BEETLE iPOS User manual

BEETLE /iPOS
Compact POS System
User Manual
Edition October 2005

Copyright© Wincor Nixdorf International GmbH, 2005
The reproduction, transmission or use of this document or its contents is not
permitted without express authority.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or
design, are reserved.
Delivery subject to availability; technical modifications possible.
Linux™ is a registered trademark of Linus Torvalds
Pentium™ is a registered trademark of the Intel Corporation
MS-DOS™, Windows 95™, Windows 98™, Windows NT™, Windows 2000™,
Windows XP™ and Windows CE™ are registered trademarks of the Microsoft Cor-
poration
PanelLink™ is a registered trademark of the Intel Corporation
BEETLE™ is a registered trademark of Wincor Nixdorf International GmbH

Contents
Manufacturers Certification................................................1
Tested Safety..............................................................................................1
Note on the laser ........................................................................................1
FCC-Class A Declaration............................................................................1
Important notes ...........................................................................................2
Introduction..........................................................................4
About this manual .......................................................................................4
Care of the BEETLE /iPOS .........................................................................5
Recycling the BEETLE /iPOS .....................................................................5
Warranty .....................................................................................................6
BEETLE /iPOS .....................................................................8
Advantages at a Glance..............................................................................8
BEETLE /iPOS Peripherals.........................................................................9
BEETLE /iPOS in a Network.....................................................................10
Before switching on the System................................................................11
Unpacking and checking the System....................................................11
Setting up the device ............................................................................12
Cabling of the BEETLE /iPOS ..............................................................12
Disconnecting cables............................................................................15
Mounting the Cable Cover....................................................................16
Power Supply (212W)...........................................................................17
Connecting to the mains power supply.................................................18
Basic settings .......................................................................................19
Adjusting the System’s Loudspeaker....................................................19
Light emitting diode (LED) ....................................................................19
Connecting peripherals .............................................................................19
Keyboard (KYBD) .................................................................................20
COM1* and COM2*..............................................................................20
COM3 and COM4.................................................................................21
Dual Monitor ........................................................................................21
Network ................................................................................................21
Cash Drawer ........................................................................................21
Modular printers ..................................................................................22
USB (Universal Serial Bus) ..................................................................22

Installing Windows Operating Systems ..........................24
Windows XP..............................................................................................25
BEETLE /iPOS - the components.....................................26
Overview...................................................................................................26
Capacative Touch Screen (Option)...........................................................29
General ................................................................................................29
Touch Screen and Sleep Mode ............................................................30
How to Operate ....................................................................................30
Cleaning Instructions ............................................................................31
Resistive Touch Screen (Option) ..............................................................32
General ................................................................................................32
How to Operate ....................................................................................33
Cleaning Instructions ............................................................................33
Swipe Card Reader (optional)...................................................................34
How to Operate ....................................................................................34
Cleaning Instructions ............................................................................34
Waiter Lock (optional) ...............................................................................35
Barcode Scanner (optional) ......................................................................36
Configuration variants ......................................................37
Availability of Interfaces ............................................................................37
Submodules for the CPU ..........................................................................38
POS Board (COM 3, COM 4, Cash Drawer) ........................................38
LAN Adapter 10/100 MBit.....................................................................38
PCI/ Mini PCI Adapter with WLAN Modul .............................................38
PCI CRT Controller (Dual Screen) .......................................................38
Installing the Submodules .........................................................................39
Inserting a POS Board ..............................................................................41
Inserting a CRT Controller (without POS Board).......................................44
Inserting a CRT Controller (POS Board existing)......................................44
Change of the Hard Disk Drive .................................................................45
Start and runup behaviour................................................46
Retail Software...................................................................48
Wincor Nixdorf Store Solutions .................................................................48
Platforms and Products.............................................................................49
Trading Post .........................................................................................49
TP.net...................................................................................................50

