Belnick GC-MBLK67-GY-GG User manual

ASSEMBLYINSTRUCTIONS
Before You Begin:
Customer Service Email: [email protected] | phone: [phone]
GC-MBLK67-GY-GG/GC-MBLK67-WH-GG
Thank you for your purchase!
58" Barn Door Style TV Stand
for up to 65" TV's
Please identify all component parts and hardware pieces required before you begin. Carefully remove all of the
components from the packaging and set aside for assembly. Assemble on a soft surface to prevent scratching during
assembly.
Tighten all components securely before use. Failure to do so may result in personal injury.
DO NOT use any sharp objects to open plastic wrapped components as damage to product or components may result.
CHOKING HAZARD - Small Parts. Adult Assembly Required.
DO NOT ALLOW CHILDREN TO CLIMB ON FURNITURE
Serious or fatal injuries can occur from furniture tipping over. You must install Tipping Restraint Hardware (where
included) to help prevent the unit from tipping and causing accidental injury, instability, death or damage. The tipping
restraint is intended only as a safety measure, it is not a substitute for proper adult supervision.
To help prevent furniture from tipping over it must be permanently attached to the wall. Anti-Tip Safety Wall Straps
suitable for the unit weight and wall materials (if not included) should be purchased and installed.
Online Assembly Instructions: http://ftp.flashfurniture.com/AssemblyInstructions/GC-MBLK67-WH-GG.pdf
Assembly Time
Load Bearing
60 min
LBS LBS LBS 200 LBS
LBS 30 LBS
LBS LBS LBS
LBS

Have a Question/Concern?
Quality products and first-class customer service are the cornerstone
of long-lasting consumer relationships. We strive toward excellence
in all we do and want you to be completely satisfied with your
purchase. Please contact our exceptional Customer Experience
Agents at the email address or phone number shown below to assist
you with any product questions or issues before requesting a return.
We look forward to serving you in a friendly, efficient manner to
resolve any issues you may have.
Customer Service Email: [email protected]
Customer Service Phone: [phone]
Our Warranty Statement
This warranty covers manufacturing defects associated with your new product. The product
is warranted from the original purchase date and to the original purchaser for normal usage,
according to the below-referenced specifications and limitations.
•Non-moving metal parts are warranted for 5 years.
•Component parts including pneumatic cylinder, control mechanism, base and casters are warranted for 2 years.
•All other items are warranted for 1 year.
Normal usage means use in compliance with the restrictions and weight limits specified for
the product. In the absence of product-specific restrictions and weight limits, normal usage
means use for no more than forty hours per week by persons weighing 250 lbs. or less.
Coverage terminates if the product is sold or otherwise transferred. Repairs made by parties
other than Belnick also void this warranty.
This warranty will not cover: (1) labor, freight, or damage from misuse, abuse, negligence,
alteration, assembly, installation, attachments, accident, vandalism, acts of nature or any
other event beyond the control of Belnick; (2) tearing, scratching, scuffing, or blemishing of
leather or fabric; (3) cosmetic damage that may result from normal usage; (4) damage
attributable to use by persons exceeding specified weight limits or commercial use
exceeding forty hours per week; or (5) rust or other damage caused by exposure to
moisture. The user assumes all risk of injury resulting from use of this product. Liability for
incidental or consequential damage is excluded. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you.

PARTS
1（1） 11（1） 1
1（2） 1
1（3） 1
1（4） 1
1（5） 1
1（6） 1
2（7）
2（8）
1（9） 1
1（10） 111
2（11）
1（12） 111
1（13） 1
1（14） 1
1（15） 1
1（16） 1
A
B
C
D
E
16+1
20+1
8+1
28+1
28+1
2F
2G
2H
4I
16+1J
12+1K
32+1L
2M
4N
4+1O
Top Plate
Bottom Plate
Right Door
Left Door
Right Side Panel
Left Side Panel
Right Rear Fascia
Right Front Fascia
Left Rear Fascia
Left Front Fascia
Dowel Pegs
Long Screw-In Pegs
Short Screw-In Pegs Door Hinges
Front Corner
Brackets
Cam Lock
Cam Lock Cover
Bottom Support Feet
Right & Left Side Bottom Plates
Inner Supports
Lower Back Panel
Upper Back Panel
Inner Supports Fascia
Door Handles
Magnetic
Door Catch Strike Plate
Short Flat Head Screws
Long Flat Head Screws
Door Handle Screws
Self-Tapping Dome Head Screw
Shelf Pegs
Middle Adjustable Shelf

