Berkel 919E User manual

Model 919E
Automatic Gravity Feed Slicer
Item #
Standard Features
➤1-speed, 1/2 HP, totally enclosed and permanently
lubricated knife motor
➤1-speed, automatic carriage produces 50 slices per
minute
➤Furnished in 115/60/1, 4.5 amp, AC, ETL listed;
also available in 1/3 HP, 220/60/1, 2.4 amp, AC,
ETL Listed
➤Low 12/5 VDC voltage for added operator protection
➤Finish is stainless steel and sanitary burnished
aluminum; unit disassembles quickly without tools
for easy cleaning
➤Nominal 12-1/2” (318 mm) diameter, hollow ground,
hardened and polished forged stainless steel knife
➤The carriage handles food up to 11” (280 mm) wide,
by 6” (152 mm) high or 8” (203 mm) diameter
➤Rear-mounted, stainless steel meat pusher extends
over the length of the product table
➤Precise slice adjustment to a thickness of
27/32” (21 mm)
➤Ergonomic style handle for ease of use
➤Built-in, top-mounted, two stone knife sharpener
with single lever, dual-action system
➤Permanent, tapered knife ring guard covers non-
slicing portion of knife even when the sharpener
and center plate are removed
➤Q-P-Q nickel plated transport slide rod with reservoir
wick for reduced wear
➤On/off, 3-position, moisture protected switch with
power light
➤Attached 6-foot, flexible, 3-wire cord and plug for
grounded receptacle
➤No-Volt release prevents activation of the slicer in
the event of a power interruption; operator must
restart the slicer
Options
❏1/3 HP, 220/60/1, 2.4 amp, AC, ETL listed
Automatic Gravity Feed Slicer Model 919E
Berkel Company • 4406 Technology Drive • South Bend, IN 46628-9700
574-232-8222 • 800-348-0251 • FAX [phone] • www.berkel.com
Form #SPC07-0902N
Safety and Convenience Features
Berkel Model 919E automatic gravity feed slicer features
Berkel’s time proven hollow ground stainless steel knife,
built-in, dual-action sharpener and a number of safety
features. The tapered permanent guard covers the non-
slicing portion of the knife even when the sharpener and
center plate are removed. The unit is easy to clean and
disassembles quickly without tools.
Accessories
❏Stainless steel vegetable ❑ 4” Extension NSF
chute with pusher legs (set of 4)
❏Skewers with coring tool ❏ Slaw tray
❏ Sharpening kit ❏Juice cup
❏Receiving tray ❑ Product fence
Approved By:
Date
C
Model 919E

Knife Ring Guard: Permanent, tapered knife guard
covers non-slicing portion of knife edge even when
the sharpener and center plate are removed.
No-Volt Release: Prevents activation of the slicer in
the event of a power interruption; operator must
restart the slicer.
On/Off Switch: Highly reliable, moisture resistant,
on/off switch and power light.
Q-P-Q Nickel Plated Transport Slide Rod with
Reservoir Wick: E-nickel plated rod undergoes Q-P-Q
impregnation increasing the lubricity of the stainless
steel reducing wear properties of the rod & bushings.
Cord and Plug: Attached 6-foot, flexible, 3-wire cord
and plug for grounded receptacle.
Warranty: All parts, service and travel coverage for
one year, excluding wear items.
As we continually strive to improve our products, specifications
are necessarily subject to change without notice.
Form #SPC07-0902N Made in the U.S.A. © 2002 Berkel Company Litho in U.S.A.
Berkel Company • 4406 Technology Drive • South Bend, IN 46628-9700
574-232-8222 • 800-348-0251 • FAX [phone] • www.berkel.com
Automatic Gravity Feed Slicer Model 919E
Model 919E
Automatic Gravity Feed Slicer
AB
C
Specifications
Motor: 1-speed, 1/2 HP, totally enclosed, perma-
nently lubricated ball bearings, thermally protected.
Carriage: 1-speed, automatic carriage produces 50
slices per minute.
Electrical: Furnished in 115/60/1, 4.5 amp, AC,
ETL listed. Also available in 1/3 HP, 220/60/1, 2.4
amp, AC, ETL Listed. Low 12/5 VDC circuitry for
added operator protection.
Finish/construction: All food contact areas are
stainless steel including the pusher, gauge plate,
product table, center plate and knife; sanitary
burnished aluminum ring guard and one-piece base
with non-slip feet. Slicer disassembles quickly
without tools for easy cleaning.
Knife: Nominal 12-1/2” (318 mm) diameter,
hollow ground, hardened and polished forged
stainless steel.
Cutting Capacity: Carriage handles food up to 11”
(280 mm) wide by 6” (152 mm) high or 8” (203
mm) diameter.
Slice Thickness: Precision gear system with
eccentric gear to prevent backlash, provides infinite
slice adjustment and consistent cuts of hard or soft
foods from tissue thin to 27/32” (21 mm).
Full Gravity Feed: Full 45°angle feed requires
less mechanical pressure. Equipped with a rear-
mounted, stainless steel meat pusher that runs
the entire length of the product table to hold
product and minimize waste. An optional screw-in
weight is also available. Ergonomic style handle
for ease of use.
Knife Sharpener: Built-in, top-mounted, two
stone, single lever, dual-action system for a
lasting, razor-sharp edge. Unit is removable and
submersible for easy cleaning.
Model No. Cutting Slice Knife Slicing Product Dimensions
Capacity Thickness Diameter Speed Width A Depth B Height C
919E 11” (280 mm) wide to 27/32” 12-1/2” 50 SPM 20” 29” 24”
6” (152 mm) high (21 mm) (318 mm) (508 mm) (737 mm) (610 mm)
8” (203 mm) dia.
Motor Electrical Weight Box Dimensions
Width Depth Height
1-speed 115/60/1 Net 114 lbs. (52 kg) 32” 30” 30”
1/2 HP Ship 152 lbs. (69 kg) (813 mm) (762 mm) (762 mm)
