BCP SKY5799 User manual

SKY5271 + SKY5272 + SKY5273 + SKY5799
Ver. 2
INSTRUCTION
MANUAL
Land Rover 2-Seater
Ride-On with Remote

bestchoiceproducts.com
Charge for 12 hrs
before initial use.
After initial charge,
follow the normal
recommended
charging time.

| 3
Please retain these instructions for future reference.
SAFETY
This vehicle must be assembled by an adult who has read and understood the instructions in this manual.
Keep the packaging and bags away from children and dispose of all packaging before use. Always use
common sense and safe practices when operating this vehicle. This product contains or emits chemicals
known in the state of California to cause cancer or birth defects or other reproductive harm.
NOTE: For best performance, only use this vehicle on flat and hard surfaces.
AGE RANGE: 3 to 8 years old
WEIGHT CAPACITY: 128 lbs. (combined)
The following safety hazards may result in serious injury or death:
• This product contains small parts. Keep children away during assembly. Make sure to remove all packaging
material and parts from underneath the vehicle body.
• Never open the battery. Batteries contain lead and lead compounds (acids) that are toxic and corrosive,
and known to the state of California to cause cancer and reproductive harm.
• Limbs, hair, and clothing can get caught in moving parts. Always wear shoes, keep limbs away from
moving parts, and do not wear loose clothing while operating this vehicle.
• This vehicle does not have brakes or braking capability. Do not leave a child unattended during operation.
Do not use this in a location that may require braking capability, as this could result in loss of control,
which may cause serious injury or death.
• Use of this vehicle near streets, motor vehicles, steps, bodies of water, sloped surfaces, hills, wet areas,
flammable vapors, in alleys, at night, or in the dark could result in an unexpected accident.
• Use of this vehicle in unsafe conditions such as snow, rain, loose dirt, mud, sand, or gravel may result in
an unexpected accident such as tipping over, and could damage the electrical system or battery.
• Do not operate this vehicle in an unsafe manner. Examples include but are not limited to:
- Pulling the vehicle with another vehicle or similar device
- Allowing more than two children to ride
- Pushing the user
- Traveling at an unsafe speed
BATTERY WARNINGS
The following safety hazards may result in serious injury or death:
• Use of a battery or charger other than the supplied rechargeable battery and charger may cause a fire
or explosion. Only use the supplied battery and charger.
• Use of the rechargeable battery and charger for any other product may result in overheating, fire,
or explosion. Never use the supplied rechargeable battery and charger with another product.
• Explosive gases are created during charging. Charge the battery in a well-ventilated area. Do not charge
the battery near heat or flammable materials.
• Contact between the positive and negative terminals may result in fire or explosion. Avoid direct contact
between the terminals. Picking up the battery by the wires or charger can cause damage to the battery
and may result in a fire. Always pick up the battery by its case or handles.
• Liquids on the battery may cause fire or electric shock. Always keep all liquids away from the battery and
keep the battery dry. Contact or exposure to battery leakage (lead acid) may cause serious injury.
If contact or exposure occurs immediately call your physician. If the chemical is on the skin or in the eyes,
flush with cool water for 15 minutes. If the chemical was swallowed, immediately give the person water
or milk. Do not give water or milk if the patient is vomiting or has a decreased level of alertness. Do not
induce vomiting.
• Battery posts, terminals, and related accessories contain lead and lead compounds (acid) – chemicals
known to the State of California to cause cancer, reproductive harm, and are toxic and corrosive.
Never open the battery.
• Tampering or modifying the electric circuit system may cause a shock, fire or explosion and permanently
damage the system. Exposed wiring and circuitry in the charger may cause electric shock. Always keep
the charger housing closed.

4|
• Maximum of two children are allowed in the vehicle at a time.
• Never leave a child unattended.
• Always sit in the seat when using this vehicle.
• Keep your hands, hair, and clothes away from moving parts.
• Children under 3 years of age cannot use the vehicle.
• Only drive on level ground.
• Do not drive the vehicle into loose dirt, mud, sand, fine gravel, or on wet surfaces.
To reduce the risk of injury, adult supervision is required. Never use on roadways, near motor vehicles, on
or near steep inclines or steps, swimming pools or other bodies of water; always wear shoes, and never
allow more than two children in the vehicle at a time.
WARNING
SPECIFICATIONS
Overall Dimensions
Weight
Weight Capacity
Age Range
Speed
Charging Time
Run Time
Battery Type
Electric Motor
Charger
Material
47.5"(L) x 33.5"(W) x 24.5"(H)
60 lbs.
128 lbs. (combined)
3 – 8 years old
Low: 1.8 mph., High: 3.7 mph.
8 – 12 hours
Initial Charge Time 12 hours
1 – 2 hours
1 - Rechargeable SLA - 12V 7AH
Double drive: 12V
Output: DC 12V
PP Plastic, Metal

