Berkel 909FS Quick start guide

Models
909FS and
919FS
Parts
Breakdowns

Sharpener
No. Description Part Number
N/S sharpener assy. w/o cover 4675-00960
sharpener assy. w/ cover 4675-00959
3 nut 2175-00387
4 washer 2275-03040
5 inside stone (deburring) 3675-00075
6 outside stone (sharpening) 3675-00076
7 nut (LH) 2175-00388
8 spindle bearing 3375-01123
9 ball 2375-00150
10 outside spindle (sharpening) 3375-01119
11 inside spindle ( deburring) 3375-01118
12 adjusting plate 3475-00789
13 washer 2275-03040
14 screw 2175-00384
16 link screw 3375-01121
18 knob 2275-00496
20cover 4675-01084
23 groove pin 2275-00220
24 retaining ring 2275-00445
25 sharpener frame 3675-00236
26 nut 2175-00386
27 bolt 2175-00385
28 spring 3275-00210
29 spring 3275-00212
30 spindle 3375-01120
31 lever 4575-00900
33 retaining ring 2275-00444
34 washer 2275-00451
36 washer (rubber) 3275-00042
38 link 3475-00791
39 retaining ring 2275-00443
41 washer 2275-00441
42 screw 2175-00382
N/S sharpener maint. kit 4975-00375

Top View
Item Description PartNumber Item Description PartNumber
1 upper guard (“T” shaped) 3775-00442 41 screw 5/16 x 1 2175-01764
42 holecover (small) 3675-00072
upper guard (909 “L” shaped) 3775-00443 43 product table complete 4675-00915
screw, adjustment (not showen) 2175-03320 44 knob, upper, 10-24 male 2275-00008
1A lower guard 3775-00441 45 knob, lower, 1/4 male 4375-00154
lower guard, assy. (with 3 & 6) 4575-00831 46 slice deflector, black plastic 3875-00134
2 screw, tamper proof 2175-00374 46 pusher 3775-00428
N/S torx bit, for tamper proot secrws 4975-09241 47 knob 2275-00043
3 pin center plate 3375-01077 48 spacer 3375-00244
4 pad upper, old style only 3875-00140 N/S handle,pusher2lbs. 3375-01065
5 pad lower, old style only 3875-00139 set screw, 3/8-16 X 3/4 2175-07175
6 post center plate 3375-01073 50 bushing 2275-00045
8 plunger center plate, assy. 2375-00139 51 pad, wear 3875-00123
9 center plate assy. (w/ 8) 4675-00968 52 pusher assy. Complete 4675-00963
10 knife bolt, 7/16-20 X 5/8 3375-01072 53 truss head screw 2175-03452
11 knife washer 3475-00781 54 shaft 3375-00242
13 knife box cover 3475-00765 55 compression spring 3275-00029
14 knife belt (flat, 60 Hz) 2375-00141 56 lock pin (plastic, push on) 3875-00022
knife belt (flat, 50 Hz) 3375-00142 guide, pusher (metal screw) 3375-01149
15 knife pulley bearing assy. 4375-00192 screw for above 2175-03441
16 screw knife box cover 2175-03452 washer, for above 3275-00111
17 knife, SS 3675-00070 57 s/s washer 2275-00438
18 knife box bolts 2175-03063 58 knob 2275-00042
19 knife box washers 2275-03065 59 spacer 3375-00243
20 knife box assy. 4675-00961 60 product table 4575-00847
21 pinupperhinge 2275-01122 61 bolt 3/8 x 1/2 2175-03277
22 upperhinge 3475-00156 62 bracket, w/ storage pin 4675-00962
23 screw upper hinge 2175-03641 63 knob 2275-00063
25 set screw 2175-07152 64 washer 2275-03050
26 cover plate 3475-00162 65 capnut 2175-07052
27 pin 3375-00291 66 plug (old style) 3375-00309
28 lowerhinge 3475-00363 setscrew (old style) 2175-05143
29 screw #10 x 3/8 2175-03441 66A pin,tableadjustment 3375-01182
30 setscrew 2175-05154 66B pin,tableadjustment 3375-01147
31 acornnut 2175-07052 68 plug 3475-00080
32 shoe post 909 4575-00208 69 screw socket HD 2175-01765
shoe post 919 4575-00117 70 support arm 4675-01103
4" shoe post 909 4575-00307 71 upperpin 2275-00065
4" shoe post 919 4575-00178 72 rivot 2275-00066
4" set of 4 posts 909 4975-00024 73 washer 2275-03020
4" set of 4 posts 919 4975-00025 74 lower pin 3375-00311
lift kit shoe post 4575-00823 76 base 3775-00431
34 shoe rubber 3675-00061 77 bracket pusher 3475-00132
35 gaugeplate 4575-00808 78 clip lock pin (old style) 2175-00435
N/S gauge plate assembly 4675-00822 79 pin, pusher storage 2175-00435
36 washer 1/4 2275-03050 80 bracket knob 3475-00133
37 nut 1/4 2175-05051 82 logo, Berkel 3175-00152
38 hole cover (large) 3675-00071 83 pusher storage pin 2175-00435
39 slice deflector, gray plastic 3875-00138 84 nut 2175-05071
40 gauge plate support 3775-00435 85 screw 2175-07179

