Beko BRH90CX User manual

Range Hood
User Manual
BRH60CX BRH90CX
EN

This product has been manufactured in environmental friendly modern plants without giving any harm to the nature.
This appliance conforms to the
WEEE regulation.
It does not contain PCB.
Please read this manual first!
Dear Customers!
Thank you for preferring a Beko product. We hope that you get the best results from
your product which has been manufactured with high quality and state-of-the-art
technology. Therefore, please read this entire user manual and all other accompanying
documents carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well. Follow all
warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences
between the models are explicitly described in the manual.
Meanings of the Symbols
Following symbols are used in the various section of this manual:
C
Important information and useful hints about
usage.
AWARNING:
Warnings for dangerous situa -
tions concerning the safety of life and property.
B
Warning for electric shock.
Warning for hot surfaces.

Hood / User Manual 3 / EN
1 Important safety and environmental
instructions
This section contains safety
instructions that will help protect
from risk of personal injury or
property damage. Failure to follow
these instructions invalidates the
granted warranty.
1.1 General safety
•Always have the installation and
repairing procedures carried out
by the Authorised Service Agent.
Manufacturer shall not be held
responsible for damages that
may be caused by unauthorised
persons.
•This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities, or
lack of experience and knowledge.
Children should be supervised to
ensure that they do not play with
the appliance.
1.1.1 Electrical safety
•Always unplug the appliance
from the mains supply during
installation, maintenance,
cleaning and repair operations.
•If the power cable is faulty,
it should be replaced by a
qualified person certified by
the manufacturer, after-sales
service or similar (preferably an
electrician) or a person described
by the importer.
•Operating voltage is 220 to 240
volts.
•If the appliance has a failure, it
should not be operated unless it is
repaired by the Authorised Service
Agent. There is the risk of electric
shock!
•Do not route power cable close
to hobs. Otherwise power cable
may cause fire since it melts down
easily.
•Never plug the hood before
installation is completed.
•In order to obtain the best
performance, external conductor
must not be longer than 4 m. It
must not contain more than 2
perpendicular (90°) angles and its
diameter must be min. ø120 mm.
•Disconnect the appliance from
mains before any intervention to
the internal parts of the appliance.
•Use the appliance with a grounded
outlet only.

4 / EN Hood / User Manual
1 Important safety and environmental
instructions
1.1.2 Product safety
•You can use a pipe with a diameter
of 120 mm or 150 mm on the flue
connection of the hood.
•Do not make connections to the
flues connected with stoves,
exhaust shafts or flues with rising
flames. Observe the rules set by
authorities on the discharge of
exhaust air.
•The minimum distance from the
surface of the hood to the upper
surface of the stove/hob should
not be less than 65 cm.
•Turn o ff the hobs before taking
away pans or pots.
•Avoid inflammable materials under
the hood.
•Oil may ignite while frying foods.
Therefore, be careful about cloths
and curtains.
•Never leave the cooker unattended
when frying foods; otherwise hot
oil may cause fire.
•There is the risk of fire if your hood
is not cleaned in the specified
periods.
•Be extremely careful and wear
gloves when cleaning the hood.
•We advise you to operate the
appliance a few minutes before
starting to cook in order to
increase the suction power. Thus,
you shall have a continuous and
stable suction power when the
vapors arise.
•Do not operate the hood without
grease filters and do not
remove the filters while it is
operated.
•Never touch the hood's lamps
after they are operated for a long
time. Hot lamps may burn your
hand.
•Avoid large flames beneath the
product. Otherwise, particles on
oil filter may ignite and lead to a
fire.
•Turn on the hobs after placing
pans or pots on it. Otherwise,
rising heat may deform certain
parts of your product.
•If the supply cord is damaged, it
m u s t b e r e p l a c e d b y t h e
manufacturer or its service agent
or a similarly qualified person in
order to avoid a hazard.

