Bernafon CHRONOS 9 Assembly instructions

FITTING GUIDE
CHRONOS 9 | 7 | 5 HEARING SYSTEMS
www.bernafon.com

3
BERNAFON CHRONOS
Overview 4
Chronos Behind The Ear (BTE) Hearing Aids
Attaching and removing Spira Flex adapter and earhook 6
Changing Spira Flex domes 7
Installation of right/left indicators 7
Replacing battery drawer 8
Chronos In The Ear (ITE) Hearing Aids
Wax protection 10
Microphone shield 11
Fitting Chronos with Oasis
Attaching programming cables 12
Screen by screen fitting instruction 13
Ordering information 21
Chronos 9 | 7 | 5 Fitting Guide
Table of contents

4
Chronos contains a full range of BTE and custom instrument styles, all available within three technology
levels. ChannelFree™ signal processing is the core technology for each Chronos instrument, and varying
levels of binaural coordination, adaptive features and wireless connectivity are available within the entire
Chronos family. This guide will help you to successfully t and manage all Chronos hearing systems.
Chronos 9 | 7 | 5 – Overview
1 Multi control
2 Microphone
2a Second microphone
3 Adapter
4 Spira Flex sound tube
5 Sound outlet
6 Dome
7 Concha clip
8 Battery drawer
9 Direct Audio Input
(with an optional
DAI adapter)
Bernafon Veras IFU micro BTE
VR_ILU_microBTEwithHook_BW_HI
2a
1
4
3
2
56
1
Bernafon nano BTE IFU
VR_ILU_nanoBTEwithSpira_BW_HI
2a
8
1
7
6
5
4
2
31 Push button
2 Microphone
2a Second microphone
3 Adapter
4 Spira Flex sound tube
5 Sound outlet
6 Dome
7 Concha clip
8 Battery drawer
Bernafon Veras IFU micro BTE
VR_ILU_microBTEwithSpira_BW_HI
15
4
3
2
2a
6
7
89
1
Chronos Micro BTE with Spira Flex sound tube system
Chronos Compact Power (CP) and Compact Power Plus (CPx) BTE with hook
Chronos Nano BTE with Spira Flex sound tube system
1 Multi control
2 Microphone
2a Second microphone
3 Earhook
4 Sound outlet
5 Battery drawer
6 Direct Audio Input
(with an optional
DAI adapter)

Bernafon Forte IFUs
CN_ILU_ITCPoverview_BW_HI
friLINE, Bernhard Carrel 15.10.2010
5
BERNAFON CHRONOS
ITCD
Bernafon Veras IFU ITC
VR_ILU_ITC1overview_BW_HI
4
6
7
8
5
1
2
3
3
4
6
5
7
1
2
ITCP
CIC
1 Vent
2 Canal
3 Sound outlet with
wax protection
4 Microphone opening
5 Battery drawer
6 Push button
(optional)
7 Volume control
(optional)
8 Second microphone
opening
1 Vent
2 Canal
3 Sound outlet with
wax protection
4 Microphone opening
5 Battery drawer
6 Pull-out string
1 Vent
2 Canal
3 Sound outlet with
wax protection
4 Microphone opening
5 Battery drawer
6 Push button
(optional)
7 Volume control
(optional)
8 Second microphone
opening
Chronos custom models
ITED
ITCPD
CICP
Bernafon Veras IFU CIC
VR_ILU_CICoverview_BW_HI
1
5
2
3
4
6
Bernafon Forte IFUs
CN_ILU_ITEDoverview_BW_HI
friLINE, Bernhard Carrel 20.10.2010
7
5
2
6
8
4
3
1
Bernafon Forte IFUs
CN_ILU_ITCPDoverview_BW_HI
friLINE, Bernhard Carrel 15.10.2010
6
5
3
1
2
7
8
4
Bernafon Forte IFUs
CN_ILU_CICPoverview_BW_HI
friLINE, Bernhard Carrel 15.10.2010
4
61
5
2
3

