Beko BFYTI 360 User manual

Floor standing
airconditioner
Installation Manual
BFYTI 360 BFYTI 361
EN AR

Please read this user manual first!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results
from your product which has been manufactured with high quality and state-of-
the-art technology. Therefore, please read this entire user manual and all other
accompanying documents carefully before using the product and keep it as a
reference for future use. If you handover the product to someone else, give the user
manual as well. Follow all warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
This product has been produced in environmentally friendly, modern facilities
Complies with the WEEE Regulation. Does not contain PCB.
C
Important information or
useful hints about usage.
A
Warning for hazardous
situations with regard to
life and property.
Warning to actions that
must never perform.
B
Warning for electric shock.
Warning for danger of fire.
Warning for hot surfaces.
Do not cover it.

Floor standing air conditioner / Installation Manual 3 / EN
CONTENTS
1 Safety rules and recommendatons for the nstaller 5
2 Safety rules and recommendatons for the user 8
3 Safety rules and prohbtons 11
4 Names of the parts 13
4.1 Indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2 Outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 Indoor unt dsplay 14
6 Indoor unt control panel 16
7 Remote control 17
8 Remote controller 18
8.1 Remote controller display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8.2 Replacement of batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
9 Operatng nstructons 23
9.1 “Swing” control of the air flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
9.2 Cooling mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
9.3 Heating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9.4 Timer mode----Timer on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
9.5 Timer mode----Timer off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9.6 Fan mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9.7 Dry mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9.9 Auto mode.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9.10 Sleep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9.11 Turbo mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9.12 Eco mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4 / EN Floor standing air conditioner / Installation Manual
CONTENTS
10Modes of operaton 31
10.1 Zone follow mode (optional). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
10.2 Mute function (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
10.3 Display function (indoor display). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
11 Protecton 33
12 Installaton manual 34
12.1 Selecting the installation place . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
12.2 Installation of the indoor unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
12.3 Installation of the outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
12.4 Operation test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
12.5 Information for the installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
13 Mantenance 45
13.1 Indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
13.2 Cleaning the heat exchanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
13.3 End of season maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
13.4 Replacing the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
14Troubleshootng 47
15 Specfcatons 49

Floor standing air conditioner / Installation Manual 5 / EN
Warning
• Read this guide before installing
and using the appliance.
• During the installation of the
indoor and outdoor units the
access to the working area
should be forbidden to children.
Unforeseeable accidents could
happen.
• Make sure that the base of the
outdoor unit is firmly fixed.
• Check that air cannot enter the
refrigerant system and check
for refrigerant leaks when
moving the air conditioner.
• Carry out a test cycle after
installing the air conditioner
and record the operating data.
• The ratings of the fuse
installed in the built incontrol
unit are T 5A/250V.
• The user must protect the indoor
unit with a fuse of suitable
capacity for the maximum input
current or with another overload
protection device.
• Ensure that the mains voltage
corresponds to that stamped
on the rating plate. Keep the
switch or power plug clean.
Insert the power plug correctly
and firmly into the socket,
thereby avoiding the risk of
electric shock or fire due to
insufficient contact.
• Check that the socket is
suitable for the plug, otherwise
have the socket changed.
• The appliance must be fitted
with means for disconnection
from the supply mains having a
contact separation in all poles
that provide full disconnection
under overvoltage category III
conditions, and these means
must be incorporated in the
fixed wiring in accordance with
the wiring rules.
• The air conditioner must be
installed by professional or
qualified persons.
1 Safety rules and recommendatons for the nstaller

6 / EN Floor standing air conditioner / Installation Manual
1 Safety rules and recommendatons for the nstaller
• Do not install the appliance
at a distance of less than
50 cm from inflammable
substances (alcohol, etc.)
Or from pressurised containers
(e.g. spray cans).
• If the appliance is used in
areas without the possibility
of ventilation, precautions
must be taken to prevent any
leaks of refrigerant gas from
remaining in the environment
and creating a danger of fire.
• The packaging materials are
recyclable and should be
disposed of in the separate
waste bins. Take the air
conditioner at the end of its
useful life to a special waste
collection centre for disposal.
• Only use the air conditioner
as instructed in this booklet.
These instructions are
not intended to cover
every possible condition
and situation. As with
any electrical household
appliance, common sense and
caution are therefore always
recommended for installation,
operation and maintenance.
• The appliance must be installed
in accordance with applicable
national regulations.
• Before accessing the terminals,
all the power circuits must be
disconnected from the power
supply.
• The appliance shall be installed
in accordance with national
wiring regulations.