Hood / User Manual 5 / EN
1 Important safety and environmental
instructions
•the appliance by a person
responsible for their safety.
•Children should be supervised so
that they do not play with the
appliance.
•To avoid the risk of fire, clean
the metal filter regularly,
permanently control pans
containing hot oil and do not
flambé food underneath the
hood.
•Do not use the hood if it
shows signs of damage or
imperfection. Contact an
authorised service agent or the
manufacturer.
•Accessible parts may heat up
when using cooking appliances.
•Do not allow the hood to be
used by children or persons
with reduced (physical, sensory
or mental) capabilities or lack of
experience and knowledge,
unless they have been given
instruction concerning use of
•Pay attention not to connect
the appliance to the flues used
by non-electrical devices. (E.g.:
Heater flue).
•Simultaneous and smooth
operation of the hood and another
device that require air is only
possible when a low pressure
of 4 Pa (0.04 mbar) is reached,
and thus the reabsorption of the
gas is avoided. This can only be
achieved by means of air coming
from uncovered openings (door,
window, ventilation openings
or other technical measures).
Pay utmost attention to provide
sufficient air flow. A flue that
provides air ingress/egress is not
enough for this purpose.
•Operate your hood for 15 minutes
more after the end of cooking or
frying in order to remove the smell
and cooking vapor in the kitchen.
•When the hood is in use, especially
A
The hood may stop working during
an electrostatic discharge
electricity supply to the hood
(e.g.lightning). This involves no risk
of damage. Switch o ff the
and reconnect after one minute.
together with gas cookers or
other fuels, make sure that
environment is ventilated with
clean air.

6 / EN Hood / User Manual
1 Important safety and environmental
instructions
1.1.3 Children's safety
•Packaging materials are dangerous
to children. Keep packaging
materials in a safe place out of
reach of children.
•Electrical appliances are
dangerous to children. Keep
children away from the product.
Do not allow children play with the
appliance.
•This appliance can be used by the
children who are at the age of 8 or
over and by the people who have
limited physical, sensory or mental
capacity or who do not have
knowledge and experience, as
long as they are supervised with
regard to safe use of the product
or they are instructed accordingly
and understand the risks of using
the product. Children should not
play with the appliance.
• CAUTION: Accessible parts may
heat up when used with a cooking
device.
1.2 Intended use
•This appliance is intended for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
•The manufacturer shall not be
liable for any damage caused by
improper use or handling.

Hood / User Manual 7 / EN
• WARNING: Failure to fix the
screws in concordance with
the instructions provided in the
manual may lead to electrical
hazards.
1.3 Compliance with WEEE
Directive and disposing of the
waste product
This product complies with EU WEEE
Directive (2012/19/EU). This product
bears a classification symbol for waste
electrical and electronic equipment
(WEEE).
This product has been manufactured with high
quality parts and materials which can be reused
and are suitable for recycling. Do not dispose of
the waste product with normal domestic and other
wastes at the end of its service life. Take it to the
collection center for the recycling of electrical and
electronic equipment. Please consult your local
authorities to learn about these collection centers.
Compliance with RoHS
Directive:
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.4 Package information
Package of the product is made of
recyclable materials in accordance with
our National Legislation. Do not dispose
of the packaging materials together with the
domestic or other wastes. Take them to the
packaging material collection points designated by
the local authorities.
1 Important safety and environmental
instructions

8 / EN Hood / User Manual
2 Technical specifications of your appliance
Fig.1 Explanatory figure of the kitchen hood
Chimney cover
Electronic control
Lighting
Baffle filter
BRH60CX BRH90CX
Width
Depth
Height
Supply Voltage
Control
Suction power
Motor power
Lamp power
Total power
Net weight
Gross weight
600 mm 900 mm
500 mm 500 mm
Min. 710 - Max. 1150 mm Min. 710 - Max. 1150 mm
220-240V~50 Hz 220-240V~50 Hz
Electronic Tact Switch with
Speed Display
700 m /h
3700 m /h 3
240 W 240 W
2 x 2 W 2 x 2 W
244 W 244 W
14.4 kg 16.3 kg
17.6 kg 20.5 kg
Electronic Tact Switch with
Speed Display

Hood / User Manual 9 / EN
2 Technical specifications of your appliance
Fig.2 Dimension drawing
600/900
500
530
24
83
Min 710 - Max 1150
320
290

