Bend-Pak HD-12LS User manual

Forward this manual to all operators.
Failure to operate this equipment as
directed may cause injury.
Revised 4/27/04
INSTALLATION AND OPERATION MANUAL
SHIPPING DAMAGE CLAIMS
When this equipment is shipped, title passes to the
purchaser upon receipt from the carrier. Consequently,
claims for the material damaged in shipment must be made
by the purchaser against the transportation company at the
time shipment is received.
BE SAFE
Your new lift was designed and built with safety in
mind. However, your overall safety can be increased
by proper training and thoughtful operation on the part
of the operator. DO NOT operate or repair this
equipment without reading this manual and the
important safety instructions shown inside.
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Tel: [phone]
Fax: [phone]
Keep this operation manual near the
machine at all times. Make sure that
ALL USERS
read this manual .
12,000 POUND
CAPACITY
FOUR-POST LIFT
Models:
HD-12LS
HD-12LSX
HD-12LSXE

12,000 POUND CAPACITY
FOUR POST
ALIGNMENT LIFT
This instruction manual has been prepared especially for you.
Your new lift is the product of over 25 years of continuous research, testing and development
and is the most technically advanced lift on the market today.
READ THIS ENTIRE MANUAL BEFORE OPERATION BEGINS.
RECORD HERE THE FOLLOWING INFORMATION
WHICH IS LOCATED ON THE SERIAL NUMBER DATA PLATE
Serial No. __________
Model No. __________
Manufacturing date __________
WARRANTY
Your new lift is warranted for five years on equipment structure; one year on all operating
components to the original purchaser, to be free of defects in material and workmanship. The
manufacturer shall repair or replace at their option for this period those parts returned to the
factory freight prepaid which prove upon inspection to be defective.
The manufacturer will pay labor costs for the first 12 months only on parts returned as
previously described.
This warranty does not extend to defects caused by ordinary wear, abuse, misuse, shipping
damage, or lack of required maintenance.
This warranty is exclusive and in lieu of all other warranties expressed or implied. In no event
shall the manufacturer be liable for special, consequential or incidental damages for the
breach or delay in performance of the warranty. The manufacturer reserves the right to make
design changes or add improvements to its product line without incurring any obligation to
make such changes on product sold previously.
Warranty adjustments within the above stated policies are based on the model and serial
number of the equipment. This data must be furnished with all warranty claims.
WARRANTY IS NOT VALID UNLESS
WARRANTY CARD IS RETURNED
2

1. Carefully remove the crating and packing
materials. CAUTION! Be careful when cutting
steel banding material as items may become
loose and fall causing personal harm or injury.
2. Inspect the lift for any signs of concealed
shipment damage or shortages. Remember to
report any shipping damage to the carrier and
make a notation on the delivery receipt.
3. Check the voltage, phase and proper
amperage requirements for the motor shown on
the motor plate. Wiring should be performed by a
certified electrician only.
1. READ AND UNDERSTAND all safety warning
procedures before operating lift.
2. KEEP HANDS AND FEET CLEAR. Remove hands
and feet from any moving parts. Keep feet clear of lift
when lowering. Avoid pinch points.
3. KEEP WORK AREA CLEAN. Cluttered work areas
invite injuries.
4. Consider work area environment. Do not expose
equipment to rain . DO NOT use in damp or wet
locations. Keep area well lighted.
5. ONLY TRAINED OPERATORS should operate this
lift. All non-trained personnel should be kept away from
work area. Never let non-trained personnel come in
contact with, or operate lift.
6. USE LIFT CORRECTLY. Use lift in the proper
manner. Never use lifting adapters other than what is
approved by the manufacturer.
7. DO NOT override self-closing lift controls.
8. REMAIN CLEAR of lift when raising or lowering
vehicle.
9. CLEAR AREA if vehicle is on danger of falling.
10. ALWAYS INSURE that the safeties are engaged
before any attempt is made to work on or near vehicle.
11. DRESS PROPERLY. Non-skid steel -toe footwear
is recommended when operating lift.
12. GUARD AGAINST ELECTRIC SHOCK. This lift
must be grounded while in use to protect the operator
from electric shock. Never connect the green power
cord wire to a live terminal. This is for ground only.
13. DANGER!
The power unit used on this lift contains
highvoltage.Disconnectpoweratthereceptaclebefore
performing any electrical repairs. Secure plug so that it
cannot be accidentally plugged in during service.
14. WARNING! RISK OF EXPLOSION
. This
equipment has internal arcing or sparking parts which
should not be exposed to flammable vapors. This
machine should not be located in a recessed area or
below floor level.
15. MAINTAIN WITH CARE
. Keep lift clean for better
and safe performance. Follow manual for proper
lubrication and maintenance instructions. Keep control
handles and/or buttons dry, clean and free from grease
and oil.
16. STAY ALERT
. Watch what you are doing. Use
common sense. Be aware.
17. CHECK FOR DAMAGED PARTS
. Check for
alignment of moving parts, breakage of parts or any
condition that may affect its operation. Do not use lift if
any component is broken or damaged.
18. NEVER remove safety related components
from
the lift. Do not use lift if safety related components
are damaged or missing.
IMPORTANT SAFETY INSTRUCTIONS
Read these safety instructions entirely!
INTRODUCTION
THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH IF NOT FOLLOWED
COULD ENDANGER THE PERSONAL SAFETY AND/OR PROPERTY OF YOURSELF AND OTHERS
AND CAN CAUSE PERSONAL INJURY OR DEATH. READ AND FOLLOW ALL INSTRUCTIONS IN
THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
3

