Beko BEVPCC 090 User manual

05M-8505903200-5321-01
EN-IT
Split type air conditioner
User Manual
BEVP C C 090/BEVP C C 091
BEVP C C 120/BEVP C C 121
BEVP C C 180/BEVP C C 181

Please read this user manual rst!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results
from your product which has been manufactured with high quality and state-of-
the-art technology. Therefore, please read this entire user manual and all other
accompanying documents carefully before using the product and keep it as a
reference for future use. If you handover the product to someone else, give the user
manual as well. Follow all warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
This product has been produced in environmentally friendly, modern facilities
Complies with the WEEE Regulation. Does not contain PCB.
C
Important information or
useful hints about usage.
A
Warning for hazardous
situations with regard to life
and property.
Warning to actions that must
never perform.
B
Warning for electric shock.
Warning for hot surfaces.
Do not cover it.
This symbol shows that the
operation manual should be
read carefully.
This symbol shows that a
service personnel should be
handling this equipment with
reference to the installation
manual.
This symbol
shows that this
appliance used
a flammable
refrigerant. If
the refrigerant
is leaked and
exposed to an
external ignition
source, there is
a risk of fire.

Air-conditioners / User’s Manual 3 / EN
CONTENTS
ENGLISH 2-42
ITALIANO 43-87

4 / EN Air-conditioners / User’s Manual
CONTENTS
1 Safety nstructons 6
2 Mantenance nstructon 15
2.1 Information in manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Information on servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3 Repairs to sealed components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.4 Repair to intrinsically safe components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.5 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.6 Detection of flammable refrigerants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.7 Leak detection methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.8 Removal and evacuation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.9 Charging procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.10 Decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.11 Labelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.12 Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3 Product ntroducton 22
4 Descrpton of components 23
4.1 View of unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2 Display screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3 Indicator light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5 Remote controller 26
6 Remote controller dsplay 28
7 Operatng method 30
7.1 Emergency run. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.2 GoClean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.3 How to adjust air flow. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Air-conditioners / User’s Manual 5 / EN
CONTENTS
7.4 Sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.5 Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.6 Turbo. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.7 Quiet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.8 LED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
8 Servce and mantenance 32
8.1 Clean the front panel and remote controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
8.2 Clean air filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8.3 No use for long time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8.4 Recommendations for energy saving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
9 Troubleshootng 35
9.1 Air Conditioner is in error. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
9.2 Remote controller is in error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
9.3 Error code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
10Normal phenomena 37
11 European dsposal gudelnes 38
12 Installaton nstructons 39
12.1 F-Gas instruction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
13Specfcatons 40

6 / EN Air-conditioners / User’s Manual
Symbol description
A
Warnng:
A symbol indicating
operation which may
cause personnel
casualties or serious
damages.
A symbol indicating
operation which may
cause personnel
casualties or property
damages.
Installation instruction
A
Warnng:
Never nstall by
yourself.
Split type air conditioner will
work for you for a long period
of time if it is correctly installed.
Improper installation could
cause problems such as leakage
of water or refrigerant, electric
shock or fire.
A
Warnng:
Please confrm the
followng before
nstallaton.
Power specfcatons: Make
sure that the capacity of socket
or breaker and power cable is
sufficient, the voltage is correct
and the socket or breaker
is grounded. There may be
hazard of fire or electric shock
otherwise.
Proper connecton of
wres and ppng: Improper
connection may decrease
the efficiency or cause air
conditioner stop running. Water
or refrigerant leakage may be
resulted as well.
Installaton envronments: Do
not install air conditioner at the
place where there is flammable
or corrosive air.
Operatng nstructon: Please
operate air conditioner in
accordance to this manual.
1 Safety nstructons

Air-conditioners / User’s Manual 7 / EN
1 Safety nstructons
Operatng nstructon
Warnngs:
• Following the safety messages
is very important. These
messages can save you from
being injured or killed. Warning
symbols alert you to be careful
and means danger. Always
follow instructions to be safe
and reduce chances of injury
or death. Warning and danger
signs will precede safety
messages.
Electrcal safety
A
Groundng:
• This room air
conditioner must be
grounded. Grounding
reduces the risk of
electric shock by
providing an escape
wire for the electric
current. If the power
cord has a grounding
plug with a
grounding wire, plug
it into an outlet that
is properly installed
and grounded. If the
power cord has not
a grounding plug
with a grounding
wire, the grounding
wire must connect
the breaker that is
properly installed
and grounded.

