WPP1 SERIES
HB0395
INSTALLATION INSTRUCTIONS
INTENDED FOR DOMESTIC COOKING ONLY
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGE 13.
READ AND SAVE THESE INSTRUCTIONS
1110540 rev. A
V
Q
0009 !
V
Q
0009 !
BEST, 926 West State Street, Hartford, Wisconsin, USA 53027 BestRangeHoods.com 800-558-1711
BEST, 550 Lemire Blvd., Drummondville, Québec, Canada J2C 7W9 BestRangeHoods.ca 800-567-3855
To register your product online or for additional information visit BestRangeHoods.com (in USA) or
BestRangeHoods.ca (in Canada)

2
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer. If you
have questions, contact the manufacturer at the address or telephone
number listed in the warranty.
2. Before servicing or cleaning unit, switch power off at service panel
and lock service disconnecting means to prevent power from being
switched on accidentally. When the service disconnecting means
cannot be locked, securely fasten a prominent warning device, such
as a tag, to the service panel.
3. Installation work and electrical wiring must be done by qualified
personnel in accordance with all applicable codes and standards,
including fire-rated construction codes and standards.
4. Sufficient air is needed for proper combustion and exhausting of
gases through the flue (chimney) of fuel burning equipment to prevent
backdrafting. Follow the heating equipment manufacturer’s guidelines
and safety standards such as those published by the National Fire
Protection Association (NFPA) and the American Society for Heating,
Refrigeration and Air Conditioning Engineers (ASHRAE) and the local
code authorities.
5. When cutting or drilling into wall or ceiling, do not damage electrical
wiring and other hidden utilities.
6. Ducted fans must always be vented to the outdoors.
7. Do not use this unit with any separate solid-state speed control device.
8. To reduce the risk of fire, use only metal ductwork.
9. This unit must be grounded.
10. When installing, servicing or cleaning the unit, it is recommended to
wear safety glasses and gloves.
11. When applicable local regulations comprise more restrictive installation
and/or certification requirements, the aforementioned requirements
prevail on those of this document and the installer agrees to conform
to these at his own expenses.
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
a) Never leave surface units unattended at high settings. Boilovers cause
smoking and greasy spillovers that may ignite. Heat oils slowly on low
or medium settings.
b) Always turn hood ON when cooking at high heat or when flambeing
food (i.e.: Crêpes Suzette, Cherries Jubilee, Peppercorn Beef Flambé).
c) Clean ventilating fans frequently. Grease should not be allowed to
accumulate on fan or filters.
d) Use proper pan size. Always use cookware appropriate for the size of
the surface element.
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE
EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE
FOLLOWING*:
1. SMOTHER FLAMES with a close-fitting lid, cookie sheet or metal tray,
then turn off the burner. BE CAREFUL TO PREVENT BURNS. IF THE
FLAMES DO NOT GO OUT IMMEDIATELY, EVACUATE AND CALL
THE FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN — You may be burned.
3. DO NOT USE WATER, including wet dishcloths or towels — violent
steam explosion will result.
4. Use an extinguisher ONLY if:
A. You know you have a Class ABC extinguisher and you already
know how to operate it.
B. The fire is small and contained in the area where it started.
C. The fire department is being called.
D. You can fight the fire with your back to an exit.
* Based on "Kitchen Fire Safety Tips" published by NFPA.
1. For indoor use only.
2. For general ventilating use only. Do not use to exhaust hazardous or
explosive materials and vapors.
3. To avoid motor bearing damage and noisy and/or unbalanced
impellers, keep drywall spray, construction dust, etc. off power unit.
4. Your hood motor has a thermal overload which will automatically shut
off the motor if it overheats. The motor will restart when it cools down.
If the motor continues to shut off and restart, have the hood serviced.
5. The minimum hood distance above cooktop must not be less than 24".
A maximum of 30" above cooktop is recommended for best capture of
cooking impurities.
6. Two installers are recommended because of the large size and weight
of this unit.
7. To reduce the risk of fire and to properly exhaust air on a ducted
installation, be sure to duct air outside — Do not exhaust air into
spaces within walls or ceiling or into attics, crawl spaces or garage.
8. Because of the high exhausting capacity of this hood, make sure
enough air is entering the house. Open a window close to or in the
kitchen.
9. To reduce the risk of fire and electrical shock, the Best WPP1 series
models should only be installed with their own built-in blowers.
10. As an alternative, this product may be installed with the UL-approved
range hood cord kit HCK44, following instructions packed with the
cord kit.
11. Please read specification label on product for further information and
requirements.
WARNING
V
Q
0009 !
CAUTION

