Belkin OmniView F1DP108Gea User manual

User Manual
F1DP108Gea
F1DP116Gea
OmniView
®
SMB
KVM-over-IP Switch
FR
DE
NL
IT
ES
EN

1.
Introduction
......................................................................................
1
Package Contents
.........................................................................
1
2.
Overview
..........................................................................................
2
Remote-M
anag
ement Features
.....................................................
2
Other Features
...............................................................................
3
Equipment Requirements
..............................................................
4
System Requirements
...................................................................
6
Unit Display Diagrams
...................................................................
7
Specifications
................................................................................
8
3.
Local Installation
............................................................................
11
Pre-Configuration
.........................................................................
11
Mounting the Switch
.....................................................................
13
Connecting the Console to the Switch
.........................................
14
Connecting Servers to the Switch
.......................................................
16
Powering Up the Systems
...........................................................
22
Daisy-Chaining Multiple KVM Switches (Optional)
.....................
23
4.
Remote Installation
........................................................................
28
Identifying the IP Address
...........................................................
28
Logging into the Web Interface
...................................................
29
Network Configuration
..................................................................
31
User Settings
...............................................................................
33
Switch Configuration
...................................................................
36
Serial Settings
.............................................................................
38
Security Settings
.........................................................................
39
Maintenance
.................................................................................
41
Table of Contents

5.
Using the Switch from a Remote Console
......................................
43
Starting a Remote Session
....................................................................
43
Using the Quick-Access Toolbar
..........................................................
45
Mouse Configuration and Settings
......................................................
46
Keyboard Configuration and Settings
................................................
50
Video Configuration and Settings
........................................................
52
Performance Settings
.............................................................................
54
Selecting a Server
...................................................................................
55
Additional Features
..................................................................................
56
Restoring Factory Defaults
....................................................................
57
6.
Using the Switch from a Local Console
..........................................
58
Selecting a Server or BANK
..................................................................
Selecting a Server or BANK .................................................................. Selecting a Server or BANK
58
AutoScan Mode
.......................................................................................
61
On-Screen Display
..................................................................................
62
Hot-Key-Command Shortcuts
..............................................................
66
Sun Combo Keys
.....................................................................................
67
Updating Firmware
..................................................................................
68
7.
Frequently Asked Questions
..........................................................
69
8.
Troubleshooting
..............................................................................
71
9.
Glossary
..........................................................................................
75
10.
Information
....................................................................................
77
Table of Contents

1
Congratulations and thank you for purchasing the Belkin OmniView SMB
KVM-over-IP Switch (the Switch). This Switch provides enterprise-class,
remote server management and allows you to monitor and control your
servers from any location over a Transmission Control Protocol/Internet
Protocol (TCP/IP) connection. This round-the-clock access enables you to
troubleshoot servers faster and more efficiently, reducing server downtime
and service costs.
This User Manual provides all the details you’ll need to install and operate
your new Switch, in addition to expert troubleshooting advice—in the
unlikely event of a problem. For quick and easy installation, please refer to
the Quick Installation Guide included in your packaging.
We appreciate your business and are confident that you will soon see for
yourself why over 1 million Belkin OmniView products are in use worldwide.
Rack-Mount
Brackets
with Screws
IEC Power Cord
OmniView SMB
KVM-over-IP Switch
User Manual
Quick
Installation Guide
Package Contents
DB9-to-RJ11
Serial Flash
Cable
DB9-to-RJ45
Serial Cable
1
2
3
4
5
6
7
8
9
10
section
Introduction

2
Remote-Management Features
• Digital or Local User
The Switch allows one user to access and control multiple servers from a local
console, or from any remote console over a TCP/IP connection.
•
Web-Browser Based
You can access the Switch from any computer connected to the LAN, WAN, or
Internet using Microsoft Internet Explorer version 6.0 or higher.
•
BIOS-Level Access
The Switch allows you to remotely access the basic input/output system (BIOS)
of your servers to make changes and perform reboots, regardless of network
connectivity or server condition.
•
User-Friendly Interface
The web-based interface allows you to set up and change the Switch’s
functions quickly and easily through your web browser, without having to install
additional software onto your computer.
•
Serial-Device Support
The Switch provides support for one serial device, such as a power distribution
unit (PDU), so you can remotely perform hard reboots of your servers.
•
Enhanced Security
The Switch provides 128-bit Secure Sockets Layer (SSL) encryption and
password protection to prevent unauthorized access to your servers and
protect data transferred over the Internet.
•
Digital Collaboration
Up to eight users can simultaneously view digital video to share technical
expertise and troubleshoot servers collaboratively.
•
Video Resolution
The Switch supports video resolutions of up to 1600x1200 @ 75Hz for both
local and remote consoles.
Overview

