Harmar Mobility AL001 Operating instructions

25SEP2020 | 630-00095 REV B
AL001
UNIVERSAL
MANUAL CARRIER
INSTALLATION/
OWNER'S
MANUAL

AL001: Install Manual
25SEP2020 | 630-00095 REV B
3
TABLE OF CONTENTS
AL001
TABLE OF CONTENTS
SAFETY ............................................................................................ 4
Safety Definition ................................................. 4
INTRODUCTION ............................................................................ 5
Device Name: AL001 ........................................... 5
Read and Understand .......................................... 5
Technical Specifications ...................................... 5
Lift Elements ....................................................... 6
PREPARATION ............................................................................... 7
Required Tools .................................................... 7
INSTALLATION .............................................................................. 8
Anti-tilt Locking Device Installation ..................... 9
WARRANTY .................................................................................. 10

AL001: Install Manual
25SEP2020 | 630-00095 REV B
4
SAFETY
AL001: SECTION 1
SECTION 1
SAFETY
SAFETY DEFINITIONS
This safety alert symbol appears with
safety statements. It means attention,
become alert, your safety and the
safety of others are involved! Please
read and abide by the message that
follows the safety alert symbol.
NOTE: Indicates a condition that should be followed in
order for the lift to function in the manner intended.
If you do not understand any portion of the
installation or operation procedures, please consult
Harmar's Technical Service Department at
800-833-0478. Do not attempt to install or use this
lift if you have any hesitation or question. Serious
injury or damage can result if proper procedures are
not followed.
Indicates a hazardous situaon that, if not
avoided, could result in death or serious injury.
WARNING
!
Indicates a hazardous situaon that, if not avoided,
could result in minor or moderate injury.
CAUTION
!
Indicates a situation which can cause damage to
the lift and/or the environment, or cause the lift to
operate improperly.
NOTICE
!

AL001: Install Manual
25SEP2020 | 630-00095 REV B
5
INTRODUCTION
AL001: SECTION 2
SECTION 2
INTRODUCTION
DEVICE NAME: AL001
Indications of Use: The intended use of the AL001 is
to lift, secure and transport an unoccupied mobility
device for patients or mobility-impaired persons.
READ AND UNDERSTAND
Read and understand this manual prior to
installation. Having an overall understanding of the
lift and proper installation techniques will help save
time, energy and avoid possible injury.
This manual provides instructions for proper
installation and operation of an AL001. Please refer
to the Owner's Manual for operating instructions.
Be sure to provide the Installation/Owner's Manual
to the owner of the lift before it is put into service.
Any alterations to the equipment without written
authorization by the manufacturer may void the
warranty.
TECHNICAL
SPECIFICATIONS
Visit harmar.com for specifications on the specific
lift model and configuration.

AL001: Install Manual
25SEP2020 | 630-00095 REV B
6
INTRODUCTION
AL001: SECTION 2
LIFT ELEMENTS
1. Ramp
2. Ramp bolt sets (2)
3. Carriage bolt sets (2)
4. Ramp bracket
5. Spring pull pin (2)
6. Reflector (2)
7. Carrier tray
8. Gear
9. Hitch pin
10. M12x70 bolt
11. Adjust bolt
12. M10x30 bolt (3)
13. Anti-tilt lock bracket
14. Lock bolt (4)

AL001: Install Manual
25SEP2020 | 630-00095 REV B
7
PREPARATION
AL001: SECTION 3
SECTION 3
PREPARATION
If you have any questions, concerns or comments,
please contact our Technical Service Department at
800-833-0478 or [e-mail].
REQUIRED TOOLS
• Wrench Set:
• Imperial
• Metric
• No. 2 Phillips Head Screwdriver

AL001: Install Manual
25SEP2020 | 630-00095 REV B
8
INSTALLATION
AL001: SECTION 4
SECTION 4
INSTALLATION
1. Insert the hitch into the carrier rack.
See Figure 4-1.
Figure 4-1
2. Insert four (4) lock bolts on the bottom of
your carrier tube. Tighten bolts firm with a
wrench. See Figure 4-2.
Figure 4-2
3. Screw spring pull pin into carrier. Add
reflectors. See Figure 4-3.
Figure 4-3
4. Screw spring pull pin into jam nut. Screw
spring pull pin into ramp bracket. Bolt bracket
to frame and secure with nuts and lock
washers. See Figure 4-4.
Figure 4-4
To prevent loosening of the spring pull pin, torque the
jam nut tightly against the ramp bracket.
NOTICE

AL001: Install Manual
25SEP2020 | 630-00095 REV B
9
INSTALLATION
AL001: SECTION 4
5. When in use: Use the safety pin to adjust the
hitch. See Figure 4-5.
Figure 4-5
6. Insert the spring pull pin into the hole to the
ramp when you fold up the ramp.
See Figure 4-6.
Figure 4-6
ANTI-TILT LOCKING DEVICE
INSTALLATION
1. Loosen the bolts on the anti-tilt lock bracket.
There should be grooves where the bolts were
tightened against the hitch receiver.
See Figure 4-7.
Figure 4-7
NOTE: This procedure is required only during the initial
installation of the anti-tilt lock bracket as the grooves will
ensure repeatable relocation of the anti-tilt lock bracket.
2. Now pull the carrier out to its final location
and install the hitch pin. Return the anti-tilt
lock bracket to the location securely against
the hitch receiver and torque the bolts. The
bolts should fall into the grooves created
earlier.
For the installaon of the an-lt lock bracket,
insert the carrier into the hitch receiver, Do not
insert the hitch pin at this point. Now slide the
carrier toward the vehicle unl it holds the an-lt
lock bracket while an addional person holds the
carrier securely against the hitch receiver. Be sure
to torque the bolts to 35'-40' lb.
WARNING
!
Large chain loops on trailer hitches will not accept
the an-lt locking device. In this case you will be
unable to use the supplied an-lt locking device.
WARNING
!

