OmniView® PRO3 USB & PS/2 KVM Switch

Control multiple USB and PS/2 servers from a single console
The OmniView PRO3 USB & PS/2 KVM Switch provides easy and dependable server control with
extraordinary performance. The Switch enables network administrators to monitor and control up to four,
eight, or 16 USB- and PS/2-platform servers from a single console. No other KVM switch provides such
an impressive set of features and value price. The PRO Series KVM Switches are the industry’s most
popular KVM switches for small-to-medium server rooms, branch locations, and test and development labs.
Designed to grow along with your server network, the Switch can be daisy-chained together with other
Belkin SMB KVM Switches and is also compatible with the OmniView PRO2 Series KVM Switch to support
up to 256 servers.
Features Benefi ts
USB & PS/2
Connection Expanded connectivity in a mixed server environment
On-Screen Display
(OSD) Simplifi es server management and allows you to assign names to each connected server
Dedicated
Daisy-Chain Ports Let you easily expand your KVM confi guration, without sacrifi cing available CPU ports
Dual-Port
Micro-Cabling
Provides cable management that reduces cable clutter by 55%, when compared to
conventional KVM cabling
Hot Keys Allow you to easily switch servers using a sequence on your keyboard
Front-Panel
Port Selectors Allow you to manually select servers at the rack
AutoScan Lets you scan and monitor the activities of all connected servers
Flash-Upgradeable
Firmware Ensures compatibility with the latest hardware
1U Design Allows for desktop or 1U rack-mountable installation
Single User Designed for SMB server rooms
Added Security Specify user names and passwords to prevent unauthorized access
On-Screen Display
Simplifi es server confi guration, control,
monitoring, and switching. Allows you to
assign names to all connected servers.
The OmniView PRO3 USB
& PS/2 KVM Switch lets
you control up to 4, 8,
or 16 USB and PS/2
servers from one USB or
PS/2 console.
OmniView PRO3 USB
& PS/2 KVM Switch
Servers

Specifications
*May be daisy-chained with up to 15 OmniView PRO Series and SMB KVM Switches.
Model No. F1DA104Z F1DA108Z F1DA116Z
No. of Users Supported 1 1 1
No. of Servers Supported 4 8 16
Daisy-Chain Maximum of 16 Switches* Maximum of 16 Switches* Maximum of 16 Switches*
Enclosure Metal with plastic faceplate Metal with plastic faceplate Metal with plastic faceplate
Dimensions 11 (W) x 1.75 (H) x 6 (L) in.
(279 x 44.5 x 150mm)
17.25 (W) x 1.75 (H) x 7.5 (L) in.
(438 x 45 x 190mm)
17.25 (W) x 3.5 (H) x 7.5 (L) in.
(438 x 89 x 190mm)
Weight 5.2 lbs. (2.4kg.) 9.2 lbs. (4.2kg.) 12 lbs. (5.4kg.)
KVM Cables Included None None None
Power/Environment
Power Requirements 12V DC, 1A power adapter
Operating Temperature 32° to 104° F (0 to 40° C)
Storage Temperature -4° to 140° F (-20 to 60° C)
Hardware Supported
Monitors CRT and LCD (with VGA support)
Keyboard/Mouse USB, PS/2
Video Resolution Up to 1920x1440 @ 75Hz
Operating Systems Windows® NT®, 2000, XP, Server 2003, and VistaTM; Microsoft® DOS 5.x and above; Red Hat® Linux® 8.x
and above; Novell® NetWare® 5.x; Mac OS® X; SunTM SolarisTM
Ports
Daisy-Chain DB25 female
Console HDDB15 female (VGA), USB (Type A), miniDIN6 (PS/2)
Servers SCSI-50
Flash Upgrade RJ11
Warranty
3 years
OmniView PRO3 USB & PS/2 KVM Switch
Rack-Mount Brackets with Screws (F1DA108Z, F1DA116Z only)
DB9-to-RJ11 Serial Flash Cable
User Manual
Quick Installation Guide
12V DC, 1A Power Adapter
Package Contents
AC Power
Back View
Dedicated Daisy-Chain Ports
Front View
Flash-Upgrade Port
Port Selectors
Server Connections with
Dual-Port Micro-Cabling
Console Connections

Belkin International, Inc. Belkin Ltd. Belkin Ltd.
310-898-1100 [phone] [phone]
Los Angeles, CA 90220, USA Rushden, United Kingdom Tuggerah, Australia
Recommended Cables:
© 2007 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Microsoft, Windows, NT, and Windows
Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Mac OS is a trademark of Apple Inc., registered
in the U.S. and other countries. 27PB093-A
Part Number Description
F1DA104Z OmniView PRO3 4-Port USB & PS/2 KVM Switch
F1DA108Z OmniView PRO3 8-Port USB & PS/2 KVM Switch
F1DA116Z OmniView PRO3 16-Port USB & PS/2 KVM Switch
Note: Specifications are subject to change without notice.
All-In-One USB KVM Cable Kit
Connects your servers to the Switch. Belkin cables offer the highest
quality possible to ensure optimal data and video transmission. Cable
Kits are sold separately for models F1DA104Z , F1DA108Z , and
F1DA116Z. One Cable Kit is required for every two servers connected.
F1D9401-06 Dual-Port KVM Cable, 6 ft., USB
F1D9401-12 Dual-Port KVM Cable, 12 ft., USB
All-In-One PS/2 KVM Cable Kit
Connects your servers to the Switch. Belkin cables offer the highest
quality possible to ensure optimal data and video transmission.
Cable Kits are sold separately for models F1DA104Z, F1DA108Z, and
F1DA116Z. One Cable Kit is required for every two servers connected.
F1D9400-06 Dual-Port KVM Cable, 6 ft., PS/2
F1D9400-10 Dual-Port KVM Cable, 10 ft., PS/2
F1D9400-15 Dual-Port KVM Cable, 15 ft., PS/2
F1D9400-25 Dual-Port KVM Cable, 25 ft., PS/2
Daisy-Chain Cable
Allows you to connect multiple Switches together to expand your
server configuration.
F1D108-CBL Daisy-Chain Cable, 2 ft.
F1D108-CBL-06 Daisy-Chain Cable, 6 ft.
F1D108-CBL-10 Daisy-Chain Cable, 10 ft.
F1D108-CBL-15 Daisy-Chain Cable, 15 ft.
F1D108-CBL-20 Daisy-Chain Cable, 20 ft.
F1D108-CBL-25 Daisy-Chain Cable, 25 ft.
