INSTALLATION AND OPERATION MANUAL
RECEIVING
The shipment should be thoroughly inspected as soon as it
is received. The signed Bill of Lading is acknowledgement
by the shipping carrier as receipt of this product as listed
in your invoice as being in a good condition of shipment. If
any of these goods listed on this Bill of Lading are missing
or damaged, do not accept goods until the shipping carrier
makes a notation on the freight bill of the missing or dam-
aged goods. Do this for your own protection.
BE SAFE
Your new lift was designed and built with safety in mind.
However, your overall safety can be increased with proper
training and thoughtful operation on the part of the opera-
tor. DO NOT operate or repair this equipment without
reading this manual and the important safety instructions
shown inside. Keep this operation manual near the lift at
all times. Make sure that ALL USERS read and understand
this manual.
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Toll Free 1-800-253-2363
Tel: [phone]
www.bendpak.com
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO INSTAL-
LATION AND OPERATION. BY PROCEEDING WITH LIFT INSTALLATION
AND OPERATION YOU AGREE THAT YOU FULLY UNDERSTAND
AND COMPREHEND THE FULL CONTENTS OF THIS MANUAL.
FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO OPER-
ATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.
Manual Revision D6 - March 2020
Manual Part Number 5900175
9,000 POUND CAPACITY
COMMERCIAL GRADE
FOUR-POST LIFTS
MODELS:
HD-9AE
Keep this operation manual near the
machine at all times. Make sure that
ALL USERS read this manual.
400V 50Hz SUPPLY DETAILS ARE
INCLUDED WITH ELECTRICAL CON-
TROL BOX. DISREGARD SUPPLY WIR-
ING DETAILS IN THIS MANUAL
EUROPEAN USERS
ORIGINAL INSTRUCTIONS IN
ENGLISH LANGUAGE

2
9,000 POUND CAPACITY, COMMERCIAL GRADE
FOUR POST ALIGNMENT LIFT
This instruction manual has been prepared especially for you.
Your new lift is the product of over 40 years of continuous research, testing and development;
it is the most technically advanced lift on the market today.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION & OPERATION BEGINS.
RECORD HERE THE LIFT AND
POWER UNIT INFORMATION WHICH IS LOCATED
ON THE SERIAL NUMBER
DATA PLATES ON THE LIFT AND
ON THE POWER UNIT
Power Unit Model # _____________
Power Unit Date Of Mfg. _____________
Power Unit Serial # _____________
Maximum Operating
Hydraulic Pressure 2,460 PSI
This information is required when
calling for parts or warranty issues.
PRODUCT WARRANTY
Our comprehensive product warranty means more than a commitment to you; it’s also a commitment to the value of
your new BendPak lift. For full warranty details and to register your new lift contact your nearest BendPak dealer or visit
http:/ / www.bendpak.com/ support/ warranty/
NOTE:
Every e󰀨ort has been taken to ensure complete and accurate instructions have been included in this manual, however, possible prod-
uct updates, revisions and or changes may have occurred since this printing. BendPak Ranger reserves the right to change specica-
tions without incurring any obligation for equipment previously or subsequently sold. Not responsible for typographical errors.

3
IMPORTANT NOTICE
Do not attempt to install this lift if you have never been
trained on basic automotive lift installation procedures.
Never attempt to lift components without proper lifting
tools such as a forklift or cranes. Stay clear of any mov-
ing parts that can fall and cause injury. These instruc-
tions must be followed to insure proper installation and
operation of your lift. Failure to comply with these instruc-
tions can result in serious bodily harm and void product
warranty. Manufacturer will assume no liability for loss or
damage of any kind, expressed or implied resulting from
improper installation or use of this product.
PLEASE READ ENTIRE MANUAL
PRIOR TO INSTALLATION.
DEFINITIONS OF
HAZARD LEVELS
Identify the hazard levels used in this manual with the
following definitions and signal words:
DANGER !
Watch for this symbol as it means: Immediate hazards
which will result in severe personal injury or death.
WARNING !
Watch for this symbol as it means: Hazards or unsafe
practices which could result in severe personal
injury or death.
CAUTION !
Watch for this symbol as it means: Hazards or unsafe
practices which may result in minor personal injury,
product or property damage.
OWNER’S RESPONSIBILITY
To maintain the lift and user safety, the responsibility of
the owner is to read and follow these instructions:
t Follow all installation and operation instructions.
t Make sure installation conforms to all applicable Local,
State, and Federal Codes, Rules, and Regulations;
such as State and Federal OSHA Regulations and
Electrical Codes.
t Carefully check the lift for correct initial function.
t Read and follow the safety instructions. Keep
them readily available for machine operators.
t Make certain all operators are properly trained,
know how to safely and correctly operate the unit,
and are properly supervised.
t Allow unit operation only with all parts in place and
operating safely.
t Carefully inspect the unit on a regular basis
and perform all maintenance as required.
t Service and maintain the unit only with authorized or
approved replacement parts.
t Keep all instructions permanently with the unit and
all decals on the unit clean and visible.
BEFORE YOU BEGIN
NOTIFY THE CARRIER AT ONCE if any hidden loss or
damage is discovered after receipt and request the carrier
to make an inspection. If the carrier will not do so, prepare
a signed statement to the effect that you have notified the
carrier (on a specific date) and that the carrier has failed to
comply with your request.
IT IS DIFFICULT TO COLLECT FOR LOSS OR DAMAGE
AFTER YOU HAVE GIVEN THE CARRIER A CLEAR
RECEIPT. Support claim with copies of the bill of lad-
ing, freight bill, invoice, and photographs, if available.
BendPak’s willingness to assist in helping you process
your claim does not make BendPak responsible for collec-
tion of claims or replacement of lost or damaged materials.