3
Table of content
1. prepare the installation ....................................................................................................................................................................3
2. select installation type ....................................................................................................................................................................4
3. hood specifications...........................................................................................................................................................................4
4. install hood mounting bracket..........................................................................................................................................................5
5. install upper flue mounting bracket .................................................................................................................................................6
6. remove hi-flow baffle filters............................................................................................................................................................6
7. install the hood ................................................................................................................................................................................7
8. connect wiring .................................................................................................................................................................................8
9. install 8" adapter/damper .................................................................................................................................................................9
10. install 10" adapter/damper..............................................................................................................................................................9
11. duct connection..............................................................................................................................................................................10
12. prepare decorative flue.................................................................................................................................................................. 10
13. install decorative flue....................................................................................................................................................................10
14. reinstall hi-flow baffle filters .......................................................................................................................................................12
15. crt option activation instructions for wpp1366ss only .............................................................................................................12
16. calibrate iQ blower system™ .........................................................................................................................................................13
17. use and care ...................................................................................................................................................................................13
18. operation .......................................................................................................................................................................................14
19. service parts ..................................................................................................................................................................................15
20. warranty ....................................................................................................................................................................................... 16
1. PREPARE THE INSTALLATION
Make sure the following items are included:
- Hood
- Decorative flue
- Upper flue mounting bracket (taped inside the hood)
- Hood mounting bracket (taped inside the hood)
- WPP1366SS: 8" round adapter and damper
- WPP13612SS and WPP14812SS: 10" round adapter and damper
- Installation manual
- Necessary hardware included in parts bag (parts left over are spare parts):
Parts sold separately:
- AEWPP1SBN: Decorative flue for ceilings up to 12' high
- HCK44: Cord kit
1 x wire clamp 5 x wall anchors 10 x no. 8 x 1-1/2"
screws
3 x wire connectors 4 x washers 6 x no. 8 x 3/8"
screws

4
2. SELECT INSTALLATION TYPE
WARNING
VQ0010 !
!
When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves.
Plan where and how the ductwork will be installed. A straight, short duct run will allow the hood to perform most efficiently. Refer to
illustration below.
Install 8-inch or 10-inch ductwork, elbows (if needed) and roof or wall cap. Connect metal ductwork to the cap and work back towards the
hood location. Use 2" metal foil duct tape to seal the joints.
The minimum hood distance above cooktop must not be less than 24". A maximum of 30" above cooktop is recommended for
best capture of cooking impurities.
HH0323
roof cap
8" (600 cfm) or
10" (1200 cfm)
round duct/elbow
wall cap
hood
24"to 30"above cooking surface
3. HOOD SPECIFICATIONS
24"
35-7/8"(36")
47-7/8"(48")
14-3/8"
C
L
5-1/8"(WPP1366SS)
(WPP13612SS)
(WPP14812SS)
5-7/16"
HK0377
10-13/16 12-15/16
35-7/8, 47-7/8
24
14-3/8
min 30-1/2 - max 43-1/8
min 31-7/8 - max 43-5/8

5
A
B
HD1530
4. INSTALL HOOD MOUNTING BRACKET
If necessary, construct a wall framing using minimum 2" x 4" lumber. Proper
structural support is required to accomodate the weight of the hood.
After the wall surface is finished, measure and mark the center of the
holes on the bracket; draw the vertical center line up to the ceiling.
Carefully center and level the hood mounting bracket over the installation
location. Secure it to the wall framing using 3 no. 8 x 1½" screws.
WARNING
VQ0010 !
!
When cutting or drilling into wall, do not damage electrical wiring
and other hidden utilities.
Ensure that the wall is solid enough to withstand the weight of the
hood.
A B
Hood distance above
cooktop (in)
Mounting bracket holes distance
above cooktop (in)
24 38-7/8
25 3 9 - 7/ 8
26 40-7/8
27 4 1 - 7/ 8
28 42-7/8
29 43-7/8
30 44-7/8
cooking surface
Standard flue
C A
Ceiling height Hood distance above
cooktop (in)
7 ft 7 in to 8 ft 7 in 24 to 30
8 ft 8 in 25 to 30
8 ft 9 in 26 to 30
8 ft 10 in 27 to 30
8 ft 11 in 28 to 30
9 ft 29 to 30
9 ft 1 in 30
*Lower part of
optional flue
AEWPP1SBN
+
Upper part of
standard flue
9 ft 2 in to 9 ft 6 in 24 to 30
Optional flue
AEWPP1SBN
9 ft 7 in to 11 ft 8 in 24 to 30
11 ft 9 in 25 to 30
11 ft 10 in 26 to 30
11 ft 11 in 27 to 30
12 ft 28 to 30
12 ft 1 in 29 to 30
12 ft 2 in 30
HD1541
C
A
36 in

6
5. INSTALL UPPER FLUE MOUNTING BRACKET
NOTE: The upper flue mounting bracket is taped inside the
hood, but the mounting bracket screws are in the parts
bag of the hood.
Center the upper flue mounting bracket with the center line drawn in
the previous step and place it flush with the ceiling.
Use the upper flue mounting bracket as a template to mark the
position of the screws.
Secure the upper flue bracket to the wall using 3 no. 8 x 1½" screws
and wall anchors if needed.
Ensure that the bracket is tight against the wall.
C
L
HD1531
3 X
ceiling
3/16" *
* for drywall anchor
only
6. REMOVE HI-FLOW BAFFLE FILTERS
Rest the range hood on a protected surface and remove the tape from the filters. Remove the filters from the range hood by pushing them
towards the nose of the hood and rotate downwards. Remove the parts bag and the hood mounting bracket from inside the hood and set
these parts aside.
HD1532
CAUTION
Keep tapes (2) holding the grease rail in place until hood is installed on the wall.
HD1543
grease rail