4 PCS
WHEEL
4 PCS
HUBCAP
1 PC
1 PC
SEAT
D
1 PC
REAR FRAME
PARTS
AB
F
E
1 SET
SIDE FRAME (L/R)
STEERING WHEEL
C
HARDWARE
1
8 PCS
M4 x 12mm
SCREW
M4 x 10mm
SCREW
2
2 PCS
TOOLS REQUIRED
APPROXIMATELY
45 MIN.
ASSEMBLY
2 PERSON
ASSEMBLY
PHILLIPS
SCREWDRIVER 128 LBS
CAPACITY
(COMBINED)
LBS
2 AAA BATTERIES
(FOR REMOTE)
+AAA -
| 5
PLASTIC
WRENCH
(2, PROVIDED)

1 PC
BACKREST
1 PC
WINDSHIELD
1 SET
J
1 PC
REMOTE CONTROL
PARTS
GH
K
1 PC
12V CHARGER
SIDE MIRRORS (L/R)
I
P S
6|
PRODUCT ASSEMBLY
1Flip vehicle over and lay it on a level surface. Remove all parts and packaging from within the
vehicle body.
NOTE: Parts are located in the compartment under the rear bracket.

| 7
PRODUCT ASSEMBLY
2
3Slide the gear boxes onto the rear axle.
NOTE: Make sure the rear axle is positioned evenly on the vehicle.
Secure the rear bracket with four part 1 screws.
Remove the nuts and washers from the rear axle.
1x4

8|
PRODUCT ASSEMBLY
4
5Remove two nuts and washers from the front axle.
NOTE: Leave two washers on the axle, one on each side.
Slide a part A wheel onto the front axle, then secure it by replacing a nut and washer. Snap on a
part B hubcap. Repeat on the other side.
Slide a part A wheel onto the rear axle, then secure it by replacing a nut and washer. Snap on a
part B hubcap. Repeat on the other side.
NOTE: Use two plastic wrenches (one on each side) and rotate in opposite directions to tighten nuts.
Ax2
Ax2
Bx2
Bx2

PRODUCT ASSEMBLY
6
7Snap in the part D rear frame and secure it with two part 1 screws.
NOTE: Snap in the back of the rear frame and then the front.
Flip the car onto its wheels. Join the connector from the part C steering wheel to the
corresponding connector on the steering wheel mount.
Press the steering wheel into the mount until it locks in place.
| 9
C
D
1x2

PRODUCT ASSEMBLY
8
9Within the seat, insert the connector into the corresponding input on the control module.
Snap in the part E side frame set (L/R).
10 |
E
RIGHT LEFT
CONTROL MODULE

PRODUCT ASSEMBLY
10
11 Attach the part I side mirror set (L/R) to the part H windshield with two part 2 screws.
Snap the windshield into the designated slots.
Insert the tabs on the part F seat into the designated slots and secure with two part 1 screws.
Slide the part G backrest into the back of the seat until it locks in place.
NOTE: Make sure to clear seatbelts out of the way during installation.
| 11
G
1x2
F
H
I
RIGHT LEFT
2x2

12 |
CHARGING INSTRUCTIONS
• Charging port is located below the seat. Insert one end of the charger into the charging port and
plug the other end into a wall outlet.
• Charge the battery 12 hours before initial use.
• On average, you will need to charge the battery between 8 and 12 hours. Do not charge the battery
for more than 20 hours. Failure to charge the battery as directed could cause permanent damage
to the battery and void the warranty.
• Damage to the battery may occur if it is allowed to drain completely. Do not allow the battery to
drain completely.
• Check the battery and charger (supply cord, connector) for wear and damage before charging.
Do not charge the battery if damage has occurred.
• Only an adult who has read and understood the safety warnings should handle, charge and
recharge the battery.
CARING FOR YOUR RIDE-ON
• Park the vehicle indoors or cover it with a tarp to protect it from wet weather.
• Do not leave the vehicle in the sun for long periods of time or fading may occur. Store in shade or
cover with tarp.
• Do not wash the vehicle with a hose.
• Do not wash the vehicle with soap.
• Charge battery at least once a month to prolong the life of the battery.
HIGH SPEED
LOW SPEED
CHARGING
PORT

