Belden Miranda DENSITE 3+ FR1 User manual

User Manual
969-99M00-100
26 October 2012

ii
Copyright © 2012 by Miranda Technologies
All rights reserved. No part of this manual may be reproduced in any form by photocopy, micro-
film, xerography or any other means, or incorporated into any information retrieval system,
electronic or mechanical, without the written permission of Miranda Technologies, Inc..
•Document revision: 100
•Document part number: 969-99M00-100
Change History
Notice
Because of continued product development, the accuracy of the information in this document
may change without notice. The information and intellectual property contained herein is confi-
dential between Miranda and the client and remains the exclusive property of Miranda. If you
find any problems in the documentation, please report them to us in writing. Miranda does not
warrant that this document is error-free.
Trademarks
Miranda is a registered trademark of Miranda Technologies, Inc..
Brand and product names mentioned in this manual may be trademarks, registered trademarks
or copyrights of their respective holders. All brand and product names mentioned in this
manual serve as comments or examples and are not to be understood as advertising for the
products or their manufacturers.
Software License Agreement and Warranty Information
Contact Miranda for details on the software license agreement and product warranty.
Revision Published Description of Changes
974-99M00-100 26 Oct 2012 Initial release

iii
Densité 3+ FR1
User Manual
Safety Compliance
Electromagnetic Compatibility
This equipment complies with:
•CSA/UL/IEC 60065, 7th Ed. + AM1, Audio, video and similar electronic appa-
ratus - Safety requirements
The power cord supplied with this equipment meets the appropriate national
standards for the country of destination.
WARNING: An appropriately listed/certified mains power supply cord must be used
for the connection of the equipment to the mains voltage at either 120V~
or 240V~.
CAUTION: These servicing instructions are for use by qualified personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all
servicing to qualified service personnel.
This equipment has been tested for verification of compliance with FCC Part 15,
Subpart B requirements for Class A digital devices.
NOTE: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.

iv
Important Safeguards and Notices
This section provides important safety guidelines for operators and service personnel. Specific
warnings and cautions appear throughout the manual where they apply. Please read and follow
this important information, especially those instructions related to the risk of electric shock or
injury to persons.
Restriction on Hazardous Substances (RoHS)
Miranda is in compliance with EU Directive RoHS 2002/95/EC governing the restricted use of
certain hazardous substances and materials in products and in our manufacturing processes.
Miranda has a substantial program in place for RoHS compliance that includes significant invest-
ment in our manufacturing process, and a migration of Miranda product electronic components
and structural materials to RoHS compliance.
It is our objective at Miranda to maintain compliance with all relevant environmental and
product regulatory requirements. Detailed information on specific products or on the RoHS
program at Miranda is available from Miranda Customer Support.
This equipment has been tested and found to comply with the requirements of the
EMC directive 2004/108/CE:
•EN 55022 Conducted emissions, Class A
•EN 55022 Radiated emissions, Class A
•EN 61000-3-2 Harmonic current emission limits
•EN 61000-3-3 Voltage fluctuation and flicker limitations
•EN 61000-4-2 Electrostatic discharge immunity
•EN 61000-4-3 Radiated electromagnetic field immunity - RF
•EN 61000-4-4 EFT immunity
•EN 61000-4-5 Surge immunity
•EN 61000-4-6 Conducted immunity
•EN 61000-4-8 Power frequency magnetic field immunity
•EN 61000-4-11 Voltage dips, short-interruption and voltage variation immunity
WARNING
Any instructions in this manual that require opening the equipment cover or
enclosure are for use by qualified service personnel only. To reduce the risk
of electric shock, do not perform any service other than that contained in
the operating instructions unless you are qualified to do so.