7
7. INSTALL THE HOOD
1. Align the hood and center it above the hood mounting bracket. Gently lower the hood until it securely engages the bracket.
2. Level the hood.
3. While the hood is hanging in place, secure it to the wall through both holes located in the upper back of hood using 2 no. 8 x 1½"
screws and washers.
CAUTION
DO NOT REMOVE the protective plastic film covering the decorative flue.
HD1534
2 X
WARNING
VQ0010 !
!
BE CAREFUL when installing the decorative flue and hood, they may have sharp edges.
HD1533
4. Using at least 1 hole on each side of the lower back of the hood, secure the hood into solid material (wall studs) using
2 no. 8 x 1½" screws and washers. If required, pre-drill holes using a 3/16" drill bit then insert wall anchors before securing the
screws.

8
8. CONNECT WIRING
WARNING
VQ0010 !
!
Risk of electric shock. Electrical wiring must be done by qualified personnel in accordance with all applicable codes and stan-
dards. Before connecting wires, switch power off at service panel and lock service disconnecting means to prevent power from
being switched on accidentally.
HD1527
HD1528
1. Remove strain relief plate.
2. Install strain relief.
3. Insert the house wiring cable through the wire clamp and tighten the wire clamp screws to secure the cable.
4. Reinstall strain relief plate.
HD1535
5. From inside the hood, remove electrical cover.
HD1536
HD1538

9
9. INSTALL 8" ADAPTER/DAMPER
HD1529
Using 4 no. 8 x 3/8” screws from parts bag, assemble the adapter/damper on the top of the hood.To ensure proper opening of the dampers,
remove shipping tape if present. Seal all joints with metal foil duct tape to eliminate air leaks.
6. Connect the power cable to the range hood wires using provided wire connectors. Connect BLACK to BLACK, WHITE to WHITE and
GREEN or bare wire under GREEN ground screw located inside the hood. DO NOT FORGET TO CONNECT THE GROUND.
7. Reinstall electrical cover removed at step 5.
8. CONNECT WIRING (continued)
HE0497
CAUTION
Make sure not to pinch any wire when reinstalling the electrical cover.
10. INSTALL 10" ADAPTER/DAMPER
HD1539
HD1540
B Using 2 no. 8 x 3/8” screws from parts bag,
assemble the adapter on the top of the hood.
Seal all joints with metal foil duct tape to
eliminate air leaks.
C Install 10" in-line damper inside the vertical
ductwork that will be attached to the hood. Do
not install in a horizontal ductwork or it will not
open and close properly. Remove shipping tape
if present. Secure the damper to the duct with 3
no. 8 sheet metal screws (not provided). Ensure
damper opens and closes freely. Seal all joints
with metal foil duct tape to eliminate air leaks.
B C
10" min.
recommended

10
Slide a 8’’ or 10” metal round duct over the adapter ring on top of the hood. Use metal foil
duct tape to seal the joint.
HJ0266
11. DUCT CONNECTION
12. PREPARE DECORATIVE FLUE
HO0431
Remove protective film on the lower part. Begin removing protective film on the upper part.
13. INSTALL DECORATIVE FLUE
HO0430
10" shown

11
HO0417
HO0417
HO0423
13. INSTALL DECORATIVE FLUE (continued)

12
14. REINSTALL HI-FLOW BAFFLE FILTERS
CAUTION
Remove protective plastic film covering hybrid baffle filters before installing them.
BInsert the end of the hybrid baffle filter in the front channel of
the hood.
C Raise the other end toward the inside and insert it in the back
channel of the hood.
HD1537
B C
15. CRT OPTION ACTIVATION INSTRUCTIONS FOR WPP1366SS ONLY
IMPORTANT NOTE: The CRT (Code Ready Technology™) option allows changing the blower output from the factory setting (600 CFM) to
a maximum of 400 CFM or 300 CFM. The CRT option activation will reduce the hood airflow thus performing within the minimal allowable
limit of Make-Up Air (MUA) codes to meet some building code requirements. Do not attempt to change the factory blower CFM setting
unless this change is required. This change will alter the performance of your product.
How to activate the CRT option:
1. Locate the dip switches on the electronic board.
ON
1234
300 CFM
SETTING
ON
1234
400 CFM
SETTING
HR0214A
3. Locate the label, next to the blower specifications label, then mark the corresponding box.
WARNING
VQ0010 !
!
Risk of electrical shock. This procedure must be done by qualified personnel in accordance with all applicable
codes and standards. Before proceeding, switch power off at service panel and lock service disconnecting means
to prevent power from being switched on accidentally.
2. Using a precision screwdriver, set the dip
switches as per one of the illustrations
hereafter.
HR0215
CAUTION
Remove tapes (2) holding the grease rail in place.