DASHBOARD DIAGRAM
MEDIA PLAYER
•Push down on the pedal to drive forward/reverse. Release the pedal to slow down and stop.
• Lights: Turn headlights on/o
• Music: Cycle through music
| 13
AUX INPUT
PLAY/PAUSE TRACK
NEXT TRACK/
INCREASE VOLUME
PREVIOUS TRACK/
DECREASE VOLUME
USB PORT
MICROSD
(TF) PORT
MODE
NOTE: By default, buttons play music included with the vehicle. Press and hold buttons for
secondary function.
• USB Port: Play music from a USB drive
• MicroSD (TF) Port: Play music from a MicroSD card
• AUX Input: Use AUX cable to plug in a music player to play music
• Mode: Press to toggle between music and FM radio
POWER SWITCH
LIGHTSMUSIC HORN FORWARD/PARK/
REVERSE
MEDIA PLAYER
PEDAL
LOW SPEED/HIGH SPEED;
CHARGING PORT

14 |
REMOTE CONTROL DIAGRAM
FEATURES
FREQUENCY KEY
TURN LEFT
TURN RIGHT
BRAKE/PARK
REVERSE
FORWARD
SPEED SELECT
SPEED INDICATOR
LIGHTS
P S
•Install 2 AAA batteries into the remote control.
•After 10 seconds of non-operation, the remote will go into power-saving mode.
Linking the remote control:
1. Press and hold the frequency key for 2-4 seconds. The speed indicator light will flash.
2. Turn the vehicle on. The speed indicator light will turn solid to indicate a successful link.
3. If the speed indicator light continues to flash (indicating an unsuccessful link), remove and reinsert
the batteries and repeat steps 1 and 2.
• Compress switch to open door
• Extra storage in the hood
• Convenient handle to transport car
CALIFORNIA PROPOSITION 65
WARNING: Battery posts, terminals, and related accessories can expose you to chemicals including
lead and lead compounds, which are known to the State of California to cause cancer and birth defects or
other reproductive harm, and are toxic and corrosive. Wash hands after handling. For more information go
to www.P65Warnings.ca.gov

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)
This product may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Responsible party (contact for FCC matters only):
Quality Control Dept.
15101 Red Hill Ave.
Tustin, CA 92780
FCC COMPLIANCE STATEMENT
TROUBLESHOOTING
REASON
Low battery
Electrical protection
Switch not in the correct position
Battery connectors disconnected
Low battery
Overloaded vehicle
Uneven or sloped road
Loose connection to motor
Battery connectors disconnected
Charger not connected
to socket or outlet
Battery does not have a full charge
Normal
PROBLEM
Battery is warm and
makes a slight noise
while charging
Slow speed
Vehicle is silent
Vehicles shakes
while driving
Battery does not last
Battery does not recharge
Vehicle does not move
SOLUTION
Fully charge the battery
Stop use for several minutes and restart
Completely press in switches
Plug in battery connectors
Fully charge the battery
Reduce the weight on the vehicle
Drive on flat pavement
Ensure the motor is properly
connected to the battery
Plug in battery connectors
Completely plug in the charger
Fully charge the battery
Normal
Diculty shifting between
forward/reverse Only shift when the vehicle is at a stop
Properly connect the steering
wheel connector
Attempting to shift while
vehicle in motion
Steering wheel is not
properly connected
| 15

All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long
as the item is returned in its original product packaging and all accessories from its original shipment are
included. All returned items will receive a full refund back to the original payment method. All returned
items will not be charged a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best
Choice Products Customer Service Representative when the return request is submitted. Items received
without an RA may not be accepted or may increase your return processing time. Once an item has been
received by Best Choice Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If
the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide
a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products,
and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items
returned are not considered undamaged until they are received by Best Choice Products and verified as
such. All damages to items are the customer’s responsibility until the item has been received by and
acknowledge by Best Choice Products as undamaged.
PRODUCT WARRANTY INFORMATION
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, unapproved modification, or neglect of this product.
HELP CENTER
Product Assembly
Product InquiryChat Support Returns & Refunds
Orders FAQ
WARNING
Question about your product? We're here to help. Visit us at:
help.bestchoiceproducts.com
CHAT
US!
