Benelec 02453 User manual

Page 1 of 6
BENELEC Pty Ltd (Inc. in NSW) A.C.N. 064 708 390 Telephone: [phone] Mail: P.O. Box 21
581-587 GardenersRoad, Mascot N.S.W.2020 Fax:[phone] Mascot,N.S.W.1460
Sydney, Australia Website: www.benelec.com.au Australia
Email: [e-mail]
Professional Wireless Products
02453 Multiband Antenna Installation Instructions
(1)
C2452V04
Bracket
Assy
HANGING MOUNT
(2)
Mounting
Bracket
Adaptor
(3) 02453
Multiband
Antenna
BALUSTRADE
MOUNT
(1)
C2452B04
Bracket
Assy
(3) 02453
Multiband
Antenna
(2)
Mounting
Bracket
Adaptor
(3) 02453
Multiband
Antenna
(1)
C2452S04
Bracket
Assy
CORNER
MOUNT
(2) Mounting
Bracket
Adaptor
(1)
C2452S04
Bracket
Assy
(2)
Mounting
Bracket
Adaptor
(3) 02453
Multiband
Antenna
FACIA
MOUNT
Patent Application - 60629/99
(3) 02453
Multiband
Antenna
(2)
Mounting
Bracket
Adaptor
(1)
C2452VS04
Bracket
Assy
SIDE
MOUNT
Vertical & horizontal
02453A
02453B
02453C
02453D
02453E

Page 2 of 6
BENELEC Pty Ltd (Inc. in NSW) A.C.N. 064 708 390 Telephone: [phone] Mail: P.O. Box 21
581-587 GardenersRoad, Mascot N.S.W.2020 Fax:[phone] Mascot,N.S.W.1460
Sydney, Australia Website: www.benelec.com.au Australia
Email: [e-mail]
Professional Wireless Products
02453 Multiband Antenna Installation Instructions
The 02453 Balustrade Mount Option is intended
for use in applications where the antenna is
required to be side mounted off beams
verandahs etc.
For best performance, the installer must ensure
that the antennas radiating section is clear of
parallel obstructions less than 200mm from the
antennas vertical position. The antenna must not
be mounted with the radiating section parallel to
any metal surface.
* Different lengths can be supplied on
request.
BALUSTRADE MOUNT
*125 mm
600 mm
Radiating Section

Page 3 of 6
BENELEC Pty Ltd (Inc. in NSW) A.C.N. 064 708 390 Telephone: [phone] Mail: P.O. Box 21
581-587 GardenersRoad, Mascot N.S.W.2020 Fax:[phone] Mascot,N.S.W.1460
Sydney, Australia Website: www.benelec.com.au Australia
Email: [e-mail]
Professional Wireless Products
02453 Multiband Antenna Installation Instructions
The 02453 Hanging Mount Option is intended for
use in applications where the antenna is required
to be mounted off beams, ceilings, etc in Car
Parks or indoor/outdoor environments.
For best performance, the installer must ensure
that the antennas radiating section is clear of
parallel obstructions less than 200mm from the
antennas vertical position. The antenna must not
be mounted with the radiating section parallel to
any metal surface.
HANGING MOUNT
* Different lengths can be supplied on
request.
Radiating Section
*150 mm
*150 mm
513 mm
Patent Application - 60629/99

Page 4 of 6
BENELEC Pty Ltd (Inc. in NSW) A.C.N. 064 708 390 Telephone: [phone] Mail: P.O. Box 21
581-587 GardenersRoad, Mascot N.S.W.2020 Fax:[phone] Mascot,N.S.W.1460
Sydney, Australia Website: www.benelec.com.au Australia
Email: [e-mail]
Professional Wireless Products
02453 Multiband Antenna Installation Instructions
The 02453 Corner Mount Option is
intended for use in applications where the
antenna is required to be mounted off wall
corners, etc in Car Parks or indoor
environments.
CORNER MOUNT
* Different lengths can be supplied on
request.
For best performance, the installer
must ensure that the antennas
radiating section is clear of parallel
obstructions less than 200mm from
the antennas vertical position. The
antenna must not be mounted with
the radiating section parallel to any
metal surface.
585 mm
*221 mm
*221 mm
Radiating Section
Patent Application - 60629/99

Page 5 of 6
BENELEC Pty Ltd (Inc. in NSW) A.C.N. 064 708 390 Telephone: [phone] Mail: P.O. Box 21
581-587 GardenersRoad, Mascot N.S.W.2020 Fax:[phone] Mascot,N.S.W.1460
Sydney, Australia Website: www.benelec.com.au Australia
Email: [e-mail]
Professional Wireless Products
02453 Multiband Antenna Installation Instructions
The 02453 Facia Mount Option
is intended for use in
applications where the antenna
is required to be mounted off
facias or vertical surfaces, etc in
Car Parks or outdoor
environments.
FACIA MOUNT
* Different lengths can be supplied on
request.
581 mm
*218 mm
*210 mm
For best performance, the installer
must ensure that the antennas
radiating section is clear of parallel
obstructions less than 200mm from
the antennas vertical position. The
antenna must not be mounted with
the radiating section parallel to any
metal surface.
Patent Application - 60629/99
Radiating Section

Page 6 of 6
BENELEC Pty Ltd (Inc. in NSW) A.C.N. 064 708 390 Telephone: [phone] Mail: P.O. Box 21
581-587 GardenersRoad, Mascot N.S.W.2020 Fax:[phone] Mascot,N.S.W.1460
Sydney, Australia Website: www.benelec.com.au Australia
Email: [e-mail]
Professional Wireless Products
*159 mm
600 mm
SIDE MOUNTING
Radiating Section
02453 Multiband Antenna Installation Instructions
The 02453 Side Mount Option is intended for use
in applications where the antenna is required to
be side mounted off beams verandahs etc.
For best performance, the installer must ensure
that the antennas radiating section is clear of
parallel obstructions less than 200mm from the
antennas vertical position. The antenna must not
be mounted with the radiating section parallel to
any metal surface.
* Different lengths can be supplied on
request.
Patent Application - 60629/99