Bottom View
No. Description Part Number No. Description Part Number
1 gauge plate support 4675-00821 39 washer 3275-00047
2 slide rod plate 3475-00162 40 screw #10 x 1/2 2175-03442
3 bushing 2275-00058 41 spring 3275-00061
4 slide rod 3375-00296 42 springhook 3275-00060
5 shim 3275-00044 43 setscrew 2175-05152
6 base gauge plate 3775-00146 44 carriage assembly 4675-00473
7 set screw 2175-05155 45 carriage cover 3475-00169
8 lock washer 2275-03050 46 oil wick 3275-00035
9 screw 1/4 x 1-1/4 2175-01054 47 bushing7/8 2275-00053
10 screw 1/4 x 1 2175-00097 48 oil hole cover 2475-00003
11 pin 2275-01131 49 plug 3375-00336
12 indexlink 4575-00101 50 setscrew 2175-00381
13 housing 3775-00365 51 rail, square 3375-00305
14 housing 3375-00431 52 flat HD screw 4/15 x 1-1/4 2175-01665
15 name plate 3175-00152 53 nut 5/16 2175-05060
16 washer 2275-03050 54 nut, locking #10 2175-00107
17 screw 1/4-20 x 1-1/4 2175-03858 55 setscrew FP #10 (adjustment) 2175-00106
18 toggle switch assy. 2675-00617 56 bolt 3375-00249
switch guard 2675-00647 58 roller bearing assembly 4375-00031
rivit, drive 1/8 X 1/8 09175-30 58 old style roller (looks like wheel) 4375-00031
20 switch box cover 3875-00137 59 bolt 5/16 x 1-1/4 2175-01065
21 switch box cover screw 2175-00375 61 lockwasher 2275-03065
22 pilotlight 2675-00669 62 bracket 3375-00304
23 lock washer 5/16 2275-01055 63 screw 5/16 x 1/2 2175-01862
24 bolt 5/16 x 1/2 2175-01060 64 flat washer 5/16 2275-01061
25 bushing 3375-01070 65 bolt 5/16 x 7/8 2175-03063
26 screw 3/8 x 1-1/4 2175-01775 66 motor clip 3275-00039
27 clamp, indexlink 3375-00298 67 motor clamp 2275-00087
28 gear segment assy. 4375-00196 68 washer 3375-00131
gear segment, 25 & 28 4975-09280 69 roller adjusting bracket 3375-00306
28A gear segment pin 3375-01102 70 cord clamp 3675-00224
29 nameplate 3175-00152 71 screw (#8 X 1/2) 2175-00105
30 indexknob 3875-00151 72 power cord NEMA-5-15P 4175-00479
index knob kit, 30 & 32 4975-09506 73 motor pulley, 60Hz 3375-01099
31 nut1/2" 2175-00121 motorpulley, 50Hz 3375-01100
32 plug 1-1/4 2275-00414 N/S fan 2375-00137
33 setscrew 2175-05163 N/S cover for fan 3875-00146
34 worm gear assembly 4675-00336 75 bolt 2175-01760
35 rubber washer 3275-00045 76 pivot assembly motor 4575-00097
36 rubber bumper 3275-00046 77 motor mount 4575-00805
37 roundrail 3375-00091 78 thread rod 2175-00378
38 snapring 2275-00092 79 1/2 hp motor (only)115V 4175-00588