STEP 1
( Selecting Site )
Before installing your new lift, check the following.
1. LIFT LOCATION: Always use architects plans
when available. Check layout dimension against
floorplan requirements making sure that adequate
space is available.
2. OVERHEAD OBSTRUCTIONS: The area
where the lift will be located should be free of
overhead obstructions such as heaters, building
supports, electrical lines etc.
3. DEFECTIVE FLOOR: Visually inspect the site
where the lift is to be installed and check for
cracked or defective concrete.
STEP 2
( Floor Requirements )
This lift must be installed on a solid level
concrete floor with no more than 3-degrees
of slope. Failure to do so could cause
personal injury or death.
A level floor is suggested for proper installation
and level lifting. If a floor is of questionable slope,
consider a survey of the site and/or the possibility
of pouring a new level concrete slab.
"DO NOT
install this lift on any asphalt surface
or any surface other than concrete.
"DO NOT
install this lift on expansion seams or
on cracked or defective concrete.
"DO NOT
install this lift on a second / elevated
floor without first consulting building architect.
"DO NOT
install this lift outdoors unless special
consideration has been made to protect the
power unit from inclimate weather conditions.
CONCRETE SPECIFICATIONS
LIFT CONCRETE
MODEL REQUIREMENT
HD-12LS
4” Min. Thickness
HD-12LSX
4” Min. Thickness
HD-12LSXE
4” Min. Thickness
TOOLS REQUIRED
"Rotary Hammer Drill Or Similar ( If Anchoring )
"3/4" Masonry Bit ( If Anchoring )
"Hammer
"4 Foot Level
"Open-End Wrench Set: 7/16" - 1-1/8"
"Socket And Ratchet Set: 7/16" - 1-1/8"
"Hex-Key / Allen Wrench Set
"Medium Crescent Wrench
"Medium Pipe Wrench
"Crow Bar
"Chalk Line
"Medium Flat Screwdriver
"Tape Measure: 25 Foot Minimum
"Needle Nose Pliers
IMPORTANT NOTICE
Do not attempt to install this lift if you have never been trained on basic automotive lift installation procedures. Never attempt
to lift components without proper lifting tools such as forklift or cranes. Stay clear of any moving parts that can fall and cause
injury. These instructions must be followed to insure proper installation and operation of your lift. Failure to comply with these
instructions can result in serious bodily harm and void product warranty. Manufacturer will assume no liability for loss or
damage of any kind, expressed or implied resulting from improper installation or use of this product.
PLEASE READ ENTIRE MANUAL PRIOR TO INSTALLATION.
NOTE
All models MUST be installed on 2500 PSI concrete
only conformIng to the minimum requirements
shown above. New concrete must be adequately
cured by at least 28 days minimum.
4

5
IMPORTANT NOTE
The power unit must be installed at the location shown above. It is important to locate the
POWER-SIDE runway ( with cylinder ) on the SAME SIDE as power unit location. Accessory
rails on the side of each runway MUST be installed to the inside.

