Beny Sports V-Fit FC1-T Manual

Assembly & User Manual
Triple Action Flywheel Cycle
FC1-T

Contents
Section Page
General Information . . . . . . 4
Before you start . . . . . . . . . 5
Safety . . . . . . . . . . . . . . . . . 6
Exercise Information . . . . . . 7
Setup Adjustments . . . . . . .13
Assembly . . . . . . . . . . . . . . 16

General Information
Quality
This exercise product has been designed and
manufactured to comply with the latest (BS EN 957)
British and European Safety Standards.
Questions
Should you encounter any difficulty with the assembly,
operation or use of your exercise product or if you
think that you may have parts missing, please DO NOT
return it to your retailer but contact us first for help and
advice, asking for CUSTOMER SUPPORT, by any of the
following means.
Tel:- 0871 222 0881 or
Fax:- 01535 637722 or
Email:- [email protected]
CUSTOMER SUPPORT is open from 9.00am to 5.00pm
from Monday to Friday
Beny Sports Co. UK Ltd.
Unit 8, Riparian Way,
The Crossings, Cross Hills,
West Yorkshire.
BD20 7BW
Queries
If you do have any queries, please ensure that you have
the following information ready for our Customer Support
Staff:
YOUR NAME
YOUR ADDRESS
YOUR PHONE NUMBER
PRODUCT MAKE OR BRAND
PRODUCT MODEL
PRODUCT SERIAL NUMBER
DATE OF PURCHASE
NAME OF RETAILER
PART NUMBERS REQUIRED
Guarantee
a). provide parts for the purchaser to effect repair.
b). repair the product returned (at the purchaser's
cost) to our warehouse.
c). replace the product if it is deemed economical to
do so.
This guarantee applies to the original purchaser only
and is not transferable.
This guarantee does not cover wear and tear on
upholstery or consumables.
This guarantee does not cover abuse or defects
caused by storage or use outside those intended.
If you need to advise us of a defect with your
product, we may ask for proof of purchase. To enable
us to service your requirement for replacement parts,
you must return the enclosed Guarantee Registration
Card within 14 days of purchase. Failure to do so
may result in any claim for replacement parts or
repairs being refused.
This does not affect your statutory rights as a
consumer.
Customer Support
Tel:- 0871 222 0881 or
Fax:- 01535 637722 or
Email:- [email protected]
CUSTOMER SUPPORT is open from 9.00am to
5.00pm from Monday to Friday
Beny Sports Co. UK Ltd.
Unit 8, Riparian Way,
The Crossings, Cross Hills,
West Yorkshire.
BD20 7BW
Beny Sports Co. UK Ltd. guarantee's its product
range for DOMESTIC USE ONLY.
For specific guarantee periods please consult the Guarantee
Registration Card supplied with your product.
During the Guarantee Period we have the right to: -
Page 4 Triple Action Flywheel Cycle

Before you Start
Tools
If required, all of our products are supplied with basic tools, which will
enable you to successfully assemble your product. However, you may
find it beneficial to have a soft-headed hammer and perhaps an
adjustable spanner handy as this may help.
Prepare the Work Area
It is important that you assemble your product in a clean, clear,
uncluttered area. This will enable you to move around the product
while you are fitting components and will reduce the possibility of
injury during assembly.
Work with a Friend
You may find it quicker, safer and easier to assemble this product with
the help of a friend as some of the components may be large, heavy
or awkward to handle alone.
Open the Carton.
Carefully open the carton that contains your product, taking note of
the warnings printed on the carton to ensure that the risk of injury is
reduced. Be aware of sharp staples that may be used to fasten the
flaps as these may cause injury. Be sure to open the carton the right
way up, as this will be the easiest and safest way to remove all the
components.
Unpack the Components
Carefully unpack each component, checking against the parts list that
you have all the necessary parts to complete the assembly of your
product.
Please note that some of the parts may be pre-fitted to major
components, so please check carefully before contacting our
CUSTOMER SUPPORT team.
In any event, please do not return the product to your retailer before
contacting us first.
Page 5Triple Action Flywheel Cycle

