Please read this user manual first!
Dear Valued Customer,
Thank you for preferring this Beko appliance. We hope that you get the best results
from your appliance which has been manufactured with high quality and state-
of-the-art technology. For this reason, please read this entire user manual and all
other accompanying documents carefully before using the appliance and keep it as a
reference for future use. If you handover the appliance to someone else, give the user
manual as well. Follow the instructions by paying attention to all the information and
warnings in the user manual.
Remember that this user manual may also apply to other models. Differences between
models are explicitly described in the manual.
Meanings of the Symbols
Following symbols are used in various sections of this user manual:
C
Important information and useful hints
about usage.
A
WARNING: Warnings against danger-
ous situations concerning the security
of life and property.
Warning for danger of fire.
B
Warning for electric shock.
Does not contan PCB.

Hood / User Manual
4 / EN
1 Important nstructons for safety and
envronment
1.1 General Safety
Important Safety Instructions Read
Carefully And Keep For Future Ref-
erence This section contains safety
instructions that will help protect
from risk of fire, electric shock, ex-
posure to leak microwave energy,
personal injury or property damage.
Failure to follow these instructions
shall void any warranty.
•Beko products comply with the
applicable safety standards;
therefore, in case of any damage
on the appliance or power cable,
it should be repaired or replaced
by the dealer, service center or a
specialist and authorized service
alike to avoid any danger. Faulty
or unqualified repair work may be
dangerous and cause risk to the
user.
•This appliance is intended to be
used in household and similar ap-
plications such as:
– Staff kitchen areas in shops, of-
fices and other working environ-
ments;
– Farm houses
– By clients in hotels, and other
residential type environments;
– Bed and Breakfast type environ-
ments.
•Operate the appliance for its in-
tended purpose only as described
in this manual.
•The manufacturer cannot be held
liable for damages resulting from
improper installation or misuse of
the product.
•This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental ca-
pabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
•Children shall not be allowed play
with the appliance. Cleaning and
user maintenance shall not be
made by children without super-
vision.
•The minimum distance between
the supporting surface for the
cooking vessels on the hob and
the lowest part of your product
must be at least 65 cm.
•If the instructions for installation
for the gas hob specify a greater
distance, this has to be taken into
account.
•Make sure that your mains power

5 / EN
Hood / User Manual
1 Important nstructons for safety and
envronment
supply complies with the informa-
tion supplied on the rating plate of
the appliance.
•Never use the appliance if the
power cable or the appliance itself
is damaged.
•Prevent damage to the power
cable by not squeezing, bending,
or rubbing it on sharp edges. Keep
the power cable away from hot
surfaces and naked flame.
•Use the appliance with a grounded
outlet only.
WARNING: Do not connect the
appliance to the mains until the
installation is fully complete.
•Place the appliance in a way so
that the plug is always accessible.
•Do not touch the lamps if they
have operated for a long time.
They can burn your hands since
they will be hot.
•Follow the regulations set out
by competent authorities on dis-
charge of the exhaust air (this
warning is not applicable for use
without flue).
•Operate your appliance after put-
ting a pot, pan etc. on the hob.
Otherwise, high heat may cause
deformation in some parts of your
product.
•Turn off the hob before taking the
pot, pan etc. from it.
•Do not leave hot oil on the hob.
Pans with hot oil may cause self
combustion.
•Pay attention to your curtains
and covers since oil may catch fire
while cooking food such as fries.
•Grease filter must be replaced
at least monthly. Carbon filter
must be replaced at least every 3
months.
•Product shall be cleaned accord-
ance with user manual. If cleaning
was not carried out in accordance
with user manual, there may be
fire risk.
•Do not use non-fire-resistant fil-
tering materials instead of the
current filter.
•Only use the original parts or parts
recommended by the manufac-
turer.
•Do not operate the product with-
out the filter and do not remove
the filters while the product is
running.
•In the event of be started any
flame, de-energize your product
and cooking appliances.
•In the event of be started any
flame, cover the flame and never