STEP 3
( Column & Cross Tube Installation )
1. Locate the columns at their respective locations according to the chalk line layout. ( See above )
Pay attention to the power unit location. DO NOT BOLT
columns down at this time. Use caution to
prevent columns from falling over. Raise the cross tubes ( making sure the plastic slide blocks are still in
position ) and drop down into the top of the columns. The large cut-out holes should be positioned inward
following the diagram on page 5. (See Fig. 1)
6
Fig. 1

2. Manually clear the SLACK SAFETY lock devises
on the end of each cross tube and slide the cross
tubes down until they rest on the safety lock position
fourth down from the top of the column. (See Fig. 2)
3. The columns and cross bars will now be in
position and spaced properly for the runways. Be
very careful not to disturb the columns and cross
tubes at this time as they may tip over causing
personal injury or harm. (See Fig. 3)
4. With the columns and cross tubes in place,
secure the column TOP CAPS using the 3/4” hex-
nuts & washers. Be sure to position the cable hole
INWARD. (See Fig. 4)
STEP 4
( Anchoring The Columns )
1. Before proceeding, double check the measure
-
ments and make certain that the bases of each
column are square and aligned with the chalk line.
2. Using the baseplate on each column as a guide,
drill each anchor hole approximately 4-1/2” deep
using a rotary hammer drill and 3/4” concrete bit.
( See Fig. 5 )
3. After drilling, remove dust thoroughly from each
hole using compressed air and/or wire brush. Make
certain that the columns remain aligned with the
chalk line. Always wear safety goggles.
4. Assemble the washers and nuts on the anchors
then tap into each hole with a hammer until the
washer rests against the baseplate. Be sure that if
shimming is required, enough threads are left
exposed. ( See Fig. 6 )
5. If shimming is required, insert the shims as
necessary under the baseplate so that when the
anchor bolts are tightened, the columns will be
plumb. ( See Fig. 7 )
Fig. 2
7
Fig. 5
Fig. 6
Fig. 3
Fig. 4

STEP 5
( Runway Installation )
1. Locate the runway with the cylinder attached
underneath. This runway will be located adjacent the
column with power unit bracket attached.
2. Position the holes on the side of the runway near
the power unit location. (See Fig. 8)
3. Line up the front of the power-side runway with the
cross tube bolt holes then temporarily bolt in position
using the 1/2” x 4” hex bolt, nut and lock washers.
(See Fig. 9)
4. Position the offside runway on top of the cross
tubes with the utility rails located inside. The
offside runway is not bolted down and can be
adjusted for different tread width vehicles.
STEP 6
( Cable Installation )
IMPORTANT!
Be careful not to damage the chrome cylinder rod
during this operation.
1. Inspect cables to insure proper lengths. All cables
should have ID tags showing proper cable lengths.
2.
Make sure the cylinder flange plate is installed with
the guide-block bracket facing AWAY from the cylinder.
3. In order to install the cables it is necessary to first
extend the hydraulic cylinder. Remove the cylinder
port plugs then use an air blow gun or come-along to
extend the cylinder.
4.
You must reinstall the rollers, spacers and cable
guards and pins in the same order as they are removed.
(See Fig. 10)
The nylon cable nuts MUST be tightened until there
is at least 1/4” of threads through the nylon end of
the nut. The cables will remain loose until start up.
8
Fig. 7 Fig. 9
Fig. 8

