Belkin FireWire 800 and USB 2.0 PCI Express Card... User manual

EN
FireWire 800 and USB 2.0
PCI Express™ Card
User Manual
F5U602ea
Add FireWire® 800 and Hi-Speed USB 2.0 ports to your computer
using PCI Express technology
EN
FR
DE
NL
ES
IT
P74967ea_F5U602ea.indb 1 14/3/06 4:36:23 pm

1
1. Introduction ...................................................................... 1
Features ........................................................................ 2
Specifications ................................................................ 2
Environment .................................................................. 2
Minimum System Requirements ................................... 3
Package Contents ......................................................... 3
2. Software Setup ................................................................. 4
3. Hardware Installation ...................................................... 6
4. Verifying Proper Installation ........................................... 8
5. Information .................................................................... 10
Table of Contents
P74967ea_F5U602ea.indb 2 14/3/06 4:36:24 pm

EN
Introduction to PCI Express
For the last 10 years, PCI has been the mainstream interface
for personal PCs, with nearly every computer using the
same PCI bus specification—32-bit, running at 33MHz, and
yielding a maximum data-transfer rate of only 133.3Mbps.
In today’s information age, with data size growing
exponentially, there is increased demand for faster transfer
rates. This demand led to Intel’s development of the PCI
Express standard, which offers increased speed and stability
for data transfers.
Common PCI Express bus forms include x1, x2, x4, x8,
and x16, with each form being characterized by a unique
slot design. A one-path transmission on a one-lane (x1) PCI
Express bus can reach speeds of up to 250MB—nearly
double the standard PCI transmission speed. A 16-lane (x16)
PCI Express bus can reach speeds of up to 16Gbps.
Introduction
1
2
3
4
5
1
P74967ea_F5U602ea.indb 1 14/3/06 4:36:24 pm

2
3
Introduction
1
2
3
4
5
Features
• Complies with one-lane 2.5Gbps PCI Express
specifications
• Offers USB 2.0 transfer rate of up to 480Mbps and 1394b
data transfer rate of up to 800Mbps
Specifications
• Interface: One-lane PCI Express
• Mode: USB2.0/1394b Combo PCI Express Card
• Controller: NEC UPD720101+ TI TSB82AA2+ TI XIO2000
• Channels: 2 external USB 2.0 ports and 1 internal port 2
external 1394b ports and 1 internal port
Environment
• Operation Temperature: 0° C ~ 57° C
• Storage Temperature: -20° C ~ 85° C
• Operation Temperature: 5 ~ 95% RH
P74967ea_F5U602ea.indb 2 14/3/06 4:36:24 pm

EN
2
3
Minimum System Requirements
• Windows®-based computer with available PCI Express
slot*
• Windows 2000, XP, 2003 Server
* Note: Enclosed Card will not fit into a standard PCI slot.
Package Contents
• FireWire 800 and USB 2.0 PCI Express Card
• User Manual
• CD Driver
Introduction
1
2
3
4
5
P74967ea_F5U602ea.indb 3 14/3/06 4:36:25 pm

4
5
1
2
3
4
5
IMPORTANT NOTE: You must install the FireWire 800 and
USB 2.0 PCI Express Card drivers prior to installing the
hardware in your computer.
1. Insert the FireWire 800 and USB 2.0 PCIe installation CD
into your CD-ROM drive. After a few moments, the main
menu will automatically start.
NOTE: If the main CD does not auto-start, click the
“Start” button and select “Run”. From the “Run” dialogue
box, enter “<driver>:\setup.exe” and click “OK” (where
“<driver>” represents the letter that identifies your CD-
ROM drive under “My Computer”—e.g., if the CD is in
drive D, enter “D:\setup.exe”).
2. Select “Install Driver”. The Software Installation Wizard will
appear and begin to download drivers.
Software Setup
P74967ea_F5U602ea.indb 4 14/3/06 4:36:25 pm

EN
4
5
Software Setup
3. If you receive the following “Software Installation”
notice, click on “Continue Anyway” to continue with the
installation process.
4. After the files have been successfully copied over, a
window will appear to confirm that driver installation is
complete. Click “OK” to complete the installation process.
5. You will be asked if you want to restart your computer
now or later. Select “No, I will restart my computer later”
and perform a manual shutdown through the “Start”
menu.
1
2
3
4
5
P74967ea_F5U602ea.indb 5 14/3/06 4:36:26 pm