3
1
2
3
4
5
6
7
8
9
10
section
Other Features
• CAT5 Technology
Integrated CAT5 technology enables you to connect the Switch to your
servers up to 100 feet (30m) away using standard CAT5 cabling and
compact Server Interface Modules. CAT5 cabling reduces cable bulk,
simplifies deployment, and allows for greater airflow in your racks,
increasing the life span of your equipment.
• Keep-Alive Intelligence
Belkin’s compact Server Interface Modules feature keep-alive intelligence,
which allows your servers to continue running in the event of power loss to
the Switch or when replacing cabling.
• KVM Expansion
The Switch can be daisy-chained with up to 15 OmniView SMB and PRO2
KVM Switches to support up to 256 servers, so your KVM configuration can
expand as your server environment grows.
• Multiple-Platform Support
The Switch supports PS/2 and USB servers, including Windows
®
,
UNIX
®
/Linux
®/Linux ®
®
, and Sun
™
.
• On-Screen Display (OSD)
The Switch features an On-Screen Display (OSD) to simplify server
management for local users. The OSD allows you to assign names to
servers and to switch easily from one server to the next.
• Firmware Updates
Flash upgrades allow you to obtain the latest firmware updates for your
Switch. These firmware updates ensure that the Switch is compatible with
the latest devices and hardware and are free for the life of the Switch. Visit
www.belkin.com for upgrade information and support.
Overview

444
Equipment Requirements
Server Interface Modules
Connecting the Switch to a server
requires a custom Belkin OmniView SMB
Server Interface Module and a standard
CAT5 patch cable.
OmniView SMB Server
Interface Modules:
F1DP101AeaAP (PS/2 style)
F1DP101AeaAU (USB style)
F1DP101AeaAL (Legacy Sun
™
miniDIN8 style)
F1DP101AeaAP-8PK (PS/2 style, 8-pack)
Note:
Product codes and availability
may vary.
F1DP101A
ea
AP
F1
DP101AeaAU
F1
DP101AeaA
L
Overview

5
1
2
3
4
5
6
7
8
9
10
section
Cables
Belkin highly recommends you use
Belkin Category 5e, FastCAT5e, or
Category 6 Patch Cables for your SMB
KVM-over-IP Switch to help ensure the
superior performance of your video.
These Cables offer the highest quality
possible to ensure optimal data and
video transmission.
Belkin UTP Patch Cables:
A3L791-XX-YYY (CAT5e)
A3L850-XX-YYY (FastCAT
™
5e)
A3L980-XX-YYY (CAT6)
Note:
Use CAT6 solid cables for
optimal video at longer lengths.
To connect multiple Switches together,
a custom Belkin OmniView Daisy-Chain
Cable is required.
OmniView Daisy-Chain Cable:
F1D108-CBL
(-XX denotes length in feet)
(-YYY denotes color)
Note:
Product codes and availability
may vary.
Overview
F1D108-CBL
A3L791-XX-YYY
A3L850-XX-YYY
A3L980-XX-YYY

6
System Requirements
Operating-System (OS) Platforms
The SMB KVM-over-IP Switch is compatible with CPUs running on, but not
limited to, the following OS platforms:
• Windows
®
NT
®
, 95, 98, 2000, Me, XP, Server 2003
• Microsoft
®
DOS 5.x and above
• Red Hat
®
Linux
®
8.x and above
• Sun
™
• Novell
™
5.x
• Solaris
™
8.x and above
Keyboards
• PS/2-compatible
Mice
• PS/2-compatible with 2, 3, 4, or 5 buttons
• PS/2-compatible wireless and optical mice
Monitors
• CRT and LCD (with VGA support)
Remote-Console Software
The SMB KVM-over-IP Switch may be accessed remotely over a TCP/IP
connection from computers using the following web browsers and OS platforms:
• Microsoft Internet Explorer 6.0 and above with ActiveX
®
support
• Windows NT, 2000, XP
Overview

