Beghelli MPL Series User manual

INSTALLATION INSTRUCTIONS
MULTIPURPOSE AREA LIGHT (MPL)
Beghelli USA
3250 Corporate Way
Miramar, Florida 33025 USA
P: 800 726 4316 / P: 954 442 6600 F:
954 442 6677
www.BeghelliUSA.com
MPL15, MPL30, MPL50

MODEL INFORMATION
MPL
WATTAGE 15W, 30W, 50W
MPL
120-277V (50/60Hz)
WET LOCATION
HT (AC ONLY)
SEE BELOW
15W: 0.9 lbs (knuckle) /1.1 lbs (yoke only)
30W: 2.5 lbs (knuckle & yoke)
50W: 3.6 lbs (knuckle & yoke)
VOLTAGE
SUITABLE FOR
OPERATION
WEIGHT
DIMENSIONS
15W 30W 50W
IP66 IK09
3G
Vibration
Rated
MULTIPURPOSE AREA LIGHT (MPL) INSTALLATION INSTRUCTIONS
MPL15, MPL30, MPL50

IMPORTANT SAFEGUARDS
WIRING DIAGRAM
MOUNTING OPTIONS
KNUCKLE MOUNT (KM)
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
This product must be installed in accordance with the applicable installation codes by a qualified electrician familiar
with the construction and operation of the product and the hazards involved.
Disconnect power at circuit breaker of fuse before starting installation.
To avoid injury, wear gloves during installation.
To reduce the risk of electrical shock and product damage, do not install this luminaire during rain or other storms.
Do not test luminaire using an electric generator before installation.
Use minimum 75°C Supply Wires.
1.
2.
3.
4.
5.
6.
SAVE THESE INSTRUCTIONS!
THERE ARE TWO MOUNTING OPTIONS FOR THE MPL15-50 LUMINAIRES.
No user serviceabl e parts. Refer service to a qualif ied service
technician. Read instruc tions prior to installing and/or operating
this device. Installatio n should be performed by a licensed
electrician/inst aller in accordance with local codes.
MULTIPURPOSE AREA LIGHT (MPL) INSTALLATION INSTRUCTIONS
NOTE: Knuckle-Mounted models are intended to be mounted to
a junction box suitable for the installation environment.
Secure luminaire to appropriate junction box.
Make supply connections inside junction box (see Wiring Diagram).
Replace junction box cover.
To adjust the vertical position of the luminaire, use a Philips
head screwdriver to loosen the adjustment screw. Reposition
the luminaire head to the desired position, then re-tighten the
adjustment screw.
1.
2.
3.
4.

To install the luminaire, mark and drill mounting holes in
the structure on which the luminaire will be mounted.
Using appropriate hardware (supplied by others), attach
the luminaire yoke to the stationary structure.
To make wire connections, route the power cord to an
appropriate junction box.
Make supply connections inside junction box (see Wiring
Diagram).
Replace junction box cover.
To adjust the vertical position of the luminaire, use a hex
wrench to loosen the adjustment screw, and reposition
the luminaire head to the desired position, then re-tight-
en the bolt.
1.
2.
3.
4.
5.
YOKE MOUNT (YM)
MULTIPURPOSE AREA LIGHT (MPL) INSTALLATION INSTRUCTIONS