9

STEP 7
( Power Unit Installation )
1. Mount the power unit to the mounting bracket
using the 5/16” x 3/4” hex bolts and nylon nuts
then fill the reservoir with 15 quarts of 10-WT
hydraulic oil or Dexron III automatic transmission
fluid. ( See Fig. 11 )
STEP 8
( Routing Hydraulic Hoses )
1.
Install the two 90 degree hydraulic fittings to the
POWER PORT and RETURN PORT of the power
unit and connect the hoses as described below. It
will be necessary to remove shipping plugs from
both ports prior to installing fittings.
2. Install the two standard bulkhead couplers at the
outside of the POWERSIDE RUNWAY adjacent to
the power unit. Tighten securely.
3. Install the two 90-degree fittings at the cylinder
ports. On the pipe thread side of the fittings it is
recommended to use teflon tape or pipe sealer. DO
NOT USE TEFLON TAPE on JIC flared end.
4. Connect hydraulic hoses as shown below making
sure to first pass through the retaining rings located
on
the underside of the runway. MAKE SURE HOSES
ARE KEPT CLEAR OF CABLES. ( See Fig. 12 )
10
Fig. 11
Fig. 12

11
STEP 9
( Routing Airline )
Route the airline as shown below making sure to position the push button air valve with the INLET
facing towards the AIR SOURCE and the OUTLET facing the direction of the COILED AIR HOSE.
Pay careful attention to keep airline clear of any pinch points. Improper assembly may result in
safety lock failure. AIR PRESSURE SHOULD BE REGULATED TO 125 PSI MAX. ( See Fig. 13 )
Fig. 13

STEP 10
( Power-Unit Start Up )
1. Have a certified electrician run 208 - 230 volt
single phase 60 HZ power supply to motor. ( If you
ordered optional three phase power refer to the
data plate found on the motor for proper power
supply. ) Be sure to size wire for a 25 amp circuit.
RISK OF EXPLOSION!
This equipment has internal arcing or parts that
may spark and should not be exposed to
flammable vapors. Motor should not be located in
a recessed area or below floor level. NEVER
expose motor to rain or other damp environments.
DAMAGE TO MOTOR CAUSED BY WATER IS
NOT COVERED UNDER WARRANTY.
STEP 11
( Lift Start Up )
1. Make sure the power unit reservoir is full with
15 quarts of 10-WT hydraulic oil or Dexron-III
automatic transmission fluid.
2. Spray the inside of the columns where the slide
blocks glide with a light lubricant or WD-40.
3. Test the power unit by depressing the push-
button switch. If the motor sounds like it is
operating properly, raise lift and check all hose
connections for leaks.
IF MOTOR GETS HOT OR
SOUNDS PECULIAR, STOP IMMEDIATELY AND
RE-CHECK ELECTRICAL CONNECTIONS.
4. Once the lift starts to raise, simultaneously
press the power unit lowering handle at the same
time you are pressing the raise button. This will
allow any air trapped in the cylinder and lines to
escape and vent into the fluid reservoir.
5. Continue raising the lift slowly until all the slack in
the cables is taken out.
RAISE THE LIFT UNTIL
THE CYLINDER BOTTOMS OUT AND THE LIFT
STOPS. ADJUST EACH CABLE SO THAT THE
SAFETY LOCKS REST AT ONE INCH ABOVE
THE TOP SAFETY LOCK POSITION.
It may be
necessary to tighten or loosen each cable to reach
the proper height. The nylon cable nuts MUST be
tightened on each end until there is at least 1/4” of
threads through the nylon end of the nut.
STEP 12
( Installing Slack Safety Springs )
The following steps involve the SLACK CABLE
SAFETY DEVICE and MAIN SAFETY. Failure to
follow these steps could result in serious injury
or death in the event of cable failure.
1. Install the SLACK SAFETY LOCK SPRINGS
on the REAR CROSS TUBE as shown. Make
sure spring ends are secure at both ends. ( See
Fig. 14 )
12
IMPORTANT NOTE:
DO NOT USE 110 VOLT POWER SUPPLY for
this power unit. damage to motor will occur which
is not covered under warranty. You must use a
separate circuit breaker for each lift.