Safety
Before you undertake any programme of exercise that will increase
cardiovascular activity please be sure to consult with your doctor.
Frequent strenuous exercise should be approved your doctor and
proper use of your product is essential. Please read this manual
carefully before commencing assembly of your product or starting to
exercise.
* Please keep all children away from exercise products when in
use. Do not allow children to climb or play on them when they
are not in use.
* For your own safety, always ensure that there is at least 1 Metre
of free space in all directions around your product while you are
exercising.
* Regularly check to see that all nuts, bolts and fittings are
securely tightened. Periodically checking all moving parts for
obvious signs of wear or damage.
* Clean only with a damp cloth, do not use solvent cleaners. If you
are in any doubt, do not use your product, but contact
CUSTOMER SUPPORT by any of the means listed on the
opposite page.
*Before use, always ensure that your product is positioned
on a solid, flat surface. If necessary, use a rubber mat
underneath to reduce the possibility of slipping in use.
* Always wear appropriate clothing and footwear such as training
shoes when exercising. Do not wear loose clothing that could
become caught or trapped during exercise.
Storage and Use
Your product is intended for use in clean dry conditions. You
should avoid storage in excessively cold or damp places as this may
lead to corrosion and other related problems that are outside our
control.
Weight Limit
Your product is suitable for users weighing:
242LBS / 17.2 Stones / 110KG or less.
Conformity
This product conforms to:
(BS EN 957) - PARTS 1 and 5 Class (H) - HOME USE - Class (C).
It is NOT suitable for therapeutic purposes.
Page 6 Triple Action Flywheel Cycle

Set-up / Adjustments
Beginning
How you begin to exercise will vary from person to person. If you
have not exercised for a long period of time, have been inactive for a
while, or are severely overweight you MUST start slowly, increasing
your exercise time gradually, by perhaps only a few minutes for each
session per week.
Combine a carefully structured nutritious diet with a simple but
effective exercise routine and this can help make you feel better, look
better and will almost certainly enable you to enjoy life more.
Aerobic Fitness
Aerobic exercise is simply defined as any sustained activity that
increases the supply of oxygen to your muscles via the blood pumped
by your heart. With regular exercise, your cardiovascular system will
become stronger and more efficient. Your recovery rate i.e. the time
taken for your heart to reach its normal resting level, will also
decrease.
Initially you may only be able to exercise for a few minutes each day.
Do not hesitate to breathe through your mouth should you need more
oxygen. Use the "talk test". If you cannot carry on a conversation
while exercising, you are working too hard! However, aerobic fitness
will be gradually built up with regular exercise, over the next six to
eight weeks.
Do not be discouraged if it takes longer than this to begin to feel less
lethargic, everyone is different and some will achieve their targets
quicker than others. Work at your own, comfortable pace and the
results will come. The better your aerobic fitness the harder you will
have to work to stay in your target zone.
Page 7Triple Action Flywheel Cycle

Set-up / Adjustments
Page 8 Triple Action Flywheel Cycle
Warm Up
A successful exercise programme consists of three parts, Warm Up,
Aerobic Exercise and Cool Down. Never start a training session
without warming up. Never finish one without cooling down correctly.
Perform between five and ten minutes of stretching before starting
your workout to prevent muscle strains, pulls and cramps.
Aerobic Exercise Session
Those new to exercise should exercise no more than every other day
to start with.
As your fitness level increases, increase this to 2 in every 3 days.
When you are comfortable with your routine, exercise for 6 days per
week. Always take at least one day off per week.
Exercising in your Target Zone
To ensure that your heart is working in its exercise target zone, you
need to be able to take your pulse. If you do not have a pulse monitor
(either from the product you are using or a proprietary independent
unit) you will need to locate the pulse in your carotid artery. This is
situated in the side of the neck and can be felt by using the index and
middle fingers. Simply count the number of beats you feel in 10
seconds and then multiply by six to get your pulse rate. This should
be taken before you start to exercise for easy reference.
People who have a greater aerobic fitness, have a lower resting pulse
level and will also be able to exercise with a higher pulse level.
Target Zone
To determine your target zone, see the chart opposite. If you are new
to exercise and by definition unfit, refer to the left column. If you
exercise regularly and have good aerobic fitness, refer to the right
column.