4
TABLE OF CONTENTS
Contents Page No.
Warranty / Serial Number Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Definitions of Hazard Levels . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Owner’s Responsibility . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installer/Operator Agreement/ Protective Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety / Warning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 1 / Selecting Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 2 / Floor Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Concrete Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Assembly View / Description of Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Floor Plan / General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Step 3 / Post and Crosstube Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
Step 4 / Raising the Crosstubes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Step 5 / Power Side Ramp Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-14
Step 6 / Off Side Ramp Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Step 7 / Cable / Sheave Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-17
Step 8 / Mounting the Hydraulic Power Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Step 9 / Routing Hydraulic Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-20
Step 10 / Routing Air Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21
Step 11 / Power Unit Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-24
Step 12 / Slack Safety Spring Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25
Step 13 / Lift Start-Up / Final Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-26
Step 14 / Anchoring the Posts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27
Step 15 / Installing Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Step 16 / Leveling / Synchronizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-28
Step 17 / Bleeding the Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Post Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Optional Equipment Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29-30
Step 18 / Operation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Step 19 / Lift Operation Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31-33
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Wire Rope Inspection and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37-40
Lubrications Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42-44
Parts Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45-47
Maintenance Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48-50
Certicate of Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

5
INSTALLER / OPERATOR
PLEASE READ AND FULLY
UNDERSTAND. BY PROCEEDING
YOU AGREE TO THE FOLLOWING.
t I have visually inspected the site where the lift is to
be installed and verified the concrete to be in good condi-
tion and free of cracks or other defects. I understand that
installing a lift on cracked or defective concrete could
cause lift failure resulting in personal injury or death.
t I understand that a level floor is required for proper
installation and level lifting.
t I understand that I am responsible if my floor is of
questionable slope and that I will be responsible for all
charges related to pouring a new level concrete slab if
required and any charges.
t I understand that BendPak lifts are supplied
with concrete fasteners meeting the criteria of the
American National Standard “Automotive Lifts - Safety
Requirements for Construction, Testing, and Validation”
ANSI/ALI ALCTV-2006, and that I will be responsible
for all charges related to any special, regional, struc-
tural, and/or seismic anchoring requirements specified
by any other agencies and/or codes such as the Uniform
Building Code (UBC) and/or International Building Code
(IBC).
t I will assume full responsibility for the concrete floor
and condition thereof, now or later, where the above
equipment model is to be installed. Failure to follow
Danger, Warning, and Caution instructions may lead to
serious personal injury or death to operator or bystander
or damage to property.
t I understand that BendPak lifts are designed to be
installed in indoor locations only. Failure to follow instal-
lation instructions may lead to serious personal injury or
death to operator or bystander or damage to property or
lift.
Failure to follow Danger, Warning, and Caution instruc-
tions may lead to serious personal injury or death to
operator or bystander or damage to property.
Please read the entire manual prior to installation.
Do not operate this machine until you have read and
have understood all of the Danger, Warning and Caution
alerts in this manual. For additional copies
or further information, contact:
BendPak Inc.
1645 Lemonwood Dr.
Santa Paula, CA. 93060
1-805-933-9970
www.bendpak.com
INSTALLER / OPERATOR
PROTECTIVE EQUIPMENT
Personal protective equipment helps makes installation
and operation safer, however, it does not take the place
of safe operating practices. Always wear durable work
clothing during any installation and/or service activity.
Shop aprons or shop coats may also be worn, however
loose-fitting clothing should be avoided.
Tight-fitting leather gloves are recommended to protect
the technician’s hands when handling parts. Sturdy leath-
er steel-toe work shoes and oil resistant soles should be
used by all service personnel to help prevent injury during
typical installation and operation activities.
Eye protection is essential during installa-
tion and operation activities. Safety glass-
es with side shields, goggles, or face
shields are acceptable. Back belts provide
support during lifting activities and are
also helpful in providing worker protection. Consideration
should also be given to the use of hearing protection if
service activity is performed in an enclosed area, or if
noise levels are high.
THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH IF NOT FOLLOWED
COULD ENDANGER THE PERSONAL SAFETY AND/OR PROPERTY OR YOURSELF AND OTHERS
AND CAN CAUSE PERSONAL INJURY OR DEATH. READ AND FOLLOW ALL INSTRUCTIONS IN
THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE.