13
Hi-Flow Baffle Filters
The hybrid baffle filters should be cleaned frequently. Use a warm detergent solution. Wash more often if your cooking style generates
greater grease — like frying foods or wok cooking.
Remove hybrid baffle filters by pushing them towards the front of hood and rotating filters downward. Baffle filters are dishwasher safe.
Allow filters to dry completely before reinstalling them in the hood.
Clean all-metal filters in the dishwasher using a non-phosphate detergent. Discoloration of the filter may occur if using phosphate detergent
or as a result of local water conditions — but this will not affect filter performance. This discoloration is not covered by the warranty.
Hood Cleaning
Stainless steel cleaning:
Avoid when choosing a detergent:
- Any cleaners that contain bleach will attack stainless steel.
- Any products containing: chloride, fluoride, iodide, bromide will deteriorate surfaces rapidly.
- Any combustible products used for cleaning such as acetone, alcohol, ether, benzol, etc., are highly explosive and should never be
used close to a range.
Do:
• Regularly wash with clean cloth or rag soaked with warm water
and mild soap or liquid dish detergent.
• Always clean in the direction of original polish lines.
• Always rinse well with clear water (2 or 3 times) after cleaning.
Wipe dry completely.
• You may also use a specialized household stainless steel
cleaner.
Don’t:
• Use any steel or stainless steel wool or any other scrapers to
remove stubborn dirt.
• Use any harsh or abrasive cleansers.
• Allow dirt to accumulate.
• Let plaster dust or any other construction residues reach the
hood. During construction/renovation, cover the hood to make
sure no dust sticks to stainless steel surface.
16. CALIBRATE IQ BLOWER SYSTEM™
After the hood is installed and wired, engage the calibration process (our Guaranteed
Performance System Technology to ensure full-rated airflow is being delivered). Prior to
calibration, ensure that all filters, light bulbs and duct system are installed.
Calibration ProCess
Hold the calibration button for 3 seconds; calibration button will light up and stay on
for up to 13 minutes. The blower will start and begin the calibration process. When
calibration is complete, one of two things will occur:
A. The blower turns off and calibration button light stays on = Successful calibration.
Press the button to turn off the LED. NOTE: The LED will also turn off if you select any
blower speed on the control.
B. The blower turns off and calibration button light blinks continuously = Too much
restriction in the ductwork is preventing the IQ Blower System™ from achieving the
rated airflow. The blower is automatically set to maximum intensity.
NOTE: Common items that cause restrictions: restricted damper flap (backdraft
damper, wall cap, roof cap), too many elbows, duct size less than 80% of hood
outlet, poor transition, use of flex ducting and/or crushed ducting.
Three options are available if your hood system has too much restriction:
1. Accept airflow as is. Press the calibration button to accept airflow as is.The IQ Blower System™ is now configured to its highest possible
performance. The blinking calibration light goes out. NOTE: The LED will also turn off if you select any blower speed on the control.
2. Correct duct restriction, clear the original calibration data, and repeat the calibration process.
a. Correct the duct restriction.
b. Clear the original calibration data by holding calibration button for 10 seconds. The light will blink 3 times to confirm and the blower
configuration will go back to default settings.
c. Repeat calibration process from the beginning.
3. Clear calibration data to reset hood to default factory settings and achieve standard high pressure blower performance by holding
calibration button for 10 seconds. The light will blink 3 times to confirm and the blower configuration will go back to default settings.
HC0113
Calibration
button
17. USE AND CARE
Grease Rail Cleaning
The grease drip rail should be cleaned frequently. Remove it from the hood (see hereafter) and use
a warm detergent solution. As with the baffle filters, wash more often if your cooking style generates
greater grease — like frying foods or wok cooking. Allow grease drip rail to dry completely before
reinstalling it in the hood.
HD1544
Foam Cleaning
Hood is equipped with sound absorbing foam. Gently clean foam surface using a soft cloth.
grease rail
sound absorbing foam

14
18. OPERATION
Always turn your blower on before you begin cooking to establish an airflow in the kitchen. Let the blower run for a few minutes to clear
the air after you turn off the range.
HC0016
sPeed 1 2 3 4 lighting intensity 1 2 3
BA C D E
a. blower delay-off button:
When blower is on, press the delay-off button to activate the delay-off function. The corresponding speed indicator LED will start flashing to
indicate this function is activated.The fan will continue to operate for 10 minutes and will stop automatically.To cancel the delay-off function,
press the blower delay-off button once again; the blower will then work in normal mode.
NOTE: The blower speed can be increased—or decreased—during delay-off mode without starting another 10-minute cycle.
b. on blower/sPeed Control button:
Press this button to turn on the blower at the last selected speed. To change the blower speed, press the button again until the desired
speed is obtained. Press and hold this button for 2 seconds to decrease the speed level down by one increment. Possible decreases are
then: 4 to 3; 3 to 2; 2 to 1 and 1 to OFF.
NOTES: 1. Each time you press the speed control button, the speed changes by increments of 1 (e.g.: speed 1 to speed 2, to speed 3,
and then speed 4). From the fourth speed, the speed goes down to level 1.
2. The last speed used is kept in memory so that when the unit is turned on, it will return to the last setting except the fourth, the
next time the blower will be turned on, it will return to speed 3.
HEAT SENTRY™
The hood is equipped with a protective device that activates when excessive heat is detected inside the hood. This device takes control of
the blower and deactivates speed 4for a 10-minute period and sets it on speed 3. During the Heat Sentry activation, only speed 3can be
used; the speed 4button will flash while the speed 3button will light up.
C. off blower/filter maintenanCe button:
Press this button to turn off the blower. Pressing this button also cancels the delay-off function (if activated).
NOTE: After 25 hours of operation, the 4 blower speed lights will flash 30 seconds to indicate the filters need to be cleaned in order to
maintain efficient hood operation. Pressing the OFF button will reset the code to indicate that maintenance has been completed.
d. off lighting:
Press this button to turn lights off.
e. on light button:
Press this button to turn on the LED lamps. The light intensity changes by increments of 1 (e.g.: Press once for low setting, once again for
medium, again for high). From the higher setting, press once to go back to the lower setting.
NOTE: The last light setting used is kept in memory. The next time the LED lamps are turned on, the last setting will be used.
WARNING
VQ0010 !
!
The HEAT SENTRY can start the blower during a range top fire or other excessive heat situations even if the hood is turned
off. In this case, it is impossible to turn the blower OFF with blower button. If you must stop the blower, do it from the main
electrical panel.
A) Blower delay-off button
B) ON blower/Speed control button
C) OFF blower/
Filter maintenance button
D) OFF lighting
E) ON light button (3 settings)