v
Densité 3+ FR1
User Manual
General Warnings
A warning indicates a possible hazard to personnel which may cause injury or death. Observe
the following general warnings when using or working on this equipment:
•Heed all warnings on the unit and in the operating instructions.
•Do not use this equipment in or near water.
•This equipment is grounded through the grounding conductor of the power cord. To avoid
electrical shock, plug the power cord into a properly wired receptacle before connecting the
equipment inputs or outputs.
•Route power cords and other cables so they are not likely to be damaged.
•Disconnect power before cleaning the equipment. Do not use liquid or aerosol cleaners; use
only a damp cloth.
•Dangerous voltages may exist at several points in this equipment. To avoid injury, do not
touch exposed connections and components while power is on.
•Do not wear rings or wristwatches when troubleshooting high current circuits such as the
power supplies.
•To avoid fire hazard, use only the specified fuse(s) with the correct type number, voltage and
current ratings as referenced in the appropriate locations in the service instructions or on
the equipment. Always refer fuse replacements to qualified service personnel.
•There are no user-serviceable fuses in this equipment. Connection to the mains supply
should be via a circuit breaker or by a mains plug which meets the relevant local standards in
the country of installation.
•To avoid explosion, do not operate this equipment in an explosive atmosphere.
•Have qualified service personnel perform safety checks after any service.
•To avoid electrical shock or fire hazard, do not operate the equipment with its covers
removed.
•To prevent equipment from overheating, provide proper ventilation.
General Cautions
A caution indicates a possible hazard to equipment that could result in equipment damage.
Observe the following cautions when operating or working on this equipment:
•When installing this equipment, do not attach the power cord to building surfaces.
•To prevent damage to equipment when replacing fuses, locate and correct the problem that
caused the fuse to blow before re-applying power.
•Use only the specified replacement parts.
•Follow static precautions at all times when handling this equipment.
•This product should only be powered as described in the manual. To prevent equipment
damage, select the proper line voltage on the power supply(ies) as described in the installa-
tion documentation.
•To prevent damage to the equipment, read the instructions in the equipment manual for
proper input voltage range selection.

vi
•Some products include a backup battery. There is a risk of explosion if the battery is replaced
by a battery of an incorrect type. Dispose of batteries according to instructions.
•Products that have (1) no on/off switch and (2) use an external power supply must be
installed in proximity to a main power output that is easily accessible.

vii
Table of Contents
1Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
The Densité 3+ FR1 Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Key Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Available Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Cards (maximum 4 per frame) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2Densité 3+ FR1 Housing Frame . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Mechanical Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Opening the Front Door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing Cards in the Densité 3+ FR1 Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using Densité 2 cards in the Densité 3+ FR1 Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing the Power Cord Retaining Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Field-Serviceable Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Changing the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Replacing the Controller Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Replacing the Frame Ventilation Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3CPU-ETH2 Controller Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Control Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using the Ethernet interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using the local control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Card-Front Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Configuring the CPU-ETH2 Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Status Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
SNMP functionality. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Data Restoration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Factory Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Time Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

viii
Local Control Panel Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Contact Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Miranda Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Corporate Head Office. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

1
Introduction
Chapter 1 is an introduction to the Densité 3+ FR1 housing frame.
Topics
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 1
Key Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 2
Available Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 2
Cards (maximum 4 per frame) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 2
The Densité 3+ FR1 Frame
Overview
The 1RU Densité 3+ FR1frame offers true multi-format operation, with the ability to process
simultaneously 3Gbps, HD, SD, and analog video, as well as AES and analog audio. The frame
provides advanced monitoring and back-up capabilities. It can be fitted with 3RU and 2RU
Densité modules (using card extenders). The frame features dual hot-swappable power supplies
and fans. The modules for the frame are also hot-swappable, and can be configured automati-
cally when a card is replaced. The frame is air-cooled and all modules, redundant PSUs and fans
are monitored to provide status via GPI or the Ethernet port. The basic frame configuration
includes one PSU and a controller card, which allows card adjustments by the front panel. Front
panel multi-color LEDs provide status reporting. Multiple video and audio formats can be fitted
in a single chassis.

