Belkin F5L009UK User manual

2 Knowing your Network USB Hub
USB-port
Power LED
Ethernet-port
Reset button
USB-port
Knowing your Network USB Hub
Power Port

Preparing for Setup 3
1.1 Plug the AC adapter into the Network USB Hub.
1.2 Check the Power LED. It should be illuminated.
1.3 Plug the Ethernet cable into the Network USB Hub.
1.4 Plug the other end of the Ethernet cable into your network router.
NOTE: If you are connected to a network router that uses Dynamic
Host Configuration Protocol (DHCP), which most networks do,
you do not need to set up your Network USB Hub.
1. Preparing for Setup

2.1 Insert the setup CD into your CD-ROM drive.
You will see the Network USB
Hub Setup CD screen. Click
“Install Control Center”.
Next
Install Control Center
4 Installing the Software
2. Installing the Software
IMPORTANT: If you do not install the software on your
PC, the Network USB Hub will not work.
2.2 You will see the “Welcome” screen.
Click “Next”.

2.3 Choose a destination folder in which to
install the software, or simply click “Next”.
Next
Next
Installing the Software 5
2.4 Choose the program group for the
software, or simply click “Next”.

2.5 Start the installation. Click “Start”.
Start
Finish
6 Installing the Software
2.6 Installation is complete. Click “Finish”

Setting and Configuring the Connection Settings
for Automatic Connection to a Device
You can connect to a device by double-clicking the device on the list,
or by selecting it on the list, and then clicking “Connect”, on the bottom
of the screen. To disconnect a device, just double-click it on the list, or
select it and then click “Disconnect”, on the bottom of the screen
WARNING: If there is more than one computer on the network sharing the
Network USB Hub, it is not recommended to automatically connect to a
device because only one computer can connect to a device at a time.
You can set your computer to automatically connect to a device on the Network USB Hub.
NOTE: This only works if the device is not already connected to
another computer.
Connected to this computer
– Currently being used
Unavailable – Removed
from the device
Not Connected – Available
Not Connected – Not available
Using the Network USB Hub Control Center 7
3. Using the Network USB Hub Control Center

3.1 Select a device to which you want to
automatically connect. Click “Properties”.
8 Using the Network USB Hub Control Center
3.2 Click to select the “Connection” tab.
Click “Automatically connect this
device when the Control Center starts”.
The next time the software starts, the
computer will automatically connect
to the device for your convenience.
Properties

4.1 Install the printer software and
driver first.
4.2 Select the printer from the list and
click “Connect”. It will install the
printer driver for the first time.
4.3 Select the printer and click “Properties”.
4.4 If you want to share a printer among
computers on the network, select “This
is a shared printer, automatically connect
and disconnect only when printing”.
4.5 Select the printer from the printer list.
4.6 Click “Apply” to apply the changes made.
4.7 This setting has to be set on all the
computers on the network to enable
the sharing feature correctly.
Configuring Printer Sharing 9
4. Configuring Printer Sharing

10 Appendix – Operation/Compatibility Notes
Certain USB devices may not be compatible with the Hub.
Since the Network USB Hub uses virtual network technology, some USB
devices (e.g., TV tuners, webcams, USB audio devices) may not be compatible
with it. You may see a warning message like the one illustrated below.
WLAN connection
The Network USB Hub’s virtual network technology may not work properly if the WLAN
connection is interrupted. If you have problems with the Network USB Hub or connected
USB devices, please make sure that your WLAN connection is strong and stable.
The Network USB Hub can support up to 15 connections
Virtual network technology limits the number of devices
the Hub can support to 16 total connections.
(IMPORTANT: One connection does not equal one device; some devices
involve more than one connection. For instance, a multifunction
printer is typically comprised of four connections.)
Appendix – Operation/Compatibility Notes
