Belkin F1DN102P User manual

Belkin® Secure 2/4 port DisplayPort
KVM Switch User Manual
User Manual
F1DN102P 2-port Displayport, Single-Head + CAC + DCU
F1DN104P 4-port Displayport, Single-Head + CAC + DCU
F1DN104W 4-port Displayport, Dual-Head + CAC + DCU
F1DN104Q 4-port Displayport, Quad-Head + CAC + DCU
Document Number 8820-00776 Rev. A00

i
TABLE OF CONTENTS
SECTIONSTable of Contents 12345678SECTIONS 12345678Table of Contents
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Operating the KVM Switch ............................... 17
Common Access Card (CAC) Configuration and Operation ... 18
Troubleshooting ........................................ 19
Information............................................. 22
Reporting Belkin Product Security Vulnerability ......... 25
Introduction ............................................. 1
Package Contents ..................................... 1
Safety Precautions ..................................... 2
Overview................................................ 3
Security Features ...................................... 3
Other Features ........................................ 5
Equipment Requirements ............................... 6
System Requirements .................................. 7
Unit Display Diagrams .................................. 8
Specifications........................................ 12
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Pre-Configuration .................................... 14
Connection and Installation............................. 15
Color Code Chip Installation ............................ 16

1
INTRODUCTION
SECTIONSTable of Contents 12345678SECTIONSTable of Contents 12345678
9
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Thank you for purchasing this Belkin Secure DisplayPort KVM. This
Switch is designed for use in secure environment installations. The
Switch offers safe centralized control, which prevents unintended
data transfer between computers running at different security levels.
The Switch provides the highest security safeguards and features that
meet today’s Information Assurance (IA) computing requirements.
Belkin Secure DisplayPort KVM is especially challenging in terms of
security as DisplayPort is a very robust protocol by nature which is
capable of transferring various types of information, such as USB and
Ethernet other than display. Belkin has developed this unique Secure
KVM switch with the highest possible security in mind, assuring no
leakage of information between connected computers through any
channels including DP dedicated channels.
This User Manual provides all the details you’ll need to install and
operate your new Switch, in addition to expert troubleshooting
advice—in the unlikely event of a problem.
Package Contents
• Belkin Secure DisplayPort KVM
• 12V 1.5A DC Power Supply
• Interchangeable Port Color Chips
• Port-Naming Labels
• User Manual
Important: This product is equipped with always-on active
anti-tamper system. Any attempt to open the enclosure
may activate the anti-tamper system and render the unit
permanently inoperable. If the unit’s enclosure appears
disrupted or if all the port LEDs flash continuously, please call
Belkin Technical Support at [phone] .
Important Security Note:
If you are aware of potential security vulnerability while
installing or operating this product, we encourage you to
contact us immediately at the following email address:
gov_securit[email protected]
Please note: Belkin Secure KVMs cannot be upgraded, serviced
or fixed.

2
SECTIONSTable of Contents 12345678SECTIONSTable of Contents 12345678
9
INTRODUCTION
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Safety Precautions
Please read the following safety precautions carefully before using
the product:
• Before cleaning, disconnect the product from the AC power source
• Be sure not to expose the product to excessive humidity.
• Do not store or use for extensive period of time in extreme thermal
conditions—it may shorten product lifetime.
• Be sure to install the product on a clean secure surface.
• Do not place the DCU cable in a path of foot traffic.
• If the product is not used for a long period of time, remove the
KVM’s wall-mount power supply from the mains jack.
• If one of the following situations occurs, get the product checked by
a qualified service technician:
o Liquid penetrates the product’s case.
o The product is exposed to excessive moisture or water.
o The product is not working well even after carefully following the
instructions in this user’s manual.
o The product has been dropped or is physically damaged.
o The product has obvious signs of breakage or loose
internal parts.
o AC Power plug or cable overheated, broken, or damaged.
• The product should be stored and used only in temperature and
humidity controlled environments as defined in the product’s
environmental specifications.
• The product contains an internal battery. Battery is non-replaceable.
Never attempt to replace battery as any attempt to open product
enclosure would permanently damage the product.