2
Introduction
Key Features and Benefits
•Multiple video and audio formats can be fitted in a single chassis
•Up to 4 cards in a single 1RU frame
•Backwards compatible with Densité 2 or Densité 3 modules
•Easy configuration by front panel or remotely via Ethernet
•Remote control by RCP-200 advanced control panel, and by Miranda’s iControl system
•Hot-swappable power supply, with optional redundant power supply
•Supports full range of interfacing, distribution and monitoring modules
•Can be stacked without additional cooling spaces
•Redundant Ethernet connections
•A dedicated slot for designated system cards
Available Options
Second power supply for redundant power security
Cards (maximum 4 per frame)
The Densité 3+ FR1 housing frame supports all current Densité 3 series cards directly. Many
Densité 2 series cards can also be installed with the use of an adapter that fits on the card, plus
an additional adapter to extend the rear panel.

3
Densité 3+ FR1 Housing Frame
Chapter 2 describes the Densité 3+ FR1 housing frame and details of its installation.
Topics
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Mechanical Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Installing Cards in the Densité 3+ FR1 Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
Using Densité 2 cards in the Densité 3+ FR1 Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 8
Field-Serviceable Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 9
Changing the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 10
Replacing the Controller Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 10
Replacing the Frame Ventilation Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 11
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 13
Description
Mechanical Layout
Front of the frame
When the frame door is opened, the front of the unit is visually divided into three sections:

4
Densité 3+ FR1 Housing Frame
•Left side - the Controller card with its attached control panel is seen on the left. The card
itself is installed in a horizontal slot near the top. A power supply is located below the con-
troller card in the frame.
•Center - four Densité 3 slots are laid out horizontally, two across by two down.
•Right side - a second power supply is located on the lower right, and above it is a single slot
reserved for System Cards.
NOTE - This slot supports ONLY designated System Cards; do not insert any other cards.
•At the time of writing, only the GPI-1501 card is supported
•For an up-to-date list of available System Cards, go to the Miranda website at
www.miranda.com
When the frame door is closed, the status LED on each of the cards in the frame is visible via a
light pipe in the door. No other controls or indicators are present.
Rear of the frame
The rear of the Densité 3+ FR1 frame is visually divided into three sections:
•Right side - this area contains inputs and
outputs for the Controller Card - the Fan
Speed control setting switch, the GPI port
and the two Ethernet ports. It also contains
the power socket for the power supply
located beneath the controller card, and
one of the two frame fans.
•Center - this area holds the rear panels associated with the frame’s four Densité-3 slots
•Left side - this area contains the power socket for the power supply located beneath the Sys-
tem Card, and one of the two frame fans.

5
Densité 3+ FR1
User Manual
Installation
Unpacking
Make sure the following items have been shipped with your Densité 3+ FR1 frame:
•Densité 3+ FR1 frame, including 1 Power Supply unit (AC in) with power cord
•CPU-ETH2 controller card
•Power cord retaining clips (2)
•A second power supply and AC cord (optional)
•A system card, per order
•Densité-series cards (per order) with associated rear panels
Opening the Front Door
The front door of the Densité 3+ FR1 frame is fastened in place by two captive thumbscrews,
one at each end of the door.
•To open the door, turn both thumbscrews counterclockwise until they release, and pull the
door away from the front of the frame.
•The door is attached to the frame by guides that slide out of the frame as the door is pulled,
and allow the door to be lowered below the frame so that cards and power supplies can be
removed and installed.
•The door can be removed completely by slipping the ends of the guides off the posts on the
door assembly. Note that you must tilt the door on an angle so the guide can move freely.
There are no electrical connections to the door.
Close the door by sliding it into position against the front of the frame, and turning the captive
thumbscrews clockwise until the door is securely fastened into place
Mounting
The Densité 3+ FR1 housing frame occupies 1RU in a standard 19” rack.
To mount the frame:
•Open the front door to expose the rack mounting flanges at the ends of the chassis.
•Install the frame in the rack using 4 standard rack-mounting screws (not supplied) through
the four holes in the mounting flanges.