6
All Chronos BTEs are available with either Bernafon’s Spira Flex thin tube and dome system or a
conventional earhook.
Chronos BTEs
Chronos Micro, CP, and CPx BTE
1 Use the pointed end of the disassembly tool to push the lock pin free.
2 Replace the hook or adapter with the desired part.
3 Replace the lock pin. (Tweezers make this easier).
Attaching and removing the earhook or Spira Flex adapter
Chronos Nano BTE
1 Pull the Spira Flex adapter or the hook upwards from the instrument.
2 Replace with a new hook or an adapter by pushing the desired part rmly onto the instrument.
Use the pointy end of the disassembly tool to push
the lock pin.
Remove hook or adapter.
VR_ILU_MicroCompactBTERemovePin_CMYK_HI
VR_ILU_MicroCompactBTERemoveHook_BW_HI
VR_ILU_NanoBTERemoveSpira_BW_HI
VR_ILU_NanoBTERemoveHook_BW_HI

7
BERNAFON CHRONOS
1 Pull the used dome off the tube and discard.
2 With clean hands, rmly push a new dome
onto the tube as far as it will go.
If the dome is not pushed all the way onto the
tube, it could fall off in the ear canal.
Changing Spira Flex domes
The soft domes are a disposable part.
The client should be supplied with spare
domes and shown how to change them.
Installation of right/left indicators
1 Open battery drawer and insert marker end into slot as shown.
2 Twist and rotate the stick to break off the marker.
Chronos Micro BTE
VR_ILU_MicroCompactBTEInstMarking1_CMYK_HI
VR_ILU_MicroCompactBTEInstMarking2_CMYK_HI
VR_ILU_MicroCompactBTEInstMarking3_CMYK_HI
Chronos Nano BTE
VR_ILU_NanoBTEInstMarking1_BW_HI
VR_ILU_NanoBTEInstMarking2_CMYK_HI
VR_ILU_NanoBTEInstMarking3_CMYK_HI

8
Chronos CP and CPx BTE
1 Open the battery drawer.
2 Insert the marker end into the slot
as shown.
Replacing battery drawer
Chronos Micro, CP, and CPx BTE
Battery drawer removal
1 Open the battery drawer and place the battery
removal tool as shown.
2 Gently pull the battery drawer off.
3 Snap the new battery drawer in place and close.
3 Twist and rotate the stick to break off
the marker.
4 Close battery drawer.

9
BERNAFON CHRONOS
Chronos Nano BTE
1 Push out the metal pin with the disassembly tool.
2 Pull the pin out with a pair of tweezers.
3 When replacing the drawer, snap in the new drawer (closed position) and use the tweezers to place
the pin into the hole.
4 Use the at end of the tweezers to push the pin completely in.
VR_ILU_NanoBTEbatteryDrawerRemove1_CMYK_HI
VR_ILU_NanoBTEbatteryDrawerRemove2_BW_HI
VR_ILU_NanoBTEbatteryDrawerMounting_BW_HI
Tamper resistant battery drawer
The following models have an optional tamper resistant battery drawer that can be ordered separately.
Micro BTE CP and CPx BTE
Bernafon Veras IFU micro BTE
VR_ILU_TamperResitantBatteryDrawerCompactBTE_BW_HI
Bernafon Veras IFU micro BTE
VR_ILU_TamperResitantBatteryDrawerMicroBTE_BW_HI
Bernafon Veras IFU micro BTE
VR_ILU_TamperResitantBatteryDrawerMicroBTE2_BW_HI

10
Chronos custom models may be supplied with one of several types of wax protection. The following
shows the insertion and removal procedure for the most common types.
Chronos ITE
Wax Protection
NoWax
Micro Wax Buster (MWB)
1. 2.
3. 4.
1. Remove a tool from the turtle.
2. Insert the empty end of the tool into the old
lter and pull it out.
3. Push a new lter into instrument.
4. Discard the used tool.
2.
1.
3.
4.
5.
1. Use the tool to pull out the old lter.
2. Take a new lter from the box.
3. Place the gray side of lter on the small end of
the tool as shown.
4. Push the lter into the instrument.
5. To clean, push down and move the lter back
and forth on a clean cloth.

