safety hazards may result in serious injury or death:
• This product contains small parts. Keep children away during assembly. Make sure to remove all
packaging material and parts from underneath the vehicle body.
•Never open the battery. Batteries contain lead and lead compounds (acids) that are toxic and corrosive,
and known to the state of California to cause cancer and reproductive harm.
•Limbs, hair, and clothing can get caught in moving parts. Always wear shoes, keep limbs away from
moving parts, and do not wear loose clothing while operating this vehicle.
•This vehicle does not have brakes or braking capability. Do not leave a child unattended during
operation. Do not use this in a location that may require braking capability, as this could result in loss of
control, which may cause serious injury or death.
•Use of this vehicle near streets, motor vehicles, steps, bodies of water, sloped surfaces, hills, wet areas,
flammable vapors, in alleys, at night, or in the dark could result in an unexpected accident.
•Use of this vehicle in unsafe conditions such as snow, rain, loose dirt, mud, sand, or gravel may result in
an unexpected accident such as tipping over, and could damage the electrical system or battery.
•Do not operate this vehicle in an unsafe manner. Examples include but are not limited to:
- Pulling the vehicle with another vehicle or similar device
- Allowing more than one rider
- Pushing the user
- Traveling at an unsafe speed
The following safety hazards may result in serious injury or death:
•Use of a battery or charger other than the supplied rechargeable battery and charger may cause a fire or
explosion. Only use the supplied battery and charger.
•Use of the rechargeable battery and charger for any other product may result in overheating, fire, or
explosion. Never use the supplied rechargeable battery and charger with another product.
•Explosive gases are created during charging. Charge the battery in a well-ventilated area. Do not charge
the battery near heat or flammable materials.
•Contact between the positive and negative terminals may result in fire or explosion. Avoid direct contact
between the terminals. Picking up the battery by the wires or charger can cause damage to the battery
and may result in a fire. Always pick up the battery by its case or handles.
•Liquids on the battery may cause fire or electric shock. Always keep all liquids away from the battery and
keep the battery dry. Contact or exposure to battery leakage (lead acid) may cause serious injury. If
contact or exposure occurs immediately call your physician. If the chemical is on the skin or in the eyes,
flush with cool water for 15 minutes. If the chemical was swallowed, immediately give the person water or
milk. Do not give water or milk if the patient is vomiting or has a decreased level of alertness. Do not
induce vomiting.
•Battery posts, terminals, and related accessories contain lead and lead compounds (acid) – chemicals
known to the State of California to cause cancer, reproductive harm, and are toxic and corrosive. Never
open the battery.
•Tampering or modifying the electric circuit system may cause a shock, fire or explosion and permanently
damage the system. Exposed wiring and circuitry in the charger may cause electric shock. Always keep
the charger housing closed.

Pg. 4
USER WARNINGS
SPECIFICATIONS
The following safety hazards may result in serious injury or death:
•Never leave a child unattended.
•Always sit in the seat when using this vehicle.
•Keep your hands, hair, and clothes away from moving parts.
•Always wear shoes when operating this vehicle.
•Only one rider is allowed on the vehicle at a time.
•Children under 3 years of age cannot use the vehicle.
•Only drive on level ground.
•Do not go near swimming pools or other bodies of water, drop-os, or up and down steep inclines.
•Do not drive the vehicle into loose dirt, mud, sand, fine gravel, or on wet surfaces.
•Do not drive the vehicle on streets or near cars.
Overall Dimensions
Weight
Weight Capacity
Age Range
Max Speed
Charging Time
Run Time
Battery Type
Electric Motor
Charger
Materials
41”(L) x 20”(H) x 28”(H)
20.3 lbs.
44 lbs.
3 to 6 years old
1.9 mph.
8 – 12 hours
Initial Charge Time 4 – 6 hours
30-40 min.
6V 4.5AH
20W
DC 6V 500MA
Plastic, metal

Pg. 5
APPROXIMATELY
45 MIN.
45 MIMBLY
1 PERSON
ASSEMBLY
44 LBS
CAPACITY
LBS
APPROXIMATELY
1 HR.
ASSEMBLY
1 PERSON
ASSEMBLY
PHILLIPS
SCREWDRIVER
PLASTIC WRENCH
(2 PROVIDED)
TOOLS REQUIRED
PARTS
HARDWARE
1
4 PCS
2
2 PCS
3
2 PCS
4
1 SET
A
D
B C
1 SET
2 PCS
1 PC 1 PC
FRONT AXLE SET
E
1 PC
WHEEL F
1 PC
FRONT FRAME
HANDLEBARS FENDER
PLASTIC SHOCKS
2 AA BATTERIES
+AA -

