Bernafon Pico RITE Series Assembly instructions

Pico RITE
Hearing System
BEHIND-THE-EAR
HEARING INSTRUMENTS
Fitting Guide

PICO RITE
3
Pico RITE Hearing Systems – Overview 5
Selection Chart for Acoustic Options 6
Fitting Ranges 7
Selecting the Speaker Unit Length 8
Attaching the Speaker Unit to a Pico RITE Hearing System 9
Detaching the Speaker Unit from a Pico RITE Hearing System 10
60- and 85-Speaker Units 11
Custom Molds for the 60- and 85-Speaker 12
Attaching the Lite Tip and the Micro Mold to the Speaker Unit 13
Detaching the Lite Tip and the Micro Mold from the Speaker 13
100-Speaker Unit for Power Fittings 14
Attaching the Wire to the Power Mold 15
Detaching the Wire from the Power Mold 15
Changing the Wax Filters 16
Fitting a Pico RITE with Oasis 17
Ordering Information 18
Table of Contents
Fitting Guide
Pico RITE Hearing Systems

4

PICO RITE
5
Pico RITE Hearing Systems – Overview
The Pico RITE receiver-in-the-ear hearing instrument is easy to handle and comfortable to wear. The
small RITE instrument, in combination with sophisticated technology, delivers tangible end-user
benets. This guide is designed to help you t and manage Pico RITE hearing systems.
Pico RITE hearing systems offer three speaker units:
·The 60-Speaker, which is appropriate for mild to moderate hearing losses
·The 85-Speaker, which is appropriate for moderate to moderately severe hearing losses
·The 100-Speaker, which provides additional power for severe hearing losses
Pico RITE with 60-Speaker
Pico RITE with 100-Speaker – Instant Fit Pico RITE with 100-Speaker – Custom Fit
Pico RITE with 85-Speaker
1JU_ILLU_PR_60_Speaker_No_Dome_front_BW
3JU_ILLU_PR_100_Speaker_No_Dome_front_BW
2JU_ILLU_PR_85_Speaker_No_Dome_front_BW
4JU_ILLU_PR_100_Speaker_Custom_With_Power_Mold_front_no_connect_BW

6
Selection Chart for Acoustic Options
The table below shows the acoustic options available for the three speaker units and the correspond-
ing wax protection system to be used.
Instant ProWax
miniFit
Open Domes
(6, 8, 10)
Bass Domes
Double Vent
(6, 8, 10, 12)
Bass Domes
Single Vent
(6, 8, 10, 12)
Power
Domes
(6, 8, 10, 12)
7JU_ILLU_PR_60_Speaker_BW
8JU_ILLU_PR_85_Speaker_BW
60-Speaker 85-Speaker
Custom Micro Mold Lite Tip ProWax
Instant ProWax
miniFit
Bass Domes
Double Vent
(6, 8, 10, 12)
Bass Domes
Single Vent
(6, 8, 10, 12)
Power Domes
(6, 8, 10, 12)
100 -Speaker
9JU_ILLU_PR_100_Speaker_BW
Custom Power Mold ProWax
6JU_ILLU_PR_100_Speaker_Custom_With_Power_Mold_no_connect_BW
100 -Speaker
5JU_ILLU_PR_100_Speaker_Custom_With_Power_Mold_front_BW

PICO RITE
7
Fitting Ranges
Expected tting ranges with each speaker unit are shown below.
85-Speaker
0
20
40
60
80
100
120
250 500 1.000 2.000 4.000 8.000
dB HL
Frequency (Hz)
100-Speaker
0
20
40
60
80
100
120
250 500 1.000 2.000 4.000 8.000
dB HL
Frequency (Hz)
60-Speaker
0
20
40
60
80
100
120
250 500 1.000 2.000 4.000 8.000
dB HL
Frequency (Hz)

8
Selecting the Speaker Unit Length
Four receiver lengths are available for all speakers. No. 1 is the shortest, while no. 4 is the longest.
Before tting Pico RITE hearing instruments, it is necessary to determine the correct speaker unit
length. The measurement procedure is the same for all speaker units.
CN_ILLU_NRMeasurementT ool_BW_HI
Place the measurement tool over the ear, keeping the top line
horizontal. With your eyes at the same level as the ear, determine
which mark is closest to an imaginary line running over the top of
the ear canal. In this example, the correct choice is size 2.
11 JU_ILLU_PR_WirePerfect_BW
Power Molds will have a better t if you choose a slightly longer
wire length than you would when tting a Power Dome. If the
top of the ear canal falls between two numbers on the gauge,
choose the higher number.
CN_ILLU_NR_Wearing instrument2_BW_HI_r
If the speaker unit wire is too long, the hearing instrument will
fall back over the ear and the microphones will point vertically
instead of horizontally. It is also unlikely that the receiver wire will
t the contours of the ear correctly.
10 JU_ILLU_PR_WireTooShort_BW
If the speaker unit wire is too short, it will have a tendency to
move out of the ear canal, and the hearing instrument will lose
stability on the ear.