6
1. Carefully remove the crating and packing materials.
CAUTION! Be careful when cutting steel banding mate-
rial as items may become loose and fall causing personal
harm or injury.
2. Check the voltage, phase, and proper amperage
requirements for the motor shown on the motor plate.
Electrical work should be performed only by a certified
electrician.
IMPORTANT SAFETY INSTRUCTIONS
Read these safety instructions entirely. Do not attempt to install this lift if you have never been trained
on basic automotive lift installation procedures. Never attempt to lift components without proper lifting tools such as
forklift or cranes. Stay clear of any moving parts that may fall and cause injury. When using your garage equipment,
basic safety precautions should always be followed, including the following:
INTRODUCTION
1. READ AND UNDERSTAND all safety warning proce-
dures before operating lift.
2. KEEP HANDS AND FEET CLEAR. Remove hands and
feet from any moving parts. Keep feet clear of lift when low-
ering. Avoid pinch points.
3. KEEP WORK AREA CLEAN. Cluttered work areas invite
injuries.
4. Consider work area environment. Do not expose equip-
ment to rain. DO NOT use in damp or wet locations. Keep
area well lighted.
5. ONLY TRAINED OPERATORS should operate this lift.
All non-trained personnel should be kept away from work
area. Never let non-trained personnel come in contact with,
or operate lift.
6. USE LIFT CORRECTLY. Use lift in the proper manner.
Never use lifting adapters other than what is approved by the
manufacturer.
7. DO NOT override self-closing lift controls.
8. REMAIN CLEAR of lift when raising or lowering vehicle.
9. CLEAR AREA if vehicle is in danger of falling.
10. ALWAYS ENSURE that the safeties are engaged before
any attempt is made to work on or near vehicle.
11. DRESS PROPERLY. Non-skid steel-toe footwear is
recommended when operating lift.
12. GUARD AGAINST ELECTRIC SHOCK.
This lift must be grounded while in use to
protect the operator from electric shock.
Never connect the green power cord wire to
a live terminal. This is for ground only.
13. DANGER! The power unit used on this lift contains high
voltage. Disconnect power at the recepta-
cle before performing any electrical repairs.
Secure plug so that it cannot be acciden-
tally plugged in during service.
14. WARNING! RISK OF EXPLOSION. This equipment
has internal arcing or sparking parts which
should not be exposed to flammable
vapors. This machine should not be located
in a recessed area or below floor level.
15. MAINTAIN WITH CARE. Keep lift clean for better and
safer performance. Follow manual for proper lubrication
and maintenance instructions. Keep control handles and/or
buttons dry, clean and free from grease and oil.
16. STAY ALERT. Watch what you are doing. Use common
sense. Be aware.
17. CHECK FOR DAMAGED PARTS. Check for alignment
of moving parts, breakage of parts or any condition that may
affect its operation. Do not use lift if any component is broken
or damaged.
18. NEVER remove safety related components from the lift.
Do not use lift if safety related components are damaged
or missing.
19. Keep hair, loose clothing, fingers, and all parts of
body away from moving parts
20. Use only as described in this manual. Use only manu-
facturer’s recommended attachments
21. ALWAYS WEAR SAFETY GLASSES. Everyday eye-
glasses only have impact resistant lenses, they are not
safety glasses
22. SAVE THESE INSTRUCTIONS.