Hood / User Manual
6 / EN
use water to extinguish.
•Unplug the appliance before each
cleaning and when the appliance
is not in use.
•The negative pressure in the en-
vironment should not exceed 4 Pa
(4 x 10 bar) while the hood for
electric hob and appliances run-
ning on another type of energy
but electricity operate simultane-
ously.
•In the environment where the ap-
pliance is being used, the exhaust
of devices running on fuel oil or
gas, such as room heater must be
absolutely isolated or device must
be hermetical type.
•When connecting the flue, use
pipes with a diameter of 120 or
150 mm. Pipe connection must
be as short as possible and have
as few elbows as possible.
Danger of choking! Keep all the
packaging materials away from
children.
CAUTION: Accessible parts may
become hot when used with cook-
ing appliances.
•The product outlet must not be
connected to air channels that in-
clude other smoke.
•The ventilation in the room may
be insufficient when the hood for
electric hob is used simultane-
ously with the devices operating
on gas or other fuels (this may not
apply to appliances that only dis-
charge the air back into the room).
•Objects placed on the product
may fall. Do not place any objects
on the product.
•Do not flambe under the your
product.
WARNING: Before installing the
Hood, remove the protective films.
•Never leave high naked flames
under the hood when it is in op-
eration
•Deep fat fryers must be continu-
ously monitored during use: over-
heated oil can burst into flames.
1 Important nstructons for safety and
envronment

7 / EN
Hood / User Manual
1.2 Compliance with the WEEE
Directive and Disposing of the
Waste Product: This product
complies with EU WEEE Directive
(2012/19/EU). This product bears a
classification
symbol for waste electrical and
electronic equipment (WEEE).
This symbol indicates that
this product shall not be
disposed with other house-
hold wastes at the end of
its service life. Used device must be
returned to offical collection point
for recycling of electrical and elec-
tronic devices. To find these collec-
tion systems please contact to your
local authorities or retailer where
the product was puchased. Each
household performs important role
in recovering and recycling of old
appliance. Appropriate disposal of
used appliance helps prevent po-
tential negative consequences for
the environment and human health.
1.3 Compliance with RoHS
Directive
The product you have purchased
complies with EU RoHS Directive
(2011/65/EU). It does not contain
harmful and prohibited materials
specified in the Directive.
1.4 Package Information
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do not
dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designat-
ed by the local authorities.
1 Important nstructons for safety and
envronment

Hood / User Manual
8 / EN
1. Inner Chmney
2. Outer Chmney
3. Glass Cover
4. Control Panel
5. Lghtnng
Values stated on the product labels or in the documentation accompanying it are obtained in laboratory
conditions in accordance with relevant standards. These values may vary depending on operational and
environmental conditions of the product.
2 Techncal specfcatons of your applance
(Figure 1)
1
2
3
4
5
HCA63640B-W HCA63640BH HCA93640BH HCA93641BH HCA63640Z
Wdth 596 mm 596 mm 896 mm 896 mm 596 mm
Depth 410 mm 410 mm 410 mm 410 mm 410 mm
Heght 750 mm/1080 mm 750 mm/1080 mm 750mm/1130 mm 750mm/1130 mm 750 mm /1080 mm
Supply
voltage 220 - 240 V~ 50 Hz 220 - 240 V~ 50 Hz 220 - 240 V~ 50 Hz 220 - 240 V~ 50 Hz 220 - 240 V~ 50 Hz
Control Wth 3 levels Wth 3 levels Wth 3 levels Wth 3 levels Wth 3 levels
Lamp
power 2 x 3 W 2 x 3 W 2 x 3 W 2 x 3 W 2 x 3 W
Ar outlet
ppe 120 / 150 mm 120 / 150 mm 120 / 150 mm 120 / 150 mm 120 / 150 mm
Motor
power 210 W 210 W 210 W 210 W 210 W
Total
power 216 W 216 W 216 W 216 W 216 W
Colour B=Black W=Whte Zara grey

9 / EN
Hood / User Manual
A
WARNING
Please consult the nearest
Authorised Service Agent for the
installation of your hood.
A
WARNING
*Preparation of location and electri-
cal installation for the product is un-
der customer’s responsibility.
A
WARNING
Remove the protective film (if any)
on the hood and flue surface after
the installation.
53 0
04 0
02
211
164
42
08
57:n M0 0801:xa
053
596
410
93 4
(Figure 2a)
3 Installng your applance
(Figure 2b)
Distance between lower surface of the hood
and upper surface of the hob should be at least
65 cm.
Have a qualified electrician make the electrical
connection.
Install your appliance so that you can reach the
power connection (plug, outlet) easily after in-
stallation.
Dimensions are given in mm.