11
BERNAFON CHRONOS
Wax Buster (WB)
1. Locate the microphone opening on the face plate.
2. With the dome side facing up, grasp the wind screen with a pair of tweezers and snap it into
the hole.
3. To remove, carefully insert the service tool into the wind screen and pop it out.
1. Insert the tool into the old lter and twist.
2. Remove the lter from the instrument.
3. Take a new lter from the box.
4. Place the lter in the instrument with the gray
side up.
5. Use the tool to tighten the lter.
6. To clean, push down and move the lter back
and forth on a clean cloth.
Wind Screen for Chronos ITC instruments
VR_ILLU_ITC_WindScreen_Place2_CMYK_HI
VR_ILLU_ITC_WindScreen_Place1_CMYK_HI
VR_ILLU_ITC_WindScreen_Removal_CMYK_HI
• • • •• • • • •• • • • •• • • • •• • • • • • • • • • •••••••••••••••••••••••••••••••
• •• ••••••••••••••• • •••••••••••••••••
• • • •• • • • •• • • • •• • • • •• • • • • • • • • • •••••••••••••••••••••••••••••••
• •• ••••••••••••••• • •••••••••••••••••
Dome side Rear side

12
Chronos is programmed with Oasis 14.0 and higher using Bernafon’s programming cables –
New Standard (no. 2).
Please always insert a fresh battery or battery pill adapter (ITCD only) prior to hearing aid programming.
Note: For the convenience of wireless hearing instrument programming, wireless compatible Chronos
devices are also compatible with the nEARcom tting system.
Fitting Chronos with Oasis
Attach the programming cables as follows:
Chronos Micro, CP, and CPx BTE
1 Open the battery drawer fully and slide the
programming adapter into the slot until it lines
up with the instrument.
2 Close the battery drawer again and plug in the
cable as shown.
Chronos Nano BTE
1 Remove the cover with the small tool as shown.
2 Plug the cable into the connector.
3 To replace the cover, hook the top end under the shell rst, then snap it in place.
VR_ILU_NanoBTEprogRemoveCover1_BW_HI
VR_ILU_NanoBTEprogConnectCable_BW_HI
VR_ILU_NanoBTEprogRemoveCover2_BW_HI
Bernafon Veras IFU micro BTE
VR_ILU_DaiFMAdapterOnMicroBTE_BW_MOD_HI
VR_ILU_MicroCompactBTEprogramAdapter_BW_HI

13
BERNAFON CHRONOS
Chronos custom models
1 For Chronos ITCD models, insert the battery pill with the red indicator pointing to the + sign and
close the battery drawer.
2 For Chronos ITED, ITCPD, ITCP, CIC and CICP models, use the FlexConnect strip. Insert a fresh
battery. Open the battery drawer slightly. With the black dot facing up, insert the end of the
FlexConnect into the space between the battery door and the hinge until the black dot touches
the faceplate. Close the drawer.
3 Place the instrument in the client’s ear and drape the strip over and behind the ear.
Open Oasis
The rst screen you will see is the product
overview screen. Select the instrument family
you prefer or press “Detect” if you already have
instruments connected for tting.
VR_ILU_ITCDinsertPill1_BW_HI
ITCD ITED, ITCPD, ITCP, CIC, CICP
Oasis Fitting Software
Activate the new Easyt option if you would like
to proceed quickly through the tting process.

14
On the left side of your screen you will see the
navigation bar, clearly showing Oasis functions
organized by category.
Connection Bar
The connection bar at the bottom of the screen
allows you to see at a glance if your instruments
are connected. If an instrument has a low battery
you will see a visual indication on the screen. The
Hi-Pro/NOAHlink bar in the center is in motion
when the software is saving data in the active
program.
Connection
Navigation bar

15
BERNAFON CHRONOS
Lifestyle Prole
The Lifestyle Prole helps to identify and prioritize
listening situations for your client. If completed,
it will determine the default settings for listening
programs and features in the tting phase.
Audiogram
The Client’s Noah audiogram will form the basis
for the Chronos frequency response. Alternatively,
in situ audiometry may be performed at this point
by clicking on “Create in situ audiogram”.
Your client’s real ear data may also be entered to
facilitate a more customized hearing aid tting.
Client
Personal Data
Review your client’s Personal Data and hearing
instrument Experience Level for accuracy.
You will also nd a choice of tting rationales.
We recommend our BernaFit NL-1 rationale for
Chronos ttings. For maximum initial comfort for
rst time hearing aid users, you may also choose
our BernaFit Comfort rationale.