7
STEP 1
(Selecting Site)
Before installing your new lift, check the following.
1. LIFT LOCATION: Always use architects plans when
available. Check layout dimension against floor plan
requirements making sure that adequate space if avail-
able.
2. OVERHEAD OBSTRUCTIONS: The area where the
lift will be located should be free of overhead obstruc-
tions such as heaters, building supports, electrical lines
etc.
3. DEFECTIVE FLOOR: Visually inspect the site where
the lift is to be installed and check for cracked or defec-
tive concrete.
5. Lift is designed for INDOOR INSTALLATION ONLY.
Outdoor use is prohibited. Always follow warnings illus-
trated on equipment labels.
STEP 2
(Floor Requirements)
This lift must be installed on a solid level concrete
floor with no more than 3° of slope. Failure to do so
could cause personal injury or death.
A level floor is suggested for proper use and installa-
tion and level lifting. If a floor is of questionable slope,
consider a survey of the site and/or the possibility of pour-
ing a new level concrete slab.
t DO NOT install or use this lift on any asphalt surface
or any surface other than concrete.
t DO NOT install or use this lift on expansion seams
or on cracked or defective concrete.
t DO NOT install or use this lift on a second / elevated
floor without first consulting building architect.
t DO NOT install this lift outside. It is only approved for
indoor installations.
t Refer to ANSI/ALI ALIS Standard (R2015) Safety
Requirements for Installation and Service for more
information about safely installing your Lift.
CONCRETE SPECIFICATIONS
LIFT MODEL CONCRETE REQUIREMENTS
HD-9AE 4.25” Min. Thickness / 3,000 PSI
DANGER !
All models MUST be installed on 3,000 PSI concrete only
conforming to the minimum requirements shown above.
New concrete must be adequately cured by at least
28 days minimum.
IMPORTANT NOTICE !
These instructions must be followed to insure proper installation and operation of your lift. Failure
to comply with these instructions can result in serious bodily harm and void product warranty.
Manufacturer will assume no liability for loss or damage of any kind, expressed or implied resulting
from improper installation or use of this product.
PLEASE READ ENTIRE MANUAL PRIOR TO INSTALLATION !
t Rotary Hammer Drill or Similar
t 3/4” Masonry Bit
t Hammer
t 4 Foot Level
t Open-End Wrench Set: SAE /Metric
t Socket And Ratchet Set: SAE/ Metric
t Hex-Key / Allen Wrench Set
t Medium Crescent & Pipe Wrenches
t Torque Wrench
t Crow Bar
t Chalk Line
t Medium Flat Screwdriver
t Tape Measure: 25 Foot Minimum
t Needle Nose Pliers
TOOLS REQUIRED
An air supply (30 PSI Min / 3 CFM Min.) will be required for the safety-lock mechanisms. See Step 11.
IMPORTANT NOTE:
BendPak lifts are supplied with installation instructions and concrete fasteners meeting the criteria as prescribed
by the American National Standard "Automotive Lifts - Safety Requirements for Construction, Testing, and
Validation" ANSI/ALI ALCTV-2011. Lift buyers are responsible for any special regional structural and/or seismic
anchoring requirements specied by any other agencies and/or codes such as the Uniform Building Code (UBC)
and/or International Building Code (IBC).

8
When removing the lift from shipping angles, pay close attention as the ramps can slide and can cause injury.
Prior to removing the bolts make sure the ramps are held securely by a fork lift or some other heavy lifting device.
PARTS INVENTORY
Be sure to take a complete inventory of parts prior to beginning installation.
Description Qty
Small Window Crosstube 1
Large Window Crosstube 1
Power Post 1
Post 3
Off Side Ramp Assembly 1
Power Side Ramp Assembly 1
Drive-Up Ramps 2
Alignment Turnplate 2
Power Unit 1
Parts Box (Packing List Enclosed) 1
Parts Bag (Packaged in Part Box) 1
Power Post
Drive-Up
Ramp
Off Side Ramp
Assembly
Power Side
Ramp Assembly
Alignment
Turnplates
Post
Small Window
Crosstube
Large Window
Crosstube

9
FLOOR PLAN / GENERAL SPECIFICATIONS
HD-9AE
Lifting Capacity 9,000 lbs / 4082 Kg.
Max capacity / front axle 4,500 lbs. / 2,041 kg
Max capacity / rear axle 4,500 lbs. / 2,041 kg
A - Overall Width 127” / 3,226 mm
B - Outside Length 198” / 5,028 mm
C - Overall Length 224” / 5,695 mm
D - Height of Columns 88” / 2,232 mm
E - Min. Runway Height 6.9” / 125 mm
F - Max. Rise 70” / 1,778 mm
G - Max Lifting Height 76.9” / 1,953 mm
H - Width Between Columns 117” / 2,972 mm
I - Runway Width 19” / 483 mm
J - Width Between Runways(*) 40” / 1017 mm
K - Length of Runways 188.5” / 4788 mm
L - Min. 4- Wheel Alignment (**) 89.5” / 2275 mm
M - Max. 4 Wheel Alignment (**) 144.7” / 3675 mm
N - Max. 2 Wheel Alignment (**) 159.7” / 4056 mm
Min. wheelbase @ rated capacity: 135”/ 3429 mm
Min. wheelbase @ 75% capacity 115” / 2921 mm
Min. wheelbase @ 50% capacity 95” / 2413 mm
Min. wheelbase @ 25% capacity 80” / 2032 mm
Locking Positions 14
Lock Spacing Every 4” / 102 mm
Lifting Time 45 Seconds
Standard Motor (**) 220 VAC / 60Hz 1 Ph.
Emission sound pressure at Operator Position < 70 dB(A)
* This dimension may be limited with the addition of rolling jacks. See Rolling Jack Specications on Separate page.
** For CE compliant countries see errata sheet included with control panel.
The design, material and specications are subject to change without notice.
NOTE:
TO CHECK IF LIFT IS SQUARE, DIAGONAL MEASUREMENTS OF POSTS AS SHOWN ABOVE MUST BE EQUAL.