Power Stroke
No. Description Part Number No. Description Part Number
1 bolt 5/16 x 2 2175-01267 N/S cover for fan if so equiped 3875-00146
2 bolt 5/16 x 3-1/2 2175-01270 40 screw 2175-03442
3 bolt 5/16 x 1-1/2 2175-01065 41 speed nut 2275-00123
4 washer 2275-01061 42 strain relief 2675-00562
5 idler pulley 4375-00137 43 bushing 2275-00021
8 pulley & pulleyassembly 4675-00811 44 key 3275-00006
9 bolt 5/16 x 3/4 2175-03062 45 crank assy. (complete) 4375-00191
10 bracket 3475-00324 46 bushing(arm) 2275-00022
11 spacer 3375-01088 47 washer 3275-00010
13 spacer 3375-00223 48 crankassembly 4375-00189
14 nut5/16 2175-05060 49 ballbearing 2375-00010
15 washer 5/16 flat 2275-01060 50 rod & brg. Assy. (short) 4675-00840
16 roller 3275-00024 51 set screw 1/4 x 5/16 2175-05152
17 lockwasher 5/16 2275-03065 52 pulley 3775-00373
18washer 1/2" hole 3275-00018 53shift lever assy. (complete) 4575-00865
19 bushing 3275-00023 54 knob (sold each, need 2) 3875-00026
20 rivet 2275-00029 55 pin 2275-00051
21 drive arm assembly 4375-00188 56 shift lever & bracket assy. 4675-00925
22 nut#10 2175-05040 57 nut 1/4" 2175-00265
24 spring 3275-00084 58 bracket 3575-00063
26 control rod 3375-00227 59 spacer 3375-01151
27 washer, plastic, 7/8" hole 3275-00032 61 spring washer 7/16" 3275-00025
28 arm, w/ 46 4375-00193 62 washer 2275-00408
29 shim, plastic 1/2" hole 3275-00128 63 bolt 1/4" 2175-00210
30washer2275-00028 64belt poly V4 2375-00138
31 rod & brg assy. (long) 4375-00197 65 belt,round 2375-00133
32 screw 5/16 x 7/8" 2175-01863 66 bearing assy. L/H 2375-00144
33 shim 09664-60 67 bearing assy. R/H 2375-00143
34 plate & shaft 4575-00075 68 motor pulley auto drive, FS 3375-01222
35 bolt 5/16 x 1-1/4 2175-01264 parts for shift lever with detent system
36 drive screw 2175-00424 53 shift lever assy. (complete) 4575-00314
37 shift plate assy 4575-00866 N/S detent plate 3475-00782
stroke plate, part of 37 3175-00571 plungerassembly 2375-00030
shift plate, part of 37 3475-00835 nut 2175-05071
38 auto base 3775-00366 37 indicatorplate 3175-00571
39 shield 3475-00783 N/S spacer, long (for control rod) 3375-00438
spacer, short (for control rod) 3375-00439

No. Description Part Number
1 cord, switch to motor 4175-00032
2switch 2675-00617
3 pilot light 2675-00669
5 circuit breaker, 12 Amp. 2675-00817
6 wire, relay socket to circuit breaker 2675-00709
7 motor ground wire 2675-00666
8power cord 4175-00479
