bemodern Elgin & Hall Mounting instructions

Micro Marble Fireplaces
INSTALLATION INSTRUCTIONS AND USER GUIDE
M
A
D
E
I
N
B
R
I
T
A
I
N
M
A
D
E
I
N
B
R
I
T
A
I
N
Important Information
Before you begin the installation, please ensure that a full and detailed inspection of all component parts is
undertaken jointly by the installer and purchaser to ensure there is no damage or manufacturing defects with the
product. Once the fireplace has been installed, no claims or responsibility will be accepted by the manufacturer
relating to chips, scratches or any other obvious defects.
Please also ensure you carefully read and fully understand these instructions before commencing installation as
we cannot accept responsibility for any damage or defects caused by non-compliance with these instructions.
These instructions are written in accordance with the ‘Stone Federation Great Britain’ guidance on fire surround
standard building practice, Building Regulations (Approved Document J) and all relevant British Standards.
This fireplace should be installed only by competent professional fireplace installers and fitted only to suitable
surfaces. You should check with your installer that the constructional elements of the intended chimney breast
and flue comply with current Building Regulations, and that they are suitable for the appliance that is to be
installed.
NOTE: Installation is not recommended as a DIY or single person task. In addition to this giving rise to the
potentially increased risk of product damage and/or incorrect installation, it should also be noted that some
marble components can be very heavy and will require two people to lift/handle. Caution should always be
exercised if attempting to lift heavy or awkward objects.
Following the installation, please leave these instructions with the householder.

Micro Marble Fireplaces
Marble is a natural product formed over millions of years by the Earth’s natural evolution process.
Consequently no two pieces of marble are exactly the same, and individual fireplaces may be slightly
different in veining, marking and shade which gives a unique quality to each and every marble product.
Veins, vents and minor pitting are to be expected within marble. These are generally accepted as industry
standard and do not detract from the quality of the finished product.
Micro Marble is produced from small pieces of real marble finely crushed and bonded to produce a
quality product for your home. Be Modern selects only the highest quality marble to manufacture your
fireplace within our UK manufacturing facilities.
Fireplace Components
A Fireplace comprises of a combination of
components which are generally as shown.
However, depending upon the exact model
purchased, it may not include all of these
components.
Specific designs may also include extra slips
and head sections to create unique models.
The fireplace interior sections (to the rear) need to be sealed to prevent leakage and to protect
from excessive heat build up. Any space between these sections and the wall/chimney breast must
therefore be filled with non-combustible stable material (i.e. mortar). For installations with Class II gas
flues always check that all joints around base blocks are sound.
Take care not to drill into flue way when drilling holes for fireplace brackets.
General Information
Be Modern Micro Marble fireplaces are suitable for installation with most gas or electric fires
(NOTE: see “High Efficiency Gas Fires” exception below).
IMPORTANT: If intending to fit a gas fire to complement your surround, we strongly advise that this is
installed and serviced only by a suitably qualified and competent GAS SAFE registered installer. This will
ensure that your gas fire is installed correctly and safely.
All of our designs are supplied with a minimum 413mm x 565mm standard fire-opening on the back
panel (although some openings will be larger in size depending on model). Should the existing fire
opening be greater than the opening in the back panel, do not use the marble back panel to reduce the
size of the opening as this may cause cracking of the marble.
2
High Efficiency Gas Fires
Due to widely varying efficiencies, heat outputs and surface temperatures of High Efficiency Gas Fires,
we unfortunately cannot recommend the installation of our Micro Marble fireplaces with this type of
appliance.

3
Installing the Fireplace
If fitting a model with halogen lights (or with an electric fire), firstly ensure that there is access to a
suitable power supply in the fitting area. If a fused spur is to be fitted (recommended), this should be
fitted prior to installation.
Always remember to allow for expansion and contraction. The fireplace must not be installed using only
mastic or other adhesives / compounds. It must be fixed with the permanent fixing brackets supplied
and be secured to a solid surface. A clear or white flexible fixing medium (such as Silicone 450 or similar)
can be used where necessary to bond component parts together. However, we recommend you do not
use“hard setting”compounds or mastics as this is prone to heat damage from expansion and contraction
over time.
Under no circumstances should grey cement, gypsum based adhesives, coloured sand or coloured
bonding plasters be used to fix the fireplace components, as these materials could discolour the marble.
Hearth
Ensure that the hearth is level and firmly secured into position on a bed of suitable mortar with the fire
opening central.
Surround Body
FIGURE 1 FIGURE 2 FIGURE 3
The tops of the leg sections have angle brackets fitted for securing direct to a wall surface. These fixing
brackets will prevent the surround from detaching itself from the wall.
Figure 1 illustrates how the angle brackets (fitted to the internal legs of the surround) are secured
behind the wall bracket at the final fitting stage for an “invisible” fixing. This is achieved by carefully
positioning the surround on the hearth in its intended position and marking the position of the wall
brackets and their screw holes. Also mark the position at the top of the legs (inside) where the mantel
shelf will sit and, using a straight edge, draw a diagonal line along the wall (from the top internal of
each leg). This will help when positioning the fixing bracket on the mantel shelf later.
Remove the surround and securely fix the wall brackets to the wall using appropriate fixings (see
‘Important Note’ below).
IMPORTANT NOTE:
Wall fixings (i.e. screws/wall plugs etc) are not supplied as these are crucially dependant upon the
type of wall and surface the surround is going to be fixed to. The installer is therefore responsible for
ensuring that suitable fittings are used according to the particular model to be installed as well as
individual fitting situations and environments.