TPLinux ................................................................................................50
Technology evaluation..........................................................................50
Appendix ............................................................................51
Technical Data for the BEETLE /iPOS......................................................51
Dimensions ...............................................................................................54
BEETLE /iPOS with a 12.1” screen ......................................................54
BEETLE /iPOS with a 15” screen .........................................................55
Glossary....................................................................................................56
Abbreviations ............................................................................................58

Manufacturers Certification
The device complies with the requirements of the EEC
directive 89/336/EEC with regard to ‘Electromagnetic
compatibility" and 73/23/ECC “Low Voltage Directive”.
Therefore, you will find the CE mark on the device or packaging.
Tested Safety
The POS system has been provided with the symbol
for “Tested Safety”.
In addition, the BEETLE has received the UL symbol
and cUL symbol.
Note on the laser
FCC-Class A Declaration
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equip-
ment generates, uses, and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interferen-
ce at his own expense.
1
TESTED SAFETY
geprüftegeprüfte
SicherheitSicherheit

Modifications not authorized by the manufacturer may void users authority
to operate this device.
This class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003
du Canada.
Important notes
The compact POS system BEETLE /iPOS conforms to the current safety
standards for data processing equipment.
nIf this device is taken from a cold environment into the operating room,
moisture condensation may form. The device must be absolutely dry
before being put into service; an acclimatization period of at least two
hours must therefore be observed.
nThis device is equipped with a safety-tested power cable and may be
connected only to a prescribed grounded-contact power socket.
nWhen setting up the device, ensure that the power socket on the device
and the grounded-contact power socket are easily accessible.
nTo disconnect the device from the supply voltage completely, switch off
the device and disconnect the power plug.
nWhenever work of any kind is done on the device, as well as when data
cables are plugged and unplugged, the device must be completely
disconnected from the line voltage. To do so, turn the device off and
unplug the power cord.
nEnsure that no foreign objects (c.g. office clips) find their way into the
device, as this may lead to electric shocks or short-circuits.
nNever plug in or unplug data communication lines during thunderstorms.
nProtect devices from vibrations, dust, moisture and heat.
nIf liquids were spilled over your BEETLE /iPOS switch off the system and
disconnect the power plug. Dry the device with a cloth and leave it
switched off for a while.
2
IMPORTANT NOTES

nAlways dispose of used parts, such as batteries, in an environmentally
safe manner.
nThe lithium battery must be disposed of in accordance with local
regulations for special waste.
nIn emergencies (e.g. damaged housing or damaged power cable,
penetration by liquids or foreign bodies), the device must be switched off
immediately, the power plug disconnected and the Customer Service of
Wincor Nixdorf (WN) or your dealer must be notified.
nThe device may only be repaired by authorized qualified personnel.
Unauthorized opening of the device and inexpertly carried-out repairs may
not only seriously jeopardize the safety of the user, but also cancel all
warranty and liability agreements.
nIf the display element is damaged and the liquid crystal solution leaks out
onto your hands or clothing, please wash your hands or clothing
immediately under running water for at least 15 minutes, using soap or
alcohol.
If the liquid comes into contact with your eyes, consult a medical
doctor immediately.
nYou should connect your BEETLE or other IT-devices only to power
supply systems with separately guided protective earth conductor (PE).
This kind of electricity system is known as TN-S network. Do not use PEN
conductors!
Please also observe the recommendations of the norm DIN VDE 0100,
Part 540, Appendix C2 as well as EN50174-2, §5.4.3. Thus, you can help
to avoid possible malfunctions.
3
IMPORTANT NOTES