Page 9Triple Action Flywheel Cycle
Set-up / Adjustments
USERS
AGE
(Years)
20-24
25-29
30-34
35-39
40-44
45-49
50-54
55-59
60 and over
UNCONDITIONED
TARGET ZONE - A
(Beats per Minute)
145 - 165
140 - 160
135 - 155
130 - 150
125 - 145
120 - 140
115 - 135
110 - 130
105 - 125
CONDITIONED
TARGET ZONE - B
(Beats per Minute)
155 - 175
150 - 170
145 - 165
140 - 160
135 - 155
130 - 150
125 - 145
120 - 140
115 - 135
Cool Down
To decrease fatigue and muscle soreness, you should also cool down
by walking at a slow relaxed pace for a minute or so, to allow your
heart rate to return to normal.
Warm Up and Cool Down Exercises
Hold each stretch for a minimum of ten seconds and then relax.
Repeat each stretch two or three times. Do this before your Aerobic
Exercise session and also after you have finished.
Head Roll
Rotate your head to the right for one count, feeling a slight pull on the
left side of your neck. Next, rotate your head back for one count,
stretching your chin. Then rotate your head to the left for one count,
feeling a slight pull on the right side of your neck. Lastly, drop your
head to your chest for one count. Repeat 2 to 3 times.
Toe Touch
Slowly bend forward from your waist, letting your back and shoulders
relax as you lower your trunk. Gently stretch down as far as is
comfortable and hold for 10 seconds.
Target Zone (con’t)

Set-up / Adjustments
Page 10 Triple Action Flywheel Cycle
Shoulder Lift
Rotate and lift your right shoulder up towards your ear for one count.
Relax then repeat for the left shoulder.
Repeat 3 - 4 times.
Calf / Achilles Stretch
Turn towards the wall and place both hands on it. Support yourself
with one leg while the other is placed behind you with the sole flat on
the floor. Bend the front leg and lean towards the wall, keeping the
rear leg straight so that the calf and Achilles tendon are stretched
hold for 5 seconds. Repeat with the other leg.
Repeat 2 - 3 times.
Side Stretch
Open both arms to the side and gently lift them above your head.
Reach your right arm as high as you can for one count, gently
stretching the muscles of the stomach and lower back. Repeat the
action with your left arm.
Repeat 3 - 4 times.
Inner Thigh Stretch
Sit on the floor and pull your legs toward your groin, the soles of your
feet together. Hold your back straight and lean forward over your feet.
Tighten the thigh muscles and hold for 5 seconds. Release and repeat
3 - 4 times.
Hamstring Stretch
Sit on the floor with your right leg extended and place your left foot
flat against the right inner thigh. Stretch forward toward the right foot
and hold for 10 seconds. Relax and then repeat with the left leg
extended.
Repeat 2 - 3 times.

Page 11Triple Action Flywheel Cycle
Set-up / Adjustments
Basic Aerobic Training Programme
For your basic Aerobic Exercise routine we suggest that you try the
following. Remember, breathe correctly, exercise at your own pace
and do not over-train as injury may result.
Week 1 & 2
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 3 & 4
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 5 & 6
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 7 & 8
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 9 & beyond
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Exercise 4 minutes at 'A'
Rest 1 minute
Exercise 2 minutes at 'A'
Exercise slowly 1 minute
Exercise 5 minutes at 'A'
Rest 1 minute
Exercise 3 minutes at 'A'
Exercise slowly 2 minutes
Exercise 6 minutes at 'A'
Rest 1 minute
Exercise 4 minutes at 'A'
Exercise slowly 3 minute
Exercise 5 minutes at 'A'
Exercise 3 minutes at 'B'
Exercise 2 minutes at 'A'
Exercise slowly 1 minute
Exercise 4 minutes at 'A'
Exercise slowly 3 minutes
Exercise 5 minutes at 'A'
Exercise 3 minutes at 'B'
Exercise 2 minutes at 'A'
Exercise slowly 1 minute
Repeat entire cycle 2 or 3
times
This is only a suggested programme and may not suit every
individual’s needs.