15
19. SERVICE PARTS
rePlaCement Parts and rePairs
In order to ensure your unit remains in
good working condition, you must use
BEST genuine replacement parts only.
BEST genuine replacement parts are
specially designed for each unit and
are manufactured to comply with all
the applicable certification standards
and maintain a high standard of safety.
Any third party replacement part
used may cause serious damage and
drastically reduce the performance
level of your unit, which will result in
premature failing. BEST recommends
to contact a certified service depot for
all replacement parts and repairs.
Key
no.Part no. desCriPtion Qty. (hood model)
wPP1366ss wPP13612ss wPP14812ss
1S1111342 upper and lower flue 1 1 1
2SV08543 8"adapter/damper 1
3SV08542 10"damper 1 1
4SV08541 10"adapter 1 1
5S1111830 grease rail 36" 1 1
S1111831 grease rail 48" 1
6S1110640 hybrid baffle filter (8.84"x15")1 1 5
7S1110641 hybrid baffle filter (11.84"x15")2 2
8S1110531 led bulb gu10 base 2 2 4
9SV09434 stainless steel light trim 2 2 2
10 SV05917 socket gu10 2 2 2
11 SV09435 socket holder gu10 2 2 2
12 SV20814 blower electronic control 1 1 1
13 SV09022 transformer 120 vac 9 volt dc 1 1 1
14 SV21416 single motor electronic drive 1
SV20818 dual motor electronic drive 1 1
15 S97018985 blower 600 cfm 1 2 2
16 S1111298 calibration button 1 1 1
*S1111897 overcurrent protection harness 1 1 1
*SV21418 high voltage single blower harness 1
*SV20824 high voltage dual blower harness 1 1
*S1111341 parts bag and brackets 1 1 1
* not shown.
HL0499
B
C
D
E
F
G
H
I
J
K
L
M
N
O
PQ