10
CLEARANCES
1. Lift Location: Use architects plan and Engineers
automatic level (transit) when available to locate lift. The
above shows clearances of a typical bay layout. Lift oor
area should be level.
2. Ceiling or overhead clearance must be 80” plus height
of tallest vehicle.
3. Estimating Column Shim requirements:
In the following section, the terms “highest” and “low-
est” refer to elevation of oor.
A. Mark locations where lift columns will be posi-
tioned in bay.
B. Place target on oor at column positions (NOT
on column base plates) and record readings.
C. Find the highest of the four locations. Find the
di󰀨erence between the readings at each of the re-
maining three columns and the highest reading.
D. The di󰀨erence is the estimated amount of shim
thickness needed at each column.
Note: Maximum shim thickness is 1/2” per column using
shims and anchors provided with lift.
If no transit is available, oor slope can be determined by
using a chalk line and level.

11
STEP 3
(Post & Crosstube Installation)
1. Place a chalk line on the floor according to the floor
plan layout. Pay attention to the Power Unit location.
Locate and place the posts at their respective locations.
DO NOT BOLT the posts down at this time. Use caution
to prevent the posts from falling over.
(See Fig. 3.1)
(If not bolting lift to the floor, skip to Item 3.)
2. To estimate the shim requirements, place a target on
floor at each post position and record the readings. Find
the highest of the four locations then find the difference
between each of the remaining posts. This difference
is the estimated amount of shim thickness that will be
required at each post. (See Fig. 3.2)
3. Using a forklift or crane, raise the cross tubes (put
the Slide Blocks into position first) and then drop the cross
tubes down into the top of the posts. NOTE: The Sheave
Windows must be positioned inward and adjacent to the
Power Unit Post. (See Fig. 3.3)
4. With the posts standing and the cross tubes in posi-
tion, install the Safety Ladders. Pass the ladders through
the post openings and drop down through the Slide Block
guide slots on the crosstubes until the ladders come to
rest on the base plates. If bolting, DO NOT BOLT posts
down at this time. (See Fig. 3.4)
Fig 3.1
Fig 3.2
NOTE:
THE MAXIMUM SHIM THICKNESS RECOMMENDED
BY THE FACTORY IS NO MORE THAN 1/2” PER
COLUMN USING SHIMS AND ANCHORS PROVIDED
WITH THE LIFT. A MAXIMUM SHIM THICKNESS OF
2” IS POSSIBLE BY ORDERING OPTIONAL SHIM
PLATES. CONTACT YOUR AUTHORIZED BENDPAK
DISTRIBUTOR FOR ORDERING INFORMATION.
Power Unit
Post
Large Window
Crosstube
Small Window
Crosstube
Fig 3.3
Fig 3.4

12
5. Install an M16 jam nut on to ladder bolt prior to the
installation of the Top Plate weldment. (See Fig 3.5)
6. Install the post TOP PLATES using the M6 hex bolts,
nuts & washers. Install the nut on each safety ladder un-
til at least 1/2” of threads are exposed and the ladder is
raised at least 1/2” off of the base plate. Be sure to posi-
tion the cable hole INWARD. (See Fig. 3.6 - 3.7)
7. The posts and crosstubes are now in position for
ramp installation. (See Fig 3.8)
STEP 4
(Raising The Crosstubes)
1. Crosstubes must be raised off the ground to facilitate
cable routing and ramp assembly.
2. Manually raise the Cross Tubes until the Primary
Safety Locks engage and rest on the third or fourth lock
position or approximately 24” o󰀨 the ground. It is impor-
tant that the SLACK SAFETY LOCK IS DISENGAGED. The
Slack Safety Locks must NEVER rest on the Safety Lad-
ders. (See Fig. 4.1 - 4.4)
Jam Nut must be
installed prior to the
installation of Top
Plate weldment
Fig 3.5
M6 Nut
M6 Washer
M6 Bolt
Top Plate
Weldment
M16 Washer
M16 Nut
Cable Hole
Fig 3.6
Fig 3.7
The Ladder must
never rest on the
base of the column
or damage to the lift
will occur
WARNING!
RAISE THE SAFETY LADDER AT LEAST
1/2” ABOVE THE BASE PLATE OR DAMAGE
TO THE LIFT WILL OCCUR.
Fig 3.8
DANGER!
BE CAREFUL NOT TO DISTURB THE POSTS AND
CROSSTUBES AS THEY MAY TIP OVER CAUSING
PERSONAL INJURY OR HARM.
IMPORTANT NOTE !
IT IS IMPORTANT THAT THE SLACK SAFETY LOCK IS
CLEARED. THE SLACK SAFETY LOCK MUST NEVER
REST ON THE SAFETY LADDER.
Fig 4.1
Primary Safety
Lock Engaged
Slack Safety Lock
Disengaged