Exercise Notes
Page 12 Triple Action Flywheel Cycle
Use this space to record your own exercise routine results.

Set-up / Adjustments
LEVELLING THE CYCLE
For security and stability, your Flywheel Cycle has a factory
welded main frame and once fully assembled correctly, should not
need further alignment. However, in the interest of safety, please
always ensure that your Flywheel Cycle is positioned on a
solid, flat surface. If necessary, use a rubber mat underneath to
reduce the possibility of slipping in use. If you need to make a fine
adjustment, simply twist the end of either Rear Frame Stabiliser
Adjustable Hex End Cap (16) to compensate for uneven floors.
16
Page 13
Triple Action Flywheel Cycle

Set-up / Adjustments
RESISTANCE ADJUSTMENT
To ensure smooth efficient cycling action, the tension belt braking
system on your Flywheel Cycle has been correctly adjusted by
our factory during production.
You can however set the range of resistance on your Flywheel
Cycle in the following manner. Turn the Tension Controller Knob (14)
fully ANTI-CLOCKWISE, release the clasp on the Tension Belt Retaining
Clip (39) then pull the Tension Belt (38) through its retaining clip until
slight resistance is felt when rotating the Pedals (17) by hand. Lock
the Tension Belt in place by pushing the clasp on the Tension Belt
Retaining Clip fully closed.
In accordance with BS EN 957,
the braking (resistance) system
on this cycle is speed
independent.
Note
There may be a small amount of
built in resistance present at first
due to the general tight fit of the
new bearings, bushes and the
drive belt.
Note
To adjust the pedalling resistance during use, start by turning the
Tension Controller Knob (14) fully ANTI-CLOCKWISE at the start of
your workout. Gradually increase the pedalling resistance by turning
the Tension Controller Knob CLOCKWISE as required.
When you have finished your routine, turn the Tension Controller Knob
(14) fully ANTI-CLOCKWISE again to ensure that the Tension Controller
Cable is not under tension when your Flywheel Cycle is not in
use.
39
38
14
Page 14
Triple Action Flywheel Cycle

Set-up / Adjustments
EXERCISE MONITOR FUNCTIONS
With your Flywheel Cycle the single screen, 5 function
Exercise Monitor is set to start automatically when you begin to cycle.
However, it is possible to switch on the monitor by pressing the Mode
Button at the bottom of the monitor. To save batter
monitor will also switch off after it has been idle for approximately
four minutes.
Please refer to the leaflet supplied with the Exercise Monitor for all
operational functions.
DRIVE CHAIN and FLYWHEEL ALIGNMENT
It may be necessary at some stage to adjust the Drive Chain (36) on
your Flywheel Cycle. This can be achieved by removing the
Chain Guard Top Trim (32) followed by the 6 pre-fitted Machine
Screws in the Chain Guards (29). Loosen the Flywheel Spindle Nuts
on both sides and adjust the two 10mm Alignment Bolt Nuts. Please
take care to adjust each side equally to ensure that the Flywheel is
kept in alignment and that there is approximately 10mm of FREEPLAY
on the Drive Chain when correctly adjusted. See Fig. 1.
29
36
Fig. 1
Page 15Triple Action Flywheel Cycle

Set-up / Adjustments
LUBRICATION AND MAINTENANCE
The moving parts in your Flywheel Cycle are all pre-lubricated
at assembly and should not require further attention. We recommend
however that the cycle is used inside and stored in a dry condition. To
clean the metal and plastic components, a general household cleaner
can be used, but please be sure to dry the cycle and any attachments
before use.
Note
In the interest of safety, do NOT
use polish or any lubricant on
the saddle or pedals.
Page 16
Triple Action Flywheel Cycle