FIGURE 4
Remove one of the screws from the surround brackets and turn it into a vertical position (Figure 2).
This allows the bracket to be “flipped down” later for easier fitting.
Do not replace the surround on the hearth as before final fixing of the surround and back panel you
will need to prepare the wall ‘keyhole’bracket for the mantel shelf (see below).
Mantel Shelf Preparation
At the final fix stage, the mantel shelf must
be secured to the wall surface using the wall
‘keyhole’ bracket supplied. In preparation for
this, firstly fix the keyhole bracket centrally
on the wooden block on the underside of the
shelf using the screws provided - See Figure 4.
Using the diagonal line drawn earlier, find the
centre position and make a mark. At a vertical
point 30mm below this mark (as shown in
Figure 4) drill and plug the wall and then screw
home fully the mantel fixing screw supplied.
DO NOT FIT THE SHELF AT THIS STAGE.
Final Fixing
The back panel can now be placed on the hearth and up against the wall. Offer the surround up to
the wall brackets. Check the surround is vertical on the front and sides and is central on the hearth. Be
careful not to drag or slide the surround across the hearth as this may cause damage.
Once happy with the centralisation of surround and back panel, pivot the surround brackets down into
their fixing position and re-affix the screws removed from the brackets earlier. Fasten securely in place.
Note: If you prefer to fix the surround from the outside, remove the angle brackets, turn them around
through 180 degrees so that the brackets protrude from the outside of the legs rather than inside.
Re-fix to provide an exterior fixing position (Figure 3).
If your surround has lights they should be fitted now and checked to ensure correct operation prior to
continuing (see‘Halogen Lights - Installation and Replacement’section). Once lights are fitted, double
check that the interior back panel is still in the correct position. This may require removal from the wall
to meet the back of the upright legs depending upon the overall rebate dimension.
Ensure all gaps between the rear of the panel and the wall are filled with non-combustible stable
material (i.e. mortar) and sealed around the fire opening so that no products of combustion can escape
into the void.
The mantel shelf can now be put in position. Slacken off the fixing screw slightly to allow the fixing
bracket to engage and use the screw head to locate the keyhole bracket. Check that mantel is held
in place by the bracket fitting before proceeding. If there is excessive play, tighten the fixing screw
and re-engage. Once happy with shelf placement remove it and place a bead of fixing medium along
the top edges of the surround. Replace the mantel shelf, re-engage the bracket with fixing screw and
bond in place on top of the legs. 4

Halogen Lights - Installation and Replacement
5
Please note that the keyhole bracket is an additional safety feature which - if installed correctly - will
prevent the mantel shelf from tipping or falling from the surround in the unlikely event of bonding
failure. It is not however intended to secure the mantel fully to the wall so a little“play” on the bracket
is to be expected and this won’t compromise the feature. A fixing medium (such as Silicone 450 or
similar) should be used to secure the mantel shelf to the main body of surround.
IMPORTANT: Mantel shelves MUST NOT be fitted using just adhesive only. The shelf is to be fitted with
the bracket supplied and then can be bonded to the mantel using a flexible fixing medium (such as
Silicone 450 or similar). The fixing medium should be applied to the top edge of surround rather than
the bottom edge of shelf for easier bonding.
Pointing & Filling
Subject to individual preference, the joints of the fireplace sections and any small gaps between it and
the wall can be filled (pointed) using an appropriate grout such as Decorators Caulk. As you grout,
remove any excess caulking and clean with a damp sponge. Rinse the sponge between each application
so as not to spread excessive grout over the surface of the surround. Once grouting is completed - and
before grout hardens - wash down the complete surround with clean warm water and a sponge.
PRE-INSTALLATION NOTES:
IMPORTANT INFORMATION:
Installing the lights into the fire surround is a relatively straightforward DIY task if the instructions are
followed. However, once fitted to the surround, they need to be connected to an appropriate electrical
supply, and we therefore recommend that the lights are hard-wired directly into a switched fused spur
by a qualified and competent electrician, ensuring all building codes and regulations are adhered to.
To prevent the risk of electrocution, it is strongly recommended that the electricity supply is switched
off at the mains throughout the installation.
Note 1: It is important to confirm the halogen lights work correctly prior to final installation of the
fireplace.
Note 2: Determine which side of the fireplace the halogen light cable will need to be routed.
Note 3: Prior to the final installation of the fireplace, make sure that the cables will not be trapped or
crushed by the fireplace installation. The back panel should be sealed so cables cannot get trapped
behind the fire. Blocks are also provided to prevent cables falling down the leg voids on marble models.
Note 4: WARNING: Do not touch the lights while they are on, or immediately after switching off, as
they become hot during operation.