3
OVERVIEW
SECTIONSTable of Contents 123456782
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
The Belkin Secure DisplayPort KVM is the most advanced and
secure commercially available KVM Switch available today. Below is a
summary of all the security features incorporated into the Switch.
Protected DisplayPort Channel
Belkin Secure DisplayPort KVM switch includes safety mechanisms
to protect DisplayPort channels and preventing leakage of information
between connected computers and the DisplayPort display.
Dedicated Processors
The Switch features a dedicated processor per computer port. This
keeps each computer running on different security levels physically
separated and secure at all times, and prevents any unintended data
leakage between computers.
No Memory Buffer
The Switch does not have a memory buffer and does not have the
ability to store data. This prevents any keystrokes or other data
input from being unintentionally transferred when switching between
computers, ensuring the integrity of data.
Non-Reprogrammable Firmware
The Switch features custom firmware that is not reprogrammable,
preventing the ability to tamper with the KVM logic.
Unidirectional Data Paths
Optical diodes used in USB data paths provide high isolation and
prevent data leakage.
Heavy Duty Aluminum Enclosure
The Belkin Secure DisplayPort KVM uses one-piece aluminum
enclosure to protect the product from physical tampering and to
minimize radiated electromagnetic emissions that can be snooped or
intercepted.
Active Always-On Anti-Tampering
Active always-on chassis anti-tampering system prevents the Belkin
Secure DisplayPort KVM electronic circuitry from being accessed and
tampered with by permanently disabling the product once tampering
is detected.
Tamper-Evident Label
A holographic security tamper-evident label is placed on the
enclosure to provide a visual indication if the Switch has been opened
or compromised.
Security Features

4
OVERVIEW
SECTIONSTable of Contents 123456782
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Tamper-Proof Hardware
All integrated circuits are soldered directly to the printed circuit board
to prevent tampering with the components.
Protected Display Information
Protected DDC/EDID emulation prevents software weaknesses that
can cause data leakage while maintaining compatibility with the
console display.
USB Device Detection
Storage and other unsafe USB devices are rejected when connected
to the Switch. Only mouse, keyboard, and CAC reader data are
passed through.
Secure Packaging
“Tear away” packaging ensures secure delivery of the Switch as it is
routed to the end user. The recyclable packaging also breaks down
flat, simplifying the cleanup process.
EAL 4+ Evaluation (Canada)
The Belkin Secure DisplayPort KVM switch was evaluated in Canada
to EAL 4+ level and is listed on the Common Criteria Portal
Tamper-Proof Hardware
All integrated circuits are soldered directly to the printed circuit board
to prevent tampering with the components.
Protected Display Information
Protected DDC/EDID emulation prevents software weaknesses that
can cause data leakage while maintaining compatibility with the
console display.
USB Device Detection
Storage and other unsafe USB devices are rejected when connected
to the Switch. Only mouse, keyboard, and CAC reader data are
passed through.
Secure Packaging
“Tear away” packaging ensures secure delivery of the Switch as it is
routed to the end user. The recyclable packaging also breaks down
flat, simplifying the cleanup process.
EAL 4+ Evaluation (Canada)
The Belkin Secure DisplayPort KVM switch was evaluated in Canada
to EAL 4+ level and is listed on the Common Criteria Portal
Bloomberg Keyboard Support
The Belkin Secure DisplayPort KVM supports the Bloomberg
Keyboard through the Console PS/2 Keyboard jack.
Other Features

5
OVERVIEW
SECTIONSTable of Contents 123456782
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Equipment Requirements
Cables
Belkin highly recommends you use Belkin Display Port/USB KVM
Cable Kits for your Switch to help ensure superior performance.
These cables offer the highest quality possible to ensure optimal data
and video transmission. One Cable Kit is required per connected
computer.
Belkin DP to DP KVM Cable Kits with audio:
F1D9019b06 – 6ft (1.8m)
F1D9017b10 – 10ft (3m)
Belkin CAC USB A/B Cables
F1D9013b06 – 6 ft. (1.8m)
F1D9013b10 – 10 ft. (3m)
F1D9013b15 – 15 ft. (4.6m)
Belkin Smart Cables
F1D9011b06 (USB to DVI-I Smart Cable, 6’)
F1D9017b06 (DP to DVI Smart Cable, 6’)
Belkin DP to DVI Cables
F2CD002b06-E (DP to DVI)
Note: Due to USB and DisplayPort signal limitations, the cable length
cannot exceed 15 feet (4.6m).

6
OVERVIEW
SECTIONSTable of Contents 123456782
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Operating-System (OS) Platforms
The Switch is compatible with computers running on, but not limited
to, the following OS platforms:
• Windows® 2000
• Windows XP (Home/Professional)
• Windows 2003 Server
• Windows 7
• Windows 8
• Windows Vista®
• Red Hat® Linux®
• Other Linux distributions
• Mac OS® X v10.3 and higher
Keyboards
• USB-compatible or keyboard + mouse composite device (keyboards
with built-in USB hubs are not supported).
Mice
• USB-compatible (non-composite)
Monitors
• Digital displays with Display Port 1.1 and 1.2 signals
Common Access Card Readers
• USB-compatible CAC or Smart Card Readers
Desktop Controller Unit
The Belkin Secure DisplayPort KVM Switch is compatible with the
following types of Remote Desktop Controller device:
• DCU device connected to the switch DCU port.
• DCU must be connected through
Belkin RJ14 custom cable standard: Belkin Part Numbers:F1D9026-06
(CABLE, RJ14, 6P6C, 26AWG, UNSHIELDED, DCU CABLE, 6’),
F1D9026-50 (CABLE, RJ14, 6P6C, 26AWG, UNSHIELDED, DCU
CABLE, 50’) and higher LAN cable.
System Requirements
Do not connect DCU to anything but Belkin Secure KVMs via
supplied RJ14 custom cable.