Hood / User Manual
10 / EN
3.1 Installaton accessores
1 x flue connection plate
1 x Ø120/150 mm plastic
flue adapter
Information required for the preparation of the in-
stallation place for your hood is given below.
3.2 Installng the hood onto
the wall
To install the hood onto the wall, loosen the
screws of hanger plates on the motor housing and
pull the plates upwards. Then, tighten the screws
of the hanger plates. (Figure 3a).
(Figure 3a)
Hanger plate
(Figure 3b)
External flue connection plate
If you will use Ø 120 mm flue pipe, install Ø 120
mm flue adapter onto it.
3 Installng your applance

11 / EN
Hood / User Manual
3.2.1 Borng the hanger holes
Affix the installation template onto the installa-
tion place of the hood. Drill the points market with
(X,Y) (Figure 4) using a Ø 8 mm bit and points
market with (Z) (Figure 4) using a Ø 6 mm bit.
Z
Y
X
COOKING ZONE
Bottom surface of the appliance
Y
Y
Z
X
Z
X
8
8
8
8 mm plastic
wall plug
6 mm plastic
wall plug
(Figure 4)
3 Installng your applance

Hood / User Manual
12 / EN
3.2.2 Hammerng the wall plugs
Hammer Ø 8 mm wall plugs (X,Y) into the holes
drilled for hanger screws. Hammer 2 x Ø 6 mm
wall plugs (Z) into the holes drilled with a Ø 6
mm bit for the external flue connection plate.
(Figure 5)
3.2.3 Installng the hanger
screws
Install 4.9x50 hanger screws into the Ø 8 mm wall
plugs (Y) you have hammered into the wall. There
must be a gap of 5 mm between the screw head
and the wall. (Figure 5)
Connect the internal flue connection plate to the
8 mm wall plugs (Z) on the wall using Ø 3.9x22
screws. (Figure 5)
Y
Y
Z
X
Z
X
(Figure 5)
4.9x50 Cross-
head screw 3.9 x 22 Cross-head screw
3.2.4 Hangng the hood onto the
wall
•Hang the hood onto the screws you have in-
stalled into the Y holes.
•Open the side suction window of the hood by
pulling it towards yourself. Install the 4.9x50
screws through the X holes located inside in
order to secure the appliance.
3 Installng your applance

13 / EN
Hood / User Manual
3.3 Installng the hood flue
Disconnect the product from mains supply before
starting flue installation. Fit the sheet metal flue
parts around the body.
Screw the external flue to the external flue con-
nection plates located on the motor housing.
(Figure 3b / 6)
Extend and screw the internal flue from its outer
edges onto the flue connection plate which was
secured to the wall (Figure 7).
(Figure 6)
(Figure 7)
3 Installng your applance

Hood / User Manual
14 / EN
3.4.1 Usng wth flue connecton
•The vapour is removed via flue pipe which is se-
cured to the connection head on the hood.
•Diameter of the flue pipe should be equal to the
diameter of connection ring. To allow the air be
removed easily out of the room in horizontal
arrangements, the pipe should be slightly tilted
upwards (approximately 10°).
3.4.2 Usng wthout flue
connecton
•Air is filtered by the carbon filter and returned to
the room. Carbon filter is used when there is no
flue in the house.
•ıf the hood will be used without flue connection
remove the diverters inside the flue adapter.
•Remove the aluminum filter. To install the car-
bon filter, center the carbon filter on the plastic
part on both sides of the fan body, and secure it
on the tabs. Secure the filter by turning the tabs
to right or left.
•Install the aluminum filter.
3.5 Flue connecton:
Place adapter supplied together with the hood
into the ventilation hole located on the top sec-
tion of the hood. Procure a pipe with a diameter of
120/150 mm. Connect one end of the pipe to the
adapter and the other end to the flue.
Make sure that these two connections are secure
enough
so that they will not dislocate when the hood
is operated in max. speed. Check that the flaps
inside flue are functional when tightened with
the clamp. Fit the flue connection pipe onto the
adapter. If you fit the flue connection pipe inside
the adapter, air suction will not occur since the
flaps that prevent air backflow will remain closed.
It is not advisable to make connections to the
flues connected with stoves or exhaust shafts. Do
not make connections to such flues.
(Figure 7)
Pipe connection must be as short as possible and
have minimum number of elbows.
A: Flue outlet pipe
B: Flaps that prevent backflow
C: Plastic flue
3.5.1 Backflow prevention system (N-RV)
When the hood is operated, flaps are closed in or-
der to prevent possible odours and dust from en-
tering into the ambient from outside.
Correct Not correct
3 Installng your applance