Introduction
With the BEETLE /iPOS Wincor Nixdorf meets the growing demands of the
retail market for sophisticated Point-of-Service and Kiosk system solutions.
Designed for food and hospitality services, the BEETLE /iPOS offers an in-
tegrated touch terminal with footprint. The innovative concept of the
BEETLE /iPOS integrates the display, the central processing unit and the
power supply unit in one housing. A variety of options such as the use as
stand or wall mounting system, integrated loudspeakers, integrated scanner
and printer enable the performance of a comprehensive range of features.
About this manual
This manual describes the compact POS system BEETLE /iPOS.
This documentation is intended to help you to work with the POS system
and to serve as a reference work. The detailed table of contents helps you
find the desired information quickly and easily.
The first section describes
neverything you need to do before switching on the POS system and
how to connect peripherals to the BEETLE /iPOS.
The second section contains
nthe installation of Windows operating systems.
The third section provides
na brief overview of the Power Managementsystem.
The fourth section contains
na brief overview of the components of your BEETLE system.
The five section provides
nthe possible configuration variants of your BEETLE /iPOS
Section six
na brief overview of the Wincor Nixdorf Retail Software.
ABOUT THIS MANUAL
4

The Appendix
ncontains the most important technical data, a glossary and a list of
abbreviations.
Notes in the manual are marked by this symbol.
This symbol is used for warnings.
The type and scope of application programs depend on the customer’s own
selection; therefore, software will not be discussed further in this manual.
Separate manuals are included in the scope of the connectable peripherals.
For this reason, a more detailed description of these devices will not be pro-
vided here. For more information see the relevant manuals.
Care of the BEETLE /iPOS
Clean your BEETLE /iPOS at regular intervals with a suitable plastic-surface
cleaner.
Make sure that the power plug is disconnected, connector cables are un-
plugged and that no liquid finds its way into the device.
The glass surface of your Touch Screen should be cleaned with a mild,
commercially available glass cleaning product. All pH neutral materials
(pH 6 to 8) are good for cleaning.
Recycling the BEETLE /iPOS
Environmental protection does not begin when
time comes to dispose of the BEETLE; it
begins with the manufacturer. This product was
designed according to our internal norm
“Environmental conscious product design and
development”.
The compact BEETLE /iPOS system is manufactured without the use of
CFCs and CCHS and is produced mainly from reusable components and
materials.
5
CARE OF THE BEETLE /IPOS

6
The processed plastics can, for the most part, be recycled. Even the preci-
ous metals can be recovered, thus saving energy and costly raw materials.
Please do not stick labels onto plastic case parts. This would help us to
re-use components and material.
You can protect our environment by switching on your equipment only when
it is actually needed. If possible, even avoid the stand-by-mode as this was-
tes energy, too. Also switch your equipment off when you take a longer
break or finish your work.
There are still some parts that are not reusable. Wincor Nixdorf guarantees
the environmentally safe disposal of these parts in a Recycling Center,
which is certified pursuant to ISO 9001 and ISO 14001.
So don’t simply throw your BEETLE system on the scrap heap when it has
served its time, but take advantage of the environmentally smart, up-to-date
recycling methods!
Please contact your competent branch or the Recycling Center Paderborn
(for European countries) for information on how to return and re-use devices
and disposable materials under the following mail address:
Email: [email protected]
We look forward to your mail.
Warranty
Wincor Nixdorf guarantees generally a warranty engagement for 12 months
beginning with the date of delivery resp. the date of acceptance. This war-
ranty engagement covers all those damages which occur despite a normal
use of the product.
Damages because of
nimproper or insufficient maintenance,
nimproper use of the product or unauthorized modifications of the product,
ninadequate location or surroundings
will not be covered by the warranty.
RECYCLING THE BEETLE /IPOS

For details please consult your contract documents.
All parts of the product which are subject to wear and tear are not included
in the warranty engagement.
Please order spare parts at the Wincor Nixdorf customer service.
7
WARRANTY