7
OVERVIEW
SECTIONSTable of Contents 123456782
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Unit Display Diagram, Front View
IMPORTANT
NOTICE:
If for any reason
the tamper-evident
seal is missing,
appears disrupted,
or looks different
than the example
shown here, please
call Belkin Technical
Support at (800)
282-2355.
(F1DN104P model shown)

8
OVERVIEW
SECTIONSTable of Contents 123456782
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Back View
(F1DN104P model shown)

9
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
OVERVIEW
SECTIONSTable of Contents 123456782
Back View
(F1DN104Q model shown)

10
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
OVERVIEW
SECTIONSTable of Contents 123456782
Back View
(F1DN104W model shown)

11
OVERVIEW
SECTIONSTable of Contents 123456782
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Part No.: F1DN102P, F1DN104P, F1DN104W
F1DN104Q
Enclosure: Metal enclosure with aluminum
faceplate
Power Requirements: 100–240VAC, 1A Max, 50/60Hz
AC Input: 100 to 240VAC
No. of Users Supported: 1
No. of Computers Supported: 2 (F1DN102P,), 4 (F1DN104P,
F1DN104W, F1DN104Q)
No. of monitors per computer supported:
F1DN102P, F1DN104P- 1
F1DN104W- 2
F1DN104Q - 3 DisplayPort and 1 DVI
Resolution Support: Up to 2560x1600
Console Keyboard Input: USB Type A
Console Mouse Input: USB Type A
Console CAC Input: USB Type A
Console Monitor Port: DisplayPort 1.1 and 1.2 Signals
Console Speaker: 3.5mm female
CPU Keyboard/Mouse Ports: USB Type B
CPU CAC Ports: USB Type B
CPU Keyboard/Mouse Ports: USB Type B
CPU Audio: 3.5mm female
CPU Monitor Ports: DisplayPort 1.1 and 1.2 Female
Port Selectors: 2 and 4 respectively for 2-
and 4-port models
LED Indicators: 2 and 4 respectively for 2-
and 4-port models
User Channel Selection Methods Front panel push-buttons,
DCU and keyboard shortcuts.
Operating Temp: 32° to 104° F (0° to 40° C)
Storage Temp: -4° to 140° F (-20° to 60° C)
Humidity: 0-80% RH, non-condensing
Warranty: 3 years
Specifications

12
OVERVIEW
SECTIONSTable of Contents 123456782
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Dimensions:
(F1DN102P/104P) 12.5 (W) x 1.7 (H) x 6.4 (L) inches
(F1DN104W) 12.5 (W) x 2.5 (H) x 6.4 (L) inches
(F1DN104Q) 12.5 (W) x 3.8 (H) x 6.4 (L) inches
Weight:
(F1DN102P/104P) 3.9 lbs.
(F1DN104W) 4.85 lbs.
(F1DN104Q) 5.85 lbs.
Made in the USA

13
INSTALLATION
SECTIONSTable of Contents 123456783
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Pre-Configuration
Where to place the Switch:
The enclosure of the Switch is designed for desktop or rack-mount
configuration. Rack-mount brackets are included with the Switch.
Consider the following when deciding where to place the Switch:
• Your proximity to the port selectors on the front of the Switch
• The lengths of the cables attached to your keyboard, monitor,
and mouse
• The location of your computers in relation to your console
• The lengths of the cables you use to connect your computers
to the Switch
Warning: Avoid placing cables near fluorescent lights,
air-conditioning equipment, or machines that create electrical noise
(e.g., vacuum cleaners).
Connection and Installation
Step 1 Connecting the Console to the Switch
Warning: Before attempting to connect anything to the Switch or your
computers, please ensure that all computer equipment and devices
are powered off.
Connect your monitor, keyboard, mouse, and speaker to the rear of
the Switch in the “User Console” section.
Step 2 Power Up
2.1 Power on the monitor.
2.2 Power up the Belkin Secure DisplayPort KVM by connecting
the power. The display diagnostic LED should be solid green
a few seconds after power up. This indicates the display EDID
information has been captured and secured.