6
Densité 3+ FR1 Housing Frame
Installing Cards in the Densité 3+ FR1 Frame
All cards can be installed with the frame power on. Each card has a connector which plugs into
the frame’s backplane for distribution of power and connection to the controller card, and a
second connector that plugs into the associated rear panel for inputs and outputs.
IMPORTANT - the rear panel must be installed before the card is inserted into the frame.
Note: If you need to install a Densité 2 series card in this frame, which has Densité 3 slots, please
see Using Densité 2 cards in the Densité 3+ FR1 Frame on page 7
To install the rear connector panel:
1 If a card is installed in the slot whose rear panel is being changed, remove it as described
below.
2 Remove the existing panel (either blank or belonging to an existing card that is being
changed) by releasing the captive screw(s) on the right-hand side
3 Position the new panel and secure it in place with the captive screw(s) on the right-hand
side.
Card Installation and removal:
1 Open the front door of the frame
2 To install a card into an empty slot, slide the card into the slot with the swivel handle to the
right, and push gently on the handle to seat the connectors. If the card requires a double-
width rear panel to accommodate a large number of connectors, it should be inserted into
the lower slot. Inserting the card into the wrong slot will not damage the card, and will be
flagged by the on-card status LED flashing red to indicate that there is no connection to the
rear panel.
N.B. the rear panel must be installed before the card.

7
Densité 3+ FR1
User Manual
3 To remove a card from a slot, tilt the swivel handle on the front of the card to lever the con-
nectors apart, then use the handle to pull the card straight out of the slot.
4 Close the front door of the frame
Note: Detailed information about the rear panel connections is included in the user manual for the
card.
Using Densité 2 cards in the Densité 3+ FR1 Frame
The Densité 3+ FR1 frame supports Miranda Densité 2 series cards. Should you need to install a
Densité 2 card in your Densité 3+ FR1 frame, you will need two adapters – one for the card, and
one for the rear panel. These adapters extend the height of the Densité 2 devices so that they
will fit into the slots of the Densité 3+ FR1 frame.
Card adapters:
There are 3 different types of adapters that
can be used, depending on the Densité 2
card geometry:
o DENSITE 3-EXT-A
o DENSITE 3-EXT-B
o DENSITE 3-EXT-C
Install these on the Densité 2 card as
follows:
1 Fit the top edge of the card into the
holding slot along the bottom edge of
the adapter.
2 Align the holes in the top of the card with the holes on the adapter, and secure them
together with the two provided screws and lock washers, as shown in the figure.
Rear Adapters
3-RU rear panel adapters are available for Single and Double Densité 2 rear panels:
•DENSITE SRP-3RU for single slot-width rear panels
•DENSITE DRP-3RU for double slot-width rear panels
Install the adapter and the rear panel as follows:
1 Position the adapter at the left of the empty slot(s) on the rear of the frame.
2 Use the captive screw in the adapter to fasten it securely in position.

8
Densité 3+ FR1 Housing Frame
3 Slip the top of the 2RU rear panel into the slot on the right of the adapter, and secure the
panel to the frame using the captive screw at the bottom of the panel.
Installing the Power Cord Retaining Clips
Each power supply is provided with a power cord retaining
clip that holds the power cord in place to prevent inadver-
tent disconnections.
With the power cord removed, install the clip into the plate
that extends out beneath the power cord socket on the rear
of the frame, by slipping the two ends of the clip into a pair
of holes in the plate Several pairs of holes are provided to
accommodate different sizes of plugs. Use the holes that
position the clip closest to the body of the plug.
Position the clip vertically and insert the plug into the
socket. Then, rotate the clip down and press the cord into
the gripping loop of the clip.
Ventilation
Ventilation for the frame is provided by two fans, one located at each end of the rear panel. The
fans draw air through the frame from the front and exhaust it to the rear. Ventilation slots are
provided in the front door of the frame to allow air to flow into the frame.
An air filter is installed in the front door behind the slots.
•Ensure that the front door ventilation slots are not obstructed.
•Check the air filter regularly to ensure that it is not plugged up with debris.