13
3. The posts and crosstubes will now be in position and
spaced properly for the ramps. Be very careful not to dis-
turb the posts and crosstubes at this time as they may tip
over causing personal injury or harm.
STEP 5
(Power Side Ramp Installation)
1. Locate the POWER SIDE RAMP easily identified by
the cylinder and sheaves assembled in the ramp or the
sheave roller mounting plates welded on the underside.
The Power Side Ramp will be positioned on the side of
the lift where the Power Unit is installed. (See Fig. 5.1)
2. Check that the cylinder ports are facing away from
the utility rail side of the Power Side Ramp. (See Fig 5.1)
3. Remove any pre-installed CABLE SHEAVES from the
POWER SIDE RAMP making sure to and pay attention
to the order in which they are removed. (This will help at
the time of re-installation.) First remove the Socket Head
Cap Screw, then press the sheave axle through the ramp
completely until the sheaves are removed. (See Fig. 5.2)
4. Position the POWER SIDE RAMP on top of the cross-
tubes with the UTILITY RAIL towards the center. Align the
holes in the ramp with the holes on the crosstubes and
bolt together using four M12 x 1.75 hex bolts, nuts, and
washers. (See Fig. 5.3)
Slack
Safety Lock
Fig 4.2
Primary
Safety Lock
Fig 4.3
Cylinder Ports
This Side
Fig 5.1
Utility Rail
This Side
Fig 5.2
Sheave
Axle Socket
Head Cap
Screw
Fig 4.4

14
STEP 6
(Off Side Ramp Installation)
3. Position the OFF SIDE RAMP on top of the crosstubes
with the UTILITY RAIL located inside. Align the holes in
the ramp with the holes on the crosstubes and bolt togeth-
er (torque to 35-45 Ft/lbs) using four M12 x 1.75 hex bolts,
nuts, and washers. (See Fig. 6.1)
STEP 7
(Cable / Sheave Installation)
1. Inspect cables to ensure proper lengths. All CABLES
should have ID tags showing proper cable lengths.
2. In order to install the cables, it is necessary to first
extend the HYDRAULIC CYLINDER. Remove both
cylinder port plugs, then use an rubber tipped air gun or
ratcheting pull-strap to extend the cylinder. IMPORTANT!
Be careful not to damage the chrome rod during this step.
(See Fig. 7.1)
Bolt Points
Fig 5.3
Fig 6.1
Utility Rail
Bolt Points
DANGER !
DO NOT PROCEED WITH CABLE INSTALLATION OR
GO NEAR THE LIFT WORK AREA UNLESS VISUAL
CONFIRMATION IS MADE OF ALL SAFETY LOCKS
BEING ENGAGED. ALL LOCKS MUST BE ENGAGED
BEFORE PROCEEDING. FAILURE TO COMPLY WITH
THESE INSTRUCTIONS MAY RESULT IN SEVERE
PERSONAL INJURY OR DEATH. (SEE PAGE 28)
WARNING!
WHEN THE CABLE ADJUSTING NUTS BOTTOM
OUT ON THE THREADED END OF THE CABLE
CONNECTOR AND THERE IS STILL SLACK IN
THE CABLES, THE CABLES HAVE STRETCHED
BEYOND THE SAFE USEFUL LENGTH AND NEED
TO BE REPLACED WITH FACTORY APPROVED
CABLE ASSEMBLIES. DO NOT PLACE WASHERS,
SPACERS OR OTHER DEVICES TO “SHORTEN” THE
EFFECTIVE CABLE LENGTH AS DAMAGE TO THE
LIFT OR INJURY TO PERSONS MAY OCCUR.
WARNING!
IF USING RUBBER-TIPPED AIR GUN, DO NOT
EXCEED 50 PSI. IF CYLINDER DOES NOT MOVE,
IMMEDIATELY DISCONTINUE USE OF AIR GUN AND
USE RATCHETING PULLSTRAP OR OTHER PULLING
DEVICE. KEEP HANDS CLEAR.
Fig 7.1
Apply Compressed
Air Here With Rubber
Tipped Air Gun