16
20. WARRANTY
FIVE-YEAR LIMITED WARRANTY FOR BEST®PRODUCTS
Warranty Period and Exclusions: Broan-NuTone, LLC (the “Company”) warrants to the consumer purchaser of its product (“you”) that the product (the
“Product”) will be free from material defects in the materials or its workmanship for a period of five (5) years from the date of original purchase (or such
longer period as may be required by applicable law) or a period of two (2) years from the date of service for any labor provided on the Product.
The limited warranty period for any replacement parts provided by the Company and for any Products repaired or replaced under this limited warranty shall
be the remainder of the original warranty period (or such longer period as may be required by applicable law).
THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS, TUBES AND BULBS, FUSES, FILTERS, DUCTS, ROOF CAPS, WALL CAPS
AND OTHER ACCESSORIES FOR DUCTING. This warranty does not cover (a) normal maintenance and service, (b) normal wear and tear, (c) any Products or
parts which have been subject to misuse, abuse, abnormal usage, negligence, accident, improper or insufficient maintenance, storage or repair (other than
repair by the Company), (d) damage caused by faulty installation, or installation or use contrary to recommendations or instructions, (f) damage caused by
exposure to salt air, (g) damage in transit, (h) natural wear of finish, (i) Products in commercial or nonresidential use, (j) damage caused by fire, flood or
other act of God, or (k) Products with altered, defaced or removed serial numbers. This warranty covers only Products sold to consumers in North America.
This warranty supersedes all prior warranties and, subject to applicable law, is not transferable from the original consumer purchaser.
No Other Warranties: This Limited Warranty contains the Company’s sole obligation and your sole remedy for defective Products. The foregoing warranties
are exclusive and in lieu of any other warranties and conditions, express or implied. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE
COMPANY DISCLAIMS AND EXCLUDES ALL OTHER EXPRESS WARRANTIES AND CONDITIONS, AND DISCLAIMS AND EXCLUDES ALL WARRANTIES
AND CONDITIONS IMPLIED BY LAW, INCLUDING WITHOUT LIMITATION THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
To the extent that applicable law prohibits the exclusion of implied warranties or conditions, the duration of any applicable implied warranty or condition
is limited to the period specified for the express warranty above. Some jurisdictions (which may include the Province of Quebec or specific US states) do
not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Any oral or written description of the Product is
for the sole purpose of identifying it and shall not be construed as an express warranty.
Whenever possible, each provision of this Limited Warranty shall be interpreted in such manner as to be effective and valid under applicable law, but if any
provision is held to be prohibited or invalid, such provision shall be ineffective only to the extent of such prohibition or invalidity, without invalidating the
remainder of such provision or the other remaining provisions of the Limited Warranty.
Remedy: During the applicable limited warranty period, the Company will, at its option, provide replacement parts for, or repair or replace, without charge,
any Product or part thereof, to the extent the Company finds it to be covered by and in breach of this limited warranty under normal use and service. The
Company will ship the repaired or replaced Product or replacement parts to you at no charge. You are responsible for all costs for removal, reinstallation
and shipping, insurance or other freight charges incurred in the shipment of the Product or part to the Company. If you must send the Product or part
to the Company, as instructed by the Company, you must properly pack the Product or part—the Company is not responsible for damage in transit. The
Company reserves the right to utilize reconditioned, refurbished, repaired or remanufactured Products or parts in the warranty repair or replacement
process. Such Products and parts will be comparable in function and performance to an original Product or part and warranted for the remainder of the
original warranty period (or such longer period as may be required by applicable law).
Company reserves the right, in its sole discretion, to refund the money actually paid by you for the Product. If the Product or component is no longer
available, replacement may be made with a similar product of equal or greater value, at Company’s sole discretion. This is your sole and exclusive remedy
for breach of this limited warranty.
Exclusion of Damages: THE COMPANY’S OBLIGATION TO PROVIDE REPLACEMENT PARTS, OR REPAIR OR REPLACE, AT THE COMPANY’S OPTION,
SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY AND THE COMPANY’S SOLE AND EXCLUSIVE OBLIGATION. THE
COMPANY SHALL NOT BE LIABLE FOR INCIDENTAL, INDIRECT, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH
THE PRODUCT, ITS USE OR PERFORMANCE.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply
to you. This warranty gives you specific legal rights, and you may also have other rights, which vary from jurisdiction to jurisdiction. The disclaimers,
exclusions, and limitations of liability under this warranty will not apply to the extent prohibited by applicable law.
This warranty covers only replacement or repair of defective Products or parts thereof at the Company’s main facility and does not include the cost of field
service travel and living expenses.
Any assistance the Company provides to or procures for you outside the terms, limitations or exclusions of this limited warranty will not constitute a waiver
of such terms, limitations or exclusions, nor will such assistance extend or revive the warranty. The Company will not reimburse you for any expenses
incurred by you in repairing or replacing any defective Product, except for those incurred with the Company’s prior written permission.
How to Obtain Warranty Service: To qualify for warranty service, you must (a) notify the Company at the address or telephone number stated below within
seven (7) days of discovering the covered defect, (b) give the model number and part identification and (c) describe the nature of any defect in the Product
or part. At the time of requesting warranty service, you must present evidence of the original purchase date. If you cannot provide a copy of the original
written limited warranty, then the terms of the Company’s most current written limited warranty for your particular product will control.
PRODUCT SPECIFICATIONS
All illustrations and specifications in this catalog are based on the latest product information available at time of production. Broan-NuTone, LLC and
BEST® reserves the right to make changes at any time, without notice, in prices, colors, materials, equipment, specifications and models, place of
manufacture and to discontinue models or equipment.
BEST, 926 West State Street, Hartford, Wisconsin, USA 53207 BestRangeHood.com 800-558-1711
BEST, 550 Lemire Blvd., Drummondville, Québec, Canada J2C 7W9 BestRangeHoods.ca 800-567-3855

SÉRIE WPP1
GUIDE D’INSTALLATION
CONÇUE POUR USAGE DOMESTIQUE SEULEMENT
INSTALLATEUR : LAISSER CE GUIDE AU PROPRIÉTAIRE.
PROPRIÉTAIRE : DIRECTIVES D’ENTRETIEN EN PAGE 29.
LIRE ET CONSERVER CES DIRECTIVES
1110540 rév. A
V
Q
0009 !
V
Q
0009 !
BEST, 926 West State Street, Hartford, Wisconsin, USA 53027 BestRangeHoods.com 800 558-1711
BEST, 550 boul. Lemire, Drummondville, Québec, Canada J2C 7W9 BestRangeHoods.ca 800 567-3855
Pour enregistrer votre produit en ligne ou pour obtenir plus d’information, consultez notre site BestRangeHoods.com
(aux États-Unis) ou BestRangeHoods.ca (au Canada)
HB0395