STEP 1
STEP 2
D*4
K*2
（5）
（7）
（12）
（13）
（5）
（15）
×
（11）
（6）
（14）
（12）
（13）
（8）
×
（1）
（2）
*8
*4
*2
*20
*16
Dowel Pegs
Long Screw-In Pegs
Top Plate
Magnetic Door Catch
Right Side Panel
Left Side Panel
Inner Supports
Right Rear Fascia
Right Front Fascia
Left Front Fascia
Left Rear Fascia
Inner Supports Fascia
Bottom Plate
Magnetic
Door
Catch
Short Screw-In Pegs
Bottom Plate
Right Side Panel
Right Side Front Fascia
Right Side Rear Fascia
STEP 2B: Ensure Cam Locks (Part D) are
inserted in holes with open side facing outwards
toward receiver hole for Screw-In pegs (Arrow
Side). Insert Short Screw-In Pegs on the Right
Side Front Fascia (Part 13) into the Cam Locks
(Part D) on the Left Side Panel. Turn Cam
Locks clockwise to tighten.
Cam Lock
STEP 2C: Ensure Cam Locks (Part C) are
inserted in holes with open side facing outwards
toward receiver hole for Screw-In pegs (Arrow
Side). Insert Short Screw-In Pegs on the Right
Side Rear Fascia (Part 12) into the Cam Locks
(Part D) on the Right Side Panel. Turn Cam
Locks clockwise to tighten.
STEP 2A Attach Bottom Plate
(Part 7) to outward bottom side of
Right Side Panel (Part 5) using (2)
Long Flat Head Screws (Part K)
Note: Ensure the arrow on the
Cam Lock is facing outwards
toward the receiving hole
Receiver Hole
Long Flat
Head Screws

STEP 3
STEP 4
K*2
D*4
D
D
×
×
（8）
D*4
（6）
（7）
（11）
（14）
（15）
STEP 3A: Attach Bottom
Plate (Part 7) to outward
bottom side of Left Side Panel
(Part 5) using (2) Long Flat
Head Screws (Part K)
Bottom Plate Left Rear Fascia
Left Front Fascia
Left Side Panel
Cam Lock
Receiver Hole
STEP 3C: Ensure Cam Locks (Part C) are inserted in
holes with open side facing outwards toward receiver
hole for Screw-In pegs (Arrow Side). Insert Short Screw-
In Pegs on the Left Side Rear Fascia (Part 15) into the
Cam Locks (Part D) on the Right Side Panel. Turn Cam
Locks clockwise to tighten.
STEP 3B: Ensure Cam Locks (Part D)
are inserted in holes with open side facing
outwards toward receiver hole for Screw-
In pegs (Arrow Side). Insert Short
Screw-In Pegs on the Left Side Front
Fascia (Part 14) into the Cam Locks (Part
D) on the Left Side Panel. Turn Cam
Locks clockwise to tighten.
Long Flat
Head Screws
Inner Supports Fascia
Inner Supports
STEP 7: Ensure Cam Locks (Part D) are inserted
in holes with open side facing outwards toward
receiver hole for Screw-In pegs (Arrow Side). Insert
Short Screw-In Pegs on the Inner Support Fascia
(Part 8) into the Cam Locks (Part D) on the Inner
Support (Part 11). Turn Cam Locks clockwise to
tighten.
Cam Lock
Ensure groove opening
faces up