15
3. You must reinstall the SHEAVES AND PINS in the same
order as they are removed. (See Fig. 7.2-7.3)
WARNING!
WHEN THE CABLE ADJUSTING NUTS BOTTOM OUT ON THE THREADED END OF THE CABLE
CONNECTOR AND THERE IS STILL SLACK IN THE CABLES, THE CABLES HAVE STRETCHED BEYOND THE
SAFE USEFUL LENGTH AND NEED TO BE REPLACED WITH FACTORY APPROVED CABLE ASSEMBLIES.
DO NOT PLACE WASHERS, SPACERS OR OTHER DEVICES TO “SHORTEN” THE EFFECTIVE CABLE LENGTH
AS DAMAGE TO THE LIFT OR INJURY TO PERSONS MAY OCCUR.
HELPFUL TIP
INSTALL THE SHEAVES AND CABLES IN THE ORDER AS
SHOWN BELOW STARTING FROM THE SHORTEST (A)
TO THE LONGEST (D).
Cable “A” Fig 7.4 Cable “C” Fig 7.5
Cable “B” Fig 7.6 Cable “D” Fig 7.7
Sheave Axle
Fig 7.2
Socket
Head Cap
Screw
Sheave
Fig 7.3
Sheave Axle
Socket
Head Cap
Screw
Sheave

16
4. With the cables properly routed, hold the sheaves in
position and install the sheave axle. (See Fig. 7.12)
5. Install the Socket Head Cap Screws though the Sheave
Axle Collars. (See Fig. 7.13)
6. Repeat the same procedure at the other end of the lift.
7. Each cable must be installed through the CABLE RETAIN-
ER first to keep the cables stowed in their proper position on the
Cable Block. Install the Cylinder Nut so that it is no more than 1/8”
away from the retaining C-clip. (See Fig. 7.14)
DANGER !
DO NOT PROCEED UNLESS VISUAL CONFIRMATION
IS MADE OF ALL SAFETY LOCKS. ALL LOCKS MUST
BE ENGAGED BEFORE PROCEEDING. FAILURE TO
COMPLY WITH THESE INSTRUCTIONS MAY RESULT
IN SEVERE PERSONAL INJURY OR DEATH.
(SEE PAGE 30)
Cable Routing
Fig 7.11
Fig 7.10
Fig 7.9
Fig 7.8
Cable “A”
Cable “D”
Cable “C”
Cable “B”
Fig 7.12
Socket Head
Cap Screw
Sheave Axle
Fig 7.13
Sheave Axle
Collar
Fig 7.14
Cable Button
Cable Retainer
Cylinder Guide
Cable Block
Cylinder Nut
C-Clip

17
8. Route the cable ends through the ends of each cross-
tube, over the SLACK SAFETY SHEAVE then to the top
of each column. Secure using the M18 hex nuts and flat
washers. Tighten each nut until there is at least 3/4” of
threading protruding through the top of the nut. The cables
will remain loose until start up and final cable adjustments
are made. (See Fig. 7.15 - 7.16)
9. After routing the cables, make sure all cables are
properly positioned and REMAIN WITHIN THE GROOVES
of ALL Sheaves. (See Fig. 7.17 - 7.18)
STEP 8
(Mounting the Hydraulic Power Unit)
1. Mount the POWER UNIT to the Mounting Bracket
using the Hex Bolts and Nylock nuts. Then FILL THE
RESERVOIR with 21 quarts of 10-WT hydraulic oil or
Dexron III automatic transmission fluid. (See Fig. 8.1)
Route lifting
cable in front
of slack safety
sheave as shown
Fig 7.15
Fig 7.16
Install each
cable nut with a
MINIMUM of 3/4”
of thread exposed
Sheave
Cable
Fig 7.17
NOTE: ALL cables MUST remain in their
sheave grooves. Before lift start-up check all
cables for proper routing.
Fig 7.18
DANGER!
LIFTING CABLES ROUTED THROUGH THE CROSSTUBES
MUST RUN BELOW THE CROSSTUBE MOUNTING BOLTS.
SERIOUS DAMAGE OR INJURY CAN OCCUR IF CABLES
ARE NOT ROUTED CORRECTLY.
DANGER !
FAILURE TO ROUTE LIFTING CABLES AS DESCRIBED
MAY LEAD TO SERIOUS PERSONAL INJURY AND/OR
DEATH TO OPERATOR OR BYSTANDER AND/OR MAY
CAUSE DAMAGE TO PROPERTY.
Fig 8.1
M8 Hex
Bolts
M8 Nylock
Nuts
Flat
Washers