Pg. 6
PARTS
G
J
HI
1 PC
1 PC
1 PC 1 PC
FOOTREST & AXLE
TRAINING WHEELS K
1 PC
CHARGER
FOOTREST & LOCK DASHBOARD

Pg. 7
TOOLS REQUIREDPRODUCT ASSEMBLY
2
1
Slide the part C fender and part D front shocks
onto the rails of the part B handlebars.
Place the part E wheel between the handlebar rails.
Remove the spacer, washer, and nut from one side
of the part A front axle set, slide the axle through
the rails and wheel, and replace the spacer, washer,
and nut on the other side of the wheel. Use a
wrench to tighten the nuts on both sides.
C
D
B
E
A
A
A
A

Pg. 8
TOOLS REQUIREDPRODUCT ASSEMBLY
3
4
Attach the part F front frame to the part B handlebars
with four part 1 screws.
Attach the front assembly to the motorcycle with the part 4 nut and bolt set.
Join the red connector on the right side of the handlebars to the red connector leading from the back of
the motorcycle.
F
B
1
4
4

Pg. 9
TOOLS REQUIREDPRODUCT ASSEMBLY
5
J
G
H
6
Flip the motorcycle over. Remove the nuts
attached to the part J training wheels, slide the
training wheels onto the bolts on the rear of
the motorcycle, then replace the nuts to secure
the training wheels.
Slide the part G footrest and axle through the body of the motorcycle. Insert the part H footrest onto the
other side of the axle and secure it with the footrest lock.

Pg. 10
DASHBOARD DIAGRAM
Music: Play sounds/music included
with the motorcycle
Light: Turn on lights
Start: Drive forward. Release the
start button to slow down and stop
7
TOOLS REQUIREDPRODUCT ASSEMBLY
+
AA
-
+
AA -
3
22
Use a screwdriver to open the compartment on
the part I dashboard. Insert 2 AA batteries into
the designated slots. Join the green/yellow
connector from the dashboard to the
corresponding green/yellow connector on the
front of the motorcycle.
Attach the dashboard to the motorcycle with two
part 2 bolts and two part 3 nuts. Close the
dashboard compartment and secure it with the
provided screw.
Note: The holes for the bolts are within the
dashboard compartment.
I

Pg. 11
CHARGING INSTRUCTIONS AND WARNINGS
• Charging socket is located in the center of the motorcycle on the right side. Insert one end of the
part K charger into the charging socket and plug the other end into a wall outlet.
• The battery should come fully charged, so you only need to charge the battery 4 to 6 hours before
initial use.
• On average, you will need to charge the battery between 8 and 12 hours. Do not charge the battery for
more than 15 hours. Failure to charge the battery as directed could cause permanent damage to the
battery and void the warranty.
• Damage to the battery may occur if it is allowed to drain completely. Do not allow the battery to
drain completely.
• Check the battery and charger (supply cord, connector) for wear and damage before charging. Do not
charge the battery if damage has occurred.
• Only an adult who has read and understood the safety warnings should handle, charge and recharge
the battery.
TROUBLESHOOTING
Reason
Low battery
Electrical protection
Switch not in the correct position
Battery connectors disconnected
Low battery
Overloaded vehicle
Uneven or sloped road
Loose connection to motor
Battery connectors disconnected
Charger not connected to socket
or outlet
Battery does not have a full charge
Normal
Problem
Battery is warm and
makes a slight noise while
charging
Slow speed
Vehicles shakes while
driving
Battery does not last
Battery does not recharge
Vehicle does not move
Solution
Fully charge the battery
Stop use for several minutes and restart
Completely press in switches
Plug in battery connectors
Fully charge the battery
Reduce the weight on the vehicle
Drive on flat pavement
Ensure the motor is properly connected to
the battery
Plug in battery connectors
Completely plug in the charger
Fully charge the battery
Normal
K

All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the
item is returned in its original product packaging and all accessories from its original shipment are included. All
returned items will receive a full refund back to the original payment method. All returned items will not be charged
a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best Choice
Products Customer Service Representative when the return request is submitted. Items received without an RA
may not be accepted or may increase your return processing time. Once an item has been received by Best Choice
Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If the
reason for return is a result of an error by Best Choice Products then Best Choice Products will provide a pre-paid
shipping label via email. Boxes for return shipping will not be provided by Best Choice Products, and is the
customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items returned are
not considered undamaged until they are received by Best Choice Products and verified as such. All damages to
items are the customer’s responsibility until the item has been received by and acknowledge by Best Choice
Products as undamaged.
CONTACT US, WE’RE HERE 7 DAYS A WEEK TO HELP YOU!
WARNING
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
PRODUCT WARRANTY INFORMATION
bestchoiceproducts.com customerservice@
bestchoiceproducts.com 844.948.8400 LEARN MORE!
CARING FOR YOUR RIDE-ON
•Park the vehicle indoors or cover it with a tarp to protect it from wet weather.
•Do not leave the vehicle in the sun for long periods of time or fading may occur.
Store in shade or cover with tarp.
•Do not wash the vehicle with a hose.
•Do not wash the vehicle with soap.