Floor standing air conditioner / Installation Manual 7 / EN
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.
1 Safety rules and recommendatons for the nstaller

8 / EN Floor standing air conditioner / Installation Manual
• Do not try to install the
conditioner alone; always
contact specialized technical
personnel.
• Cleaning and maintenance
must be carried out by
specialised technical personnel.
In any case disconnect the
appliance from the mains
electricity supply before
carrying out any cleaning or
maintenance.
• Ensure that the mains voltage
corresponds to that stamped
on the rating plate. Keep the
switch or power plug clean.
Insert the power plug correctly
and firmly into the socket,
thereby avoiding the risk of
electric shock or fire due to
insufficient contact.
• Do not pull out the plug to
switch off the appliance when
it is in operation, since this
could create a spark and cause
a fire, etc.
• This appliance has been made
for air conditioning domestic
environments and must not
be used for any other purpose,
such as for drying clothes,
cooling food, etc.
• The packaging materials are
recyclable and should be
disposed of in the separate
waste bins. Take the air
conditioner at the end of its
useful life to a special waste
collection centre for disposal.
• Always use the appliance with
the air filter mounted. The use
of the conditioner without air
filter could cause an excessive
accumulation of dust or waste
on the inner parts of the device
with possible subsequent
failures.
2 Safety rules and recommendatons for the user

Floor standing air conditioner / Installation Manual 9 / EN
• The user is responsible for
having the appliance installed
by a qualified technician,
who must check that it is
earthed in accordance with
current legislation and insert a
thermomagnetic circuit breaker.
• The batteries in remote
controller must be recycled or
disposed of properly.
Disposal of Scrap Batteries ---
Please discard the batteries as
sorted municipal waste at the
accessible collection point.
• Never remain directly exposed
to the flow of cold air for a long
time. The direct and prolonged
exposition to cold air could be
dangerous for your health.
Particular care should be taken
in the rooms where there are
children, old or sick people.
• If the appliance gives off smoke
or there is a smell of burning,
immediately cut off the power
supply and contact the Service
Centre.
• The prolonged use of the
device in such conditions could
cause fire or electrocution.
• Have repairs carried out only by
an authorised Service Centre
of the manufacturer. Incorrect
repair could expose the user to
the risk of electric shock, etc.
• Unhook the automatic switch
if you foresee not to use the
device for a long time.
The airflow direction must be
properly adjusted.
• The flaps must be directed
downwards in the heating
mode and upwards in the
cooling mode.
• Only use the air conditioner
as instructed in this booklet.
These instructions are not int
ended to cover every possible
condition and situation. As
with any electrical household
appliance, common sense and
caution are therefore always
recommended for installation,
operation and maintenance.
2 Safety rules and recommendatons for the user

10 / EN Floor standing air conditioner / Installation Manual
• Ensure that the appliance is
disconnected from the power
supply when it will remain
inoperative for a long period
and before carrying out any
cleaning or maintenance.
• Selecting the most suitable
temperature can prevent
damage to the appliance.
2 Safety rules and recommendatons for the user

Floor standing air conditioner / Installation Manual 11 / EN
• Do not bend, tug or compress
the power cord since this
could damage it. Electrical
shocks or fire are probably
due to a damaged power cord.
Specialised technical personnel
only must replace a damaged
power cord.
• Do not use extensions or gang
modules.
• Do not touch the appliance
when barefoot or parts of the
body are wet or damp.
• Do not obstruct the air inlet
or outlet of the indoor or the
outdoor unit.
The obstruction of these
openings causes a reduction
in the operative efficiency of
the conditioner with possible
consequent failures or
damages.
• In no way alter the
characteristics of the appliance.
• Do not install the appliance in
environments where the air
could contain gas, oil or sulphur
or near sources of heat.
• This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
• Do not climb onto or place any
heavy or hot objects on top of
the appliance.
• Do not leave windows or doors
open for long when the air
conditioner is operating.
• Do not direct the airflow onto
plants or animals.
• A long direct exposition
to the flow of cold air of
the conditioner could have
negative effects on plants and
animals.
3 Safety rules and prohbtons

12 / EN
•
•
•
•
•
3

Floor standing air conditioner / Installation Manual 13 / EN
4.1 Indoor unt
1
2
3
4
5
6
7
8
9
10
Indoor unt
1. Airflow direction flaps
2. Deflectors
3. Indoor unit rating label
4. Signal receiver
5. Led display
6. Control panel
7. Front panel
8. Air filter
9. Front panel
10. Remote controller
4.2 Outdoor unt
11
12
13
14
15
Outdoor unt
11. Air outlet grille
12. Outdoor unit rating label
13. Terminal block cover
14. Gas valve
15. liquid valve
C
Note: the above figures are only
intended to be a simple diagram
of the appliance and may not
correspond to the appearance
of the units that have been
purchased.
4 Names of the parts

14 / EN Floor standing air conditioner / Installation Manual
1
2 4 6 17 8 18 10 11
7 8 14-13-123 16 15 5
2 3 4 5 6 7 8 9 4 7 63 5
Signal receptor Signal receptor
A
Warnng:
The shape and position
of indicators may vary
according to the model, but
their function is the same.
5 Indoor unt dsplay

Floor standing air conditioner / Installation Manual 15 / EN
No. Led Functon
1Shows that the unit is powered
2Feel mode indicator
3Dehumidifying indicator
4Cooling indicator
5Indicates the set temperature in °C or ° F or time in hour
6Heating indicator, flashes in defrost circle and Anti-cold air function,
7Fan only operation indicator,
8
Timer on
Timer o
Timer mode
9Healthy indicator
10 Eco indicator
11 Super indicator
12 High Fan Speed indicator
13 Middle Fan Speed indicator
14 Low Fan Speed indicator
15 "Flap" Swing indicator
16 Sleep indicator
17 Deflectors Swing indicator
18 Anti-mildew indicator
5 Indoor unt dsplay