C D
A B
6
LIGHTING INSTALLATION INSTRUCTIONS
Step 1
Before beginning, ensure that your work area is clear and dry and that you have read through the full
installation instructions.
Step 2
Unravel the cable to the light bulb housing
and feed the cable up through one of the
light apertures in the surround, securing in
place (see Photograph A).
Step 3
Repeat Step 2 for the second light.
Step 4
For surrounds with the optional IR sensor, unravel the sensor cable and feed the cable up through the
small aperture in the surround. Push the sensor unit tight into the socket aperture (see Photograph B).
Step 5
Plug the mains in-line cable connectors together and position the cable with attached transformer at
the rear of the fire surround, allowing some slack for connection of the other components.
Step 6
For fire surrounds with the optional IR sensor
switch. Plug the connector in to the sensor
switch control box (see Photograph C).
Step 7
Plug both the halogen lights in to the
connector block. The plugs retaining clip
must securely grip the retaining groove
(see Photograph D).
Step 8
Ensure that you are able to draw the cables back through the light holes up to the in-line connector
without them being damaged or becoming trapped. Enough“slack”is required to allow removal should
the transformer or sensor require servicing at a later date, so – rather than using cable ties to tidy up
cables – it is better to leave them loose within the surround (resting on the internal top ledge under the
mantel shelf). The Installation of lights is now complete.
Step 9
With the lights now installed into the fire surround, they need to be connected to the mains electrical
supply. If (as recommended) this is to be to a fused spur, this work should always be undertaken by a
qualified and competent electrician.
WARNING: Before undertaking any servicing always disconnect the lights from the mains electricity
supply. Servicing should ONLY be undertaken by a qualified and competent electrician.

7
LIGHTS WITH OPTIONAL SENSOR SWITCH - OPERATING INSTRUCTIONS
Step 1
To switch the lights on, glide your hand past the sensor at a distance of approximately 50mm.
Step 2
To switch the lights off, glide your hand past the sensor once again.
REPLACING THE HALOGEN BULBS
Bulb specification: Halogen 12V MAX 20W G4.
For replacement halogen bulbs contact the BE MODERN HELPLINE on 0191 430 0901 or alternatively
consult your local electrical retailer / DIY store.
Step 1
Before replacing the bulb switch off the power and allow the bulbs to cool down completely.
Step 2
To remove the cover from the halogen bulb position a small flat blade screwdriver in
the groove around the glass ring and lightly lever the metal ring (which secures
the frosted glass in place) out of the housing.
With the glass diffuser removed the bulb can be withdrawn from its socket. Replace with a new bulb,
then gently ease the frosted glass and metal ring back into position (see Photographs E & F).
IMPORTANT
Please do not:-
• Drag or drop heavy objects such as metal coal scuttles on the hearth surface.
• Stand on the hearth. This is not only potentially dangerous, but could also disfigure the surface
texture.
• Place objects heavier than 5kg on top of the mantel shelf.
• Use any detergents to clean the marble. Use only a damp cloth and clean water to wipe clean
the marble surfaces.
We hope that you are pleased with the product and the installation of your Fireplace.
Please contact your supplier in the first instance should you have any concerns or questions.
E F

Be Modern (‘the Company’) provides a 12 month guarantee in respect of the fireplace (‘the
Product’) ranges subject to the following terms and conditions.
In the event of service being required, the purchaser should initially contact the retailer/installer
who supplied the product and they will assist and advise you further as necessary.
1. The 12 month Guarantee applies to all Products in the ranges manufactured by the Company
where:
(i) The Product has been purchased and installed within the UK
(ii) It relates to the initial installation as carried out for the original purchaser
This guarantee is not transferable
2. Proof of Purchase must be retained by the Purchaser for the period of the Guarantee.
3. A full and detailed inspection must have been carried out on all component parts by the
installer and/or the end user prior to the start of installation, to ensure there was no damage or
manufacturing defects.
4. The 12 month Guarantee does not apply to:
a. Any damages caused to the Product as a direct result of incompetent installation
b. Damage caused by misuse of the Product or where normal standards of care and use have not
been complied with
c. Damage or defects due to misuse, accident or unauthorised alterations
d. Damaged or broken component parts reported after installation
e. Any other obvious defects reported after installation
f. Halogen bulbs
5. During the 12 month period following Product purchase, the Guarantee covers the making
good (whether by repair or replacement at the Company’s discretion) of the Product only for
claims arising from defective manufacture and/or materials of the “Product” covered in Point 1,
on the proviso that:
a. The Product has been fully inspected prior to installation
b. The Product has been installed as per Be Modern recommendations
c. Our Liability is limited to the free replacement of the parts affected
This Guarantee does not affect your statutory rights
GUARANTEE
8
Be Modern Group Ltd, 19/34 Bedesway, Bede Industrial Estate, Jarrow, Tyne & Wear, NE32 3BE
November 2013. MFP 2