8 / EN Air-conditioners / User’s Manual
Warnng:
• Improper use of the grounding
plug or breaker can result in
a risk of electric shock. Call a
qualified electrician if you don’t
understand the grounding
instructions or if you are not
sure if the air conditioner
is properly grounded. If the
wall outlet or breaker is not
grounded, please contact an
electrician to have it replaced
with a properly grounded outlet
or breaker. Do not, under
any crcumstances, cut or
remove the thrd (ground)
prong from the power cord.
Adapter plug: We strongly
advse aganst usng an
adapter plug or breaker.
Operatng condtons
1. Temperature: T1 instance:
-10°C - 43°C (14°C - 43°C in
cooling-only type)
If the unit runs beyond the
temperature for a long time,
it may cause cooling capacity
to decrease or protector to
work.
2. Relative humidity: <80%
If the unit runs beyond the
humidity range, condensate
may be formed near blade
and outlet of air conditioner.
It’ s normal.
3. In heating operation, strange
smell may come from the unit.
It is Normal phenomenon.
4. The performance parameters
refer to name plate.
5. The waterproof level of
indoor unit is IPXO. Do not use
it in the laundry or bathroom.
6. The outdoor unit can’ t be
installed in a closed area.
1 Safety nstructons

Air-conditioners / User’s Manual 9 / EN
• This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
Children should be supervised
to ensure that they do not
play with the appliance. The
appliance is only to be used
with the power supply unit
provided with the appliance.
• This appliance can be used
by children aged from 8
years and above if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved. Cleaning and user
maintenance shall not be
made by children unless they
are aged from 8 years and
above and supervised. Keep
the appliance and its cord out
of reach of children aged less
than 8 years.
• If the supply cord is damaged,
it must be replaced by the
manufacturer or its agent or
similarly qualified person in
order to avoid hazard.
• Detail of type and rating
of fuse, or rating of circuit
breakers;
• Fuse of indoor unit:
T 3.15A/5A 250V/AC
• For 7k~12k models, fuse of
outdoor unit: T 15A 250VAC.
• For 18k models, fuse of
outdoor unit: T 20A 250VAC.
• For 24k models, fuse of
outdoor unit: T 30A 250VAC.
• This appliance is intended
to be used in household and
similar applications such as
1 Safety nstructons

10 / EN Air-conditioners / User’s Manual
– Staff kitchen areas in shops,
offices and other working
environments;
– farm houses;
– by clients in hotels, motels
and other residential type
environments;
– bed and breakfast type
environments;
• The appliance shall state the
insulation of a residual current
device (RCD) having rated
residual operating current not
exceeding 30mA.
Tps
• Install the unit on the north
side, as normally that is the
shaded side. This will enhance
the operation of your unit.
• Use correct electric voltage
and proper ampere for the unit
to run effectively.
• Only let a certified electrician
do any modifications to your
electrical outlet or breaker.
• Use a dedicated line for
the operation of your air
conditioner to avoid the
possibility of an electrical
surge.
• If the supply cord is damaged,
it must be replaced by the
manufacturer or its service
agent or a similarly qualified
person in order to avoid a
hazard.
• The dimensions of the
space necessary for correct
installation of the appliance
including the minimum
permissible distances to
adjacent structures.
• The appliance shall be installed
in accordance with national
wiring regulations.
• Disconnect the power
supply before cleaning and
maintenance.
1 Safety nstructons