9
Densité 3+ FR1
User Manual
The filter may be cleaned by rinsing in warm water. Dry thoroughly before replacing it in the
frame.
In addition to the main frame cooling fans, each installed power supply has its own fan that pulls
air into the front of the supply. This fan only operates when the frame temperature is high.
Fan Speed Control
A slider switch beside the controller-side fan on the rear panel allows the speed of the two rear-
panel fans to be specified by the user. Two settings are provided:
•FULL - the fans operate at top speed at all times.
•VAR - the fan speed is managed by the controller card, which is monitoring the temperature
inside the frame.
Use a small tool (e.g. a pen tip or a small screwdriver) to change the switch setting.
GPI
Alarms generated on the controller card may be reported on the GPI connector on the rear
panel.
Users who wish to utilize this alarm reporting mech-
anism should be aware of the circuit driving the GPI
connector, in order to correctly interpret its
signalling.
Field-Serviceable Items
Field-serviceable items on the Densité 3+ FR1 frame itself include the power supplies, the
controller card, and the ventilation fans.
The power supplies and controller card are located behind the door on the front panel.
Controller System card
Power supply Power supply

10
Densité 3+ FR1 Housing Frame
Changing the Power Supply
The Densité 3+ FR1 frame supports dual redundant hot-swappable power supplies. The basic
configuration includes a single supply, plus an empty slot for the optional redundant power
supply. Installing a second power supply module and applying power to it automatically
engages the redundant supply mode. Each power supply has its own power socket on the rear
panel, and should be connected to the AC supply using the supplied power cord or other
approved cord.
•A single power supply can be installed in either of the two slots, but it makes sense to install
it in the right hand slot so that it is not necessary to remove the controller card if you need to
remove the power supply.
•Power integrity is enhanced if the two supplies are plugged into different circuits
To install or change a power supply module:
1 Open the front door of the frame
2 If you are removing the left-side power supply, you must first remove the controller card.
See the following section.
3 Remove the power supply module by pulling on the handle on its front panel and sliding it
out of the frame
4 Slide the new power supply module into the slot, and push it gently into position to seat
the connectors. There is no guiding slot - the supply base sits on the floor of the frame.
5 If you removed the controller card in step 2, reinstall it according to the instructions in the
next section.
6 Close the front door of the frame. The door secures the power supplies in place.
Replacing the Controller Card
The Controller card is located on the upper left-hand side of the frame, above the power supply.
To replace the card, proceed as follows:
1 Open the front door of the frame.
2 Grasp the metal handle on the upper left-hand side of the card; it will slide out so that it can
be gripped properly.
3 Pull gently on the handle until the card is released from the rear connector, and then slide
the card out of the frame.
4 Slide the new card into the controller slot, and push gently on the card edge to engage the
rear connectors.
5 Be sure to close the front door before operating the Densité 3+ FR1 frame, to ensure proper
ventilation.

11
Densité 3+ FR1
User Manual
Replacing the Frame Ventilation Fans
In case of failure of one of the two cooling fans on the rear of the frame, replace it according to
the following steps.
1 Procure a replacement fan assembly.
It is comprised of a fan and an
attached circuit board. It is available
from Miranda as part #0969-0400
2 Remove the defective fan from the frame:
•Remove the two screws that secure the fan assembly to the frame and pull the fan
assembly straight out of the frame.
•Retain the screws, as they will be used to install the replacement fan assembly.
3 Install the replacement fan:
•Slide the new fan assembly into the opening on the rear panel, pushing it straight in and
ensuring that the connector on the assembly mates with the socket in the frame.

12
Densité 3+ FR1 Housing Frame
NOTE: the two ventilator fans are mounted at different
angles, as shown in the above figure. Align the circuit
board on the fan assembly with the notches in the
edge of the rear-panel opening (see arrows in figure at
right) to ensure the correct alignment.
The socket into which the circuit board connects is
hidden from view by the fan assembly during installa-
tion and there is no guide to ensure that they are
aligned. The easiest way to make sure that the con-
nector and socket have mated properly is to install the
fan with the frame power turned on. You will hear the
fan start up when the connection is made.
•Use the two screws that were retained when the old fan assembly was removed to
secure the new fan assembly to the rear panel.