18
AFIN DE RÉDUIRE LES RISQUES D’INCENDIE,
D’ÉLECTROCUTION OU DE BLESSURES CORPORELLES,
SUIVEZ LES DIRECTIVES SUIVANTES :
1. N’utilisez cet appareil que de la façon prévue par le manufacturier. Si
vous avez des questions, contactez le manufacturier à l’adresse ou au
numéro de téléphone indiqués dans la garantie.
2. Avant de réparer ou de nettoyer l’appareil, couper l’alimentation
électrique en verrouillant le panneau de distribution afin d’éviter sa
remise en marche accidentelle. Si le panneau de distribution ne peut
être verrouillé, y fixer un avertissement en évidence, telle qu’une
étiquette de couleur vive.
3. Les travaux d’installation et de raccordement électrique doivent être
effectués par une personne qualifiée, conformément aux codes et
aux standards de construction, incluant ceux concernant la protection
contre les incendies.
4. Une quantité d’air adéquate est requise afin d’assurer une bonne
combustion et l’évacuation des gaz par la cheminée dans le cas
des équipements alimentés au gaz afin de prévenir les retours de
cheminée. Conformez-vous aux instructions et aux standards de
sécurité des manufacturiers d’équipement de chauffage, tel qu’ils
sont publiés par la National Fire Protection Association (NFPA) et
l’American Society for Heating, Refrigeration and Air Conditioning
Engineers (ASHRAE) ainsi que les responsables des codes locaux.
5. Lorsque vous coupez ou perforez un mur ou un plafond, prenez garde
de ne pas endommager les fils électriques ou autre installation qui
pourraient y être dissimulés.
6. Les ventilateurs avec conduits doivent toujours évacuer l’air
à l’extérieur.
7. Ne pas utiliser cet appareil avec une commande de vitesse à
semi-conducteur.
8. Afin de réduire les risques d’incendie, n’utilisez que des conduits
de métal.
9. Cet appareil doit être mis à la terre.
10. Il est recommandé de porter des lunettes et des gants de sécurité lors
de l’installation, de l’entretien ou de la réparation de cet appareil.
11. Lorsqu’une réglementation est en vigueur et qu’elle comporte des
exigences d’installation et/ou de certification plus restrictives, lesdites
exigences prévalent sur celles de ce document et l’installateur entend
s’y conformer à ses frais.
AFIN DE RÉDUIRE LES RISQUES DE FEU DE CUISINIÈRE :
a) Ne jamais laisser les appareils de cuisson sans surveillance lorsqu’ils
sont réglés à feu vif. Les débordements engendrent de la fumée et
des déversements graisseux pouvant s’enflammer. Chauffez l’huile
lentement, à feu doux ou moyen.
b) Mettez toujours la hotte en marche lorsque vous cuisinez à feu vif ou
que vous cuisinez des mets flambés (par ex. : crêpes Suzette, cerises
jubilé, steaks au poivre flambés).
c) Nettoyez régulièrement la (les) roue(s) du ventilateur. Ne laissez pas
la graisse s’accumuler sur le ventilateur, les filtres ou les conduits
d’évacuation.
d) Utilisez le bon format de casserole. Servez-vous toujours de casseroles
et d’ustensiles appropriés à la dimension de la surface chauffante.
AFIN D’ÉVITER TOUT RISQUE DE BLESSURES LORS D’UN
FEU DE CUISINIÈRE, SUIVEZ CES DIRECTIVES* :
1. Étouffez les flammes avec un couvercle hermétique, une tôle à biscuits
ou un plateau métallique et ensuite, éteindre le brûleur. PRENEZ
SOIN D’ÉVITER les brûlures. SI LES FLAMMES NE S’ÉTEIGNENT
PAS IMMÉDIATEMENT, ÉVACUEZ LES LIEUX ET APPELEZ
LES POMPIERS.
2. NE PRENEZ JAMAIS UNE CASSEROLE EN FLAMMES DANS VOS
MAINS. Vous pourriez vous brûler.
3. N’UTILISEZ PAS D’EAU, incluant un linge à vaisselle ou une serviette
mouillée, cela pourrait occasionner une violente explosion de vapeur.
4. N’utilisez un extincteur QUE DANS LE CAS OÙ :
A. Vous savez qu’il s’agit d’un extincteur de classe ABC et que vous
en connaissez le fonctionnement.
B. Le feu est petit et limité à l’endroit où il a débuté.
C. Les pompiers ont été avisés.
D. Vous pouvez combattre l’incendie en ayant accès à une sortie
de secours.
*Tirées du Kitchen Fire Safety Tips publié par la NFPA.
1. Pour une utilisation à l’intérieur seulement.
2. Pour usage domestique seulement. Ne pas utiliser pour évacuer des
vapeurs ou des matières dangereuses ou explosives.
3. Afin d’éviter tout dommage au moteur et de débalancer ou de
rendre bruyante la roue du moteur, garder votre appareil à l’abri des
poussières de gypse et de construction/rénovation, etc.
4. Le moteur de votre hotte encastrable possède une protection
thermique qui éteindra automatiquement le moteur s’il devient
surchauffé. Le moteur redémarrera automatiquement une fois refroidi.
Si le moteur continue à arrêter et à redémarrer, faites-le vérifier.
5. La distance minimale entre le bas de votre hotte et la surface de
cuisson ne doit pas être inférieure à 24 po. Un maximum de 30 po
au-dessus de la surface de cuisson est recommandé pour une
meilleure évacuation des odeurs de cuisson.
6. Deux installateurs sont recommandés lors de l’installation vu la grande
dimension et le poids de cet appareil.
7. Afin de réduire les risques d’incendie, assurez-vous d’évacuer l’air à
l’extérieur. Ne pas évacuer l’air dans des espaces restreints comme
l’intérieur des murs ou plafond ou dans le grenier, faux plafond
ou garage.
8. À cause de la grande capacité d’évacuation de cet appareil, il est
recommandé d’ouvrir une fenêtre dans ou près de la cuisine afin de
remplacer l’air évacué.
9. Afin de réduire les risques d’incendie et d’électrocution, les modèles
Best de la série WPP1 doivent être installés uniquement avec leurs
ventilateurs internes intégrés.
10. Cet appareil peut être installé avec le cordon électrique de hotte
HCK44 homologué par UL en suivant les instructions incluses dans
l’emballage du cordon électrique.
11. Veuillez consulter l’autocollant apposé à l’intérieur du produit pour
plus d’information ou autres exigences.
AVERTISSEMENT
V
Q
0009 !
ATTENTION