STEP 5
STEP 6
J*8
F*2
D*4
（2）
（2）
（5）
（6）
STEP 5: Attach Bottom Support Feet (Part F) onto pre-
marked holes on Bottom Plate using (8) Short Flat Head
Screws (Part ) J
Bottom Plate
Bottom Support Feet
Short Flat
Head Screws
STEP 3: Ensure Cam Locks (Part D) are inserted in holes with open side facing outwards
toward receiver hole for Screw-In pegs (Arrow Side). Insert Long Screw-In Pegs (Part B) at
the bottoms of the Left Side Panel (Part 6) and Right Side Panel (Part 5) into the Bottom
Plate (Part 2) and Turn Cam Locks clockwise to tighten. Ensure Dowel Pegs (Part A) are
fully seated when tightened.
Note: Ensure Groove in Bottom Plate (Part 2) faces the rear and aligns with the grooves in
the Left & Right Side Panels.

STEP 7
STEP 8
D*4
（9）
（10）
STEP 7: Carefully place frame into an upright
position. Place the Lower Rear Panel (Part 9) into the
grooves on the Left & Right Side Panels and slide down
into the groove on the Bottom Plate. Once seated place
the Upper Rear Panel (Part 10) into the grooves on the
Left & Right Side Panels and slide down until it meets
the Lower Rear Panel.
STEP 8: Ensure Cam Locks (Part D) are inserted in holes with
open side facing outwards toward receiver hole for Screw-In
pegs (Arrow Side). Slide Inner Supports (Part 11) onto Long
Screw-In Pegs on the bottom plate ensuring that the Front
Fascia are facing Left and Right (See Diagram). Turn the Cam
Locks (Part D) clockwise to tighten.
Long Screw-In Pegs
Slide Down
Slide Down
Long Screw-In Pegs
Ensure Inner Support Fascia is
Facing Right
Ensure Inner Support Fascia is
Facing Left

STEP 9
STEP 10
D*8D*8
E*28
K*8
（1）
Ensure Notch Is Facing Back Of Stand
STEP 9A: Ensure Cam Locks (Part C) are inserted in holes with open side facing
outwards toward receiver hole for Screw-In pegs (Arrow Side). Place Top Plate
(Part 1) onto the assembled frame. Confirm that all Screw-In Pegs and Dowel Pegs
that were preassembled in STEP 1 are seated correctly. The groove on the underside
of the Top Plate should be seated completely on the Upper Back Panel. Turn the
Cam Locks (Part D) clockwise to tighten.
Top Plate
Cam
Lock
Cover
STEP 9B: Cover all Cam Locks with
Cam Lock Covers (Part E)
E*28
STEP 10: Attach Upper and Lower Back Panels to the
Inner Supports using (8) Long Flat Head Screws
Long Flat Head Screws

STEP 11
STEP 12
L*12
N*4
*4
*2
H*2
I*4
（3）
（4）
（3）
（4）
STEP 11: Attach Hinges (Part N) to Left Door (Part 4) and
Right Door (Part 3) using (12) Self-Tapping Dome Head
Screws (Part L)
STEP 12A: Attach Strike Plates (Part G) to the Left and Right
Doors using (4) Short Flat Head Screws (Part J)
Strike Plate
Short Flat
Head Screws
STEP 12B: Attach Door Handles (Part H) to
Left and Right Front Doors using (4) Door
Handle Screws (Part I)

STEP 13
STEP 14
L*12
M*2
L*8
*4
（4）
（3）
（4）
（3）
STEP 13: Attach Door Hinges to Assembled Frame using
(12) Self Tapping Dome Head Screws (Part L)
Front
Corner
Bracket
STEP 14A: Attach Front Corner Brackets (Part M) to Top
Plate using (8) Self-Tapping Dome Head Screws
STEP 14B: Insert Shelf Pegs (Part O) in the holes at your
desired height

STEP 15
STEP 16
（16）
STEP 15: Lay Adjustable Middle Shelf (Part 16) on the Shelf Pegs