Assembly
Item 31
Qty 4
Item 26
Qty 1
Item 27
Qty 4
Item 21
Qty 7
Item 23
Qty 3
Item 28
Qty 4
Item 18
Qty 4
ACCESSORY FITMENT LIST
The following accessories are loosely assembled to the frame or and will need to be removed prior to assembly
The following accessories are supplied in a pack and should be checked before attempting assembly
All accessories are drawn to scale.
These are all the accessories you will need to complete the assembly of your product.
Item 22
Qty 4
Triple Action Flywheel Cycle
Page 17

Assembly
Loosely attach the Front and Rear Frame Stabilisers
(2 and 3) to the Main Frame (1) with 2 x M8 x 65mm
Carriage Bolts (18), 2 x M8 Curve Washers (28),
2 x M8 Spring Washers (27) and 2 x M8 Dome Nuts
(22) for each Stabiliser.
If not already fitted, push a Rear Frame Stabiliser
Hex End Cap (16) firmly onto each end of the Rear
Frame Stabiliser.
22
27
28
18
16
16
3
22
27
28
15
2
18
1
Note
Securely tighten all 4 bolts now.
1
Beny Sports Co. UK Ltd
Unit 8, Riparian Way,
The Crossings, Cross Hills,
West Yorkshire.
BD20 7BW
Carefully unpack each component, checking against the parts list that
you have all the necessary parts to complete the assembly of your
product.
Please note that some of the parts may be pre-fitted to major
components, so please check carefully before contacting our
CUSTOMER SUPPORT team.
In any event, please do not return the product to your retailer before
contacting us first.
Tel:- 0871 222 0881 or
Fax:- 01535 637722 or
E-mail:- [email protected]
CUSTOMER SUPPORT is open from 9.00am to 5.00pm from Monday
to Friday
PLEASE NOTE THAT FOR SAFETY AND EFFICIENCY, 2 PEOPLE SHOULD
CARRY OUT THE FOLLOWING PROCEDURES
2Carefully lower each Handlebar (4U & 5U) into its
correct lower frame (4L & 5L) and fit loosely using
4 x M8 x 15mm Allen Bolts (31), 4 x M8 Spring
Washers (27) and 4 x M8 Flat Washers (21).
Ensure the Handlebars are correctly located,
then tighten all 4 Allen Bolts.
Pull handlebars into Vertical position.
31
27
21 5L
4L
4U
5U
Page 18 Triple Action Flywheel Cycle

Assembly
4Lubricate the Handlebar Tube ends or the inside of the Handlebar
Foam Handgrips (25) with a small amount of spray furniture polish
and slide onto the bars.
3Slide the Exercise Monitor (12) onto the bracket at the top of one of
the Handlebars and carefully connect the Monitor Pick-up Cable (13)
into the Monitor Wire Plug. Remove the M4 x 12mm screw (26) from
the Tension Controller (14) open the bracket, slide on the rubber
sleeve and fit the Tension Controller to the opposite Handlebar
securing in place with the M4 x 12mm Screw previously removed.
12
26
14
13
4U
25
5U
25
Page 19Triple Action Flywheel Cycle

Assembly
Assembly
Assemble the Pedals (Left and Right) (17) to the Pedal Crank (33).
Both Pedals MUST be tightened securely otherwise damage may
occur to the Crank.
Fit the Pedal Straps (Marked L and R) ensuring a snug, but not tight
fit with your normal footwear.
One Pedal is supplied with a
RIGHT HAND THREAD for the
RIGHT HAND SIDE of the cycle
and must be fitted by turning
CLOCKWISE. The other Pedal is
supplied with a LEFT HAND
THREAD for the LEFT HAND SIDE
and must be fitted by turning
ANTI-CLOCKWISE.
Caution
17 (L)
17 (R)
33
5
6
Page 20 Triple Action Flywheel Cycle