PICO RITE
9
Attaching the Speaker Unit to a Pico RITE Hearing System
The correct speaker unit attachment is imperative. The following instructions apply to all types of
speaker units for Pico RITE hearing systems.
1 Slide the connector plug into the connector socket
of the instrument
2 Ensure that the snap on the connector plug is
completely inserted into the opening on the
hearing instrument housing
3 To test the attachment of the speaker unit to the
hearing instrument, gently pull the speaker wire
near the connection to the hearing instrument as
shown. If the speaker comes off, then it was not
attached properly.
Speaker units can easily sustain internal
damage if dropped. Before you attach the
speaker unit, please place a dome on the
speaker to protect it.
12 JU_ILLU_PR_AttachingSpeaker1_BW
13 JU_ILLU_PR_AttachingSpeaker2_BW
click
14 JU_ILLU_PR_AttachingSpeaker3_BW
2
3
1

10
Detaching the Speaker Unit from a Pico RITE
Hearing System
1 Hold the instrument rmly with one hand, and
with the other hand hold the multi tool. Place the
pointed end of the tool underneath the locking
snap and push it up until the connector plug is
free.
2 Gently pull the connector plug out of the socket.
If it does not come out easily, verify that the snap
is completely free.
Do not attempt to detach the speaker unit
by pulling on the wire. This could damage
both the speaker unit and the hearing
instrument.
15 JU_ILLU_PR_DetachingSpeaker1_BW
16 JU_ILLU_PR_DetachingSpeaker2_BW
1
2

PICO RITE
11
60- and 85-Speaker Units
The 60- and 85-Speaker units are suitable for mild to moderately severe losses and come in four
lengths. They can be used for instant and custom ttings.
To obtain a more secure hold in the ear canal, an ear grip should be used. There are two different
types of ear grips: one for the 60-Speaker and one for the 85-Speaker. Ensure that you apply the
proper ear grip with the corresponding speaker.
If the ear grip seems too long, it may be trimmed to the desired length. Be careful not to leave a
sharp end when cutting since this could cause irritation on the skin.
Attaching the Ear Grip to the 60-Speaker
1 Bring the tip of the speaker close to the ear grip opening
2 Push the speaker through the opening
3 The left/right marking on the speaker unit must be completely uncovered
1 2 3
Attaching the Ear Grip to the 85-Speaker
1 Bring the tip of the speaker close to the ear grip opening
2 Push the speaker through the opening as far as possible
21

12
Custom Molds for the 60- and 85-Speaker
For custom ttings, two different types of molds can be attached to the 60- and 85-Speaker, the
Micro Mold and the Lite Tip. Both come with an adapter already inserted, colored red (right) or blue
(left) to indicate which ear. The color dot on the top of the custom mold indicates the front and top
position in the ear canal.
1 Front-top indicator
2 Speaker adapter
3 ProWax lter
4 Pull-out string
5 60-Speaker
6 Left/Right indicator
7 ProWax miniFit lter
8 85-Speaker
Tools for Custom Molds
There are two separate tools that can be used to attach and detach the 60- and
85-Speaker. A marking on the tool indicates for which speaker type it is intended.
A custom mold built for one type of
speaker unit, cannot be attached to
another one.
Micro Mold
7JU_ILLU_PR_60_Speaker_BW
5
6
7
8JU_ILLU_PR_85_Speaker_BW
7
6
8
Lite Tip
LT_ILLU_LiteTipNoWaxFilter_CMYK_HI
14 2
3
LT_ILLU_LiteTipNoWaxFilter_CMYK_HI
1 2 34
LT_ILLU_LiteTipNoWaxFilter_CMYK_HI
LT_ILLU_LiteTipNoWaxFilter_CMYK_HI

