Belnick Modern Bar Height Stool User manual

Thank you for your purchase!
Modern Bar Height Stool
ASSEMB INSTRUCTIONS
Before u Begin:
 


Caution:
 


Warning:
 


 
 





PARTS
A 
BI 
CI 
D □
STEP 1
STEP 1: Lay the Seat (Part A) upside
down on a clean surface and put the
footrest (Part D) on the underside of
the seat.
STEP 3
D
A
STEP 3: Slide the
Footrest (Part D) up
the outside of the
Legs and align the
screw holes. Attach
using (4) M6 *40
Screws (Part F).
Tighten using Small
Allen Wrench (Part I).
1pc SEAT
2pcs BACK
LEGS
2pcs FRONT
1pc
0 0
0
LEGS
FOOT
REST
E 
F 
G 9
H 
0 0
0
 
I 

M6*20
12pcs 
M6*40 
4pcs
4pcs FLOOR
GLIDES

1 pc 
STEP 2
B
D
A
C
STEP 4
     


(b�



I  
1 pc 
STEP 2: Attach Back
Legs (Part B) and Front
Legs (Part C) to the
Seat through the inside
of the Footrest ( Part D)
using (12) M6*20
Screws (Part E) and
Large Allen Wrench
(Part H) . Do not
completely tighten the
screws.
STEP 4: Return chair
to the upright position
Footrest
S eat
Large A llen
Wrench
M6*20 Screw
B
a c k L eg
F ootre s t
Seat
Front Leg
Screw in (4) Floor
Glides (Part G).
Small Allen Wrench
M6*40 Screw
Floor Glide