16 / EN Floor standing air conditioner / Installation Manual
1
Swing
Temp down Temp up Fan Swing Mode
Fan Temp- Temp+ Mode On/O
234 5 6
3 4 2 1 5 6
No. Button Functon
1Swing To activate or deactivate of the movement of the "Flaps" and deflectors.
2Fan To select the fan speed of auto/low/mid/high
3Temp- Decrease the temperature or time by 1 unit
4Temp+ Increase the temperature or time by 1 unit
5Mode To select the mode of operation
6On/Off To switch the conditioner on and off.
7Composite button
Keep pressing the Swing button on the control panel for 3 seconds (two
beeps), then press the button "Temp up" activates the "flaps" the air flow
is directed from up to down and press the button "Temp down" activates
the "deflectors" the air flow is directed from rightward or leftward.
A
Warnng:
The shape and position of the emergency button may be different
according to the model, but their function is the same.
C
Note:
The external static pressure of heat pumps is 0 Pa for all models.
6 Indoor unt control panel

Floor standing air conditioner / Installation Manual 17 / EN
7 Remote control
No. Button Functon
1(Temp up) Press it to increase temperature/time setting.
2(Temp down) Press it to decrease temperature/time setting.
3On/Off Press it to start or stop operation.
4Fan To select the fan speed of auto/low/mid/high.
5Timer Press it to set auto-off timer.
6Sleep To activate the function "Sleep"
7Eco
In cooling mode, press this button, the temperature will increase 2°C
on the base of setting temperature
In heating mode, press this button, the temperature will decrease 2°C
on the base of setting temperature
8Mode To select the mode of operation
9Turbo
Press this button to activate/deactivate the Super function which
enables the unit to reach the preset temperature in the shortest time.
In Cool mode, the unit will give the maximum cooling temperature with
16°C, high fan speed. In Heat mode, the unit will give the maximum
heating temperature with 31°C, high fan speed.
10 Swing To activate or deactivate of the movement of the deflectors.
11 Display To switch on/off the Led display
12 Mute To activate the function of Mute.
13 Zone follow
To switch active/deactive "Zone follow" function. The air conditioner
will regulate the room temperature based on the temperature
(0°C-50°C) around the remote controller. This function will terminate
2 hours later once it's active. (If applicable)
14 (Mode+Timer) To activate the function of Child Lock when press Mode and Timer
buttons together. (If applicable)
A
Warnng:
• The out looking and some function of remote controller maybe
difference.
• The shape and position of buttons and indicators maybe difference
according to the model, but their function is the same.
• The unit confirms the correct reception of each press button with a beep.

18 / EN Floor standing air conditioner / Installation Manual
4
3
1
2
7
6
12
8
10
5
11
13
9
Temp
Sleep Display Timer
Mute Turbo Zone
follow
Swing
Mode
Fan
Eco
A
Warnng:
• The out looking and some function of remote controller maybe difference.
• The shape and position of buttons and indicators maybe difference
according to the model, but their function is the same.
8 Remote controller

Floor standing air conditioner / Installation Manual 19 / EN
8.1 Remote controller
dsplay
Meanng of symbols on the lqud crystal
dsplay
No. Symbols Meanng
1Auto mode
indicator
2Cooling indicator
3Dehumidifying
indicator
4
Fan only
operation
indicator
5Heating indicator
6Signal reception
indicator
7Timer Off
indicator
8Timer On
indicator
9Auto Fan
indicator
10 Low Fan Speed
indicator
No. Symbols Meanng
11 Middle Fan Speed
indicator
12 High Fan Speed
indicator
13 Sleep indicator
14 Flap Swing
indicator
15 Turbo indicator
16 Eco indicator
17 Clock indicator
18 Zone follow
indicator
8 Remote controller

20 / EN Floor standing air conditioner / Installation Manual
8.2 Replacement of
batteres
(1)
Heat
°F
Cool
°F
No
Remove the battery cover plate from the rear
of the remote controller, by sliding it in the
direction of the arrow.
Install the batteries according the direction
(+and -) shown on the remote controller.
Reinstall the battery cover by sliding it into place.
A
Warnng:
• Use 2 LRO 3 AAA (1.5V)
batteries. Do not use
rechargeable batteries.
Replace the old batteries
with new ones of the same
type when the display is no
longer legible.
• Do not dispose batteries as
unsorted municipal waste.
Collection of such waste
separately for special
treatment is necessary.
A
Refer to pcture 1:
• When you open the battery cover, you can see a DIP switch on the cover
back. 1
DIP switch on
position
Function
°C The remote controller is adjusted in degree celsius
°F The remote controller is adjusted in degree fahrenheit.
Cool The remote controller is adjusted in only cooling mode.
Heat The remote controller is adjusted in cooling and heating mode.
C
Note: After adjusting the function, you need to take out the
batteries and repeat the procedure described above.
8 Remote controller