PICO RITE
13
Attaching the Lite Tip and the Micro Mold to the Speaker Unit
1 Use the tool which is appropriate for the speaker. Place the receiver into the cup pin of the tool and
push the wire into the groove to obtain a stable attachment. The curve of the speaker and the tool
should face the same direction. Make sure that the ProWax miniFit is on the receiver (refer to
page 16).
2 Before inserting the receiver into the mold, turn the receiver so that the wire and “up” marking
on the mold are properly aligned. Carefully center the receiver in the middle of the adapter before
pushing it in. Insert the receiver into the Custom Mold. Place the mold against the table and push
the receiver rmly in place. Gently pull the wire to make sure that the speaker is inserted properly.
Cover the sound outlet with a ProWax lter.
3 Make sure that the mold sits correctly in the patient’s ear and check the position of the wire.
If necessary, the wire is bendable by heating.
Detaching the Lite Tip and the Micro Mold from the Speaker
1 Remove the ProWax from the Custom Mold (refer to page 16)
2 Press the pointed end of the tool into the mold to release the speaker unit while rmly holding the
mold
3 Push the tool into the mold. The mold will disengage with a click.
17 JU_ILLU_PR_AttachingLiteTip1_BW
1
18 JU_ILLU_PR_AttachingLiteTip2_BW
2
19 JU_ILLU_PR_AttachingLiteTip3_BW
2
1 2
click
3

14
00-Speaker Unit for Power Fittings
The 100-Speaker unit is intended for severe hearing losses. This speaker comes in two versions: one
version is for instant ttings and one version is for custom ttings.
100-Speaker for Instant Fittings with Domes
Refer to page 6 to see which types of domes can be used to t the 100-Speaker unit.
100-Speaker for Custom Fittings
1 100-Speaker unit
2 Sound outlet with ProWax miniFit
The 100-Speaker for custom ttings comes pre-attached in a custom Power Mold that ts the ear
canal. The wire is attached separately to the mold in the appropriate length. To choose the
appropriate speaker wire length, refer to page 8. The wire can be replaced via a connector system on
the Power Mold faceplate.
A specic tool should be used to attach and detach the wire from the Power Mold.
9JU_ILLU_PR_100_Speaker_BW
1
2
6JU_ILLU_PR_100_Speaker_Custom_With_Power_Mold_no_connect_BW

PICO RITE
15
Detaching the Wire from the Power Mold
1 Remove the cover by very gently sliding the special screwdriver-like blade of the tool between the
wire and the faceplate and then apply a slight upwards pressure
2 Insert the other end of the tool into the notch which is on the connector, making sure that the tool
is attached rmly
3 Gently rotate the tool in the direction of the arrow until the wire comes apart from the connector
Attaching the Wire to the Power Mold
1 Plug the wire into the Power Mold connector
2 Slightly press with the thumb, to stabilize the connection
3 Put the cover on
4 Press with the thumb until it clicks
5 Connect the complete assembly to the hearing instrument
Click!
CAUTION
132 dB SPL output
12 JU_ILLU_PR_AttachingSpeaker1_BW
Click!
1
4
2
5
3
1
3
2

16
Changing the Wax Filters
Wax Protection
The Pico RITE hearing instrument offers two types of wax lters, the ProWax and the ProWax
miniFit.
For an overview on the use of these lters, refer to page 6.
The wax lters should be changed as needed, to ensure efcient wax protection, and to prolong the
life of the speaker unit. Visually inspect the lters. If they are clogged or there is no sound coming
from the device, replace them.
1 Remove a tool from the turtle
2 Insert its empty end into the old lter and pull it out
3 Push a new lter into the sound outlet
4 Discard the used tool. It cannot be reused.
ProWax ProWax miniFit
1
3
2
4
1
3
2
4

PICO RITE
17
Fitting a Pico RITE with Oasis
Pico RITE hearing systems are programmed with Oasis 20.0 or higher software, standard (no. 2)
programming cables and the FlexConnect strip.
1 Always insert a fresh battery prior to programming. Open the battery drawer slightly. With the
black dot facing up, insert the end of the FlexConnect into the space between the battery door and
the hinge until the black dot touches the housing. Close the drawer.
2 Place the instrument in the client’s ear
3 Plug the programming cable into the FlexConnect strip
For your convenience, the wireless Pico RITE hearing instrument is compatible with the nEARcom
wireless programming system.
Do not use FlexConnect Mini
Not ok
FC_MINI_ILLU_Overview_BW
1
Ok
Use FlexConnect
20 JU_ILLU_PR_AttachingFlexConnect1_BW
1
21 JU_ILLU_PR_AttachingFlexConnect2_BW
2
3

