Wiring the Power Unit 5585152 Page 1of 3 TSB 105-122022
BendPak Technical Service Bulletin
PL-6000DC - Wiring the 5585152 Power Unit
BendPak TSB 105–122022
The purpose of this Technical Service Bulletin is to describe a change in the four-conductor interconnecting
cable colors on the PL-6000DC Lift. The internal electrical connections in the 5585152 Power Unit and Lift
Control Panel are detailed in a revised Schematic and Control Panel Wiring Diagrams. The Installation
manual will be updated with the corrected schematic and wiring diagrams.
Connecting the Power Unit P/N: 5585152
Verify the Power Unit part number. The label identifying the Power Unit is located on the motor housing.
This Power Unit is provided with a Pigtail for the 220 VAC, 60Hz power input, the Controls input and the
bottom right Pigtail. See Figure below.
⚠DANGER All wiring must be performed by a licensed, Electrician in accordance with national and
local electrical codes. If someone who is not a certified Electrician attempts these tasks,
they could be electrocuted, resulting in serious injury or death.
Do not perform any
maintenance or installation on the Lift without first verifying that
main electrical power has been disconnected from the Lift and
cannot be re-energized until all procedures are complete
.

Wiring the Power Unit 5585152 Page 2of 3TSB 105-122022
Wiring Diagram
Drawing not to scale. Control Panel wire side view.
Control Panel Wiring

Wiring the Power Unit 5585152 Page 3of 3TSB 105-122022
Schematic 220 VAC, 60 Hz. 1 Phase (5585152):
If you have questions about your BendPak Lift, go to Bendpak.com/support,email
[e-mail], or call [phone] ext. 196.