13
2. Check all MAIN SAFETY LOCKS to make sure
they move freely and spring back to the lock
position when released.
3. Lubricate all SAFETY PIVOT points with
WD-40 or equal.
STEP 13
( Final Assembly )
1. Tighten the cable adjusting nuts on the top of
each column and at the cylinder flange until all
remaining safety locks raise to one inch above the
top lock position. This will ensure that the cables
are adjusted evenly.
The nylon cable nuts MUST be tightened on
each end until there is at least 1/4” of threads
through the nylon end of the nut. Failure to do
so could result in serious injury or death.
2. After connecting the air supply, press the PUSH
BUTTON AIR VALVE and check that all safety
locks are functioning properly, then lower the lift
by pressing the push button air valve and power
unit lowering valve simultaneously.
NOTE:
There will be some initial stretching of the
cables in the beginning. It will be necessary to
re-adjust the cables a week after first use, then
every three to six months thereafter.
3. Run the lift up and down a few times to insure
that the locks are engaging uniformly and that the
safety release mechanisms are functioning
properly. Re-adjust if necessary.
4. Install the front tire stops. ( See Fig. 15 )
5. Install the approach ramps on the entry side of
the lift. Drive a vehicle onto the lift making sure to
set the emergency before exiting the vehicle.
Run the lift up and down two times with a vehicle
to ensure that the locks are engaging uniformly
and that the safety release mechanisms are
functioning properly. Re-adjust if necessary.
Post-Installation Check-Off
"Columns Properly Shimmed And Stable
"Anchor Bolts Tightened
"Pivot / Roller Pins Properly Attached
"Electric Power Supply Confirmed
"Cables Adjusted Properly
"Safety Locks Functioning Properly
"Check For Hydraulic Leaks
"Oil Level
"Lubrication of Critical Components
"Check For Overhead Obstructions
"Runways Level
"All Screws, Bolts, and Pins Secured
"Surrounding Area Clean
"
Operation, Maintenance and Safety Manuals
on Site
Fig. 14
Fig. 15

14
OPERATION:
To Raise Lift;
"Position vehicle tires in the center of each runway.
"Set parking brake or use wheel chock to hold vehicle in position.
"Before raising vehicle, be sure all personnel are clear of the lift and surrounding area. Pay
careful attention to overhead clearances.
"Raise the lift to the desired height by pressing the push button on the power unit.
"After vehicle is raised to the desired height, lower the lift on the nearest safety lock. Do not
allow cables to be remain slack.
"Check to make sure all four safeties are engaged BEFORE ENTERING work area.
To Lower Lift;
"Raise the lift off the safety locks by pressing the push button on the power unit. Make sure
you raise the lift by at least two inches to allow adequate clearance for the locks to
clear.
"Press the push button air safety valve and HOLD.
"Push the LOWERING HANDLE on the power unit until the lift has descended completely.
When lowering the lift PAY CAREFUL ATTENTION that all personnel and objects are kept clear.
ALWAYS keep a visual line of site on the lift AT ALL TIMES. ALWAYS make sure that all FOUR
LOCKS are disengaged. If one of the locks inadvertently locks on descent the lift and/or vehicle
may disrupt causing personal injury or death.
Weekly Maintenance
"Lubricate all rollers with general purpose oil or WD-40.
"Check all cable connections, bolts and pins to insure proper mounting.
"Lubricate safety lock pivot points with general purpose oil or WD-40.
Monthly Maintenance
"Check safety locks to insure they are in good operating condition.
"Check all cables for excessive signs of wear
"Make a visual inspection of ALL MOVING PARTS and check for excessive signs of wear
"Replace ALL FAULTY PARTS before lift is put back into operation.
WARNING!
"NEVER EXCEED THE RATED CAPACITY of lift.
"DO NOT USE LIFT if any component is found to be defective or worn.
"NEVER OPERATE LIFT with any person or equipment below.
"ALWAYS STAND CLEAR of lift when lowering or raising.
"NEVER OPERATE LIFT with any person or equipment below.
"ALWAYS INSURE SAFETY LOCKS ARE ENGAGED before entering work area.
"NEVER LEAVE LIFT IN ELEVATED CONDITION unless all four safety locks are engaged.

15

16

17

18