18
Ordering Information
60-Speaker Units
85-Speaker Units
00-Speaker Units
Part Number Description Comments
149271 Speaker Unit, 1R 60
For instant and custom ttings
7JU_ILLU_PR_60_Speaker_BW
149272 Speaker Unit, 1L 60
149273 Speaker Unit, 2R 60
149274 Speaker Unit, 2L 60
149275 Speaker Unit, 3R 60
149276 Speaker Unit, 3L 60
149277 Speaker Unit, 4R 60
149278 Speaker Unit, 4L 60
Part Number Description Comments
149279 Speaker Unit, 1L 85
For instant and custom ttings
8JU_ILLU_PR_85_Speaker_BW
149280 Speaker Unit, 1R 85
149281 Speaker Unit, 2L 85
149282 Speaker Unit, 2R 85
149283 Speaker Unit, 3L 85
149284 Speaker Unit, 3R 85
149285 Speaker Unit, 4L 85
149286 Speaker Unit, 4R 85
Part Number Description Comments
149287 Speaker Unit, 1L 100
For instant ttings
9JU_ILLU_PR_100_Speaker_BW
149288 Speaker Unit, 1R 100
149289 Speaker Unit, 2L 100
149290 Speaker Unit, 2R 100
149291 Speaker Unit, 3L 100
149292 Speaker Unit, 3R 100
149293 Speaker Unit, 4L 100
149294 Speaker Unit, 4R 100

PICO RITE
19
00-Speaker Wires
Wax Filters
Part Number Description Comments
149302 Wire for speaker, 1L
For custom ttings
6JU_ILLU_PR_100_Speaker_Custom_With_Power_Mold_no_connect_BW
149301 Wire for speaker, 1R
149300 Wire for speaker, 2L
149299 Wire for speaker, 2R
149298 Wire for speaker, 3L
149297 Wire for speaker, 3R
149296 Wire for speaker, 4L
149295 Wire for speaker, 4R
Part Number Description Comments
130091 ProWax miniFit lter. Turtle with
6 lters each. Hydrophobic coating.
To be attached onto the
·60 -Speaker
·85-Speaker
·100-Speaker
123459 ProWax lter. Turtle with 6 lters
each. Hydrophobic coating.
To be attached onto custom
earmolds
Domes
Part Number Description Comments
149303 Open Dome miniFit 6 mm
Open Domes
Clamshell including 10 domes
149304 Open Dome miniFit 8 mm
149305 Open Dome miniFit 10 mm
149306 Bass Dome Double miniFit 6 mm
Bass Domes with double vent
Clamshell including 10 domes
149307 Bass Dome Double miniFit 8 mm
149308 Bass Dome Double miniFit 10 mm
149309 Bass Dome Double miniFit 12 mm
149310 Bass Dome Single miniFit 6 mm
Bass Domes with single vent
Clamshell including 10 domes
14 9 311 Bass Dome Single miniFit 8 mm
149312 Bass Dome Single miniFit 10 mm
149313 Bass Dome Single miniFit 12 mm
149314 Power Dome miniFit 6 mm
Power Domes
Clamshell including 10 domes
149315 Power Dome miniFit 8 mm
149316 Power Dome miniFit 10 mm
149317 Power Dome miniFit 12 mm

20
Tools
Speaker Kits
Part Number Description Comments
127816 Tool, Lite Tip/Micro Mold
60-Speaker To attach and detach the
60-Speaker to a custom mold
126977 Tool, Lite Tip/Micro Mold
85-Speaker To attach and detach the
85-Speaker to a custom mold
143070 Tool, for plug To unplug the wire from the
100-Speaker Power Mold
890-60-232-00 Multi-tool Tool with vent cleaner, screwdriver,
magnet for battery change
890-60-320-00 Multi-tool, extension To detach the speaker from the
Pico RITE hearing instrument.
To be used with the Multi-tool.
890-21-291-00 Measurement tool for speaker wire
lengths
5
4
3
2
1
127908 Set of 3 covers, Transparent
For 100-Speaker Power Mold
127909 Set of 3 covers, Beige
127910 Set of 3 covers, Light Brown
12 7 911 Set of 3 covers, Medium Brown
127912 Set of 3 covers, Dark Brown
127913 Set of 3 covers, Black
149876 Ear Grip, 60-Speaker (5 pcs) miniFit
Plastic bags with 5 pieces
149877 Ear Grip, 85-Speaker (5 pcs) miniFit
Part Number Description Comments
149445 Fitting Kit, miniFit speakers
Bernafon
Fitting Kit for miniFit speakers
contains:
·60-Speakers (lengths 2 and 3)
·85-Speakers (lengths 2 and 3)
·Open domes
·Bass domes
·Tools