15 / EN
Hood / User Manual
(A): 1st level key
(B): 2nd level key
(C): 3rd level key
(D): Light On / Off key
4.1 Dgtal electronc control
wth 3 levels
(A) You can start your hood at speed level 1 by
pressing this key.
When you press this key again to switch off the
appliance, speed level indication on the display
disappears.
(B) key: You can start your hood at speed level 2
by pressing this key.
When you press this key again to switch off the
appliance, speed level indication on the display
disappears.
(C) key:You can start your hood at speed level 3 by
pressing this key.
When you press this key again to switch off the
appliance, speed level indication on the display
disappears.
(D) key: Light On/Off Key: You can illuminate the
cooking area by pressing this key.
Auto-stop in 15 min.:
This appliance is equipped with an Auto-Stop
function which allows the appliance to ventilate
the room for an additional period of time in order
to remove the unpleasant odour and vapour in the
room after the cooking is over. Appliance stops au-
tomatically after a certain period of time.
To enable the Auto-stop function, press any of the
speed level keys (A, B, C) on the control for longer
than 2 seconds. A timer with 15 minutes will be
activated.
If you press the same speed level key while the
Auto-stop function is enabled, function will be
disabled and the appliance will stop.
If you select a different speed level this function
will be disabled.
If you want your appliance to stop automatically,
you must enable the Auto-stop function again.
Periodical cleaning of metal filters:
Filters must be cleaned at about every 60 hours of
operation or 4 weeks depending on the frequency
of usage.
(Figure 8)
4 Operatng your applance
A B C D

Hood / User Manual
16 / EN
4 Operatng your applance
4.2 Energy effcent usage:
•When operating the hood, adjust the speed
level according to the odour and vapour inten-
sity in order to prevent unnecessary power con-
sumption.
•Use low speeds in normal conditions (1-2), and
high speed (3) when smell and vapors are inten-
sified.
•Lights on the hood are intended for illuminating
the cooking zone.
Using them to illuminate the ambient/kitchen will
result with unnecessary power consumption and
inadequate illumination.
4.3 Operatng the hood:
•Hood is equipped with a motor having various
speed settings.
•For a better performance, we advise you to
use low speeds in normal conditions, and high
speeds when smell and vapors are intensified.
•You can start the hood by pressing the desired
speed level key (A,B,C).
•You can illuminate the cooking area by pressing
the light key. (D)

17 / EN
Hood / User Manual
Prior to cleaning and maintenance, unplug the ap-
pliance or turn the main switch off or loosen the
fuse that supplies the hood.
5.1 Alumnum flter
This filter captures oil particles in the air. You are
recommended to clean your filter every month
under normal usage conditions. First remove the
aluminum filters for this process. Wash the filters
with liquid detergent and rinse them with water
and install them back after they get dry. Aluminum
filters may get discolored as they are washed; this
is normal and you don't need to change your filter.
5.1.1 Removng the alumnum
flters
1. Push the alumnum flter lock forward.
2. Then, slghtly lower t and pull forward.
Otherwse, you may bend the flter. (Fgure 9)
After the alumnum flter s washed and dred,
renstall the flter to ts slot by applyng above
steps n reverse order.
Carbon filter (Using without flue)
This filter removes the cooking odours. If it is not
possible to use a flue, it purifies the air which is
circulated inside the kitchen. Carbon filter of your
appliance will get clogged in time depending on
the frequency of use, style of cooking and regular
cleaning of the aluminum filters.
A
Caution!
Carbon filter should never be
washed.
You may obtain carbon filters from Beko
Authorised Service Agents.
5.2.1 Replacng the carbon flter
•Remove the aluminum filters. (Figure 9)
•To remove carbon filter, turn the tabs counter-
clockwise and release the filter. (Figure 10
•Install the new carbon filter.
•Install the aluminum filters.
(Figure 10)
Anti-odor filters contain charcoal (active carbon).
They must be changed with periods of approxi-
mately 6 months.
Regardless of using a carbon filter or not, alumi-
num filters must always be installed.
Do not operate your appliance without the alu-
minum filter in place. Using with carbon filter will
decrease suction performance of the appliance.
C
You can also wash aluminum filters
in dishwasher.
5 Cleanng and mantenance
(Figure 9)