16
Fitting
Acoustics
Oasis will recommend acoustics based on the
hearing loss. If you wish to modify the choices,
you may do so in the Acoustics screen. Be
sure that the ear piece selected in the software
matches that actually tted to Chronos.
Program assignment
In this screen you may add or change programs
as desired. If you have completed the Lifestyle
Prole, the programs chosen for the client will be
displayed.
Live Music Plus and the new Cinema program for
Chronos 9 models can be selected here.
Instrument view
This screen shows a summary of the instruments
you are tting, including serial number, acoustics
and accessories that have been paired to the
instruments.
Hearing Instrument

17
BERNAFON CHRONOS
Amplication Adjustment
Oasis offers three levels of ne-tuning, from simple (level 1) to advanced (level 3). Buttons across the
top of the screen allow you to quickly change the tuning level as desired. Additional buttons on the
bottom of the screen allow you to select the program that you would like to adjust.
Amplication
Advanced Soft Noise Management
The controls for this feature can be found on both the Level 2 and Level 3 amplication screens
as shown.
Additional Program Access
The arrow on the bottom right of the Amplication screen leads to additional programs, depending on
the hearing instrument model or optional accessories selected.
Here you may nd the following programs to adjust the:
· SoundGate Phone and Entertainment programs
· AutoTelephone program
· DAI/FM program

18
Feature Options
This screen allows you to optimize the features
specic to each program. The buttons at the
bottom of the screen allow you to easily switch
between the programs.
Transient Noise Reduction (CN9 and CN7)
A new feature to suppress short duration, high
intensity sounds: Off, Medium, High.
Directionality
Program Omnidirectional, Fixed or Adaptive
Directional microphone settings according to your
client’s needs.
True DirectionalityTM (CN9 BTE models)
Provides a directional microphone behavior similar
to the pinna for BTE wearers.
Adaptivity
The Adaptivity control affects how fast the auto-
matic features change. The default of this control
depends on the age of the client.
Features
Environment Optimizer (CN9 and CN7)
The Environment Optimizer allows you to select
a listening environment in the Multi-environment
program for special enhancement: Off, Quiet,
Speech in Quiet, Speech in Noise, Noise.
Adaptive Noise Reduction
Manages distracting environmental noises: Off,
Minimum, Medium or Maximum.
Wind Noise Monitor
Activate to provide relief from noise resulting from
windy environments.
Binaural Coordination
Select this feature to binaurally coordinate the fol-
lowing options: Volume control, program changes,
environment classication, and non-telephone ear
attenuation, depending on the style and model
chosen.

19
BERNAFON CHRONOS
Adaptive Feedback Canceller Plus
The Adaptive Feedback Canceller Plus in Chronos
automatically calculates the predicted feedback
limits (shown as a dashed purple line). For greater
accuracy, it is benecial to measure the actual
feedback limits for your client. Click on “Measure”
and follow the prompts. The feedback manager
settings can be adjusted to ensure feedback-free
listening for your client in all programs.
Feedback Manager
Logging and Learning
Data logging
The data logging in Chronos records operational
statistics including program usage, listening envi-
ronments, user adjustments and feedback moni-
toring. Click on the appropriate button to view the
logged data. Note that the instruments must be
worn a minimum of 8 hours before statistics are
available.
VC learning (CN9 and CN7)
Chronos has a learning feature that works to track
volume control changes and gradually modify the
volume level setting over time to match the level
preferred by the listener. Learning is available for
all microphone programs and can be enabled in
Oasis. Volume level changes are applied after
20 hours of learning in the same program.

20
End Session
Options
In this section you have access to all local con-
trols, indicators and external devices.
Controls
The Controls tab includes on-screen instructions
to help you pair Chronos instruments to either the
SoundGate or RC-P remote control. You will also
nd synchronization of controls, volume control
range and Smart VC (CN9) options here.
Tips for Successful Pairing:
1. Make sure the device has a fully charged battery (SoundGate) or a relatively fresh battery (RC-P).
2. Hold the device at least 50 cm (2 feet) away from the instruments.
3. When the screen instructions appear, wait 2 – 4 seconds before pushing the button each time.
4. Press “OK” to save.
Indicators
This screen allows you to congure the frequency
and level of all indicators. It is also possible to
demonstrate each indicator to the client.
Save and Quit
This screen shows a summary of the programs
and settings in the instrument as well as providing
a space for tting comments.