19
Table des matières
1. préparer l’installation ......................................................................................................................................................................19
2. choisir le type d’installation.............................................................................................................................................................20
3. spécifications de la hotte .................................................................................................................................................................20
4. installer le support de montage de la hotte .....................................................................................................................................21
5. installer le support de montage du conduit décoratif supérieur .......................................................................................................22
6. enlever les filtres àchicanes hybrides.............................................................................................................................................22
7. installer la hotte..............................................................................................................................................................................23
8. effectuer les branchements............................................................................................................................................................. 24
9. installer le volet/adaptateur de 8 po................................................................................................................................................25
10. installer le volet/adaptateur de 10 po ............................................................................................................................................25
11. raccorder le conduit ......................................................................................................................................................................26
12. préparer le conduit décoratif.........................................................................................................................................................26
13. installer le conduit décoratif.........................................................................................................................................................26
14. réinstaller les filtres àchicanes hybrides......................................................................................................................................28
15. instructions d’activation de l’option crt pour wpp1366ss seulement ........................................................................................... 28
16. calibrer le ventilateur iQmc .............................................................................................................................................................29
17. entretien ........................................................................................................................................................................................29
18. fonctionnement .............................................................................................................................................................................. 30
19. pièces de remplacement ..................................................................................................................................................................31
20. garantie .........................................................................................................................................................................................32
1. PRÉPARER L’INSTALLATION
S’assurer que les articles suivants soient inclus:
- Hotte
- Conduit décoratif
- Support de montage du conduit décoratif supérieur (fixé à l’intérieur de la hotte)
- Support de montage de la hotte (fixé à l’intérieur de la hotte)
- WPP1366SS : volet et adaptateur rond de 8 po
- WPP13612SS et WPP14812SS: volet et adaptateur rond de10 po
- Guide d’installation
- Quincaillerie nécessaire incluse dans le sac de pièces (les pièces restantes sont des pièces de rechange):
Items vendus séparément:
- AEWPP1SBN : Conduit décoratif pour plafonds jusqu’à 12 pi de hauteur
- HCK44: Ensemble cordon électrique
1 x serre-fils 5 x ancrages
muraux
10 x vis
no. 8 x 1-1/2 po
3 x capuchons de
connexion 4 x rondelles
6 x vis
no. 8 x 3/8 po

20
2. CHOISIR LE TYPE D’INSTALLATION
AVERTISSEMENT
VQ0010 !
!
Lors de l’installation, de l’entretien ou de la réparation de cet appareil, il est recommandé de porter des gants et des lunettes
de sécurité.
Établir où le conduit passera entre la hotte et l’extérieur. Un conduit droit et court permettra à la hotte de fonctionner plus efficacement. Se
référer à l’illustration ci-dessous.
Installer un conduit de 8 po ou de 10 po, des coudes (si requis) et un capuchon de mur ou de toit. Relier le conduit en métal au capuchon,
puis acheminer le conduit jusqu’à l’emplacement de la hotte. Sceller hermétiquement les raccords à l’aide de ruban adhésif de métal de
2 po de largeur.
La distance minimale entre le bas de votre hotte et la surface de cuisson ne doit pas être inférieure à 24 po. Un maximum de 30 po
au-dessus de la surface de cuisson est recommandé pour une meilleure évacuation des odeurs de cuisson.
HH0323
capuchon de toit
conduit/coude rond de
8 po (600 pi3/min)ou
10 po (1200 pi3/min)
capuchon de mur
hotte
de24 po à30 po au-dessus de la
surface de cuisson
3. SPÉCIFICATIONS DE LA HOTTE
24 po
35-7/8 po(36 po)
47-7/8 po(48 po)
14-3/8 po
C
L
5-1/8 po (WPP1366SS)
(WPP13612SS)
(WPP14812SS)
5-7/16 po
HK0377F
10-13/16 12-15/16
35-7/8, 47-7/8
24
14-3/8
min 30-1/2 - max 43-1/8
min 31-7/8 - max 43-5/8