AL001: Install Manual
25SEP2020 | 630-00095 REV B
10
WARRANTY
AL001: SECTION 5
1-YEAR LIMITED WARRANTY
PRODUCT COVERED: AL001
SECTION 5
Your lift came with a separate warranty page on
page 15. You must return this page within ten
(10) days of installation to register your lift. This
warranty policy page must remain in your Owner’s
Manual for your records. Do not tear out this page.
Dealer/Installer Name:
Address:
Phone:
E-Mail:
If you need service or warranty work, your dealer
will require the information below to receive factory
information or order parts for your lift.
Date Purchased:
Serial # of the Lift:
THIS EXPRESS WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES OR CONDITIONS, INCLUDING ALL IMPLIED
WARRANTIES OR MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, AND THERE ARE NO
WARRANTIES THAT EXTEND BEYOND THE DESCRIPTION
OF THE LIMITED WARRANTY DESCRIBED HEREIN. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND
YOU MAY ALSO HAVE OTHER LEGAL RIGHTS WHICH
VARY FROM STATE TO STATE.
Harmar Mobility warrants to the original purchaser
of an AL001 sold by Harmar to be free of defects
in material, mechanical and electrical components
(parts), excluding labor cost, batteries, paint, rust
and covers, for a period of one (1) year from date
of retail purchase, provided that the products have
been installed, maintained and operated properly.
Harmar and its dealers shall not be liable for any
consequential, special or incidental damages arising
out of the purchase or use of the unit or resulting
from the breach of this Limited Warranty, or any
implied warranty. This warranty is not transferable.
This warranty does not cover defects in vehicles on
which Harmar products are installed or malfunctions
in Harmar products caused by defects in any part of
the vehicle. All warranty claims must be reported to
the dealer from whom the lift was purchased as they
have responsibility for handling warranty claims.
The dealer is to contact the Technical Services
Department of Harmar and provide the serial
number of the product along with a description and
evidence of the defect(s) supporting a warranty
claim. Dealers may charge for labor, service, travel,
or other associated costs to make repairs, and such
charges are not covered by this Limited Warranty.
It is permissible to have any repairs or replacement
work done as a result of any defects in material and
workmanship by someone other than the Dealer
under this Limited Warranty. All parts used to
replace defective materials must be genuine Harmar
parts to be covered by this Limited Warranty.
This Limited Warranty grants specific legal rights,
other rights vary from state to state. Harmar will
not be charged for labor, consequential damage
or repair expenses. Harmar will not, under any
circumstances, be liable for the loss of the use of
its products or loss of time. Defective parts must
be returned, if requested, prepaid, to Harmar
for inspection prior to credit or replacement. At
Harmar’s discretion, any part found to have been
modified, over-stressed, damaged by accident, or
misused is not covered by this warranty.

AL001: Install Manual
25SEP2020 | 630-00095 REV B
11
WARRANTY
AL001: SECTION 5
PRODUCT INFORMATION
Model:
Serial Number:
Purchase Date:
Installation Date:
INSTALLER INFORMATION
Company Name:
Contact Name:
Address:
Phone:
Fax:
Email:
APPLICATION INFORMATION
 Scooter  Power Wheelchair
 Wheelchair  N/A
Year:
Manufacturer:
Model:
PURCHASER INFORMATION
Name:
Address:
Phone:
Email:
ADDITIONAL INFORMATION
How did you hear about Harmar?
 Harmar Dealer
 Internet
 Magazine
Which:
 Friend or Acquaintance
 Saw Harmar product somewhere
 Other:
I purchased my Harmar li because of:
 Style/Appearance
 Harmar Representative
 Previous Experience
 Ease of Use
 Recommendation
 Price/Value
PLEASE FILL OUT ALL FIELDS AND RETURN WITHIN TEN (10) DAYS OF PRODUCT INSTALLATION.
Fax completed form to 1-866-234-5680 or mail to:
Harmar, ATTN Warranty Department, 2075 47th Street, Sarasota Florida 34234.

AL001: Install Manual
25SEP2020 | 630-00095 REV B
12
WARRANTY
AL001: SECTION 5
Page Intenonally Le Blank

AL001: Install Manual
25SEP2020 | 630-00095 REV B
13
NOTES

AL001: Install Manual
25SEP2020 | 630-00095 REV B
14
NOTES

AL001: Install Manual
25SEP2020 | 630-00095 REV B
15
NOTES