7
1
2
3
4
5
6
7
8
9
10
section
(F1DP116Gea model shown)



               
AutoScan Button
7-Segment LED for
BANK Identification
Port Selectors
BANK
Scroll Buttons
LED Indicators for
Port Identification


Daisy-Chain Port
 
  

Console
VGA
Monitor Port
Flash-Upgrade Port
Console PS/2
Mouse/Keyboard
Ports
CPU Connections
Using CAT5 Cabling
Serial-Device Port
Ethernet
Connection

Go-Local Button
AC Power
Cooling Fan
Back View
Unit Display Diagrams
Front View
(F1DP116Gea model shown)
Overview

8
Specifications
Part No.:
F1DP108Gea, F1DP116Gea
No. of Users Supported:
1 digital or 1 local
No. of Servers Supported:
8 and 16 respectively for 8- and
16-port models
Daisy-Chain:
Maximum of 16 Switches*
Enclosure:
Metal enclosure with high-impact
plastic faceplate
Power Requirements:
100–240VAC @ 47–63Hz/1A
Operating Temp:
0° to 40° C
Storage Temp:
-20° to 60° C
Humidity:
0-80% RH, non-condensing
Video-Resolution Support:
Local analog port:
Up to 1600x1200 @ 75Hz
Digital port:
Up to 1600x1200 @ 75Hz
Console Keyboard Emulation:
PS/2
Console Mouse Emulation:
PS/2
Console Keyboard Input:
MiniDIN6 (PS/2)
Console Mouse Input:
MiniDIN6 (PS/2)
Console Monitor Port:
HDDB15 female (VGA)
CPU Ports:
RJ45
Ethernet Port:
RJ45 (10/100Base-T connection)
Typical Bandwidth:
0.31Mbps**
Serial-Device Port:
RJ45
Flash-Upgrade Port:
RJ11
Power Connection:
IEC
Port Selectors:
8 and 16 respectively for 8- and
16-port models
LED Indicators:
8 and 16 respectively for 8- and
16-port models
Warranty:
2 years
Overview

9
1
2
3
4
5
6
7
8
9
10
section
Dimensions:
(F1DP108Gea) 17.25 x 1.75 x 7.5 in.
(438 x 45 x 190mm)
(F1DP116Gea) 17.25 x 1.75 x 7.5 in.
(438 x 45 x 190mm)
Weight:
(F1DP108G) 5.0 lbs. (2.3kg.)
(F1DP116G) 5.0 lbs. (2.3kg.)
*May be daisy-chained with up to 15 OmniView SMB and PRO2 KVM Switches. OmniView
SMB KVM-over-IP Switches may not be daisy-chained together.
**Typical bandwidth is defined as typical “non-intensive” administrative use at 16-bit color,
1024x768 resolution.
Note:
Specifications are subject to change without notice.
SMB Server Interface Module, PS/2
Part No.:
F1DP101AeaAP
Emulation:
Keyboard and mouse signals
Power:
Via attached server
Keyboard/Mouse Connection:
MiniDIN6 (PS/2)
Monitor Connection:
HDDB15 male (VGA)
Resolution Support:
Up to 1600x1200 @ 75Hz
Max. Distance Supported:
100 ft. (30m)
Weight:
0.25 lbs. (0.11kg.)
Unit Dimensions:
1.8 x 3.5 x 0.9 in. (46 x 89 x 23mm)
VGA-Cable Length:
8 in. (203mm)
PS/2-Cable Length:
19 in. (483mm)
Overview

10
SMB Server Interface Module, USB
Part No.:
F1DP101AeaAU
Emulation:
Keyboard and mouse signals
Power:
Via attached server
Keyboard/Mouse Connection:
USB Type A
Monitor Connection:
HDDB15 male (VGA)
Resolution Support:
Up to 1600x1200 @ 75Hz
Max. Distance Supported:
100 ft. (30m)
Weight:
0.25 lbs. (0.11kg.)
Unit Dimensions:
1.8 x 3.5 x 0.9 in. (46 x 89 x 23mm)
VGA-Cable Length:
8 in. (203mm)
USB-Cable Length:
19 in. (483mm)
SMB Server Interface Module, Legacy Sun
Part No.:
F1DP101AeaAL
Emulation:
Keyboard and mouse signals
Power:
Via attached server
Keyboard/Mouse Connection:
MiniDIN8 (Legacy Sun)
Monitor Connection:
HDDB15 male (VGA)
Resolution Support:
Up to 1600x1200 @ 75Hz
Max. Distance Supported:
100 ft. (30m)
Weight:
0.25 lbs. (0.11kg.)
Unit Dimensions:
1.8 x 3.5 x 0.9 in. (46 x 89 x 23mm)
VGA-Cable Length:
8 in. (203mm)
SUN-Cable Length:
19 in. (483mm)
Overview