6 7
1. After completion of software setup, shut down your
computer and disconnect all connected devices and
peripherals.
2. Remove the cover from your computer. Refer to your
computer manufacturer’s user manual for details on how
to do this. Touch any bare metal portion of your computer
case to discharge yourself of any static electricity. This
prevents damage to your computer and the PCI Express
Card.
3. Locate the PCI Express slot on your computer’s main
circuit board. Remove the metal plate that covers the
rear slot corresponding to the PCI Express slot you have
selected (see image below).
4. Remove the PCI Express Card from its protective anti-
static packaging. Handle it by the metal bracket; do not
touch the gold-edged connectors. Insert the PCI Express
Card into the PCI Express slot, carefully aligning the rear
bracket to the computer case. Make sure that the edge of
the PCI Express Card is fully inserted into the slot.
Hardware Installation
1
2
3
4
5
P74967ea_F5U602ea.indb 6 14/3/06 4:36:26 pm

EN
6 7
5. Replace the slot-cover screw.
6. After installing the PCI Express Card, replace your
computer’s outer cover and turn on your computer.
NOTE: Do not plug any devices into the PCI Express
Card until driver installation is completely finished.
7. The New Hardware Wizard will launch and recognize the
PCI Express Card.
8. Windows will automatically install the correct driver.
Installation is now complete. The PCI Express Card is now
ready to use.
Hardware Installation
1
2
3
4
5
P74967ea_F5U602ea.indb 7 14/3/06 4:36:27 pm

8
Check the Windows Device Manager to confirm that your
PCI Express Card has been properly installed.
1. Right-click on “My Computer” and
select “Manage”.
2. Select the “Device Manager” tab.
3. Click the (+) sign next to “IEEE 1394 Bus host controllers”.
The “IEEE 1394 Bus host controllers” will now include
one “Texas Instruments OHCI Compliant IEEE 1394 Host
Controller” entry.
4. Click the (+) sign next to “Universal Serial Bus controllers”.
It will now include two “NEC PCI to USB Open Host
Controller” entries and one “Standard Enhanced PCI to
USB Host Controller” entry.
Verifying Proper Installation
1
2
3
4
5
9
P74967ea_F5U602ea.indb 8 14/3/06 4:36:27 pm

EN
8
Verifying Proper Installation
9
1
2
3
4
5
P74967ea_F5U602ea.indb 9 14/3/06 4:36:28 pm

10
11
Information
CE Declaration of Conformity
We, Belkin Corporation, declare under our sole responsibility that the F5U602, to
which this declaration relates, is in conformity with Generic Emissions Standard EN
55022:1998 Class B, EN50081-1 and with Generic Immunity Standard EN50082-1
1992.
Modifications
The FCC requires the user to be notified that any changes or modifications to this
device that are not expressly approved by Belkin Corporation may void the user’s
authority to operate the equipment.
Belkin Corporation Limited Lifetime Product Warranty
Belkin Corporation warrants this product against defects in materials and
workmanship for its lifetime. If a defect is discovered, Belkin will, at its option,
repair or replace the product at no charge provided it is returned during the
warranty period, with transportation charges prepaid, to the authorized Belkin
dealer from whom you purchased the product. Proof of purchase may be required.
This warranty does not apply if the product has been damaged by accident, abuse,
misuse, or misapplication; if the product has been modified without the written
permission of Belkin; or if any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF
ALL OTHERS, WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN
SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING,
WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220,
declare under our sole responsibility that the product,
F5U602ea
to which this declaration relates,
Complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
FCC Statement
1
2
3
4
5
P74967ea_F5U602ea.indb 10 14/3/06 4:36:29 pm

EN
10
11
Information
No Belkin dealer, agent, or employee is authorized to make any modification,
extension, or addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF
WARRANTY, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT
LIMITED TO, LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR
REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR DATA STORED IN,
OR USED WITH, BELKIN PRODUCTS.
Some states do not allow the exclusion or limitation of incidental or consequential
damages or exclusions of implied warranties, so the above limitations or
exclusions may not apply to you. This warranty gives you specific legal rights, and
you may also have other rights that vary from state to state.
1
2
3
4
5
P74967ea_F5U602ea.indb 11 14/3/06 4:36:29 pm

Belkin Ltd.
Express Business Park
Shipton Way, Rushden
NN10 6GL, United Kingdom
[phone]
[phone] fax
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk, The Netherlands
[phone]
[phone] fax
Belkin Tech Support
Europe: 00 800 223 55 460
© 2006 Belkin Corporation. All rights reserved. All trade names are registered trademarks of
respective manufacturers listed. FireWire is a trademark of Apple Computer, Inc., registered in the
U.S. and other countries. PCI Express is a trademark of PCMCIA. P74967ea
Belkin GmbH
Hanebergstrasse 2
80637 Munich, Germany
[phone]
[phone] fax
Belkin SAS
130 rue de Silly
92100 Boulogne-Billancourt, France
[phone]
[phone] fax
FireWire 800 and USB 2.0
PCI Express™ Card
P74967ea_F5U602ea.indb 12 14/3/06 4:36:30 pm