10 / EN Hood / User Manual
3 Operating your appliance
The hood is designed for suction of fumes while
preparing meals. The device can be operated in
two modes:
As extractor: vapors are removed outside
the room by means of a venting pipe. The venting
pipe is not available with the device and must be
purchased separately.
A
Use the shortest vapor discharging
pipe possible.
A
The venting pipe shall have the
smoothest inner surface as possible
(it is not recommended to use pipes
of type spiro).
A
Use a pipe with as few bends as
possible (bending angles should not
be greater than 90 degrees).
A
It is not recommended to apply
section changes of the pipe (larger
to smaller e.g. air outlet Ø150 mm to
air outlet Ø120mm).
As absorber: vapors are cleaned of grease
and odors before they are returned to the room
through the grille on the upper chimney cover. If
the hood shall work as an absorber, it is necessary
to install an active carbon filter. The carbon
filter is not standard equipment; it must be
purchased from a vendor.

Hood / User Manual 11 / EN
4 Installing your appliance
A
T h e ex h a u s t a ir m u s t n ot be
discharged into a flue which is used
for exhausting fumes from other
appliances burning gas or other fuels.
Assembly Insole
900 550
700 460
600 440
A B
•The above restrictions do not apply to hoods
wi th no fumes outlet to out sid e
(recirculation system with activated charcoal
filter).
•Use a rigid PVC pipe with a min. Ø l20 mm to
evacuate fumes outside.
•Install the hood in line with the
instructions on the template .
Regulations concerning the discharge
of air have to be fulfilled.

12 / EN Hood / User Manual
4 Installing your appliance
Before installation, the following must be done:
•Check that the dimensions of the purchased
product are adapted to the selected target spot.
•Disconnect and remove (if possible) the
furniture located in the installation area of the
hood to get easy access to the ceiling or wall
to which the hood is to be fitted. If this is not
possible, the elements located near the working
area must be secured.
•Verify if there is a plug socket close to the hood
installation area and if it is possible to connect
the hood to the vent pipe evacuating the vapors
outside.
•Verify if the drilling spots do not cover
installation wires (electrical, hydraulic, etc.).
•Be equipped with the following tools: measuring
tape, pencil, drill/ driver, drill Ø8, screwdriver,
bubble level.
4.1 Installation works
A
The installation must be carried out
very carefully, so as not to scratch
the chimney cover and the hood.
A
B
C
DE
F
[Ø6 x 30mm] x8
[4 x 32mm] x8
[4 x 12mm] x4

Hood / User Manual 13 / EN
4 Installing your appliance
[Ø6 x 30mm] x4 [4 x 32mm] x4

14 / EN Hood / User Manual
4 Installing your appliance
[4 x 12mm] x2
[Ø6 x 30mm] x4 [4 x 32mm] x4

4 Installing your appliance
[4 x 12mm] x2
Hood / User Manual 15 / EN

4 Installing your appliance
4.2 Electric connection
The mains voltage must correspond to the voltage
indicated on the rating plate affixed to the inside
of the hood. If the kitchen hood is equipped with
a plug, it should be put in a socket connector that
meets the requirements of binding regulations
and is located in an easily accessible place. If the
hood is not fitted with a plug, the installation of
the hood should be entrusted to someone with
appropriate permissions (e.g. electrician).
A
Before connecting the hood:
switch o ff the electricity supply
and check that the supplied voltage
and frequency coincide with that
i n d i c at e d o n t h e a p p l i a n c e
nameplate.
If the extractor hood has a plug, connect it to
a power socket in line with applicable regulations,
located in an accessible area.
If the hood does not have a plug, connect it
directly to the electrical grid, protected by a
separator device accessible for disconnection, in
line with local regulations.
16 / EN Hood / User Manual