14
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
INSTALLATION
SECTIONSTable of Contents 123456783
INSTALLATION
SECTIONSTable of Contents 123456783
Step 4 Powering Up the Computers
Power up all the attached computers, and check for display
and peripheral functionality. All computers can be powered on
simultaneously.
Note: Your computers should recognize the Switch and automatically
install the HID USB driver if necessary.
When you power on your computers, the Switch emulates both a
mouse and keyboard on each port and allows your computers to
boot normally. The computer connected to port “1” will be displayed
on the monitor. Check to see that the keyboard, monitor, and mouse
are working normally. Proceed to do this with all occupied ports to
verify that all computers are connected and responding correctly.
If you encounter an error, check your cable connections for that
computer and reboot. If the problem persists, please refer to the
Troubleshooting section in this User Manual.
Step 3 Connecting Computers to the Switch
3.1 Make sure all computers are powered off.
3.2 Using the Belkin DP/USB KVM Cable Kit (sold separately),
connect the computers to a port on the rear of the KVM Switch.
Note: The Cable Kit must be connected directly to a free USB port on
your computer with no USB hubs or other devices in between.

15
INSTALLATION
SECTIONSTable of Contents 123456783
INSTALLATION
SECTIONSTable of Contents 123456783
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Color Code Chip Installation
The Belkin Secure DisplayPort KVM port-selector buttons can
be color-coded for easier identification. Refer to the installation
instructions below.
Note: You may have to remove the existing black color chip first.
Port Name Label
The included network-name and blank labels can be placed in the
area underneath the port-selector buttons for port identification.

16
SECTIONSTable of Contents 123456784
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
OPERATING THE KVM SWITCH
Operation
Selecting a Computer Using Port Selectors
Now that you have connected your console and computers to the
Switch, it is ready for use. You can select which computer you wish
to control by pressing the corresponding port selector on the front of
the Switch. The LED number will illuminate to indicate which computer
(or port) is currently selected. It may take approximately 1 second for
the video signal to sync after switching ports. This is normal behavior
and is dependent on the display connected. This is normal operation
and ensures that proper synchronization is established between the
monitor and the connected computers.
Keyboard and mouse inputs can only be sent to the selected
computer, and video outputs can only be received from the selected
computer. The Switch also prevents any data transfer between
connected computers, ensuring the security of your computers.
Please note that the default port at power-up is port 1. In case
of a power failure or if the power is cycled, the Switch will
default to port 1.

17
COMMON ACCESS CARD (CAC) CONFIGURATION AND OPERATION
SECTIONSTable of Contents 123456785
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
Step 1 Installation
1.1 Using the included USB cable, connect one end of the cable to
the computer that requires CAC, and the other end to the CAC
port on the Belkin Secure DisplayPort KVM that corresponds to
the computer.
1.2 Enable CAC for the same port connection in Step 1.1 by switching
the CAC switch to the right.
1.3 Repeat steps above for additional computers that require CAC.
Note: Make sure that the CAC switch is disabled (left) for all other
non-connected CAC systems.
1.4 Once configured, the CAC connection will be switched only when
required by the connected computer. When switching from a CAC
enabled port to a non-CAC enabled port, the CAC connection will
remain with the last previously selected port where the CAC was
set to enable.
CAC connection to the computer requires a separate USB cable
connection and allows the user to specify whether there is a
CAC required for that computer or not. This allows the CAC to be
connected and controlled separately to the keyboard, mouse, video
and audio.

18
TROUBLESHOOTING
SECTIONSTable of Contents 123456787
Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual
General
My computer does not boot when connected to the Switch but
works fine when I connect my keyboard, video, and mouse directly
to my computer.
• Make sure that the DP/USB KVM Cable Kit is connected tightly
between the Switch and the computer.
The Switch does not turn on.
• Ensure that the AC power cord is securely connected to both the
AC inlet and to the wall outlet.
• Check that the power switch is in the ON position.
The Switch makes rapid clicking noises and the port LEDs flash
continuously when turned on.
• If the clicking noises continue, the unit may have been tampered
with or experienced severe impact.
NOTE: This Switch is equipped with active anti-tamper triggers. Any
attempt to open the enclosure will activate the anti-tamper triggers
and render the unit inoperable. If the unit’s enclosure appears
disrupted or if all the port LEDs flash continuously, please call Belkin
Technical Support at [phone].
Video
I am getting ghosting, shadowing, or fuzzy images on
my monitor.
• Check that all video cables are inserted properly to the Switch,
computer, and monitor.
• With everything connected, power-cycle the Belkin Secure
DisplayPort KVM to reset the video.
• Make sure the Video Diagnostic LED is solid green.
• Check that the monitor you are using supports the resolution and
refresh-rate setting on your computer.
• Lower the video resolution of your monitor.
• Check that the video-cable length does not exceed 15 feet (4.6m).
• Check that the graphics card you are using supports the resolution
and refresh-rate setting on your computer.
• Connect the monitor directly into the computer you are having
trouble with to see if the problem still appears.
• Do not use video splitters.