FR
Carte PCI Express™
FireWire 88 et USB 2.0
Manuel de l’utilisateur
F5U602ea
Ajoutez des ports FireWire® 800 et USB 2.0 Haut Débit à votre
ordinateur grâce à la technologie PCI Express
FR
P74967ea_F5U602ea.indb 1 14/3/06 4:36:41 pm

1
1. Introduction ...................................................................... 1
Caractéristiques ............................................................ 2
Spécifications ................................................................ 2
Environnement .............................................................. 2
Configuration minimum requise .................................... 3
Contenu de l’emballage ................................................ 3
2. Installation du logiciel ..................................................... 4
3. Installation du matériel ...................................................6
4. Vérification de l’installation ............................................. 8
5. Information .................................................................... 10
Table des matières
P74967ea_F5U602ea.indb 2 14/3/06 4:36:41 pm

FR
Qu’est-ce que le PCI Express ?
Au cours des 10 dernières années, le PCI a fait office
d’interface de choix pour les ordinateurs personnels :
presque chaque ordinateur est doté du même bus PCI 32
bits à 33 MHz, offrant une bande passante maximum de
133,3 Mbps. Aujourd’hui, à l’ère de l’information, la taille
des données augmente exponentiellement, ce qui accroît
la demande pour des débits de transfert plus rapide. Cette
demande amena Intel à développer la norme PCI Express,
qui procure des transferts de données plus rapides et plus
fiables.
Les bus PCI Express standard comprennent les formules
x1, x2, x4, x8, et x16, chacune d’entre elles ayant un
emplacement de conception unique. Une transmission à
chemin unique sur un bus PCI Express à voie unique (x1)
peut atteindre un débit pouvant aller jusqu’à 250 Mo, près
du double du débit standard PCI. Un bus PCI Express à 16
voies (x16) peut atteindre une bande passante de 16 Gbps.
Introduction
1
2
3
4
5
1
P74967ea_F5U602ea.indb 1 14/3/06 4:36:41 pm

2
3
Introduction
1
2
3
4
5
Caractéristiques
• Conforme aux caractéristiques techniques PCI Express
2,5 Gbps à une voie
• Procure un débit USB 2.0 jusqu’à 480 Mbps et un débit
1394b jusqu’à 800 Mbps
Caractéristiques techniques
• Interface : PCI Express à une voie
• Mode : Carte PCI Express USB 2.0/1394b
• Contrôleur : NEC UPD720101+ TI TSB82AA2+ TI XIO2000
• Canaux : USB 2.0 : 2 ports externes, 1 port interne ;
1394b : 2 ports externes et 1 port interne
Environnement
• Température de fonctionnement : 0 °C ~ 57 °C
• Température de stockage : -20 °C ~ 85 °C
• Température de fonctionnement : 5 ~ 95 % HR
P74967ea_F5U602ea.indb 2 14/3/06 4:36:41 pm

FR
2
3
Configuration minimum requise
• Ordinateur Windows®avec emplacement PCI Express
libre *
• Windows 2000, XP, Server 2003
* Remarque : Cette Carte ne convient pas aux
emplacements PCI standard.
Contenu de l’emballage
• Carte PCI Express FireWire 800 et USB 2.0
• Manuel de l’Utilisateur
• CD de pilotes
Introduction
1
2
3
4
5
P74967ea_F5U602ea.indb 3 14/3/06 4:36:42 pm

4
5
1
2
3
4
5
REMARQUE IMPORTANTE : Vous devez d’abord installer
les pilotes de la Carte PCI Express FireWire 800 et USB
2.0 avant de procéder à l’installation physique de la carte
sur votre ordinateur.
1. Insérez le CD d’installation de la Carte PCIe FireWire 800
et USB 2.0 dans votre lecteur de CD-ROM. Le menu
principal apparaît automatiquement après quelques
instants.
REMARQUE : Si le CD ne démarre pas automatiquement,
cliquez sur le bouton « Start [Démarrer] » et choisissez
« Run [Exécuter] ». Dans la boîte de dialogue, entrez
« <lecteur>:\Setup.exe » et cliquez sur « OK » (où
« <lecteur> » est la lettre qui correspond à votre lecteur de
CD-ROM, sous « Poste de Travail ». Par exemple, si votre
lecteur porte la lettre D, tapez « D:\setup.exe ».)
2. Sélectionnez « Install Driver [Installer le pilote] »).
L’assistant d’installation apparaît et télécharge les pilotes.
Installation du logiciel
P74967ea_F5U602ea.indb 4 14/3/06 4:36:42 pm
