Belimo AMX24-SR-X1 User manual

Technical Data 64335
Power Supply 24 VAC ± 20%, 24 VDC -10% + 20%
Power Consumption Running 2.5
Power Consumption Holding 0.4 W
Transformer Sizing 5 VA
Electrical Connection 3ft [1m], 18 GA appliance cable with 1/2”
conduit connector
Overload Protection electronic throughout 0° to 95° rotation
Operating Range Y 2 to 10 VDC, 4 to 20 mA w/ ZG-R01 (500 Ω,
1/4 W resistor)
Input Impedance 600 Ω
Feedback Output U 2 to 10 VDC, 0.5 mA max
Angle of Rotation Max. 95°, adjustable with mechanical stop
Torque 180 in-lbs [20 Nm] minimum
Direction of Rotation (Motor) reversible with built-in switch
Position Indication reflective visual indicator (snap on)
Manual Override external push button
Running Time (Motor) 150 sec
Ambient Humidity 5 to 95% RH non condensing (EN 60730-1)
Ambient Temperature Range -22°F to 122°F [-30°C to 50°C]
Storage Temperature Range -40°F to 176°F [-40°C to 80°C]
Housing NEMA 2, IP54
Agency Listings† cULus acc. to UL60730-1A/-2-14, CAN/CSA
E60730-1:02, CE acc. to 2004/108/EC and
2006/95/EC
Noise Level (Motor) <45 dB (A)
Servicing maintenance free
Quality Standard ISO 9001
Weight 2.2 lb [1 kg]
†Rated Impulse Voltage 800V, Type action 1, Control Pollution Degree 3.
AMX24-SR-X1
Modulating, Non-Spring Return, 24 V, for 2 to 10 VDC or 4 to 20 mA
800-543-9038 USA 866-805-7089 CANADA 203-791-8396 LATIN AMERICA / CARIBBEAN
Date created, 05/17/2017 - Subject to change. © Belimo Aircontrols (USA), Inc.

Wiring Diagrams
INSTALLATION NOTES
Provide overload protection and disconnect as required.
Actuators may also be powered by 24 VDC.
Only connect common to negative (-) leg of control circuits.
A 500 Ωresistor (ZG-R01) converts the 4 to 20 mA control signal to 2
to 10 VDC.
Actuators may be connected in parallel if not mechanically linked. Power
consumption and input impedance must be observed.
Meets cULus requirements without the need of an electrical ground
connection.
!WARNING! LIVE ELECTRICAL COMPONENTS!
During installation, testing, servicing and troubleshooting of this
product, it may be necessary to work with live electrical components.
Have a qualified licensed electrician or other individual who has been
properly trained in handling live electrical components perform these
tasks. Failure to follow all electrical safety precautions when exposed to
live electrical components could result in death or serious injury.
Blk (1) Common
Red (2) Hot +
Control Signal
(+)
VDC/mA
(–)
Feedback Signal
(+)
2 to 10 VDC (–)
Ω
500 Ω
Line
Volts
Org (5) U Output
Wht (3) Y Input, 2 to 10V
24 VAC Transformer
21
8
2 to 10 VDC / 4 to 20 mA Control
AMX24-SR-X1
Modulating, Non-Spring Return, 24 V, for 2 to 10 VDC or 4 to 20 mA
800-543-9038 USA 866-805-7089 CANADA 203-791-8396 LATIN AMERICA / CARIBBEAN
Date created, 05/17/2017 - Subject to change. © Belimo Aircontrols (USA), Inc.