BEETLE /iPOS
Advantages at a Glance
nErgonomic Terminal Workplace
nDesigned for Touch Operation
n12.1”/15” TFT Flat Screen (Capacative or Resistive Touch Technology)
nSplash proof Design
nMultimedia Capabilities
nMagnetic/ Smart Card Reader
nUser Identification with waiter lock
nMotion and Proximity Sensor
nStand or Wall Mounting Options
nHard Disk or Flash Disk
nIntel Processor Pentium 4 mobile Technologie
As there is this great deal of scope for implementing the BEETLE /iPOS, it
can be applied in all trade market segments like specialist retailers, depart-
ment stores, self-service stores or in restaurants and pubs.
The illustrations below show you how your compact POS system can grow -
from a scanner to integration in a network.
ADVANTAGES AT A GLANCE
8

BEETLE /iPOS Peripherals
9
BEETLE /IPOS PERIPHERALS
Printer
Scanner
Cash Drawer
Scale
Keyboard
Customer Display
Monitor

BEETLE /iPOS in a Network
BEETLE /IPOS IN A NETWORK
10
Server
Ethernet 10/100 Base T

Before switching on the System
Unpacking and checking the System
Unpack the parts and check to see whether the delivery matches the infor-
mation on the delivery note.
The carton contains the basic unit and a country-specific accessories kit.
Some ordered composition may be installed.
If damage has occurred during shipping or if the package contents do not
match the delivery note, promptly inform your Wincor Nixdorf sales outlet.
Please indicate the number of your delivery ticket and delivery ticket position
and serial number of the respective device. The serial number can be found
on the label illustrated below which is located at the rear of the housing; it
may be necessary to remove the cable cover.
The serial number is located on the label below the bar code.
CABLING OF THE BEETLE /IPOS
11
Wincor Nixdorf
Made in Singapore
WN0199901107
BEETLE /iPOS P4m
017500 000000
100-120V / 200-240V
50/60 Hz 5/3 A

It is absolutely necessary to check the function of the original equipment be-
fore you perform any changes (e.g. by installing an expansion card). Only
then is it possible to accept a functional defect as a claim.
Transport the device only in its original packaging (to protect it against im-
pact and shock).
Setting up the device
Set up the BEETLE system where it will not be exposed to extreme environ-
mental conditions. Protect the device from vibrations, dust, moisture, heat
and strong magnetic fields.
If the equipment is to be fitted, you must ensure that the specified minimum
distances are maintained and constant ventilation is provided. The minimum
distance upwards is 10 mm. The immediate ambient temperature of the sys-
tem must not exceed 40° C/104 °F. These requirements are met, for exam-
ple, if the equipment is not built into an enclosed piece of furniture.
Cabling of the BEETLE /iPOS
Always make sure that the system is switched off when you do cabling
works.
Install the system by following the steps described below:
nThe cable cover must be removed, if present.
Unlock the cable
cover.
12
CABLING OF THE BEETLE /IPOS

Press on the
center of the cable
cover and push it
backwards (1).
Take off the cover
(2).
Remove the port cover on the bottom side of the BEETLE system:
Tilt the screen
backwards.
First remove the
cover of the loud-
speaker. Now you
can easily reach
the ports.
13
CABLING OF THE BEETLE /IPOS



Pull the cover in
your direction and
take it off.
Plug the cables.
In this case: the
keyboard cable.
Lead the cable
through the back
center so that after
completing the
connection of the
cables all can fit
under the cable
cover.
Plug one end of the power cable into the socket of the BEETLE /iPOS.
Close the cable cover.
14
CABLING OF THE BEETLE /IPOS

Switch on the
power supply.
Close the cable
cover and move it
from the rear to the
front side.
Lock the cable
cover.
Connect the other end of the power cable to the main power supply.
Never connect data cables or power supply cables with the system switched
on (exception: USB cables)!
Disconnecting cables
Never unplug a cable by pulling the cable but take hold of the actual plug it-
self. Follow the procedure below when disconnecting cables:
nTurn off all power and equipment switches.
nRemove the cable cover.
nUnplug all data communication cables from the sockets of the data
networks.
15
DISCONNECTING CABLES
1
0
1
0