18
WARNING !
DO NOT run Power Unit with no oil. Damage to pump can occur.
The Power Unit must be kept dry. Damage to Power Unit caused by water or other liquids such as
detergents, acid etc., is not covered under warranty.
Operate lift only between temperatures of 41 °- 104° F.
Improper electrical hook-up can damage motor and will not be covered under warranty.
Motor can not run on 50HZ without a physical change in motor.
Use a separate breaker for each Power Unit.
Protect each circuit with time delay fuse or circuit breaker.
For 208-230 volt, single phase, use a 25 amp fuse.
For 208-230 volt, three phase, use a 20 amp fuse.
For 380-440 volt, three phase, use a 15 amp fuse.
The standard Power Unit for your lift is 220 volt, 60HZ, single phase. All wiring must be per-
formed by a certied electrician only.
SEE WIRING INSTRUCTIONS AFFIXED TO MOTOR FOR PROPER WIRING INSTRUCTIONS.
NOTE:
Check the Power Unit to determine proper connection ports for Power and Return lines.
It will be necessary to remove shipping plugs from both ports prior to installing Fittings.
STEP 9
(Routing Hydraulic Hoses)
1. Install the 90-degree Hydraulic Fitting to the POWER
PORT and the 90° Air Line Compression Fitting to the
RETURN PORT of the Power Unit and connect the Hoses
as described below. It will be necessary to remove the ship-
ping plugs from both ports prior to installing the Fittings.
(See Fig. 9.1 - 9.2)
NOTE: Return Port may be on the same side as the Power
Port on some models.
Install Fittings
90° Air Line
Compression
Fitting
90° O-Ring
Fitting
Fig. 9.1
Fig. 9.2
Remove
Shipping Plugs
Power Port
Return Port
Remove
Shipping Plugs
Power
Port
Return
Port
Fig. 9.1

19
2. Remove the captive nut on the Compression Fitting.
Insert the Plastic Air line through the alignment sleeve and
into the end of the tting until it bottoms out. Then tighten
the nut on the tting. (See Fig 9.3)
3. Install the 90-degree Hydraulic Fitting in the port at the
ram end of the Cylinder. On the pipe thread side of the Fitting
it is recommended to use Teflon Tape or pipe sealer. DO
NOT USE TEFLON TAPE on the JIC flared end.
(See Fig. 9.4 )
4. Install the 90-degree Air Line Compression Fitting in the
port at the base, pinned end of the Cylinder. On the pipe
thread side of the Fitting, it is recommended to use Teflon
Tape or pipe sealer. (See Fig. 9.5)
5.
Route both the Power Unit Hydraulic Hose and TWO (2)
lengths of Air Line through the Flex Hose. (See Fig. 9.6)
6. Install the end of Flex Hose with the Straight Fitting on
the Hydraulic Hose into the hole in the Powerside Runway
adjacent to the Power Unit. Install the end of the Flex
Hose with the 90° Fitting on the Hydraulic Hose in the
Flex Hose Bracket Assy. Tighten the plastic nuts securely.
(See Fig 9.7)
Fig 9.4
Fig 9.5
Fig 9.6
Flex Hose Power Hose
Air Line Hose
90° Hose End
90° Air Line
Compression
Fitting
Fig. 9.7
Fig. 9.3
90° Air Line
Compression
Fitting
90° O-Ring
Fitting
Fig. 9.2

20
7. Connect the hydraulic hose and air line as shown
below making sure the hydraulic hose passes through the
retaining rings. MAKE SURE HOSES ARE KEPT CLEAR OF
CABLES. There will be one air line hose left unconnected in
this step. This air line will be used to activate the pneumatic
safety locks in the next step. See page 19 for Compression
Fitting instructions. (See Fig. 9.8)
8. Connect the straight end of the Power Unit Hydraulic
Line to the 90° Power Unit Fitting. Connect the Return Air
Line to the 90° Air Fitting. There will be one air line hose
left unconnected at this time. This air line hose will be used
to activate the pneumatic safety locks on the next page.
(See Fig. 9.9)
STEP 10
(Routing Air Lines)
1. Mount the Push Button Air Valve Assembly on to the
power unit mounting bracket. The Push Button Air Valve
should be positioned away from the Power Side Ramp on
the “out” side of the lift for operator safety. (See Fig 10.1)
2. Route the air line that was left unconnected in Step 9
to the 90° Air Line Compression Fitting of the Push Button
Air Valve Assembly. (See Fig 10.2)
3. Once the air line has been connected with the Push
Button Air Valve, cut the air lines to length by following
the Safety Air Line Routing diagram located on Page 20
and connect female branch “tee” fittings where needed.
Fig. 9.7
Retaining Ring
Retaining Ring
Straight Hose End
Fig. 9.8
Fig. 10.1
Air Supply In
Fig. 10.2
NOTE:
A FILTER/REGULATOR/LUBRICATOR MUST BE
INSTALLED ON AIR SUPPLY AT LIFT. FAILURE TO DO
SO WILL VOID THE WARRANTY.
NOTE:
MAKE SURE THE PUSH BUTTON AIR VALVE PORT
MARKED “INLET” IS FACING TOWARDS THE SOURCE
OF COMPRESSED AIR.
Push Button
Air Valve
Assembly
To Flex Hose