Hood / User Manual
18 / EN
5.3 Cleanng
Particularly do not neglect to clean your hood im-
mediately after you have made frying.
Use a soft cloth soaked with liquid detergent to
clean the outer surface of your hood.
Never use abrasive or scratching materials for
cleaning.
You may use the cleaning agents commercially
available for persistent grease etc. by following
the warnings on the product. In order not the
scratch the brushed steel body, wipe in the same
direction with the bush trace.
Do not use cleaning agents containing hydro-
chloric acid, bleach or abrasive powders in order
to maintain the surface quality of your product.
Use a cloth dampened in soapy water or special
stainless steel cleaning spray for stainless steel
steel surfaces. Remove the protective foil on the
appliance.
A
Caution!
You may cause a fire if you do not
follow the instructions on the clean-
ing and replacement of the filters of
your hood.
If you need to transport the appliance:
•Keep the original packaging of the appliance.
Transport the appliance with its original pack-
age, and follow the transport markings on the
original package.
If you do not have the original package:
•Do not place any objects on the hood.
•Protect the outer surface from impacts.
•Pack the appliance so that it would not be dam-
aged during transport.
5.4 Replacng the lamps
Disconnect the hood from the mains supply.
This appliance is equipped with 3 W halogen
lamps.
To replace the halogen lamps, press the lamp
downwards from the rear section of the lamp
holder to release the lamp. Then turn it counter-
clockwise by 1/4 tour and remove it.
Perform the above steps in reverse order to fit the
new lamps.
C
You may procure lamps from
Authorised Service Agents.
5 Cleanng and mantenance
Max:3W

Cooker Hood / User Manual 19 / EN
Troubleshooting Root Cause Help
Applance s not
workng. Check your fuses. Fuse may be blown, nspect and restore t.
Applance s not
workng. Check the electrcal connecton. Mans voltage shall be bet-
ween 220 and 240 V.
Applance s not
workng. Check the electrcal connecton. Check f other applance n your ktchen operate.
Illumnaton lght
does not operate. Check the electrcal connecton. Mans voltage shall be bet- ween 220 and 240 V.
Illumnaton lght
does not operate. Inspect the lamp swtch. Lamp swtch shall be at "on" poston.
Illumnaton lght
does not operate. Inspect the lamps. The lamps of the applance shall llumnate.
Ar nlet of the appl-
ance s nadequate. Inspect the alumnum flter. Under normal operatng condtons, alumnum gre-
ase flter shall be cleaned at
least once n a month.
Ar nlet of the appl-
ance s nadequate. Check the ar dscharge chmney. The ar dscharge chmney shall be at “on” poston.
Ar nlet of the appl-
ance s nadequate. Inspect the carbon flter. The flters of the applances wth carbon flters shall
be replaced once n every
3 months under normal
condtons.
6 Troubleshootng

Bitte lesen Sie zunächst diese Anleitung!
Sehr geehrte Kundn, sehr geehrter Kunde,
Velen Dank, dass Se sch für deses Gerät der Marke Beko entscheden haben. Wr snd
überzeugt, dass Se mt desem Gerät, das mt den höchsten Qualtätsanforderungen
und modernster Technologe hergestellt wurde, beste Ergebnsse erzelen werden.
Btte lesen Se de gesamte Bedenungsanletung und alle anderen Begletdokumente
aufmerksam, bevor Se das Gerät verwenden; bewahren Se se zum künftgen
Nachschlagen scher auf. Wenn Se das Gerät an jemanden wetergeben, händgen
Se hm btte auch dese Anletung aus. Befolgen Se de Anwesungen, ndem Se alle
Informatonen und Warnhnwese n der Bedenungsanletung beachten.
Btte denken Se daran, dass dese Bedenungsanletung eventuell für mehrere
Modelle geschreben wurde. Unterschede zwschen den Modellen werden n der
Anletung klar und deutlch beschreben.
Bedeutung der Symbole
Folgende Symbole werden n den verschedenen Abschntten deser Anletung
verwendet:
C
Wchtge Informatonen und nützlche
Hnwese zur Verwendung.
A
WARNUNG: Warnhnwese zu gefährlchen
Stuatonen m Hnblck auf de Scherhet
von Leb, Leben und Egentum.
Warnung vor Brandgefahr.
B
Warnung vor Stromschlägen.
Das Gerät erfüllt de Vorgaben der
WEEE Rchtlne.
Deses Produkt wurde mt der modernsten Technologe und unter umweltfreundlchen Bedngungen
hergestellt.
PCB-fre