11
1
2
3
4
5
6
7
8
9
10
section
Pre-Configuration
(Typical Switch configuration)
Where to place the Switch:
The enclosure of the Switch is designed for stand-alone or rack-mount
configuration. The Switch can be mounted to a standard 19-inch server rack
using the included rack-mount brackets and screws.
Consider the following when deciding where to place the Switch:
• whether or not you intend to use the front-panel port selectors
• the lengths of the cables attached to your keyboard, monitor, and mouse
• the location of your servers in relation to your console
• the lengths of the cables you use to connect your servers to the Switch
Local Installation
CAT5 Cables
OmniView SMB
KVM-over-IP Switch
PS/2, USB and
SUN servers
SUN servers
LAN/WAN
Local Console
User
Server Interface
Modules

12
Cable-Distance Requirements (for PS/2, USB, and Sun Servers)
VGA signals transmit best up to 100 feet (30m). Beyond that length, the
probability of video degradation increases. For this reason, Belkin recommends
that the length of the CAT5 UTP cable between the Switch and the connected
servers does not exceed 100 feet (30m).
Note:
The Belkin CAT5 Extender (F1D084vea2) may be used to extend your
console (keyboard, mouse, and monitor) by up to 300 feet (91m).
Warning:
Avoid placing cables near fluorescent lights, air-conditioning
equipment, or machines that create electrical noise (e.g., vacuum cleaners).
You are now ready to begin installation of your Switch. The following
sections (pages 13–22) provide complete instructions for the hardware
setup of a single Switch (F1DP108Gea, F1DP116Gea).
Local Installation

13
1
2
3
4
5
6
7
8
9
10
section
Step 1 Mounting the Switch
Note:
Before you begin, locate the MAC address and device number on the
back of the Switch. You will need these numbers later in the installation process,
so it is highly recommended that you record these numbers below before
mounting the Switch to your rack.
MAC Address
Device Number
The Switch includes adjustable mounting brackets ideal for installation in
19-inch racks. The mounting brackets feature three adjustment positions that
allow you to set the Switch’s face flush with the ends of the rails, or to extend the
Switch past the front of the rails. Please follow these simple steps to achieve the
desired adjustment.
1.1
Determine how far you would like the Switch to protrude from the rack.
Select a bracket-hole scheme.
1.2
Attach the bracket to the side of the Switch using the Phillips screws
provided. (Refer to diagram below.)
1.3.
Mount the Switch to the rack rails. (Refer to diagram below.)
Your Switch is now mounted securely to the rack and you are ready to
connect your console.
Local Installation

14
Step 2 Connecting the Console to the Switch
2.1
Connect your monitor VGA cable to the VGA port on the back of the
Switch in the “Console” section. (Refer to diagram below.)
 
  

2.2
Connect your keyboard and mouse PS/2 cables to the PS/2 keyboard
and mouse ports on the back of the Switch in the “Console” section.
(Refer to diagram below.)
 
  

Local Installation

15
1
2
3
4
5
6
7
8
9
10
section
2.3
Locate and connect a cable from your local area network to the RJ45
Ethernet port on the back of the Switch. (Refer to diagram below.)
 
  

2.4
Attach the power cord to the IEC power jack on the back of the Switch,
and power up the Switch. (Refer to diagram below.)
Local Installation
 
  


16
Step 3 Connecting Servers to the Switch
(PS/2 Connection)
3.1
Make sure your server is powered off.
3.2
Using the Belkin OmniView SMB Server Interface Module for PS/2
(F1DP101AeaAP), connect the VGA connector to the monitor port on
your server. (Refer to diagram below.)
3.3
Connect the PS/2 mouse and keyboard connectors to the mouse and
keyboard ports on the server. (Refer to diagram below.)
Server
Server Interface Module
Server Interface Module
Local Installation