Hood / User Manual 17 / EN
5 Cleaning and maintenance
Before carrying out any maintenance operations
on the appliance, remove the plug from the
wall outlet. The hood should be cleaned with
mild cleaning agents, do not use abrasives.
Regular maintenance significantly improves the
performance and durability of the hood. The hood
should be cleaned at least once a month or every
35 hours of hood operation. To clean hood DO NOT
USE ALCOHOL-BASED AGENTS. Satin items (inox)
should be cleaned with special preparations for
that purpose.
A
Failure to comply with the provisions
relating to cleaning of the device and
replacement of filters may cause fire
risks. It is therefore recommended
to comply with the guidelines given
herein. The manufacturer is not lia-
ble for any damage to the engine or
fires caused by improper use.
A
Always switch off the electricity
supply before carrying out
maintenance work on the hood. In
the event of a fault, contact an
official distributor or authorised
service agent.
5.1 Exterior Cleaning
Use non-corrosive, liquid detergent and avoid
the use of abrasive cleaning products.
5.2 Grease Filter
To avoid fires, clean thoroughly once a month
or whenever the display pilot light indicates
as such. To do so, remove the filters and
wash with hot water and detergent. If using
a dishwasher, position the filters vertically to
prevent solid remains from depositing on
them. do not use polish to clean or shine.
5.3 Activated Charcoal Filter
C
Increase the filter cleaning/
replacement frequency if the hood
is used for more than 2 hours a
day. Always use genuine filters
from the manufacturer.
Replace the charcoal filter every 3 months.
5.4 Replacing of lighting
Do not handle the bulbs until the
electricity supply has been switched
o ffand they have cooled.
A
Use new bulbs according to that
indicated on the hood name plate.
C
O n co o ke r ho o d s e q ui p p e d w i t h L E D
lamps, the lights should only be used during
operation of the motor. They should not be
left on permanently and use as a light source.
Contact customer service for bulb
replacement on specific model.
C

18 / EN Hood / User Manual
6 Control of hood operation
6.1 Control of the hood
The different control panels are described
below. Check the panel model installed on
your hood and see the figure indicated in each
case.
6.2 Methods of reducing the
effect of cooking process on
the environment
•To reduce Energy consumption, cook with using
covers on kitchenware.
•Grease filters must be kept clean
(recommended length of grease filter
operation between cleanings is max. 35h of
hood operation).
•Take care of permeability of the ventilation
pipes.
•The operation level of the turbine when cooking
shall be always set to a minimum gear, which
will allow removing the fumes at the current
intensity of cooking.
Four-speed panel - Digital display
1 - Lighting on and off.
2 - Extractor fan on and off.
3 - Decrease extractor fan speed.
4 - Extractor fan speed display panel.
5 - Increase extractor fan speed.
6 - Enable extractor fan turbo speed.
7 - Enable and disable extractor fan timer.
Timer:
The extractor fan works for 5 min. at the
current speed and another 5 min. at each
if the lower speeds until it stops and the
lighting switches off.
1 22 23 24 25 26

Hood / User Manual 19 / EN
7 Solving problems
Symptoms Cause Repairing method
One or more light points do not
operate.
Defective halogen/ LED bulb. The light bulb needs to be replaced
with a new, compatible with the symbol
specified in the instruction manual for
the cooker hood.
loosely fitted leaving clearance. vertically, tighten all mounting screws.
If the recommendations above do not solve the problem, contact an authorised service agent entitled to repair.
Under no circumstances is the hood user entitled to independent repair.
No symbol is shown on the display, the
hood does not respond to pressing the
control fields.
The touch control is probably
suspended.
Disconnect the hood from the power
supply for about 15 sec. and switch it on
again.
The hood has very poor vapor suction. Probably cause is dirty filters. The grease filter must be cleaned in the
dishwasher or replace with a new one.
The carbon filter (if present) must be
replaced with a new one.
The hood generated excessive noise
and vibration.
This may be caused by an incorrect
installation of the hood to the wall
or kitchen cabinets. Not all provided
screws have been used or screws are
The hood must be mounted to a wall or
cabinet by using all the points provided
for by the manufacturer. After adjusting
the position of the hood horizontally and

www.beko.com
8Legal Information
8.1 The Manufacturer
Is not responsible for any failure to observe
the instructions given in this manual and
current safety regulations for the correct use of
the equipment.
•
Reserves the right to make any modications
to the equipment or this manual without
prior notice.
•
Contact our ocial distributor should you
require technical assistance or additional
information on our products.
VER 1712
